PACKAGE CONTENTS
* 1x Fiber Splice Tray
Note : AT-300 & AT-300-V2 only for H40-044-30-150 & H40-044-90-250 & H40-044-91-250 & H40-082-30-250 &
H21-082-30-150 use.
Installation
AT-300 fiber panel
AT-300
Junction Box
AT-300-V2 fiber panel
AT-300-V2
Junction Box
AT-300 & AT-300-V2 Fiber Splice Tray
Quick Installation Guide
* 1x Quick Installation Guide
Remove the screws
Remove the screws
P/N: A625008101G
Mounting screws
Mounting screws
Advertisement
Related Manuals for AETEK AT-300
Summary of Contents for AETEK AT-300
- Page 1 P/N: A625008101G Quick Installation Guide PACKAGE CONTENTS * 1x Fiber Splice Tray * 1x Quick Installation Guide Note : AT-300 & AT-300-V2 only for H40-044-30-150 & H40-044-90-250 & H40-044-91-250 & H40-082-30-250 & H21-082-30-150 use. Installation AT-300 fiber panel Remove the screws...
- Page 2 1. Open Outdoor PoE Switch cover. 2. Remove the screws on the top above Outdoor PoE Switch. 3. Load the AT-300 & AT-300-V2 into the Outdoor PoE Switch. 4. After installation, lock the Outdoor PoE Switch cover. 5. Install the Outdoor PoE Switch on a wall or pole or corner (with AT-100 or AT-101 or AT-200)
