Pribusin RCI-100 Series Instruction Manual

Remote control signal interface
Hide thumbs Also See for RCI-100 Series:

Advertisement

Table of Contents

Instruction Manual
Model:
Function:
Communication:
Input:
Output:
Power:
Serial #:
For Technical Assistance And Questions Call
USA: (231) 788-2900 CANADA: (905) 660-5336
RCI-100-XXX
Remote Control Signal Interface
XXX=SER: RS-232/485
XXX=MDM Modem Dial-Up
XXX=FSK: Leased Line
XXX=RF9: 900 Mhz Wireless
XXX=R
F150 150 MH
:
1 "Dry" Contact and 1 Analog Input
1 Form 'C' Contact and 1 Analog Output
117VAC, 50/60Hz
24 VDC
(If special or required)
Manufacturers of Process
Controls and Instrumentation
z Wireless

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCI-100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Pribusin RCI-100 Series

Summary of Contents for Pribusin RCI-100 Series

  • Page 1 Manufacturers of Process Controls and Instrumentation Instruction Manual Model: RCI-100-XXX Function: Remote Control Signal Interface Communication: XXX=SER: RS-232/485 XXX=MDM Modem Dial-Up XXX=FSK: Leased Line XXX=RF9: 900 Mhz Wireless XXX=R F150 150 MH z Wireless Input: 1 “Dry” Contact and 1 Analog Input Output: 1 Form ‘C’...

  • Page 2: Standard Features

    Model: RCI-100-RF150 Remote Control Signal Interface Manufacturers of Process With 150MHz MURS Radio Frequency Link Controls and Instrumentation Standard Features: Bi-directional Communication using License-free 150MHz Radio Band 2 Watt selectable Radio Power Provides Reliable Communication 150MHz RF Band Does Not Require Line-Of-Sight 1 Dry Contact and 1 Analog Inputs 1 'C' Relay Contacts and 1 Analog Outputs Point-to-Point or Host-to-Multipoint Topologies...
  • Page 3 1 Contact 1 Analog 1 Analog 1 Contact 1 Contact Manufactured By: CANADA: USA: Pribusin Inc. Pribusin Inc. 743 Marquette Ave. 101 Freshway Dr. Unit 57 Muskegon, MI 49442 Concord, Ontario, L4K 1R9 www.pribusin.com Ph: (231) 788-2900 Ph: (905) 660-5336 info@pribusin.com...

  • Page 4: Restocking Policy

    Restocking Policy All product returned to Pribusin Inc. in prime condition (not damaged, scratched or defaced in any way) within seven (7) months from the original date of shipment is subject to a 50% restocking charge. All product must be accompanied by a Return Authorization number (RA number) which must be obtained from Pribusin Inc.
  • Page 5 RCI-100 Connections: The RCI-100 is the main board of an RCI-100-XXX Telemetry system. It provides the input and output signal connections as well as the power supply for the unit. A separate communications board is added to the RCI-100 to allow it to communicate with other units. This communications board may have its own configuration that is in a separate section of this manual.
  • Page 6 Inputs: The RCI-100 has one dry contact input and one 0-20mA input. The dry contact input is excited with 24VDC and will source approximately 20mA when the contact is closed. A red LED lights up when the contact input is closed. The analog input is configured as a 0-20mA input and has a 250...
  • Page 7 Outputs: The RCI-100 has one form ‘C’ relay contact output and one 0-20mA analog output. The relay contact is capable of switching 120VAC, 10A or 240VAC, 6A. An energy absorbing varistor is installed across each contact to limit switching transients. A second relay contact acts as a communications fail indicator.
  • Page 8 RCI-100 Configuration: The RCI-100 requires no configuration other than for its communication fail operation. In the event of a communications failure on the communications board, the RCI-100 can be set up to take various actions on its outputs. This may be desirable in order to place connected devices into a safe operating mode.
  • Page 9 RF150 Communication Option: The –RF150 communications option to the RCI series utilizes license-free 150-154 MHz MURS Band radio frequency transmissions to exchange the signal data between a host and its remote(s). There are two types of Topologies that can be configured: 1) Point-to-Point and 2) Host-to-Multipoint. In a Point-to-Point topology one host communicates with one remote.
  • Page 10 Radio Configuration: The radio communication board has two banks of 8-position DIP switches: SW1 and SW2. The function of these switches is slightly different for a host unit and a remote unit. We recommend powering the unit down while making any changes to the configuration. SW1- HOST REMOTE...
  • Page 11 Interrogation Interval: This parameter determines how often the radios connect to update the input and output signals. SW1-4 SW1-5 Interrogation interval 10 sec 30 sec 1 min 5 min Reply Timeout: The default reply timeout of 1 second is adequate for most applications.
  • Page 12 Host Configuration: To make an RCI-100 operate as a host unit, make sure that SW2-8 is flipped down. Next, set the number of remotes that the host is to communicate with using SW1-1, -2, -3. These switches are binary encoded as shown in the chart to the right.
  • Page 13 Remote Configuration: To make an RCI-100 operate as a REMOTE unit, make sure that SW2-8 is switched OFF. Next, set the remote address using SW1-1, -2 & -3. Each SW1-1 SW1-2 SW1-3 Remote Address remote in a system must have a unique address. Next, set the number of channels on this remote using SW2-1.
  • Page 14 Point-to-Point Communication Communication between one host and one remote is called point-to-point. Example 1: An RCI-100 Host communicating with an RCI-100 Remote RCI-100 (Host) RCI-100 (Remote) Host Channels: 1 Interval: 10 sec. Remote Channels: 1 Interval: 10 sec. Number of Remotes: 1 MURS Channel: 1 Address: 1 MURS Channel: 1...
  • Page 15 Example 4: An RCI-800 Host communicating with an RCI-800 Remote RCI-800 (Host) RCI-800 (Remote) Host Channels: 8 Interval: 10 sec. Remote Channels: 8 Interval: 10 sec. Number of Remotes: 1 MURS Channel: 1 Address: 1 MURS Channel: 1 Channels on Remotes: 8 Power: 1 Watt PHP: 1 Power: 1 Watt...
  • Page 16 Point-to-Multipoint Communication Communication between a host and more than one remote is called point-to-multipoint. Example 1: An RCI-200 Host communicating with (2) RCI-100 Remotes RCI-200 (Host) RCI-100 (Remote 1) RCI-100 (Remote 2) Host Channels: 2 Remote Channels: 1 Remote Channels: 1 Number of Remotes: 2 Address: 1 Address: 2...
  • Page 17 Example 3: An RCI-800 Host communicating with (2) RCI-400 Remotes RCI-800 (Host) RCI-400 (Remote 1) RCI-400 (Remote 2) Host Channels: 8 Remote Channels: 4 Remote Channels: 4 Number of Remotes: 2 Address: 1 Address: 2 Channels on Remotes: 4 Interrogation: 30 sec. Interrogation: 30 sec.
  • Page 18 Received Signal Strength Indicator (RSSI): The radio communications board has a signal strength indicator on the right hand edge to show the level of the signal that was received from another radio. The indicator consists of 3 LED’s labeled SS1, SS2 &...
  • Page 19 Placing them parallel to one another greatly diminishes the transmission between antennas. (YAGI-YAGI) (OMNI-OMNI) (OMNI-YAGI) We suggest you consult Pribusin Inc. or your local Sales Rep. to discuss your antenna and cable requirements. ..\Manuals\RCI-100-RF150 rev.A.doc Page 15 of 15...
