- Page 1 ASSEMBLY INSTRUCTIONS / INSTRUCTIONS D'ASSEMBLAGE / INSTRUCTIVO DE ARMADO FG-DI-PU-2-922-AS-USA FG-KO-PU-2-922-GT-USA Update 25 Jul 2023...
- Page 2 NOTES ON ASSEMBLY / NOTES POUR L’ASSEMBLAGE / NOTAS SOBRE EL ENSAMBLE • To ensure ease of assembly read all instructions before assembly and follow step by step illustrations. • Keep instructions for future use. • Adult assembly required. 2 person required. •...
- Page 3 WARNING AVERTISSEMENT / ADVERTENCIA Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Serious or fatal crushing injuries can occur from furniture tip-over. To help prevent tip-over: • Place heaviest items in the lowest drawers. •...
- Page 4 MINIFIX CAM & MINIFIX BOLT & WOOD DOWEL CAMÉRA MINIFIX & BOULON MINIFIX & CHEVILLE BOIS PASADOR DE MADERA CÁMARA MINIFIX & PERNO MINIFIX & MINIFIX BOLT BOULON MINIFIX PERNO MINIFIX ✗ ✓ NO GAP PAS D'ÉCART NINGÚN ESPACIO MINIFIX CAM CAMÉRA MINIFIX CÁMARA MINIFIX WOOD DOWEL...
- Page 5 SPECIAL TIPS FOR FITTING DRAWER CONSEJOS ESPECIALES PARA EL MONTAJE DEL CAJÓN CONSEILS SPÉCIAUX POUR LE MONTAGE DU TIROIR DRAWER SLIDE - CABINET MEMBER - LEFT WALL FRONT BACK SCREW THRU THIS HOLE DRAWER SLIDE - CABINET MEMBER - RIGHT FLOOR BACK FRONT...
- Page 7 HARDWARE QUINCAILLERIE / HERRAJE ø Screw M4 x 38mm Cam Bolt EU 24 Dowel 8 x 30mm 4 units 18 units 24 + 2 units Screw M10 x 3/4” Screw M4 x 16mm Screw M3.5 x 15mm 8 units 1 unit 8 units Nail Pin Floor Glide...
- Page 8 STEP 1 K x 4 D x 8 STEP 2 L x 1 F x 4...
- Page 9 STEP 3 H x 4 B x 4 STEP 4 B x 12...
- Page 10 STEP 5 C x 8 STEP 6 I x 4...
- Page 11 STEP 7 C x 1 STEP 8 C x 2...
- Page 12 STEP 9 I x 6 STEP 10 C x 1...
- Page 13 STEP 11 I x 2 STEP 12 C x 8...
- Page 14 STEP 13 I x 4 STEP 14 G x 10 90°...
- Page 15 STEP 15 B x 2 STEP 16 C x 4...
- Page 16 STEP 17 I x 2 STEP 18 A x 4...
- Page 17 STEP 19 J x 1 E x 1 STEP 20 M x 1 F x 4...
- Page 18 STEP 21 STEP 22...
- Page 19 MAXIMUM LOADS CHARGES MAXIMALES / CARGA MAXIMA 8.8 lbs 4 kg 6.6 lbs 3 kg This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Ce meuble a été conç pour supporter les charges maximales indiquées. En excédant ces limites de charge, le meuble pourrait devenir instable, s'effondrer, et/ou causer des blessures graves.
