Aeropro RP17315 Series Instruction Manual

1/4”(6mm) angle die grinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1/4"(6mm) Angle Die Grinder
Model No.:□RP17315□RP17315M
Contain:
◎ Technical Data
◎ Important safety rules
◎ Operating Instructions
◎ Maintenance
◎ Parts List
※ Technical Data
Grinder cap..................................................................................................1/4"(6mm)
Free speed...................................................................................................20,000rpm
Avg.air consumption................................................................................3cfm(85.5 l/min)
Operating pressure.......................................................................................90psi(6.3bar)
Air inlet size.........................................................................................................1/4"
Air hose...........................................................................................................3/8"ID
A weighted sound pressure level.......................................................................... 93dB(A)
Sound power level..........................................................................................104 dB(A)
Vibration in the handle........................................................................ 1.73m/s
INSTRUCTION MANUAL
IMPORTANT:
Upon receipt of the product,
read and follow all safety rules,
operating instructions before first use it.
And retain this manual for future reference.
2017
2
2
,K=1.33 m/s

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP17315 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Aeropro RP17315 Series

Summary of Contents for Aeropro RP17315 Series

  • Page 1 1/4”(6mm) Angle Die Grinder Model No.:□RP17315□RP17315M INSTRUCTION MANUAL IMPORTANT: Upon receipt of the product, read and follow all safety rules, operating instructions before first use it. And retain this manual for future reference. Contain: ◎ Technical Data 2017 ◎ Important safety rules ◎...

  • Page 2: General Safety Rules

    General safety rules - For multiple hazards, read and understand the safety instructions before installing, operating, repairing, maintaining, changing accessories on, or working near the die grinder. Failure to do so can result in serious bodily injury. - Only qualified and trained operators should install, adjust or use the die grinder. - Do not modify this die grinder.

  • Page 3: Repetitive Motions Hazards

    - For overhead work, wear a safety helmet. - Be aware that there is a running-on of the rotary inserted tool after the start-and-stop device has been released. - Warnings shall be given against the risk of explosion or fire due to the material being processed. Repetitive motions hazards - When using a die grinder to perform work-related activities, the operator can experience discomfort in hands, arms, shoulders, neck or other parts of the body.

  • Page 4: Dust And Fume Hazards

    Dust and fume hazards - Dust and fumes generated when using die grinders can cause ill health (for example cancer, birth defects, asthma and/or dermatitis); risk assessment and implementation of appropriate controls for these hazards are essential. - Risk assessment should include dust created by the use of the tool and the potential for disturbing existing dust.

  • Page 5: Additional Safety Instructions For Pneumatic Power Tools

    - Select, maintain and replace the consumable/inserted tool as recommended in the instruction handbook, to prevent an unnecessary increase in vibration levels. - Support the weight of the tool in a stand, tensioner or balancer if possible. - Hold the tool with a light but safe grip, taking account of the required hand reaction forces, because the risk from vibration is generally greater when the grip force is higher.

  • Page 6: Loading And Operation

    dangerous causing damage or personal injury. 4. Drain the air tank daily. Water in the air line will damage the tool. 5. Clean air inlet filter weekly. 6. Line pressure should be increased to compensate for unusually long air hoses (over 8 meters). The hose diameter should be 3/8”...

  • Page 7: Maintenance

    ※ Maintenance  WARNING: Disconnect tool from air supply before changing accessories, servicing or performing maintenance. Replace or repair damaged parts. Use genuine parts only. Non-authorised parts may be dangerous 1. Lubricate the air tool daily with a few drops of air tool oil dripped into the air inlet 2.

  • Page 8: Exploding View

    ※ Exploding view Issue date:24.11.2012 Version number:V1 Description Description Description Description Collect bolt Hex nut Cylinder O-ring 3.5x1.6 Collect Locking ring Rotor O-ring 4x2 Drive shift O-ring 22.4x1.8 Blade Woodruff key Rubber ring Rear cover Compressed spring Fixed bolt Woodruff key Ball bearing Adjustable button Ball bearing...
