ONFORU G20UV Product Manual

LED FLOOD LIGHT
Product Manual
MODEL:
D30UV
SPECIFICATIONS
LED FLOOD LIGHT
Model
G20UV
Input Voltage
Input Current
0.14A
Rated Power
20W
Wavelength
CRI
Power Factor
Chromaticity coordinate
Beam Angle
t a
Luminaire Location SUITABLE FOR WET LOCATIONS
DIMENSIONS
Model
G20UV
153x28x97 mm /
Dimensions（LxWxH）
6.02x1.1x3.82 in
Weight 0.41 kg / 0.90 lb
D50UV
Model
208x37x127 mm/
Dimensions（LxWxH）
8.19x1.46x5in
Weight 0.58KG /1.27lb
Note:
The intended purpose of this special
purpose product: This light is used to
create atmosphere. it is not suitable for
household room illumination，the light
source is not intended for use in other
applications.
G20UV D50UV D100UV
D50UV D100UV
D30UV
100-120V～60Hz
0.41A 0.85A
0.25A
50W
100W
30W
385-400nm
-1.9
≥0.9
x=0.1763 y=0.0317
120°
-20-40°C/-4°F-104°F
D30UV
175x33x107 mm/
6.89x1.3x7.68in
0.4 kg / 0.88 lb
D100UV
249x39x149 mm/
9.8x1.54x5.87in
0.92 kg / 2.03 lb
H
W
L
3
COMPONENTS AND STRUCTURE
G20UV
D50UV
2
1
1. Cover
US 1.5m(4.92ft)
2. LED Light Source
3. Lamp Bracket
PREPARATION
Check all components for damage, do not use the product if
it is damaged.
Estimated Assembly Time:10-30 minutes
TOOLS REQUIRED（not included）
Flathead Screwdriver Electric drill
screwdriver
WARNING:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH
THE APPLICABLE INSTALLATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF
THE PRODUCT AND THE HAZARDS INVOLVED.
RISK OF SHOCK- BEFORE BEGINNING INSTALLATION,TURN
OFF ELECTRICITY AT THE CIRCUIT BREAKER BOX OR THE
MAIN FUSE BOX.
D30UV
D100UV
3
2
Eye Protection Pliers Step Ladder
4
