- Page 1 LMT070DICFWD-NFN-2 LCD Module User Manual Prepared by: Checked by: Approved by: LINLI Date: 2019-06-26 Date: Date: Rev. Descriptions Release Date Preliminary release 2019-06-26 URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 1 of 10...
-
Page 2: Table Of Contents
Driving TFT LCD Panel ............................5 Optical Characteristics ......................5 LCD Module Design and Handling Precautions ..............7 CTP Mounting Instructions ....................8 RTP Mounting Instructions ....................9 Warranty ..........................10 URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 2 of 10... -
Page 3: General Specification
*2. For “color scales” display content. *3. Color tone may slightly change by Temperature and Driving Condition. 2. Block Diagram Backlight 800 x480 pixels Source Driver TMDS_D2+/-,TMDS_D1+/- HDMI interface TMDS_D0+/-,TMDS_Clock+/- SCL_HDMI,SDA_HDMI VDD, VSS Power Circuit URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 3 of 10... -
Page 4: Terminal Function
Power supply for DDC memory Hot_Plug_Detect Output Hot Plug Detect signal Note: 1：HDMI terminal should be well connect before power on (hot-plug is not allowed) 2：Support Standard HDMI Signal, from PC： -640x480,60Hz 800x480,60Hz 800x600,60Hz URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 4 of 10... -
Page 5: Absolute Maximum Ratings
Note 5 Luminance uniformity Note 1,7 Test Conditions: 1. IF= 200 mA, VF=9.6V, and the ambient temperature is 25. ℃ 2. The test systems refer to Note 1 and Note 2 URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 5 of 10... - Page 6 Bp (Max.) = Maximum brightness in 9 measured spots x100% Bp (Min.) = Minimum brightness in 9 measured spots Area of NTSC triangle Note 7: Measured the luminance of white state at center point URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 6 of 10...
-
Page 7: Lcd Module Design And Handling Precautions
请勿挤压液晶显示屏表面，这将导致显示颜色的异 Do not add excessive force on surface of LCD, which may cause 常。 the display color change abnormally. 液晶屏由玻璃制作而成，任何机械碰撞(如从高处跌 LCD panel is made with glass. Any mechanical shock (e.g. 落)均有可能损坏液晶显示模块。 URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 7 of 10... -
Page 8: Ctp Mounting Instructions
They should only provide appropriate 置. support and keep the module in place. The mounting structure should be strong enough to prevent 安装结构应具有足够的强度，以防止外部不均匀力或 external uneven force or twist act onto the module 扭曲力作用到模块上。 Figure 2 URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 8 of 10... -
Page 9: Rtp Mounting Instructions
RTP V.A. should be bigger than the TFT V.A. RTP 的可视区 V.A. 应不小于 TFT 的可视区 V.A. and RTP A.A. should be bigger than the TFT A.A. 及 RTP 的动作区 A.A. 应不小于 TFT 的动作区 A.A. (Figure 5) (附图 5) URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 9 of 10... -
Page 10: Warranty
We cannot accept responsibility for intellectual property of a third part, which may arise through the application of our product to our assembly with exception to those issues relating directly to the structure or method of manufacturing of our product. URL: www.topwaydisplay.com Document Name:LMT070DICFWD-NFN-2-Manual-Rev0.1 www.topwaysz.com Page: 10 of 10...
