- Page 1 GK58FTIPO User Manual Get the most out of your appliance For your digital manual, how-to videos and support visit electrolux.com/getstarted...
-
Page 2: Table Of Contents
12. GUARANTEE ....................35 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 3: Children And Vulnerable People Safety
ENGLISH responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 •... - Page 4 NEVER try to extinguish a fire with water, but switch • off the appliance and then cover flame e.g. with a lid or a fire blanket. CAUTION: The appliance must not be supplied • through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.
-
Page 5: Safety Instructions
ENGLISH 2. SAFETY INSTRUCTIONS 2.1 Installation • The appliance must be earthed. • Before carrying out any operation WARNING! make sure that the appliance is Only a qualified person must disconnected from the power supply. install this appliance. • Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power WARNING! - Page 6 The isolation time. device must have a contact opening • Do not put flammable products or width of minimum 3 mm. items that are wet with flammable products in, near or on the appliance.
-
Page 7: Installation
ENGLISH Sensor in the dishwasher. The not use any abrasive products, silicone handle may discolour, which abrasive cleaning pads, solvents or has no effect on how the Food Sensor metal objects. operates. 2.6 Service • Use the original packaging to store the Food Sensor. - Page 8 N PE L1 L2 3.5 Attaching the seal - 3.6 Assembly Integrated installation 1. Clean the rabbets in the worktop. 2. Cut the supplied 3x10mm seal stripe into 4 stripes. The stripes must have the same length as the rabbets.
-
Page 9: Product Description
ENGLISH If the appliance is installed above a drawer, the hob ventilation can warm up the items stored in the drawer during the cooking process. min. 28 mm 4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Induction zone with Assisted Cooking Induction zone with Assisted Cooking and Pan Fry Control panel... - Page 10 Symbol Comment ON / OFF To activate and deactivate the hob. Menu To open and close the Menu. Food Sensor To open the Food Sensor menu. Zone selection To open the slider for the selected zone. Zone indicator To show for which zone the slider is active.
- Page 11 ENGLISH Food Sensor in the liquid 2-5 cm above without it, e.g. to prepare pancakes. The the minimum level mark. Place the Food available options depend on the kind of Sensor on the rim of the pot or pan by dish you want to make.
-
Page 12: Before First Use
4.5 OptiHeat Control (3 step Lock - this function temporarily Residual heat indicator) disables the control panel during cooking. WARNING! Child Lock - this function disables the III / II / I There is a risk of control panel while the hob does not burns from residual heat. -
Page 13: Menu Structure
ENGLISH the boiling point with the tolerance range If you replace the Food Sensor with a of + / - 2 °C. new one, you need to pair it with your hob. Follow the procedure when: 1. Touch • you install the hob for the first time; Select Settings >... -
Page 14: Daily Use
Settings Child Lock Stopwatch Hob²Hood Refer to the Hob²Hood section in "Daily use". Food Sensor Connection Calibration Pairing Setup Assisted Cooking Language Key Tones Buzzer Volume Display Brightness Service Demo Mode License Show Software Version Alarm History Reset All Settings 6. -
Page 15: Using The Cooking Zones
ENGLISH Heat setting The hob deacti‐ vates after 4 hours 7 - 9 1.5 hour You can also change the heat setting while cooking. Touch the zone selection When you use Pan Fry the symbol on the main view of the control hob deactivates after 1.5 panel and move you finger to the left or hours. -
Page 16: Power Management
6.6 PowerBoost This function activates more power for the appropriate induction cooking zone; it depends on the cookware size. The function can be activated only for a limited period of time. 1. Touch the desired zone symbol first. 2. Touch... - Page 17 ENGLISH The function does not stop automatically. For Pan Fry follow the For Sous Vide the hob will automatically instructions on the display. deactivate after a maximum of four Add oil once the pan is hot. hours. To stop the function, touch , or With Assisted Cooking the the symbol of the active zone, and select...
- Page 18 Set the time (optionally). The time of the Once the pot reaches the intended cooking session depends on the temperature, an acoustic signal sounds thickness and type of food. and a pop-up window appears. 5. Touch OK to continue.
-
Page 19: Countdown Timer
ENGLISH 1. Set the heat setting for the 1. Touch on the display to open the appropriate cooking zone first and Menu. then set the function. 2. Select Hob Functions > Melting from 2. Touch the zone symbol. the list. 3. -
Page 20: Child Lock
To To deactivate the function touch deactivate the function turn the the left of the timer value, touch next switch off. to it and confirm your choice when a pop- To leave the Menu, touch or the right up window appears. -
Page 21: Changing The Modes
ENGLISH There are 4 brightness levels, 1 is the lowest and 4 is the highest. Auto‐ Boiling Frying matic 1. Touch on the display to open the light Menu. 2. Select Settings > Setup > Display Brightness from the list. Fan speed Fan speed 3. -
Page 22: Hints And Tips
7. HINTS AND TIPS 7.2 Correct pans for Pan Fry WARNING! function Refer to Safety chapters. Use only pans with flat bottom. To check 7.1 Cookware if the pan is correct: 1. Put your pan upside down. For induction cooking zones 2. -
Page 23: Examples Of Cooking Applications
ENGLISH 7.5 Examples of cooking • clicking: electric switching occurs, the pot is detected after you place it on applications the hob. • hissing, buzzing: the fan operates. The correlation between the heat setting The noises are normal and do not of a zone and its consumption of power indicate any malfunction. - Page 24 7.6 Hints and Tips for the Food Sensor For functions such as Assisted Cooking and Sous Vide, you can use the Food Sensor on the left side of the hob only. With the Thermometer function you can use the Food Sensor also on the right side of the hob.
-
Page 25: Cooking Guide
ENGLISH cutting boards for different types of food. • Pay special attention to food hygiene when preparing poultry, eggs, and fish. Poultry should always be prepared at the temperature of at least 65 °C for a minimum of 50 minutes. •... - Page 26 Food type Cooking Preparation Thickness / Core Cooking time method level amount of temp / (min) food cooking temp (°C) Beef - Sous Vide rare 2 cm 50 - 54 45 - 90 steak 4 cm 100 - 150...
- Page 27 ENGLISH Food type Cooking Preparation Thickness / Core Cooking time method level amount of temp / (min) food cooking temp (°C) Eggs Sous Vide M - size 63 - 64 soft 45 - 70 65 - 67 medium 45 - 70 68 - 70 hard 45 - 70...
-
Page 28: Care And Cleaning
• Always remove the Food Sensor To find the full range of cooker hoods before turning the food over. which work with this function refer to our consumer website. The Electrolux cooker 7.9 Hints and Tips for hoods that work with this function must Hob²Hood... -
Page 29: Cleaning The Hob
ENGLISH • Scratches or dark stains on the water rings, fat stains, shiny metallic surface have no effect on how the hob discoloration. Clean the hob with a operates. moist cloth and a non-abrasive • Use a special cleaner suitable for the detergent. - Page 30 Problem Possible cause Remedy The display does not react Part of the display is cov‐ Remove the objects. Move to the touch. ered or the pots are placed the pots away from the dis‐ too near to the display.
- Page 31 ENGLISH Problem Possible cause Remedy The display shows the You did not calibrate the Calibrate the Food Sensor temperature of water is Food Sensor or you did it again. Refer to "Calibrat‐ higher than 100°C. incorrectly. ing". You moved the hob to a You may also need to different location.
- Page 32 Problem Possible cause Remedy You cannot activate a Another function is running Stop the function before function. on the same cooking zone, you activate another. which prevents the activa‐ tion. Assisted Cooking or Sous At the beginning of a cook‐...
-
Page 33: Technical Data
Make sure, you operated the hob correctly. If not the 10. TECHNICAL DATA 10.1 Rating plate Model GK58FTIPO PNC 949 596 910 00 Typ 62 B4A 01 CA 220 - 240 V / 400 V 2N 50 - 60 Hz Induction 7.35 kW... -
Page 34: Cooking Zones Specification
Food Sensor is approved for use in contact with food. 11. ENERGY EFFICIENCY 11.1 Product information according to EU 66/2014 valid for EU market only Model identification GK58FTIPO Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter of circular cook‐... -
Page 35: Energy Saving
ENGLISH EN 60350-2 - Household electric cooking • When you heat up water, use only the appliances - Part 2: Hobs - Methods for amount you need. measuring performance • If it is possible, always put the lids on the cookware. The energy measurements referring to •... - Page 36 For Switzerland: Where should you take your old equipment? Anywhere that sells new equipment or hand it in to official SENS collection points or official SENS recycling firms. The list of official SENS collection points can be found at www.erecycling.ch...
- Page 40 www.electrolux.com/shop...
