Planet Networking & Communication ANT-SE17A Installation Manual

I. Package contents:
1. Antenna body
3. M6_16mm screw – 8 pcs
5. M6 S/Washer – 10 pcs
7. M-type bracket – 1 pcs
9. Antenna support plate – 1 pcs
II. Pole mount

NOTE:
5GHz 16.5dBi Sector Antenna
ANT-SE17A
INSTALLATION GUIDE
2. M6_60mm screw – 2 pcs (for pole mount)
4. M6 washer – 10 pcs
6. M6 nut – 4 pcs
8. Back support plate – 1 pcs (for pole mount)
a. Please mount the antenna on the pole of 2" diameter at most.
b. Attach Antenna support plate
tilt, select from 0-10 degrees tilt when tightening screws
p
bracket
φ
TP screw 4_20mm – 4 pcs (for wall mount)
Wall plug – 4 pcs (for wall mount)
r
to antenna for either uptilt or down-
l
into
