Elk RYVYR INDUS 2 V-INDUS2-24DW Installation Instructions

A divsion of ELK Group International
THANK YOU FOR CHOOSING RYVYR
Please take a few minutes to review this manual before you start installation. If you encounter
any installation problems, please don't hesitate to contact us. Before you begin, please
observe all local building codes. Unpack the new product and inspect for damage. The
appearance of your vanity may differ from the illustrations in this guide. These instructions
still apply. Please ensure the finished wall is straight and plumb and the floor is flat and
perpendicular to the finished wall.
SUGGESTED TOOLS AND MATERIALS
Phillips Screwdriver
ROUGHING-IN
5.5" (140mm)
6.5" (165mm)
FLOOR
For customer support please visit www.ryvyr.com or call 866.395.8112 weekdays 8:00 to 5:00 ET or fax 866.395.8113 any time
V-INDUS2-24DW | V-INDUS2- 30DW | V-INDUS2-36DW | V-INDUS-48DW
Level
Model #
V-INDUS2-24DW 24"
V-INDUS2-30DW 30"
V-INDUS2-36DW 36"
V-INDUS2-48DW 48"
X" (ymm)
0.8" (20mm)
3.9" (100mm)
Drill
X Y
610mm
762mm
914mm
1219mm
33.9" (862mm)
INSTALLATION INSTRUCTIONS
1 0 '
Tape Measure Safety Glasses
21.5" (546mm)
10.75" (273mm)
INDUS 2
TM
VANITY STAND
FINISHED
WALL
02.2017
