DVD-VCR COMBINATION
DVD-V5000/AAFES
SERVICE
For mechanical disassembly and adjustment, refer to the "Mechanical Manual" (TS-10
DVD-VCR COMBINATION
EJECT
OPEN/CLOSE
LINE IN 1
POWER
CHANNEL
REC
VIDEO
L
AUDIO
R
SELECT
COPY
Manual
AC68-01405A).
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVD-V5000/AAFES and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung DVD-V5000/AAFES

Summary of Contents for Samsung DVD-V5000/AAFES

  • Page 1: Table Of Contents

    6. Exploded View and Parts List EJECT 7. Electrical Parts List OPEN/CLOSE LINE IN 1 POWER CHANNEL VIDEO AUDIO SELECT COPY 8. Block Diagram 9. PCB Diagrams 10. Wiring Diagram 11. Schematic Diagrams © Samsung Electronics Co., Ltd. JUN. 2001 Printed in Korea AC68-01643A...

  • Page 2: Precautions

    Fig. 1-1 AC Leakage Test 10. Never defeat any of the B+ voltage interlocks. Do not apply AC power to the unit (or any of its assemblies) unless all solid-state heat sinks are correctly installed. Samsung Electronics...
  • Page 3 Use replacement components that have the same ratings, especially for flame resistance and dielectric strength specifications. A replacement part that does not have the same safety characteristics as the original might create shock, fire or other hazards. Samsung Electronics...

  • Page 4: Handling The Optical Pick-Up

    ◆ Be sure to put on a wrist strap grounded to the sheet. ◆ Be sure to lay a conductive sheet made of copper etc. Which is grounded to the table. Samsung Electronics...

  • Page 5: Pick-Up Disassembly And Reassembly

    3) Make solder land 4 points short on Pick-up. (See Fig. 1-3) 4) Disassembly the Pick-up. Note : If the assembly and disassembly are not done in correct sequence, the Pick-up may be damaged. PICK-UP ASS'Y SOLDER LAND 4 POINTS SHORT Fig. 1-3 Samsung Electronics...
  • Page 6 PICK-UP ASS'Y SOLDER LAND 4 POINTS SHORT...
  • Page 7 PICK-UP ASS'Y SOLDER LAND 4 POINTS SHORT...
  • Page 8 PICK-UP ASS'Y SOLDER LAND 4 POINTS SHORT...

  • Page 9: Product Specifications

    DVD-Video, CD-Digital Audio (5” and 3.5”), CD-Video, MP3 files on CD-ROM FREQ. RESPONSE 96/48kHz Sampling: 4Hz-22kHz S/N RATIO 110dB DYNAMIC RANGE 96dB 0.003% POWER REQUIREMENT 120V AC, 60Hz, 27 watts CLOCK BACKUP TIME 6 hours SYSTEM ENVIRONMENT 41-104 F (5-40 C); 10%~75% humidity WEIGHT 21.5 Ibs. Samsung Electronics...
  • Page 10 Product Specifications MEMO Samsung Electronics...

  • Page 11: Disassembly And Reassembly

    Fig. 3-1 Cabinet Top Removal 3-1-2 Decoration-LEG Removal Œ REMOVE 2 SCREWS ´ RELEASE 3 HOOKS (Bottom View) Fig. 3-3 Ass’y Front Panel Removal 3-1-4 Function-Timer PCB Removal Fig. 3-2 Decoration-LEG Removal Œ RELEASE 6 HOOKS Fig. 3-4 Function-Timer PCB Removal Samsung Electronics...

  • Page 12: Chassis Removal

    3-1-6 VCR Main PCB Removal ΠREMOVE 3 SCREWS When installing the ass'y full deck on the Main PCB, be sure to align the assembly point of mode switch. MODE SWITCH ASSEMBLY POINT Fig. 3-6 VCR Main PCB Removal Samsung Electronics...

  • Page 13: Circuit Board Locations

    Disassembly and Reassembly 3-2 Circuit Board Locations Fig. 3-7 Circuit Board Locations Samsung Electronics...
  • Page 14 3) Pull the Tray Disc ¨ to disassemble , while simultaneously pushing 2 Stoppers ˆ (left, right) in the direction arrow “C”, “D”. ˆ STOPPER ˇ SLIDER HOUSING "C" ¨ TRAY DISC "B" "A" Œ SCREW DRIVER "D" ´ EMERGENCY HOLE ˆ STOPPER Fig. 3-8 Tray Disc Removal Samsung Electronics...

  • Page 15: Assy P/U Deck Removal

    2) Lift down the Assy P/U Deck ˇ while simultaneously pushing 2 Hooks ¨, ˆ in the direction of arrow “A”, “B”. ¨ HOOK "A" ˆ HOOK "B" <Assembly Point> Œ DCN2 ´ DCN3 SLIDER HOUSING ˇ ASSY- P/U DECK Fig. 3-9 Assy P/U Deck Removal Samsung Electronics...
  • Page 16 ˆ SLIDER HOUSING "A" ¨ GEAR TRAY ˇ PULLEY GEAR Œ BELT Ô HOOK ” MOTOR LOAD ASSY ˝ HOUSING PCB  DECK PCB "C" Ø SOLDERING "C" "C" ’ 3 HOOKS <Bottom Side> Fig. 3-10 Housing Ass’y Removal Samsung Electronics...

  • Page 17: Sub Chassis Removal

    1) Remove the Soldering of Motor Feed (+, - wire) Œ. 2) Remove the 4 Screws ´. 3) Lift up the Ass’y Brkt Deck ˇ. ´ 4 SCREWS ˇ ASSY-BRAK DECK Œ SOLDERING OF MOTOR FEED (+, - WIRE) Fig. 3-11 Sub Chassis Removal Samsung Electronics...
  • Page 18 7) Remove 3 Spring Spindle ’ and Motor Spindle Ass’y ˝. ˝ MOTOR SPINDLE ˆ SHAFT PICK-UP Ø PICK-UP ASS'Y ¨ 2 SCREW ’ SPRING SPINDLE Œ WASHER ´ GEAR FEED B ∏ 1 SCREW ” 2 SCREWS ˇ GEAR FEED A Fig. 3-12 Ass’y Brkt Deck Removal Samsung Electronics...

  • Page 19: Vcr Alignment And Adjustments

    Adjustment ; "5" ANGLE ZOOM 3D SOUND A.DUB TV/VCR 100+ SELECT NVRAM Option Setting TV VIEW PREV.CH ; "VOL +" INPUT MENU/CLEAR SETUP /ENTER Head Switching TITLE SUBTITLE AUDIO MARK Adjustment ; "SP/SLP" SP/SLP SET TIMER RETURN SEARCH/INDEX Fig. 4-1 Samsung Electronics...

  • Page 20: Alignment And Adjustment

    Alignment and Adjustments 4-1-2 SW710 (TEST) location for adjustment mode setting TEST (SW710) BUTTON Fig. 4-2 Function-Timer PCB (Top View) Samsung Electronics...

  • Page 21: Mechanical Adjustment

    2) Press the “SW710 (TEST)” button on F/Timer PCB 6) Turn the Power off. to set the adjustment mode. (See Fig. 4-2) 3) Press the “5” button of remote control then adjustment is operated automatically. (See Fig. 4-1) Samsung Electronics...
  • Page 22 41 42 43 44 45 46 47 48 PLEASE WAIT CNG : SAVE : ENTER CNG : SAVE : ENTER Fig.4-4 Fig. 4-5 <Table 4-1 NVRAM Option Table> MODEL OPTION NUMBER DVD-V5000 2, 4, 10, 11, 17, 19, 23, 26, 27, 29, 30, 31 Samsung Electronics...

  • Page 23: Troubleshooting

    5. Troubleshooting Samsung Electronics...
  • Page 24 Troubleshooting Samsung Electronics...
  • Page 25 Troubleshooting Samsung Electronics...
  • Page 26 Troubleshooting Samsung Electronics...
  • Page 27 Troubleshooting Samsung Electronics...
  • Page 28 Troubleshooting Samsung Electronics...
  • Page 29 Troubleshooting Samsung Electronics...
  • Page 30 Troubleshooting Samsung Electronics...
  • Page 31 Troubleshooting Samsung Electronics...
  • Page 32 Troubleshooting 5-10 Samsung Electronics...
  • Page 33 Troubleshooting Samsung Electronics 5-11...
  • Page 34 Troubleshooting 5-12 Samsung Electronics...
  • Page 35 Troubleshooting Samsung Electronics 5-13...
  • Page 36 Troubleshooting 5-14 Samsung Electronics...
  • Page 37 Troubleshooting Samsung Electronics 5-15...
  • Page 38 Troubleshooting 5-16 Samsung Electronics...
  • Page 39 Troubleshooting Samsung Electronics 5-17...
  • Page 40 Troubleshooting 5-18 Samsung Electronics...
  • Page 41 Troubleshooting Samsung Electronics 5-19...
  • Page 42 Troubleshooting MEMO 5-20 Samsung Electronics...

  • Page 43: Exploded View And Parts List

    6-4 DVD Mechanical Parts - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-8 Samsung Electronics...

  • Page 44: Cabinet Assembly

    Exploded View and Parts List 6-1 Cabinet Assembly Samsung Electronics...
  • Page 45 ASSY PCB VCR-MAIN DIGITAL;DVD-V1000,DVD+VCR, AC92-01029A ASSY PCB-SMPS;SV-DVD90,A/DUB,SP/LP,MULTI AH92-01004C ASSY PCB DVD-MAIN;DVD-V1000D/XAA,AUD.B, 4H, AC92-01031A ASSY PCB-F/T;DVD-V1000,A/DUB,SP/LP,MULTI 3711-003460 CONNECTOR-HEADER;NOWALL,20P,1R,1.5mm,STR CN3A1B 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm CN602B 3809-001131 CABLE-FLAT;30V,80C,110MM,7P,1.25MM,UL289 CN8A 3809-001264 CABLE-FLAT;30V,80C,260MM,35P,1.25MM,UL28 CN8B 3809-001265 CABLE-FLAT;30V,80C,300MM,35P,1.25MM,UL28 LD601A AC61-21009A HOLDER-LED;-,POM(M90-44),-,BLK,-,X-9 S601A AC61-21008A HOLDER-SENSOR;-,POM(M90-44),-,BLK,-,X-9 S602A AC61-21008A HOLDER-SENSOR;-,POM(M90-44),-,BLK,-,X-9 UT01 AC59-00052B REMOCON-ASSY;SVD-V1000,-,-,-,38KEY,-,-,- Samsung Electronics...

  • Page 46: Vcr Mechanical Parts (Top Side)

    G001 K490 K502 K530 G555 B473 G530 B474 G450 G510 G680 G420 G480 (OPTIONAL) K546 K250 K240 (OPTIONAL) K248 B575 G681 B410 K350 K110 B440 K182 B448 K340 K330 B452 G546 K470 K140 K188 G527 G520 G070 G060 Samsung Electronics...
  • Page 47 K250 AC69-00104A BAND-BRAKE ASS’Y;TS-10,-,-,-,-,-,- K330 AC66-30550A LEVER-S.BRAKE ASSY;-,POM+SUS,-,-,-,X-9 K340 AC66-30549A LEVER-T.BRAKE ASSY;-,POM+SUS,-,-,-,X-9 K350 AC61-00106A SPRING-BRAKE;TS-10,SUS304-WPB,-,-,-,-,-, K470 AC66-00020A SLIDER-FL DRIVE;TS-10,SECC E20/20,1.0,-, K490 AC61-00120A HOLDER-FL CASS. ASS’Y;TS-10,-,-,-,-,- K502 AC61-60561A SPRING-FL.LEVER-LR;-,ES,SUS304 WPB,PI2.7 K530 AC66-00034A LEVER-FL ARM ASS’Y;TS-10,-,-,-,-,-,-,- K546 AC61-50658A GUIDE-CASS. DOOR;X-9,POM,-,-,-,NTR Samsung Electronics...

  • Page 48: Vcr Mechanical Parts (Bottom Side)

    Exploded View and Parts List 6-3 VCR Mechanical Parts (Bottom Side) G542 B462 B456 B560 B460 B500 B458 B464 B488 B501 B489 B484 B468 K222 K200 K225 K221 B478 B570 Samsung Electronics...
  • Page 49 LINK-LOADING S;TS-10,SECC E20/20,0.8,-,- B500 AC66-00024A LEVER-T LOADING;TS-10,POM,-,-,-,-,NAT,- B501 AC66-00022A LINK-LOADING T;TS-10,SECC E20/20,0.8,-,- B560 AC31-00010A MOTOR-CAPSTAN;-,SANKYO,-,- B570 AC60-10514A SCREW-CAPSTAN;-,-,M2.6,L6,PH,+,-,-,-,- G542 AC66-60051A BELT-PULLEY;-,5CM-70,2 * 2,-,71.3,-,X-9 K200 AC61-21012A HOLDER-CLUTCH ASSY;-,-,-,-,-,X-9 K221 AC66-20581A GEAR-CENTER ASSY;-,POM,M=O.5,-,HIGHT T., K222 AC60-30306A WASHER-SLIT;-,-,ID2.1,OD5.0,T0.5,-,POLYS K225 AC66-00006A LEVER-UP DOWN;TS-10,POM,-,-,-,-,NAT,- Samsung Electronics...

  • Page 50: Dvd Mechanical Parts

    Exploded View and Parts List 6-4 DVD Mechanical Parts H107 H105 H106 H103 H102 H101 H240 H108 H104 H250 H241 H211 H203 H207 H208 H202 H201 H204 H206 H205 H210 H209 Samsung Electronics...
  • Page 51 GEAR-FEED B;-,POM M90-44,-,-,-,-,-,-,-,- H206 AC60-30306A WASHER-SLIT;-,-,ID2.1,OD5.0,T0.5,-,POLYS H207 AH31-00022A MOTOR-SPINDLE ASSY;RSM-2610D,DP-7,-,-,-, H208 AH61-00403A SPRING-SPINDLE;-,SWPB,-,CS,PI4.9,PI0.7,- H209 AH61-00513A CHASSIS-SUB;DP-7,ABS(SR-0320),-,-,-,-,-, H210 AH31-00016A MOTOR-FEED ASSY;-,DP-5,-,- H211 AH97-00708A ASSY-PICK-UP;-,SOH-DM2,ASSY-PICK-UP H240 AH92-00963A ASSY-MILLENO DECK PCB 2LD;DVD-M101,MILLE H241 3809-001252 CABLE-FLAT;30V,80C,180mm,22P,1mm,UL2896 H250 AH92-00900B ASSY PCB-DECK B;DVD-V1000,MILLENO DECK(B Samsung Electronics...
  • Page 52 Exploded View and Parts List MEMO 6-10 Samsung Electronics...

  • Page 53: Electrical Parts List

    S601 0603-001011 PHOTO-TR;NPN,35V,6V,50mA,75mW,BK D613 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP S602 0603-001011 PHOTO-TR;NPN,35V,6V,50mA,75mW,BK D620 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP SW601 AC34-20100A SWITCH-MODE;-,-,X-9,- D688 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, SW602 AC34-20100B SWITCH-REC;-,-,X-9,- D692 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP W007 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm IC601 AC09-00030A IC MCU;UPD78F4928,100PIN,QFP,-,16BIT,PLA W024 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM IC604 AC14-12009W IC-RESET;PST572K,TO-92,R59-1766 2.5V Samsung Electronics...
  • Page 54 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012 C3A09 2401-000407 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5 R3A02 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012 C3A10 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 R3A03 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M C3A11 2301-000174 C-FILM,PEF;15nF,5%,100V,TP,7.2x4.0x7.5mm R3A04 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 C3A12 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 R3A05 2007-000757 R-CHIP;330KOHM,5%,1/10W,DA,TP,2012 C3A13 2301-000161 C-FILM,PEF;12nF,5%,50V,TP,6.5X5.5X3.0X5, R3A06 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM C3A14 2301-001014 C-FILM,PEF;6.8nF,5%,50V,TP,7x3x6,5mm R3A07 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 55 AH14-10004R IC;M74HCU04,SOP,TAPE 14P C503 2401-000918 C-AL;22uF,20%,16V,GP,-,6.3x7,5 2702-000106 INDUCTOR-RADIAL;100uH,10%,6.2x7.4mm C504 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 AL201 2901-001125 FILTER-EMI ON BOARD;50V,0.5A,-,220pF,7x2 C505 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012 AOP1 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m C506 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 AR10 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M C507 2401-000918 C-AL;22uF,20%,16V,GP,-,6.3x7,5 AR11 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M C508 2203-000891 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,2012 Samsung Electronics...
  • Page 56 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C6212 2203-000634 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,201 C861 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C6223 2203-000634 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,201 C862 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C6264 2203-001579 C-CERAMIC,CHIP;15nF,10%,50V,NP0,TP,2012 C863 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C6802 2202-000173 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1 C864 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C6803 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 C865 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C6804 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP, C866 2401-001353 C-AL;470uF,20%,10V,GP,TP,8x11.5,5 Samsung Electronics...
  • Page 57 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,- VR11 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM LV32 AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,- VR22 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM PT01 AC26-00002L TRANS SWITCHING;EER3531,SV-DVD90,FREE,-, VR23 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20. VR24 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000113 R-CARBON;18KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2001-000113 R-CARBON;18KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2001-000113 R-CARBON;18KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2001-000113 R-CARBON;18KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2001-000096 R-CARBON(S);1MOHM,5%,1/2W,AA,TP,2.4X6.4M 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 58 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 RDP2 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM MR32 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 RDP4 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 RDP5 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 RDP6 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 RVP1 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 RVP2 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 RVP3 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 2802-001152 RESONATOR-CERAMIC;20MHZ,0.5%,TP,5.5X3.5X Samsung Electronics...
  • Page 59 CORE-FERRITE BEAD;AB,120ohm,2x1.25x0.9mm SC48 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm SC49 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT- SC50 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT- SC51 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP SC52 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608 SC54 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608 RR10 2007-000312 R-CHIP;10OHM,5%,1/8W,DA,TP,3216 SC55 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 Samsung Electronics...
  • Page 60 R-CHIP;1OHM,5%,1/4W,DA,TP,3216 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 SR69 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608 0402-000309 DIODE-RECTIFIER;1SR154-400,400V,1A,PSM SR70 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 ZE30 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 SR71 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 ZE34 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 SR72 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 ZE36 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 SR73 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 ZE37 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 SR74 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 ZIC1 1204-001673 IC-DECODER;ZIVA4.1,QFP,208P,1100MIL,PLAS Samsung Electronics...
  • Page 61 ASSY PCB-DECK B;DVD-V1000,MILLENO DECK(B C703 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP, HCN1 AC39-00072A CBF HARNESS;001-003009,-,-,5P,80,-,-,526 C705 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 HSW1 3409-001119 SWITCH-DETECTOR;5V DC,1.0A,DPST,30gf,- C706 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V C707 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3. C712 2202-000183 C-CERAMIC,MLC-AXIAL;2.2NF,20%,16V,Y5R,TP C713 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP, C714 2202-000183 C-CERAMIC,MLC-AXIAL;2.2NF,20%,16V,Y5R,TP CN701 3710-001145 CONNECTOR-SOCKET;20P,1R,1.5mm,STRAIGHT,S D701 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, Samsung Electronics...
  • Page 62 Electrical Parts List MEMO 7-10 Samsung Electronics...
  • Page 63 Electrical Parts List Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark Samsung Electronics 7-11...

  • Page 64: Block Diagram

    8. Block Diagram Samsung Electronics...
  • Page 65 Block Diagram MEMO Samsung Electronics...

  • Page 66: Pcb Diagrams

    9-6 Housing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9-5 Samsung Electronics...
  • Page 67 PCB Diagrams 9-1 S.M.P.S. Samsung Electronics...
  • Page 68 PCB Diagrams 9-2 VCR Main Samsung Electronics...
  • Page 69 PCB Diagrams 9-3 DVD Main Samsung Electronics...
  • Page 70 PCB Diagrams 9-4 Function-Timer 9-5 DVD Deck 9-6 Housing Samsung Electronics...
  • Page 71 PCB Diagrams MEMO Samsung Electronics...

  • Page 72: Wiring Diagram

    10. Wiring Diagram Samsung Electronics 10-1...
  • Page 73 Wiring Diagram MEMO Samsung Electronics 10-2...

  • Page 74: Schematic Diagrams

    11-13 DVD Deck - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11-15 Samsung Electronics...

  • Page 75: Block Identification Of Main Pcb

    Schematic Diagrams ◆ Block Identification of Main PCB VCR MAIN PCB <Component Side> <Conductor Side> DVD MAIN PCB <Component Side> Samsung Electronics 11-2...
  • Page 76 Schematic Diagrams 11-1 S.M.P.S. Samsung Electronics 11-3...

  • Page 77: Power Drive

    Schematic Diagrams 11-2 Power Drive Samsung Electronics 11-4...

  • Page 78: Function-Timer

    Schematic Diagrams 11-3 Function-Timer Samsung Electronics 11-5...

  • Page 79: System Control/Servo

    Schematic Diagrams 11-4 System Control/Servo Samsung Electronics 11-6...

  • Page 80: A/V

    Schematic Diagrams 11-5 A/V Samsung Electronics 11-7...
  • Page 81 Schematic Diagrams 11-6 TM-Blcok Samsung Electronics 11-8...

  • Page 82: Digital Audio

    Schematic Diagrams 11-7 Digital Audio Samsung Electronics 11-9...

  • Page 83: Hi-Fi

    Schematic Diagrams 11-8 Hi-Fi Samsung Electronics 11-10...

  • Page 84: Osd

    Schematic Diagrams 11-9 OSD Samsung Electronics 11-11...

  • Page 85: Input-Output

    Schematic Diagrams 11-10 Input-Output Samsung Electronics 11-12...

  • Page 86: Dvd Main-Micom/Av Decoder

    Schematic Diagrams 11-11 DVD Main-Micom/AV Decoder Samsung Electronics 11-13...

  • Page 87: Servo

    Schematic Diagrams 11-12 Servo Samsung Electronics 11-14...

  • Page 88: Dvd Deck

    Schematic Diagrams 11-13 DVD Deck Samsung Electronics 11-15...
  • Page 89 Schematic Diagrams MEMO Samsung Electronics 11-16...
  • Page 90 TS-10 DECK MECHANICAL Manual ◆ File with the SERVICE MANUAL. TS-10 DECK CONTENTS 1. Disassembly and Reassembly ELECTRONICS 2. Alignment and Adjustment © Samsung Electronics Co., Ltd. JUN. 2001 Printed in Korea AC68-01451A...

  • Page 91: Disassembly And Reassembly

    1-1-1 Top View Œ ´ ˇ ¨ ˆ Ø Fig. 1-1 Top parts Location-1 Œ GEAR FL CAM ´ MOTOR LOADING ASS’Y ˇ LEVER FL ARM ASS’Y ¨ HOLDER FL CASSETTE ASS’Y ˆ LEVER FL DOOR Ø SLIDER FL DRIVE Samsung Electronics...
  • Page 92 ´ CYLINDER ASS’Y ˝ GEAR IDLE ˇ ACE HEAD ASS’Y Ô LEVER IDLE ¨ LEVER UNIT PINCH ASS’Y  LEVER T BRAKE ASS’Y ˆ LEVER #9 GUIDE ASS’Y Ò DISK T REEL Ø LEVER TENSION ASS’Y ∏ BAND BRAKE ASS’Y Samsung Electronics...
  • Page 93 Œ GEAR JOINT 1 ´ GEAR JOINT 2 ˇ BRACKET GEAR ¨ MOTOR CAPSTAN ASS’Y ˆ LEVER T LOAD ASS’Y Ø GEAR LOADING DRIVE ∏ LEVER S LOAD ASS’Y ” HOLDER CLUTCH ASS’Y ’ BELT PULLEY ˝ SLIDER CAM Samsung Electronics...

  • Page 94: Lever Fl Door Removal

    Lever FL Cassette-R ´ at disassembling and "B" reassembling. ´ LEVER FL DOOR ˇ HOOK "C" Fig. 1-4 Lever FL Door Removal RAIL [B] Œ HOLDER FL ´ LEVER FL CASSETTEE -R CASSETTEE ASS`Y "A" BOSS [A] Fig. 1-5 Holder FL Cassette Ass’y Removal Samsung Electronics...
  • Page 95 Fig. 1-8 Lever FL Arm Ass’y Removal ´ GEAR FL CAM Œ SLIDER FL DRIVE Fig. 1-6 Slider FL Drive Removal Œ GEAR FL CAM GEAR WORM WHEEL POST TIMING POINT Fig. 1-7 Gear FL Cam, Gear Worm Samsung Electronics...

  • Page 96: Gear Worm Wheel Removal

    1) Remove the screw Œ. 1) Remove the Gear Worm wheel Œ. 2) Remove the Motor Loading Ass’y ´. ´ MOTOR LOADING ASS`Y Œ SCREW Œ GEAR WORM WHEEL Fig. 1-10 Motor Loading Ass’y Removal Fig. 1-9 Gear Worm Wheel Removal Samsung Electronics...

  • Page 97: Bracket Gear, Gear Joint 2, 1 Removal

    Fig. 1-11 Bracket Gear, Gear Joint 1,2 Removal Fig. 1-13 Gear Loading Drive, Slider Cam, Lever T, S Load Ass’y Removal Œ GEAR JOINT1 ´ GEAR JOINT2 ˇ SLIDER CAM TIMING POINT 2 TIMING POINT 1 Fig. 1-12 Gear Joint 1,2 Assembly Samsung Electronics...

  • Page 98: Gear Loading Drive, Slider Cam

    LEVER LOAD T LEVER LOAD S Lever Tension Drive Removal TIMING POINT 2 TIMING POINT 3 PIN A PIN C PIN D PIN B ˇ SLIDER CAM Fig. 1-14 Gear Loading Drive, Slider Cam, Lever Load S, T Ass’y Assembly Samsung Electronics...

  • Page 99: Lever Tension Ass'y, Band Brake Ass'y Removal

    ˇ SPRING BRAKE Œ SPRING TENTION LEVER STOPPER Œ LEVER S BRAKE ASS`Y "A" HOOK(C) MARK[B] HOOK(B) ´ LEVER T BRAKE ASS`Y Fig. 1-16 Lever Tension Ass’y, Band Brake Ass’y Removal Fig. 1-17 Lever Brake S, T Ass’y Removal Samsung Electronics...
  • Page 100 ´ DISK T REEL add oil in the boss of Lever Idle Œ. "A" Œ LEVER IDLE ´ GEAR IDLE "B" ´ GEAR IDLE HOOK "C" Fig. 1-19 Disk S, T Reel Removal Fig. 1-18 Gear Idle Ass’y Removal 1-10 Samsung Electronics...
  • Page 101 Fig. 1-21 Lever Up Down Ass’y Removal SPRING GEAR CENTER ASS'Y GUIDE LEVER UP DOWN ASS'Y RING <BAD> <GOOD> GEAR POST HOOK Fig. 1-20 Holder Clutch Ass’y Removal MAIN BASE Fig. 1-22 Lever Up Down Ass’y Removal Samsung Electronics 1-11...

  • Page 102: Guide Cassette Door Removal

    Œ GUIDE CASSETTE DOOR Œ LEVER UNIT PINCH ASS`Y HOOK [A] ´ PLATE JOINT ˇ SPRING PINCH DRIVE Fig. 1-23 Guide Cassette Door Removal Fig. 1-24 Lever Unit Pinch Ass’y, Plate Joint, Spring Pinch Drive Removal 1-12 Samsung Electronics...

  • Page 103: Fe Head Removal

    2) After reinstalling, check the bottom side of the Post #9 Guide to the top side of Main Base. "A" Œ SPRING #9 GUIDE ´ LEVER #9 GUIDE ASS`Y "B" Fig. 1-26 FE Head Removal Fig. 1-25 Lever #9 Guide Ass’y Removal Samsung Electronics 1-13...

  • Page 104: Ace Head Removal

    2) Remove the screw Œ. 3) Lift the ACE Head Ass’y ´. Œ SLIDER S ASS`Y Œ SCREW ´ SLIDER T ASS`Y ´ HEAD ACE ASS`Y Fig. 1-28 Slider S, T Ass’y Removal Fig. 1-27 ACE Head Removal 1-14 Samsung Electronics...
  • Page 105 1) Release the Hook Œ. 2) Lift the Lever Head Cleaner Ass’y ´. ´ LEVER HEAD CLEANER ASS'Y Œ HOOK SLEEVE-HEAD CLEANER ˇ CYLINDER ASS'Y Fig. 1-29 Plate Ground Deck, Cylinder Ass’y Removal Fig. 1-31 Level Head Cleaner Ass’y Removal Samsung Electronics 1-15...
  • Page 106 3) Rotate Gear Worm Œ clockwise using screw driver again up to the state of eject mode and then pick out the tape.(Refer to Fig.1-33) ˇ MOTOR CAPSTAN ASS'Y Fig. 1-32 Damper Capstan,Motor Capstan Ass’y Removal FRAME Fig. 1-33 1-16 Samsung Electronics...
  • Page 107 CAPSTAN MOTOR PULLEY BELT PULLEY ∆ HOLDER CLUTCH ASS’Y GEAR CENTER ASS’Y GEAR IDLE (2Point) LOADING MOTOR BAND BRAKE ASS’Y BRAKE T ASS’Y ◆ : Add Oil ∆ : Cleaning O : Check and replacement in necessary Samsung Electronics 1-17...
  • Page 108 Disassembly and Reassembly MEMO 1-18 Samsung Electronics...

  • Page 109: Alignment And Adjustment

    Fig. 2-1 Location of Tape Transport Adjustment FE HEAD CYLINDER ASS'Y PINCH ROLLER GUIDE ROLLER "S" GUIDE ROLLER "T" POST TENSION #8 GUIDE POST #9 GUIDE POST #3 GUIDE POST MAIN BASE ACE HEAD CAPSTAN SHAFT Fig. 2-2 Tape Travel Diagram Samsung Electronics...

  • Page 110: Tape Transport System Adjustment

    ADJUSTMENT Fig. 2-3 Location of ACE Head Adjustment Screw 1) See “2. Alignment and Adjustment” for ACE Head position (X-Point) adjustment. AUDIO HEAD VIDEO HEAD 0 ~ 0 .25 mm CONTROL HEAD Fig. 2-4 ACE Head Height Adjustment Samsung Electronics...
  • Page 111 ) driver to obtain a flat video RF envelope as shown in Fig. 2-8. IDEAL ENVELOPE S HEIGHT TOO HIGH S HEIGHT TOO LOW T HEIGHT TOO HIGH T HEIGHT TOO LOW GUIDE ROLLER S GUIDE ROLLER T Fig. 2-8 Guide Roller S, T Height Adjustment Samsung Electronics...

  • Page 112: Reel Torque

    3) Brake is operated by slider cam at FF/REW mode. 4) Transportation of accurate driving force is done by gears. (Gear Center Ass’y) Note : If the spec. does not meet the followings speci- fications, replace the holder clutch ass’y and then recheck. Samsung Electronics...
