Pribusin RCI-100 Series Instruction Manual
Remote control signal interface
Hide thumbs
Also See for RCI-100 Series:
- Instruction manual (22 pages) ,
- Instruction manual (19 pages)
Advertisement
Quick Links
Instruction Manual
Model:
Function:
Communication:
Input:
Output:
Power:
Serial #:
For Technical Assistance And Questions Call
USA: (231) 788-2900 CANADA: (905) 660-5336
RCI-100-XXX
Remote Control Signal Interface
XXX=SER: RS-232/485
XXX=MDM Modem Dial-Up
XXX=FSK: Leased Line
XXX=RF9: 900 Mhz Wireless
XXX=NET: TCP/IP - Ethernet
1 "Dry" Contact and 1 Analog Input
1 Form 'C' Contact and 1 Analog Output
117VAC, 50/60Hz
24 VDC
(If special or required)
Manufacturers of Process
Controls and Instrumentation
Advertisement
Related Manuals for Pribusin RCI-100 Series
Summary of Contents for Pribusin RCI-100 Series
- Page 1 Manufacturers of Process Controls and Instrumentation Instruction Manual Model: RCI-100-XXX Function: Remote Control Signal Interface Communication: XXX=SER: RS-232/485 XXX=MDM Modem Dial-Up XXX=FSK: Leased Line XXX=RF9: 900 Mhz Wireless XXX=NET: TCP/IP - Ethernet Input: 1 “Dry” Contact and 1 Analog Input Output: 1 Form ‘C’...
-
Page 2: Restocking Policy
Restocking Policy All product returned to Pribusin Inc. in prime condition (not damaged, scratched or defaced in any way) within seven (7) months from the original date of shipment is subject to a 50% restocking charge. All product must be accompanied by a Return Authorization number (RA number) which must be obtained from Pribusin Inc. -
Page 3: Specifications
Model: RCI-100-SER Manufacturers of Process Remote Control Signal Interface Controls and Instrumentation RS232/485 Standard Features: new spec sheet Bi-directional Communication using an RS232/485 Serial Bus Link 1 Dry Contact and 1 Analog Input 1 'C' Relay Contact and 1 Analog Output No Calibration Required Microprocessor Controlled for High Accuracy Power: 117 VAC 50/60 Hz (Optional 24 VDC) - Page 4 System C (232/485COM) * Additional Signal Booster(s) required for 32+ devices (see SPB-485) Manufactured By: USA: CANADA: missing connection Pribusin Inc. Pribusin Inc. diagram and 743 Marquette Ave. 101 Freshway Dr. Unit 57 enclosure drawing Muskegon, MI 49442 Concord, Ontario, L4K 1R9 www.pribusin.com...
- Page 5 RCI-100 Connections: The RCI-100 is the main board of an RCI-100-XXX Telemetry system. It provides the input and output signal connections as well as the power supply for the unit. A separate communications board is added to the RCI-100 to allow it to communicate with other units. This communications board may have its own configuration that is in a separate section of this manual.
- Page 6 Inputs: The RCI-100 has one dry contact input and one 0-20mA input. The dry contact input are excited with 24VDC and will source approximately 20mA when the contact is closed. A red LED lights up when a contact input is closed. The analog inputs are configured as 0-20mA inputs and have a 250Ω...
- Page 7 Output Calibration & Input Testing: The outputs on the RCI-100 are factory calibrated and should not require any adjustments. To check the calibration of the outputs and relays use jumpers H1-7 & H1-8 as shown below to set them to known states. If an output should require some adjustment, the main circuit board has to be removed from the analog input/output board to gain access to the output calibration potentiometers.
- Page 8 RCI-100 Configuration: The RCI-100 requires no configuration other than for its communication fail operation. In the event of a communications failure on the communications board, the RCI-400 can be set up to take various actions on its outputs. This may be desirable in order to place connected devices into a safe operating mode.
- Page 9 100-SER pictures SERIAL Communication Option: (x3) The -SER communications option for the RCI series utilizes either an RS-232 or RS-485 link to exchange the signal data between a host and its remote(s). There are three types of Topologies that can be configured: 1) Point-to-Point, 2) Host-to-Multipoint and 3) PC-to-Multipoint In a Point-to-Point topology one host communicates with one remote.
- Page 10 SERIAL Configuration: All SERIAL configurations are done via two banks of DIP switches SW1 and SW2. The switches are located on the communications board just above the main circuit board. They are a slide switch type that slides up for ON and down for OFF if viewed straight-on with the RCI mounted upright on a wall.
- Page 11 Host Configuration: To make an RCI-100 operate as a host unit, make sure that SW1-8 is flipped to the ON position. Next, set the number of remotes that the host is to communicate with using SW1-1. These switches are binary encoded as shown in the chart below.
- Page 12 Next, set the number of channels of the host using SW1-6, -7. An RCI-100 can at most have 1 channel. This is the number of channels that will be exchanged between the host and each remote. 1 Channel SW2-3 SW2-4 Channels on Host remove blank rows An optional Reply Timeout parameter can be set on...
- Page 13 Remote Configuration: To make an RCI-100 operate as a REMOTE unit, make sure that SW1-8 is flipped to the OFF position. Next, set the remote address using SW1-1, -2, & -3. This switch is binary encoded and you will have to convert the remote address to binary first. SW1-1 SW1-2 SW1-3...
- Page 14 PC or PLC Interfacing using MODBUS ASCII: The RCI-200-SER can communicate directly to a PC or PLC using MODBUS ASCII protocol. Numerous off-the-shelf software packages have built-in MODBUS support. The following information provides the MODBUS specific parameters necessary to configure the PC/PLC software. Message Format Speed Start...
