- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. MIDEA MPF08CR71-1 Owner's Manual Shop genuine replacement parts for MIDEA MPF08CR71-1 Find Your MIDEA Dehumidifier Parts - Select From 152 Models -------- Manual continues below --------...
- Page 2 The design and specifications are subject to change without prior notice MPF08CR71 for product improvement. MPF10CR71 Consult with your dealer or MPF12CR71 manufacturer for details. MPF14CR71 www.midea.com version A - 03 - 2017...
-
Page 4: Table Of Contents
Owner’s Manual 0 Safety Precautions ................3 Unit Specifications and Features ........... 5 Operating Instructions ..............7 Installation Instructions ..............12 Care and Cleaning ................17 Troubleshooting Tips ............... 18 Remote Control Operating Instructions ........19 Sociable Remark ................28 Warranty .................... -
Page 5: Safety Precautions
Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury. - Page 6 WARNING • The unit must be kept free from obstruction to ensure proper function. • DO NOT allow children to play with the air conditioner. Children must be supervised around the unit at all times. • If the air conditioner is knocked over during use, turn off the unit and unplug it from the main power supply immediately.
-
Page 7: Unit Specifications And Features
Unit Specifications and Features Preparation Control panel Upper air filter (behind the grille) Handle (both sides) Horizontal Upper air intake louver blade Drain outlet Air outlet Lower air filter Lower air intake Power plug socket Drain outlet (only for pump heating mode) Power cord outlet Caster Power cord buckle... -
Page 8: Specifications
Specifications MODEL MPF08CR71 MPF10CR71 MPF12CR71 MPF14CR71 1Ph, 115V-, 60Hz 1Ph, 115V-, 60Hz 1Ph, 115V-, 60Hz 1Ph, 115V-, 60Hz Power supply Ph-V-Hz 8000 10000 12000 14000 Capacity Btu/h Rated 1130 1350 1575 input Rated Cooling 11.8 current Btu/W.h Moisture removal (26.7/20.9°C) Moisture removal (35/28.3°C) 30.3... -
Page 9: Operating Instructions
Operating Instructions Key Pad Features LED Display (3s activate ion) Swing Sleep Auto Mode Up (+) and Power Control Mode Timer Speed Selector Down (-) Control Button Swing Button (optional) Timer button (Applicable to the models with auto swing Used to initiate the AUTO ON start time feature only) and AUTO OFF stop time program, in Used to initiate the Auto swing feature. - Page 10 LED Display (3s activate ion) Swing Sleep Auto Mode Up (+) and Power Control Mode Timer Speed Selector Down (-) Control Button LED display Mode button Shows the set temperature in °C or °F Selects the appropriate operating mode. Each time you press the button, a mode and the Auto-timer settings.
- Page 11 Operation Instructions COOL operation • Press the “FAN SPEED” button to choose the fan speed. The temperature can not • Press the “MODE” button until the “COOL” be adjusted. indicator light comes on. • Do not put the duct to window. •...
-
Page 12: Other Features
Other Features FOLLOW ME/TEMP SENSING Feature (optional) NOTE This feature can be activated from the remote control ONLY. The remote control serves as a remote thermostat allowing for the precise temperature control at its location. To activate the Follow Me/Temp Sensing feature, point the remote control towards the unit and press the Follow Me/Temp Sensing button. - Page 13 • During heating pump mode, remove the lower drain plug from the back of the unit, install the drain connector (5/8” universal female mender) with 3/4” hose (locally purchased). For the models without drain connector, just attach the drain hose to the hole. Place Remove the open end of the Hose adaptor directly over the the lower...
-
Page 14: Installation Instructions
Installation Instructions Choosing the Right Location Your installation location should meet the following requirements: • Make sure that you install your unit on an even surface to minimize noise and vibration. • The unit must be installed near a grounded plug, and the Collection Tray Drain (found on the back of the unit) must be accessible. - Page 15 Tool Needed • Medium Philips screwdriver; • Tape measure or ruler; • Knife or scissors; • Saw (optional, to shorten window adaptor for narrow windows). Acessories Your Window Installation Kit fits windows 67.5-123 cm (26.5-48”) and can be shortened for smaller windows. Part Description Quantity...
- Page 16 Window Installation Kit Step One: Preparing the exhaust hose Exhaust hose Exhaust hose assembly assembly Press the exhaust hose into the window slider adaptor and unit adaptor, clamp automatically by elastic buckles of the adaptors. Unit Window slider adaptor adaptor Step Two: Install the exhaust hose Hook Hole Seat...
- Page 17 NOTE Once the Exhaust Hose assembly and Adjustable Window Slider are prepared, choose from one of the following two installation methods. Type 1: Hung window installation Foam seal B (Adhesive type-shorter) Cut the adhesive foam seal A and B strips to the proper lengths, and attach them to the window sash and frame as shown.
- Page 18 Type 2: Sliding window installation Foam seal B (Adhesive Cut the adhesive foam seal A and B strips to the type-shorter) proper lengths, and attach them to the window sash and frame as shown. Foam seal A (Adhesive type) 2. Insert the window slider assembly into the window opening.
-
Page 19: Care And Cleaning
Care and Cleaning Safety Precautions • Always unplug the unit before cleaning or servicing. • DO NOT use flammable liquids or chemicals to clean the unit. • DO NOT wash the unit under running water. Doing so causes electrical danger. •... -
Page 20: Troubleshooting Tips
Troubleshooting Tips Faults Diagnosis Please check the machine according to the following form before asking for maintenance: Problem Possible Cause Troubleshooting P1 Error Code. The water collection tray is full. Turn off the unit, drain the water Unit does not from the water collection tray turn on when and restart the unit. -
Page 21: Remote Control Operating Instructions
Remote Control Operating Instructions Remote Control Specifications Model RG57H2(B)/BG(C)EF Rated voltage 3.0V (Dry batteries R03/LR03x2) Signal receiving range Environment -5°C ~ 60°C (23°F ~ 140°F) Function Buttons Before you begin using your new air conditioner, make sure to familiarize yourself with its remote control. - Page 22 Handing the Remote Control NOT SURE WHAT A FUNCTION DOES? Refer to the How to Use Basic Functions and How to Use Advanced Functions sections of this manual for a detailed description of how to use your air conditioner. SPECIAL NOTE Button designs on your unit may differ slightly from the example shown.
- Page 23 Remote LED Screen Indicators Transmission Indicator Lights up when remote sends signal to unit ON/OFF display MODE display Appears when the unit is turned on and disappears when it is turned off Displays the current mode, including: TIMER ON display TIMER OFF display AUTO Displays when...
- Page 24 How to Use Use the Basic Fuctions SETTING TEMPERATURE The operating temperature range for units is 17-30°C (62°F-86°F). You can increase or decrease the set temperature in 1°C (1°F) increments. AUTO operation In AUTO mode, the unit will automatically select the COOL, O N /O F F SHORT FAN, HEAT or DRY mode based on the set temperature.
- Page 25 FAN operation 1. Press the MODE button to select FAN mode. 2. Press FAN button to select the fan speed: AUTO, LOW, MED or HIGH. 3. Press the ON/OFF button to start the unit. O N /O F F SHORT NOTE TIMER MODE...
- Page 26 Setting the Timer Fuctions Your air conditioning unit has two timer-related functions: TIMER ON - sets the amount of timer after which the unit will automatically turn on. TIMER ON TIMER ON TIMER OFF - sets the amount of time after which the unit will automatically turn off.
- Page 27 3. Wait 2 seconds, then the TIMER OFF function will be activated. The digital display on your remote control will then return to the temperature display. T imer on NOTE When setting the TIMER ON or TIMER OFF functions, Continue to press up to 10 hours, the time will increase in 30 minute O N /O F F...
- Page 28 How to Use Use the Advanced Fuctions SLEEP Function The SLEEP function is used to decrease energy use while you sleep (and don t need the same temperature settings to stay comfortable). This function can only be activated via remote control. Note: The SLEEP function is not O N /O F F...
- Page 29 NOTES • When there are wide differences between remote controller Illustration and “USER’S MANUAL” on function description, the description on “USER’S MANUAL” shall prevail. • The device could comply with the local national regulations. In Canada, it should comply with CAN ICES-3(B)/NMB-3(B). In USA, this device complies with part 15 of the FCC Rules.
-
Page 30: Sociable Remark
Sociable Remark When using this dehumidifier in the European countries, the following information must be followed: DISPOSAL Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal, there are several possibilities: A.
