Any Stresses exceeding the Absolute Maximum Ratings may cause substantial damage to the device. Functional operation of this device at other conditions beyond those listed in the specification is not implied and prolonged exposure to extreme conditions may affect device reliability. URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
Chip select de-assert to reassert SCK falling edge to SO hold time SPI Function Select: Command Comments 10000000 8-bit Write 11000000 8-bit Read 10001000 16-bit Write 11001000 16-bit Read the other reserved URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
Active Reset Pulse Width (see Note) Note: The Reset input should be held low for longer than 150ns to guarantee reset. For more information and details please refer to LCD controller (S1D13L01) datasheet. URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
TOPWAY LCD Module User Manual LMT035KDH03-NHA 5. Optical Characteristics Note : The parameter may slightly change over temperature, driving voltage and materials. URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
Page 10
Note 6: reference Figure8 Definition of Color of CIE Coordinate and NTSC Ratio. Color gamut: Area of RGB triangle X100% Area of NTSC triangle Figure 12 URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
6082A 0 0 0 A[7:0]-> A[15:8] -> A[18:16] Vertical Non-Display Period Register (VNDP) 1 0 0 D[7:0] Vertical Non-Display Period Bit[7:0] = vertical non-display period in lines 1 0 0 D[15:8] URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
Page 12
D[7:0] PIP Layer Width Bit[9:] = PIP Layer Horizontal Display Period in number of pixels PIP D[15:8] PIP Layer 1 0 0 Layer Horizontal Display Period in number of pixels Width URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
Page 13
Note: Access of PLL Setting 0, PLL Setting 1, PLL Setting 2 and Internal Clock Configuration is only possible in Power Save Mode PSM0. For more information and details please refer to S1D13L01 datasheet. URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
Do not add excessive force on surface of LCD, which may cause 常。 the display color change abnormally. 液晶屏由玻璃制作而成,任何机械碰撞(如从高处跌 LCD panel is made with glass. Any mechanical shock (e.g. 落)均有可能损坏液晶显示模块。 dropping from high place) will damage the LCD module. URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
They should only provide appropriate 置. support and keep the module in place. The mounting structure should be strong enough to prevent 安装结构应具有足够的强度,以防止外部不均匀力或 external uneven force or twist act onto the module 扭曲力作用到模块上。 Figure 2 URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
RTP V.A. should be bigger than the TFT V.A. RTP 的可视区 V.A. 应不小于 TFT 的可视区 V.A. and RTP A.A. should be bigger than the TFT A.A. 及 RTP 的动作区 A.A. 应不小于 TFT 的动作区 A.A. (Figure 5) (附图 5) URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
We cannot accept responsibility for intellectual property of a third part, which may arise through the application of our product to our assembly with exception to those issues relating directly to the structure or method of manufacturing of our product. URL: www.topwaydisplay.com Document Name: LMT035KDH03-NHA-Manual-Rev0.3.DOC www.topwaysz.com Page: of 15...
