- Page 1 VR-486 / VW-486 / VR-806 Series Vari-Angle Illuminator Installation Guide Rev. 1.0...
-
Page 2: Revision History
Revision History: * Rev. 1.1: Initial Release Package Contents VR-486 series only VR-806 series only The 1/4" screws and washers are used to secure the illuminator to an external camera housing. NOTE: • The wall-mount , laser alignment kit , remote controller , and other accessory are separately purchased. - Page 3 RISK GROUP 3 WARNING IR emitted from this product, Do not look at operating lamp. IR illuminators RISK GRORP 3 / WARNING IR emitted from this product. / Avoid eye exposure. Use appropriate shielding or eye protection. Do not look at operating lamp. Class III luminaires Do not stare at the operating light source. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
-
Page 4: Mechanical Drawings
Mechanical Drawings 73mm(2.87") 49mm(1.93") 27.4mm(1.08") 160mm(6.3") 69.4mm(2.73") 93.4mm(3.68") 117.4mm(4.62") Standard Small U bracket Standard Small U bracket 9.85 18.5... -
Page 5: Hardware Overview
Hardware Overview Reserved mounting holes for external camera housing U bracket Mounting holes Optional mounting points for U bracket Dehumidifier Light sensor membrane Reserved Combo cable Unit Weight: 2.1KG. Max. Project Area: 34684.7mm 160mm(6.3") -
Page 6: Using The Remote Controller
Using the Remote Controller Beam angle selectors Only function in VR806 series These buttons provide quadruple proportions of adjustable angles from the narrowest, 33%, 66%, to the widest. These angles vary with different models. When a beam angle is selected, you can use the fine-tune buttons below to tune for a desired effect. - Page 7 Installation Beam angle adjust: You must first survey the installation site and determine the illumination distance. VR-486 series Use a coin or flat blade screwdriver to open the waterproof cover at the back of the illuminator. 35-Kg-cm Tips: You may forget your current beam angle configuration. In this case, turn many full circles clockwise until the rotation resistance is felt (returns to the widest angle, reaches its mechanical stops), and then turn the selector counter-clockwise according to the angle listed on the tables. Each full...
- Page 8 The factory default for the beam angle selector is always at the Widest angle. When you turn the selector many rounds to its widest or the narrowest position, a rotation resistance can be felt. That means the mechanical stop is reached, and you should not use more force. Refer to the tables below for the configurable IR light beam angles and the number of full circles needed to change to the preferred beam angles. Each full circle corresponds to a preset beam angle.
- Page 9 VR-486-4080 Rotate Full circle Beam angle Single mount Double mount Triple mount direction Distance(m) Width(m) Distance(m) Width(m) Distance(m) Width(m) 80° 100.7 84.9 142.4 103.9 174.4 77° 98.6 87.7 139.5 107.4 170.8 74° 96.5 90.5 136.4 110.9 167.1 Counter-clockwide 66° 87.0 94.8 123.1 116.0...
- Page 10 VW-486-2040 Rotate Full circle Beam angle Single mount Double mount Triple mount direction Distance(m) Width(m) Distance(m) Width(m) Distance(m) Width(m) 40° 87.4 169.7 123.5 207.8 151.3 36° 81.2 176.8 114.9 216.5 140.7 Counter-clockwide 29° 77.6 212.1 109.7 259.8 134.4 Narrower 27° 75.9 223.4 107.3...
- Page 11 VR-806 series Use the remote controller to adjust the beam angle. The factory default for the beam angle selector is always at the Widest angle. Refer to the tables below for the configurable IR light beam angles and the definitions of the remote controller buttons. Each button changes to a preset beam angle. Example: Width Angle Distance 40° 33° 27° 100% On/Off Status Dimming Zoom VR-806-1040 Button Beam angle Single mount Double mount Triple mount Distance(m) Width(m)
-
Page 12: Cable Pinouts
Cable Pinouts Name Color Gauge Description (20AWG) Power input 24V DC±10% Black (20AWG) 24V AC±10% (50/60Hz) Green (26AWG) LED ON/OFF control * Dry contact Logic level 1(Open) = LED off Logic level 0(Close to GND) = LED on * Wet contact Logic level 1: 4V~40 V = LED off Logic level 0: 0.8V MAX = LED on Yellow (26AWG) Ground Purple (26AWG) Light sensor status output 1. Open = Day 2. Short = Night (300 lux for IR ON) Blue (26AWG) Ground RS485+ Orange (26AWG) RS485 interface control RS485- Brown... - Page 13 Coordination with Cameras via the DI and DO Pins +3.3V +3.3V Switch +3.3V Fuse/50mA External power source Relay Camera DI pins IR LED ON/OFF control (Green & Yellow wires) This mode means that illuminator On/Off control is triggered by camera or other alarm system. Users can decide using the appropriate dry/wet contacts depending on wiring condition. DI+: Green = TTL + voltage DI-: Yellow = TTL – voltage (GND) * Dry contact...
- Page 14 Light sensor status output (Purple & Blue wires) This mode means that camera Day/Night mode switching is coordinated with and is triggered by the illuminator's light sensor via the DO(Digital output) connection (connected to the camera's DI pins). Users can configure the camera configuration to control the corresponding illuminator On/Off status. DO+: Purple= Open drain output, 45V Max. (current must be under 100mA) DO-: Bule = GND Light sensor status output 1. Open = Day 2. Short = Night (lower than 300 lux for IR to turn ON) Stand-alone illuminator mode This mode means that the illuminator's On/Off control is triggered by its light sensor, in the case, the default wiring is connecting the green wire with purple wire. Some cameras have related settings that need the inter-connection with the illuminator. For example, some cameras come with an IR cut filter that need to be turned off when entering night mode; or, automatically turn on the adjacent illuminator when entering night mode.
-
Page 15: Mounting Configuration & Dimensions
Mounting Configuration & Dimensions Swivel Positions and Directions 170 mm 502.8 mm 400 mm 255 mm 105 mm USABLE USABLE AREA AREA 502.8... -
Page 16: Installation
IV Installation Install the wall-mount bracket to a preferred location at your installation site. Drill mounting holes and a cable routing hole (if preferred) on a wall. Install the bracket. Prepare and route the wiring, Ethernet and 24V power source. Install the IR illuminator to the bottom of the housing. Attach the included grip stricker to the U bracket. - Page 17 Secure the U bracket to the IR illuminator using the included hex screws. Flip the housing over and place it on a clean, stable surface. Secure the IR illuminator to the bottom of the housing using the included wrench and a hex socket screw.
- Page 18 You can turn the IR illuminator so that its flat side is parallel with the housing, and that you can turn the assembly over and work on the inside of the housing. Put a foam pad below before you work on the wiring to avoid scratching the surface. Prepare power wires, a ground wire, and a CAT5e Ethernet cable. Pass them through the M16 waterproof connectors under the housing. Ethernet cable Ø4 ~ 6.5mm Power wires &...
- Page 19 BR: brown solid When done, tighten up and install the waterproof connectors. Assemble the camera components, e.g., the CS ring and lens module. Secure the mounting plate to the bottom of the camera (the label side) using the included screw. There is a plastic mount pad in the package. You do not need the mounting pad using the AETEK camera.
- Page 20 This page is intentionally left blank.
