- Page 1 ASSEMBLY INSTRUCTIONS / INSTRUCTIONS D'ASSEMBLAGE / INSTRUCTIVO DE ARMADO FG-WH-PU-3-297-UK FG-LR-PU-3-297-RV-UK Update 26 Jul 2023...
- Page 2 NOTES ON ASSEMBLY / NOTES POUR L’ASSEMBLAGE / NOTAS SOBRE EL ENSAMBLE • To ensure ease of assembly read all instructions before assembly and follow step by step illustrations. • Keep instructions for future use. • Adult assembly required. 2 person required. •...
- Page 3 WARNING AVERTISSEMENT / ADVERTENCIA Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Serious or fatal crushing injuries can occur from furniture tip-over. To help prevent tip-over: • Place heaviest items in the lowest drawers. •...
- Page 4 MINIFIX CAM & MINIFIX BOLT & WOOD DOWEL CAMÉRA MINIFIX & BOULON MINIFIX & CHEVILLE BOIS PASADOR DE MADERA CÁMARA MINIFIX & PERNO MINIFIX & MINIFIX BOLT BOULON MINIFIX PERNO MINIFIX PLEASE TICK TO SHOW THE CORRECT LAYER OPTION ✗ ✓...
- Page 5 SPECIAL TIPS FOR FITTING DRAWER CONSEJOS ESPECIALES PARA EL MONTAJE DEL CAJÓN CONSEILS SPÉCIAUX POUR LE MONTAGE DU TIROIR DRAWER SLIDE - CABINET MEMBER - LEFT WALL FRONT BACK SCREW THRU THIS HOLE DRAWER SLIDE - CABINET MEMBER - RIGHT FLOOR BACK FRONT...
- Page 7 HARDWARE QUINCAILLERIE / HERRAJE Screw M4 x 38mm Unita M6.3 x 50mm Minifix Bolt EU 24 18 units 12 units 4 units Dowel M8 x 30mm Screw 3.5 x 25mm Screw 4 x 30mm 2 units 32 + 2 units 2 units Screw 3.5 x 15mm Screw M6 x 8mm...
- Page 8 STEP 1 O x 12 K x 1 H x 4 FRONT BACK SECOND HOLE PLEASE ENSURE TO FIX THE SCREWS AS PER ABOVE POINTED HOLES INSTRUCTION TO AVOID DISTORTION OF OVERALL LOOK OF PRODUCTS...
- Page 9 STEP 2 D x 22 M x 2 G x 2 ✓ ✗...
- Page 10 STEP 3 A x 14 STEP 4 C x 10...
- Page 11 STEP 5 STEP 6 G x 2...
- Page 12 STEP 7 J x 10 STEP 8 Q x 6...
- Page 13 STEP 9 D x 2 M x 2 G x 4 STEP 10 A x 4...
- Page 14 STEP 11 I x 22...
- Page 15 STEP 12 R x 2 F x 2 STEP 13...
- Page 16 STEP 14 D x 8 C x 2 ✓ ✗ STEP 15...
- Page 17 STEP 16 J x 2 STEP 17...
- Page 18 STEP 18 B x 4 STEP 19 N x 1 E x 2...
- Page 19 STEP 20 L x 1 G x 4 STEP 21...
- Page 20 STEP 22 P x 7 STEP 23 P x 7...
- Page 21 SPECIAL TIPS FOR FITTING ANTI-TOPPLE SAFETY STRAP CONSEJOS ESPECIALES PARA LA COLOCACIÓN DE LA CORREA DE SEGURIDAD ANTITOPPLE CONSEILS SPÉCIAUX POUR LE MONTAGE DU TIROIR WARNING: IT IS STRONGLY RECOMMENDED THAT YOU ANCHOR THIS PRODUCT TO A WALL M3.5 x 25mm STRAP (200mm) WALL FIXING HARDWARE LIST...
- Page 22 MAXIMUM LOADS CHARGES MAXIMALES / CARGA MAXIMA 8 lbs 4 kg This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Ce meuble a été conç pour supporter les charges maximales indiquées. En excédant ces limites de charge, le meuble pourrait devenir instable, s'effondrer, et/ou causer des blessures graves.
