Page 1 User Manual DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router March 2025...
Page 2: Table Of Contents
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router User Manual Contents Chapter 1. Introduction.........5 Contents and Audience............5 Conventions..............5 Document Structure............5 Chapter 2. Overview..........6 General Information............6 Specifications..............8 Product Appearance............15 Upper Panel..............15 Back Panel...............17 Delivery Package............19 Chapter 3. Installation and Connection......20 Before You Begin............20 Connecting to Mobile Device with D-Link Assistant Application....21...
Page 3 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router User Manual Statistics..............75 Network Statistics............75 DHCP..............76 Routing..............77 Clients and Sessions.............79 Port Statistics............80 Multicast Groups............81 IPsec Statistics............82 VPN Statistics............83 Connections Setup............84 WAN..............84 Creating Dynamic IPv4 or Static IPv4 WAN Connection....86 Creating Dynamic IPv6 or Static IPv6 WAN Connection....89 Creating PPPoE WAN Connection..........92...
Page 4 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router User Manual Advanced..............191 VLAN..............192 WAN Assignment............195 Using LAN Ports as WAN Ports..........195 Using WAN Port as LAN Port..........196 SNMP..............197 DNS..............200 DDNS..............202 Ports Settings............204 Redirect..............207 Routing..............208 TR-069 Client............210 Port Mirroring............212 UPnP..............214 UDPXY..............216 IGMP/MLD..............218 ALG/Passthrough............220 CoovaChilli.............222...
Page 5: Chapter 1. Introduction
Chapter 2 gives an overview of the router's hardware and software features, describes its appearance and the package contents. Chapter 3 explains how to install the router DIR-X1860 and configure a PC in order to access its web-based interface. Chapter 4 describes all pages of the web-based interface in detail.
Page 6: Chapter 2. Overview
You are able to connect the wireless router DIR-X1860 to a cable or DSL modem or to a private Ethernet line and use a high-speed Internet connection to successfully fulfill a wide range of professional tasks.
Page 7 Smart adjustment of Wi-Fi clients is useful for networks based on several D-Link access points or routers – when the smart adjustment function is configured on each of them, a client always connects to the access point (router) with the highest signal level.
Page 8: Specifications
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Specifications Hardware Processor · MT7621AT (880MHz, dual core) · 256MB, DDR3L SDRAM Flash · 128MB, NAND · Interfaces 10/100/1000BASE-T WAN port · 3 10/100/1000BASE-T LAN ports LEDs · Power ·...
Page 9 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Software Network functions · DHCP server/relay · Advanced configuration of built-in DHCP server · Stateful/Stateless mode for IPv6 address assignment, IPv6 prefix delegation · Automatic obtainment of LAN IP address (for access point/repeater/client modes) ·...
Page 10 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Wireless Module Parameters Standards · IEEE 802.11ax · IEEE 802.11ac Wave 2 · IEEE 802.11a/b/g/n Frequency range · 2400 ~ 2483.5MHz · 5150 ~ 5350MHz The frequency range depends upon the ·...
Page 11 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Wireless Module Parameters Receiver sensitivity · 802.11a (typical at PER < 10% (1000-byte PDUs) at room temperature 25 °C) -92dBm at 6Mbps -90dBm at 9Mbps -89dBm at 12Mbps -87dBm at 18Mbps...
Page 12 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Wireless Module Parameters 5GHz, HT40 -88dBm at MCS0/8 -85dBm at MCS1/9 -83dBm at MCS2/10 -80dBm at MCS3/11 -76dBm at MCS4/12 -72dBm at MCS5/13 -70dBm at MCS6/14 -68dBm at MCS7/15 ·...
Page 13 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Wireless Module Parameters 2.4GHz, HE40 -90dBm at HE0 -88dBm at HE1 -85dBm at HE2 -83dBm at HE3 -80dBm at HE4 -76dBm at HE5 -74dBm at HE6 -72dBm at HE7 -69dBm at HE8...
Page 14 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Operating Environment Power · Output: 12V DC, 1A Temperature · Operating: from 0 to 40 °C · Storage: from -20 to 65 °C Humidity · Operating: from 10% to 90% (non-condensing) ·...
Page 15: Product Appearance
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Product Appearance Upper Panel Figure 1. Upper panel view. Mode Description The router is being loaded. Solid orange The router is powered on. Solid white Power The firmware is being updated.
Page 16 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Mode Description The default WAN connection is on. Solid white The default WAN connection is off, • Solid orange there are no WAN connections • Internet created. The router is powered off, or •...
Page 17: Back Panel
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Back Panel Figure 2. Back panel view. Port Description LAN 1-3 3 Ethernet ports to connect computers or network devices. A port to connect to a cable or DSL modem or to a private Ethernet...
Page 18 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Overview User Manual Port Description A button to connect mesh network devices, set up wireless connection (the WPS function), and enable/disable the wireless network. To connect mesh network devices: with the device turned on and factory default settings or with the EasyMesh function enabled in the router settings, press the button, hold it for 2 seconds, and release.
Page 19: Delivery Package
• “Quick Installation Guide” (brochure). • The “User Manual” and “Quick Installation Guide” documents are available on D-Link website (see www.dlink.ru). Using a power supply with a different voltage rating than the one included will cause damage and void the warranty for this product.
Page 20: Chapter 3. Installation And Connection
Computer or Mobile Device Configuration of the wireless dual band gigabit router with a built-in 3-port switch DIR-X1860 (hereinafter referred to as “the router”) is performed via the built-in web-based interface. The web- based interface is available from any operating system that supports a web browser.
Page 21: Connecting To Mobile Device With D-Link Assistant Application
4. In the list of available wireless networks on your mobile device, select the wireless network DIR-X1860 (for operating in the 2.4GHz band) or DIR-X1860-5G (for operating in the 5GHz band). 5. In the opened window, enter the network key (see WPS PIN on the barcode label on the bottom panel of the device) as the password and connect to the wireless network of DIR- X1860.
Page 22: Connecting To Pc
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Connecting to PC PC with Ethernet Adapter 1. Connect an Ethernet cable between any of LAN ports located on the back panel of the router and the Ethernet port of your PC.
Page 23: Obtaining Ip Address Automatically (Os Windows 7)
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Obtaining IP Address Automatically (OS Windows 7) 1. Click the Start button and proceed to the Control Panel window. 2. Select the Network and Sharing Center section. (If the Control Panel has the category...
Page 24 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 3. In the menu located on the left part of the window, select the Change adapter settings line. Figure 4. The Network and Sharing Center window. Page 24 of 289...
Page 25 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 4. In the opened window, right-click the relevant Local Area Connection icon and select the Properties line in the menu displayed. Figure 5. The Network Connections window. Page 25 of 289...
Page 26 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 5. In the Local Area Connection Properties window, on the Networking tab, select the Internet Protocol Version 4 (TCP/IPv4) line. Click the Properties button. Figure 6. The Local Area Connection Properties window.
Page 27 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 6. Make sure that the Obtain an IP address automatically and Obtain DNS server address automatically choices of the radio buttons are selected. Click the OK button. Figure 7. The Internet Protocol Version 4 (TCP/IPv4) Properties window.
Page 28: Obtaining Ip Address Automatically (Os Windows 10)
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Obtaining IP Address Automatically (OS Windows 10) 1. Click the Start button and proceed to the Settings window. 2. Select the Network & Internet section. Figure 8. The Windows Settings window.
Page 29 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 3. In the Change your network settings section, select the Change adapter options line. Figure 9. The Network & Internet window. Page 29 of 289...
Page 30 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 4. In the opened window, right-click the relevant Local Area Connection icon and select the Properties line in the menu displayed. Figure 10. The Network Connections window. 5. In the Local Area Connection Properties window, on the Networking tab, select the Internet Protocol Version 4 (TCP/IPv4) line.
Page 31 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 6. Make sure that the Obtain an IP address automatically and Obtain DNS server address automatically choices of the radio buttons are selected. Click the OK button. Figure 12. The Internet Protocol Version 4 (TCP/IPv4) Properties window.
Page 32: Pc With Wi-Fi Adapter
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual PC with Wi-Fi Adapter 1. Connect the power cord to the power connector port on the back panel of the router, then plug the power adapter into an electrical outlet or power strip.
Page 33: Obtaining Ip Address Automatically And Connecting To Wireless Network (Os Windows 7)
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Obtaining Address Automatically Connecting to Wireless Network (OS Windows 7) 1. Click the Start button and proceed to the Control Panel window. 2. Select the Network and Sharing Center section. (If the Control Panel has the category...
Page 34 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 6. Make sure that the Obtain an IP address automatically and Obtain DNS server address automatically choices of the radio buttons are selected. Click the OK button. Figure 14. The Internet Protocol Version 4 (TCP/IPv4) Properties window.
Page 35 User Manual 9. In the opened Wireless Network Connection window, select the wireless network DIR-X1860 (for operating in the 2.4GHz band) or DIR-X1860-5G (for operating in the 5GHz band) and click the Connect button. Figure 16. The list of available networks.
Page 36: Obtaining Ip Address Automatically And Connecting To Wireless Network (Os Windows 10)
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Obtaining Address Automatically Connecting to Wireless Network (OS Windows 10) 1. Click the Start button and proceed to the Settings window. 2. Select the Network & Internet section. Figure 17. The Windows Settings window.
Page 37 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual 6. Make sure that the Obtain an IP address automatically and Obtain DNS server address automatically choices of the radio buttons are selected. Click the OK button. Figure 18. The Internet Protocol Version 4 (TCP/IPv4) Properties window.
Page 38 User Manual 9. In the opened Wireless Network Connection window, select the wireless network DIR-X1860 (for operating in the 2.4GHz band) or DIR-X1860-5G (for operating in the 5GHz band) and click the Connect button. Figure 20. The list of available networks.
Page 39: Connecting To Web-Based Interface
Enter key. Also you can enter the IP address of the device (by default, 192.168.0.1). Figure 22. Connecting to the web-based interface of the DIR-X1860 device. If the error “ The page cannot be displayed ” (or “ Unable to display the page ”/“ Could not connect to remote server ”) occurs upon connecting to the web-based interface of the router,...
Page 40 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual If you configured the device previously, after access to the web-based interface the login page opens. Enter the username (admin) in the Username field and the password you specified in the Password field, then click the LOGIN button.
Page 41: Web-Based Interface Structure
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Web-based Interface Structure Summary Page On the Summary page, detailed information on the device state is displayed. Figure 25. The summary page. Page 41 of 289...
Page 42 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual The Device Information section displays the model and hardware version of the router, the firmware version, and other data. To contact the technical support group (to send an e-mail), left-click the support e-mail address.
Page 43: Home Page
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Home Page The Home page displays links to the most frequently used pages with device's settings. Figure 26. The Home page. Other settings of the router are available in the menu in the left part of the page.
Page 44: Menu Sections
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Menu Sections To configure the router use the menu in the left part of the page. In the Initial Configuration section you can run the Initial Configuration Wizard. The Wizard...
Page 45: Notifications
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Installation and Connection User Manual Notifications The router's web-based interface displays notifications in the top right part of the page. Figure 27. The web-based interface notifications. Click the icon displaying the number of notifications to view the complete list and click the relevant button.
Page 46: Configuring Via Web-Based Interface
If you perform initial configuration of the router via Wi-Fi connection, please make sure that you are connected to the wireless network DIR-X1860 (for operating in the 2.4GHz band) or DIR- X1860-5G (for operating in the 5GHz band) and click the NEXT button.
Page 47 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual On the opened page, click YES in order to leave the current language of the web-based interface or click NO to select the other language. Figure 31. Selecting a language.
Page 48: Selecting Operation Mode
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Selecting Operation Mode Select the needed operation mode and click the NEXT button. Router In order to connect your device to a wired ISP, on the Device mode page, from the Connection method list, select the Autonomous value.
Page 49 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In order to connect your device to a wireless ISP (WISP), on the Device mode page, from the Connection method list, select the Autonomous value. Then from the Work mode list select the WISP Repeater value.
Page 50: Access Point Or Repeater
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Access Point or Repeater In order to connect your device to a wired router for adding a wireless network to the existing local network, on the Device mode page, from the Connection method list, select the Autonomous value.
Page 51 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In order to connect your device to a wireless router for extending the range of the existing wireless network, on the Device mode page, from the Connection method list, select the Autonomous value.
Page 52: Mesh Network Main Device (Controller)
User Manual Mesh Network Main Device (Controller) In order to configure DIR-X1860 as a main device of your mesh network, from the Connection method list, select the EasyMesh value. Then from the Device role list, select the Controller value. From the Backhaul list, select the band where your mesh network operates. Also you can connect devices into the mesh network using an Ethernet cable by connecting it to LAN ports of the main and subordinate device or two subordinate devices.
Page 53 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In order to connect your main device to a wired ISP, from the Work mode list, select the Router value. In this mode you can configure a WAN connection, set your own settings for the wireless network in the 2.4GHz and 5GHz bands, configure LAN ports to connect an STB or VoIP phone,...
Page 54 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In order to connect your main device to a wireless ISP (WISP), from the Work mode list, select the WISP Repeater value. In this mode you can connect your device to another access point, configure a WAN connection, set your own settings for the wireless network in the 2.4GHz and...
Page 55: Mesh Network Subordinate Device (Agent)
User Manual Mesh Network Subordinate Device (Agent) In order to configure DIR-X1860 as a subordinate device of your mesh network, from the Connection method list, select the EasyMesh value. Then from the Device role list, select the Agent value. From the Backhaul list, select the band where your main device (in the Controller role) operates.
Page 56: Changing Lan Ipv4 Address
If you want to manually assign the LAN IPv4 address for DIR-X1860, do not select the Automatic obtainment of IPv4 address checkbox and fill in the IP address, Subnet mask, DNS IP address, Hostname fields and, if needed, the Gateway IP address field.
Page 57: Wi-Fi Client
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Wi-Fi Client This configuration step is available for the WISP Repeater and Repeater modes. 1. On the Wi-Fi Сlient page, click the WIRELESS NETWORKS button and select the network to which you want to connect in the opened window.
Page 58 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The number of the key (from first to fourth) which will be used for Default key ID WEP encryption. Encryption key WEP as Select the checkbox to set a hexadecimal number as a key for encryption.
Page 59: Configuring Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Configuring WAN Connection This configuration step is available for the Router and WISP Repeater modes. You should configure your WAN connection in accordance with data provided by your Internet service provider (ISP).
Page 60: Static Ipv4 Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Static IPv4 Connection Figure 42. The page for configuring Static IPv4 WAN connection. Fill in the following fields: IP address, Subnet mask, Gateway IP address, and DNS IP address.
Page 61: Static Ipv6 Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Static IPv6 Connection Figure 43. The page for configuring Static IPv6 WAN connection. Fill in the following fields: IP address, Prefix, Gateway IP address, and DNS IP address.
Page 62: Pppoe, Ipv6 Pppoe, Pppoe Dual Stack, Pppoe + Dynamic Ip (Pppoe Dual Access) Connections
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual PPPoE, IPv6 PPPoE, PPPoE Dual Stack, PPPoE + Dynamic IP (PPPoE Dual Access) Connections Figure 44. The page for configuring PPPoE WAN connection. In the Username field enter the login and in the Password field enter the password provided your ISP.
Page 63: Pppoe + Static Ip (Pppoe Dual Access) Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual PPPoE + Static IP (PPPoE Dual Access) Connection Figure 45. The page for configuring PPPoE + Static IP (PPPoE Dual Access) WAN connection. In the Username field enter the login and in the Password field enter the password provided Click the Show icon ( your ISP.
Page 64: Pptp + Dynamic Ip Or L2Tp + Dynamic Ip Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual PPTP + Dynamic IP or L2TP + Dynamic IP Connection Figure 46. The page for configuring PPTP + Dynamic IP WAN connection. In the Username field enter the login and in the Password field enter the password provided by your ISP.
Page 65: Pptp + Static Ip Or L2Tp + Static Ip Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual PPTP + Static IP or L2TP + Static IP Connection Figure 47. The page for configuring PPTP + Static IP WAN connection. In the Username field enter the login and in the Password field enter the password provided by your ISP.
Page 66: Configuring Wireless Network
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Configuring Wireless Network This configuration step is available for the Router, Access point, WISP Repeater, and Repeater modes. 1. On the Wireless Network 2.4 GHz page, in the Network name field, specify your own name for the wireless network in the 2.4GHz band or leave the value suggested by the...
Page 67 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual 5. If you want to create an additional wireless network isolated from your LAN in the 2.4GHz band, select the Enable guest network checkbox (available for the Router and WISP Repeater modes only).
Page 68: Configuring Lan Ports For Iptv/Voip
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Configuring LAN Ports for IPTV/VoIP This configuration step is available for the Router mode. On the IPTV page, select the Is an STB connected to the device checkbox.
Page 69 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual On the VoIP page, select the Is an IP phone connected to the device checkbox. Figure 51. The page for selecting a LAN port to connect a VoIP phone.
Page 70: Changing Web-Based Interface Password
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Changing Web-based Interface Password On this page, you should change the default administrator password. To do this, enter a new password in the User’s interface password and Password confirmation fields. You may set any password except admin.
Page 71 If problems of connection have not been solved, contact the technical support of your ISP (as a rule, the technical support phone is provided with the agreement) or the D-Link technical support (the phone number will be displayed on the page after several attempts of checking the connection).
Page 72: Connection Of Multimedia Devices
The Multimedia Devices Connection Wizard helps to configure LAN ports or available wireless interfaces of the router for connecting additional devices, for example, an IPTV set-top box or IP phone. Contact your ISP to clarify if you need to configure DIR-X1860 in order to use these devices.
Page 73 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual If you need to configure a connection via VLAN, click the ADVANCED MODE button. Figure 55. The Multimedia Devices Connection Wizard. The advanced mode. In the WAN section, click the Add icon Figure 56.
Page 74 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To deselect the port or wireless interface in the simplified mode, left-click the selected element (the frame will disappear) and click the APPLY button. To deselect the port or wireless interface in the advanced mode, select the No value from the Bridged with drop-down list of the element corresponding to the needed LAN port or interface.
Page 75: Statistics
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Statistics The pages of this section display data on the current state of the router: network statistics • IP addresses leased by the DHCP server • the routing rules and routing tables •...
Page 76: Dhcp
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual DHCP The Statistics / DHCP page displays the information on devices that have been identified by hostnames and MAC addresses and have got IP addresses from the DHCP server of the router.
Page 77: Routing
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Routing The Statistics / Routing page displays the routing rules and routing tables. Figure 59. The Statistics / Routing page. The Rules section displays routing rules, their corresponding routing tables, incoming and outgoing interfaces, priority levels, and other data.
Page 78 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 60. The routing table page. The opened page displays the information on routes in the selected routing table. The table contains destination IP addresses, gateways, subnet masks, and other data.
Page 79: Clients And Sessions
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Clients and Sessions On the Statistics / Clients and Sessions page, you can view the list of devices connected to the local network of the router and information on current sessions of each device.
Page 80: Port Statistics
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Port Statistics On the Statistics / Port Statistics page, you can view statistics for traffic passing through ports of the router. The information shown on the page can be used for diagnosing connection problems.
Page 81: Multicast Groups
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Multicast Groups The Statistics / Multicast Groups page displays addresses of active multicast groups (including IPTV channels and groups for transferring service information) to which the device is subscribed, and the interface through which the device is subscribed.
Page 82: Ipsec Statistics
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual IPsec Statistics On the Statistics / IPsec Statistics page, you can view statistics for IPsec tunnels of the router. For each tunnel the following data are displayed: name and state (when the connection is on, its...
Page 83: Vpn Statistics
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual VPN Statistics On the Statistics / VPN Statistics page, you can view the list of clients connected to the PPTP or L2TP server of the router. Figure 65. The Statistics / VPN Statistics page.
Page 84: Connections Setup
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Connections Setup In this menu you can configure basic parameters of the router's local area network and configure connection to the Internet (a WAN connection). On the Connections Setup / WAN page, you can create and edit connections used by the router.
Page 85 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 67. The Connections Setup / WAN page. The advanced mode. To create a new connection, click the ADD button ( ) in the Connections List section. Upon that the connection creation page opens.
Page 86: Creating Dynamic Ipv4 Or Static Ipv4 Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Creating Dynamic IPv4 or Static IPv4 WAN Connection On the connection creation page, in the General Settings section, select the relevant value from the Connection type drop-down list and specify the needed values.
Page 87 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 69. The page for creating a new Static IPv4 connection. The Ethernet section. Parameter Description Ethernet A MAC address assigned to the interface. This parameter is mandatory if your ISP uses MAC address binding.
Page 88: Subnet Mask
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 70. The page for creating a new Static IPv4 connection. The IPv4 section. Parameter Description IPv4 For Static IPv4 type IP address Enter an IP address for this WAN connection.
Page 89: Creating Dynamic Ipv6 Or Static Ipv6 Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Creating Dynamic IPv6 or Static IPv6 WAN Connection On the connection creation page, in the General Settings section, select the relevant value from the Connection type drop-down list and specify the needed values.
Page 90 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 72. The page for creating a new Static IPv6 connection. The Ethernet section. Parameter Description Ethernet A MAC address assigned to the interface. This parameter is mandatory if your ISP uses MAC address binding.
Page 91 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description IPv6 For Static IPv6 type IPv6 address Enter an IPv6 address for this WAN connection. The length of the subnet prefix. The value 64 is used usually.
Page 92: Creating Pppoe Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Creating PPPoE WAN Connection On the connection creation page, in the General Settings section, select the relevant value from the Connection type drop-down list and specify the needed values.
Page 93 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 75. The page for creating a new PPPoE connection. The Ethernet section. Parameter Description Ethernet A MAC address assigned to the interface. This parameter is mandatory if your ISP uses MAC address binding. In the field, enter the MAC address registered by your ISP upon concluding the agreement.
Page 94 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 76. The page for creating a new PPPoE connection. The PPP section. Parameter Description Move the switch to the right if you don't need to enter a username Without authorization and password to access the Internet.
Page 95: Authentication Protocol
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Select a method of MPPE encryption. No encryption: MPPE encryption is not applied. • MPPE 40 128 bit: MPPE encryption with a 40-bit or 128-bit •...
Page 96 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 77. The page for creating a new PPPoE connection. The IPv4 section. Parameter Description Obtain DNS server Move the switch to the right to configure automatic assignment of addresses DNS server addresses.
Page 97: Creating Pptp, L2Tp, L2Tp Dual Stack, Or L2Tp Over Ipsec Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Creating PPTP, L2TP, L2TP Dual Stack, or L2TP over IPsec WAN Connection On the connection creation page, in the General Settings section, select the relevant value from the Connection type drop-down list and specify the needed values.
Page 98 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description For the PPTP and L2TP types only. Move the switch to the right to allow using RIP for this connection. Figure 79. The page for creating a new PPTP connection. The PPP section.
Page 99 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The maximum size of units transmitted by the interface. Select a method of MPPE encryption. No encryption: MPPE encryption is not applied. • MPPE 40 128 bit: MPPE encryption with a 40-bit or 128- •...
Page 100 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 80. The page for creating a new PPTP connection. The IPv4 section. Parameter Description Obtain DNS server Move the switch to the right to configure automatic assignment of addresses DNS server addresses.
Page 101 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description From the drop-down list, select the mode of a prefix request from a delegating DHCPv6 server to configure a range of IPv6 addresses for the local network.
Page 102 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description IPsec (for the L2TP over IPsec type) A key for mutual authentication of the parties. Click the Show icon Pre-shared key ) to display the entered key.
Page 103 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual If you want to use this WAN connection to access the Internet, select the to the Internet choice of the radio button. Then select an existing connection which will be used to access the PPTP/L2TP server and click the CONTINUE button;...
Page 104: Creating Pppoe Ipv6 Or Pppoe Dual Stack Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Creating PPPoE IPv6 or PPPoE Dual Stack WAN Connection On the connection creation page, in the General Settings section, select the relevant value from the Connection type drop-down list and specify the needed values.
Page 105 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description If the switch is moved to the right, the router responds to ping Ping requests from the external network through this connection. For security reasons, it is recommended to disable this function.
Page 106 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 85. The page for creating a new PPPoE IPv6 connection. The PPP section. Parameter Description Move the switch to the right if you don't need to enter a username Without authorization and password to access the Internet.
Page 107 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Select a method of MPPE encryption. No encryption: MPPE encryption is not applied. • MPPE 40 128 bit: MPPE encryption with a 40-bit or 128-bit •...
Page 108 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 86. The page for creating a new PPPoE Dual Stack connection. The IPv4 section. Parameter Description IPv4 (for the PPPoE Dual Stack type) Obtain DNS server...
Page 109 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description From the drop-down list, select the mode of a prefix request from a delegating DHCPv6 server to configure a range of IPv6 addresses for the local network.
Page 110: Creating 6In4 Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Creating 6in4 WAN Connection Before configuring the connection, please first register on a tunnel broker’s web site. On the connection creation page, in the General Settings section, select the relevant value from the Connection type drop-down list and specify the needed values.
Page 111 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Enter the address of the routed IPv6 subnet (without specifying the Routed IPv6 network prefix length) provided by the tunnel broker. Move the switch to the right to set the maximum size of units transmitted by the interface automatically.
Page 112: Creating 6To4 Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Creating 6to4 WAN Connection On the connection creation page, in the General Settings section, select the relevant value from the Connection type drop-down list and specify the needed values.
Page 113: Creating 6Rd Wan Connection
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Creating 6rd WAN Connection On the connection creation page, in the General Settings section, select the relevant value from the Connection type drop-down list and specify the needed values.
Page 114 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The number of bits in the IPv4 address of the router in the 6rd IPv4 mask length domain. Move the switch to the right to exchange traffic between clients through the main host of the network in the 6rd domain.
Page 115: Lan
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To configure the router's local interface, go to the Connections Setup / LAN page. IPv4 Go to the IPv4 tab to change the IPv4 address of the router, configure the built-in DHCP server, specify MAC address and IPv4 address pairs, or add own DNS records.
Page 116 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Available if the Access point or Repeater mode was selected in the Initial Configuration Wizard. Gateway IP address The gateway IPv4 address which is used by the router to connect to the Internet (e.g., for synchronizing the system time with an NTP...
Page 117 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Dynamic IP Addresses An operating mode of the router's DHCP server. Disable: The router's DHCP server is disabled, clients' IP • addresses are assigned manually.
Page 118 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The IPv4 address of the external DHCP server which assigns IPv4 addresses to the router's clients. To specify several IPv4 addresses, click the ADD button, and in the External DHCP server IP line displayed, enter an IPv4 address.
Page 119 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the opened window, you can specify the following parameters: Parameter Description Supported DHCP From the drop-down list, select an option which you want to options configure.
Page 120 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual If needed, you can add your own address resource records. To do this, click the ADD button ( in the Hosts section (available if in the Dynamic IP Addresses section the DHCP value is selected from the Mode of IPv4 address assignment drop-down list).
Page 121: Ipv6
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual IPv6 Go to the IPv6 tab to change or add the IPv6 address of the router, configure IPv6 addresses assignment settings, specify MAC address and IPv6 address pairs, or add own DNS records.
Page 122 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Available if the Access point or Repeater mode was selected in the Initial Configuration Wizard. If needed, specify a DNS server IPv6 address. If you want to specify several DNS servers, click the ADD button, and in the line displayed, enter the IPv6 address.
Page 123 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Dynamic IP Addresses Select the needed value from the drop-down list. Disable: Clients' IPv6 addresses are assigned manually. • Stateless: Clients themselves configure IPv6 addresses •...
Page 124 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the Static IP Addresses section, you can specify MAC address and IPv6 address pairs (set a fixed IPv6 address in the local area network for a device with a certain MAC address). The router...
Page 125 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To remove a record, in the Hosts section, select the checkbox located to the left of the relevant line in the table and click the DELETE button ( After completing the work with records, click the APPLY button.
Page 126: Wan Failover
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual WAN Failover On the Connections Setup / WAN Failover page, you can enable the WAN backup function, which provides you with uninterrupted access to the Internet. When your main connection breaks down, the router activates the backup connection;...
Page 127 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the Connections IPv4 section, the existing IPv4 connections are displayed in order of their priority. The first connection on the list serves as the main connection, the others are backup connections.
Page 128 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the Check with ping section, specify settings of checking the connection using ICMP ping mechanism. Parameter Description Check with ping A time period (in seconds) between regular checks of the hosts’...
Page 129: Traffic Balancing
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Traffic Balancing On the Connections Setup / Traffic Balancing page, you can enable the traffic balancing function. This function enables equal load balancing on the router and increases maximum bandwidth of your Internet connection while using several WAN connections (for example, if access to the Internet is provided by several ISPs).
Page 130 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the opened window, specify the needed parameters. Parameter Description From the drop-down list, select a WAN connection to which traffic Connection balancing will be applied. Select a value from the drop-down list.
Page 131: Vpn
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In this menu you can configure VPN connections based on IPsec/GRE/EoGRE/IPIP/EoIP protocols and create a PPTP or L2TP server and accounts for access to it. IPsec On the VPN / IPsec page, you can configure VPN tunnels based on IPsec protocol.
Page 132: General Settings
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To create a new tunnel, click the ADD button ( ) in the Tunnels section. The values selected from the IP version , Mode , IKE version lists and the values of the Pre-shared key field and elements in the The First Phase and The Second Phase sections should be the same for both parties of the tunnel.
Page 133 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Name A name for the tunnel for easier identification. IP version An IP version. Move the switch to the right to allow a remote host with any public IP address to connect to the router via IPsec protocol.
Page 134 4500 is used. The NAT Traversal function allows VPN traffic to pass through the NAT-enabled device. DIR-X1860 allows to forcibly encapsulate VPN traffic in UDP packets for passing through a remote device regardless of whether it supports address translation.
Page 135 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Using DPD protocol (Dead Peer Detection) allows to check the status of the remote host in the tunnel: if encrypted packets exchange between the router and the remote host breaks down, the router starts sending DPD requests to the remote host.
Page 136 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To specify encryption algorithms for the first and second phases of the IPsec tunnel, click the ADD button ( ) in the The First Phase and The Second Phase sections correspondingly. You can specify several combinations of encryption algorithms for each phase of the IPsec tunnel.
Page 137 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Hashing algorithm Select a hashing algorithm from the drop-down list. Size of hash The length of the hash in bits. Hashing mode Select a hashing mode from the drop-down list.
Page 138 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 108. The window for adding a tunneled network. In the opened window, you can specify the following parameters: Parameter Description A local subnet IP address and mask.
Page 139 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To edit fields in the Tunneled Networks section, select the relevant line in the table. In the opened window, change the needed parameters and click the SAVE button.
Page 140: Gre
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual On the VPN / GRE page, you can configure VPN tunnels based on GRE protocol. GRE (Generic Routing Encapsulation) is a protocol for tunneling network packets, which enables you to create unprotected VPN tunnels.
Page 141 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual You can specify the following parameters: Parameter Description Tunnel settings Move the switch to the right to enable the GRE tunnel. Enable Move the switch to the left to disable the GRE tunnel.
Page 142: Ipip
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual IPIP On the VPN / IPIP page, you can configure VPN tunnels based on IPIP protocol. IPIP (IP Encapsulation within IP) is a protocol for IP-tunneling network packets, which enables you to create unprotected VPN tunnels, encapsulating IP packets within other IP packets.
Page 143 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual You can specify the following parameters: Parameter Description Tunnel settings Move the switch to the right to enable the IPIP tunnel. Enable Move the switch to the left to disable the IPIP tunnel.
Page 144: Pptp/L2Tp Servers
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual PPTP/L2TP Servers On the VPN / PPTP/L2TP Servers page, you can create PPTP or L2TP VPN servers. To configure a PPTP or L2TP server, go to the relevant tab.
Page 145 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 114. The page for adding a PPTP server. You can specify the following parameters: Parameter Description PPTP Server / L2TP Server Move the switch to the right to enable the server.
Page 146 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description VPN network Server local IP address The IP address of the VPN server. Start client IP The start IP address of the address range for VPN server’s clients.
Page 147: Enable Authentication
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Authentication Move the switch to the right to enable authentication. Upon that the Enable authentication Multiple sessions, CHAP, MSCHAP, MSCHAPv2, and PAP lists are displayed on the page.
Page 148 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Advanced Settings Available for a PPTP server. Maximum number of The maximum number of devices allowed to connect to the PPTP connections server. Available for an L2TP server.
Page 149 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The mode of IP address assignment. Select a value from the drop- down list. Auto: The IP address is assigned to the user automatically. •...
Page 150: Vpn Users
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual VPN Users On the VPN / VPN Users page, you can create user accounts to provide authorized access to a PPTP or L2TP server. Figure 116. The VPN / VPN Users page.
Page 151: Eogre
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual EoGRE On the VPN / EoGRE page, you can configure VPN tunnels based on EoGRE technology. EoGRE (Ethernet over GRE) technology allows transferring traffic through VPN tunnels in heterogeneous networks, encapsulating Ethernet frames with the help of GRE protocol and transferring them over a network which uses a network protocol of another level.
Page 152 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Move the switch to the right to use the EoGRE tunnel as an interface for creating a WAN connection. For further configuration, you need to create a VLAN which will include the EoGRE interface (see the...
Page 153: Eoip
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual EoIP On the VPN / EoIP page, you can configure VPN tunnels based on EoIP technology. EoIP (Ethernet over IP) technology allows creating an Ethernet tunnel between two routers via connections which can transmit IP packets (e.g., IPIP, PPTP connections).
Page 154 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual You can specify the following parameters: Parameter Description Move the switch to the right to enable the EoIP tunnel. Enable Move the switch to the left to disable the EoIP tunnel.
Page 155 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description A number of failed attempts to check the state of the tunnel on the Attempts other end after which the tunnel is disabled. By default, the value 5 is specified.
Page 156: Wi-Fi
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Wi-Fi In this menu you can specify all needed settings for your wireless network. Basic Settings In the Wi-Fi / Basic Settings section, you can change basic parameters for the wireless interface of the router and configure the basic and additional wireless networks.
Page 157: Enable Wireless
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the Basic Settings section, the following parameters are available: Parameter Description To enable Wi-Fi connection, move the switch to the right. To disable Wi-Fi connection, move the switch to the left.
Page 158 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The wireless channel number. To select a channel manually, left-click; in the opened window, select a channel and click the SAVE button. The action is available...
Page 159: Band Steering
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 123. Creating a wireless network. Parameter Description Wi-Fi Network The Band Steering technology allows wireless clients to choose the frequency band with the best signal strength.
Page 160 Max associated clients of connected clients. If the wireless network broadcasting is disabled, devices cannot connect to the wireless network. Upon that DIR-X1860 can connect to another access point as a wireless client. To enable/disable broadcasting on a schedule, click the Set schedule icon ( ).
Page 161 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Move the switch to the right to forbid wireless clients of this Clients isolation wireless network to communicate to each other. This function is available for the additional network. Move the...
Page 162 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Authentication type Description A mixed type of authentication. When this value is selected, devices WPA-PSK/WPA2-PSK using the WPA-PSK authentication type and devices using the mixed WPA2-PSK authentication type can connect to the wireless network.
Page 163 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description For Open authentication type only. To activate WEP encryption, move the switch to the right. Upon that Enable encryption WEP the Default key ID drop-down list, the Encryption key WEP as HEX switch, and four Encryption key fields are displayed on the page.
Page 164 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The time period (in seconds), at the end of which a new key for Group key update WPA encryption is generated. When the value 0 is specified for this interval field, the key is not renewed.
Page 165 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To edit the basic or additional wireless network, left-click the relevant line in the table. On the opened page, change the needed parameters and click the APPLY button.
Page 166: Client Management
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Client Management On the Wi-Fi / Client Management page, you can view the list of wireless clients connected to the router. Figure 128. The page for managing the wireless clients.
Page 167: Wps
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual On the Wi-Fi / WPS page, you can enable the function for configuration of the WLAN and select a method for connection to the WLAN. The WPS function helps to configure the protected wireless network automatically. Devices connecting to the wireless network via the WPS function must support the WPS function.
Page 168 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To activate the WPS function via the web-based interface, on the tab of the relevant band, click the ENABLE WPS button. When the WPS function is enabled, the Information section is available on the page.
Page 169: Using Wps Function Via Web-Based Interface
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Using WPS Function via Web-based Interface To connect to the basic wireless network via the PIN method of the WPS function, follow the next steps: 1. Click the ENABLE WPS button.
Page 170: Using Wps Function Without Web-Based Interface
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Using WPS Function without Web-based Interface You can use the WPS function without accessing the web-based interface of the router. To do this, you need to configure the following router's settings: 1.
Page 171: Wmm
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual On the Wi-Fi / WMM page, you can enable the Wi-Fi Multimedia function. To configure the 2.4GHz band or 5GHz band, go to the relevant tab. The WMM function implements the QoS features for Wi-Fi networks. It helps to improve the quality of data transfer over Wi-Fi networks by prioritizing different types of traffic.
Page 172 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameters of the Access Categories are defined for both the router itself (in the Access Point section) and wireless devices connected to it (in the Station section).
Page 173 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Acknowledgment. Answering response requests while transmitting. Displayed only in the Access Point section. If the switch is moved to the left, the router answers requests.
Page 174: Client
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Client On the Wi-Fi / Client page, you can configure the router as a client to connect to a wireless access point or to a WISP. To configure the 2.4GHz band or 5GHz band, go to the relevant tab.
Page 175 When you have configured the parameters, click the APPLY button. When connecting to a wireless access point, the wireless channel of DIR-X1860 will switch to the channel of the access point to which you have connected. Page 175 of 289...
Page 176 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In addition, the Connection Information section in which you can view the connection status and the network basic parameters is displayed. If you want to connect to the WISP network, after configuring the device as a client, you need to create a WAN connection with relevant parameters for the WiFiClient_2GHz interface in the 2.4GHz band or for the WiFiClient_5GHz interface in the 5GHz band.
Page 177: Additional
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Additional On page of the Wi-Fi / Additional section, you can define additional parameters for the WLAN of the router. To configure the 2.4GHz band or 5GHz band, go to the relevant tab.
Page 178 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual The following fields are available on the page: Parameter Description The channel bandwidth for devices operating on modern standards. Bandwidth When the Auto value is selected, router automatically chooses the most suitable channel bandwidth for these clients.
Page 179 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Available on the 2.4 GHz tab. TX Beamforming is the signal processing/directing technology Enable TX which helps to support a high enough transfer rate in the areas with Beamforming difficult conditions for the signal propagation.
Page 180: Airtime Fairness
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Airtime Fairness is a technology which helps to equally distribute data transmission time between all wireless network clients operating on different standards. Upon that clients operating on modern standards transmit more data during the same period of time.
Page 181 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The number of beacon frames between sending DTIM messages DTIM period (messages notifying on broadcast or multicast transmission). The time interval (in seconds) between keep alive checks of wireless Station Keep Alive devices from your WLAN.
Page 182: Mac Filter
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual MAC Filter On the Wi-Fi / MAC Filter page, you can define a set of MAC addresses of devices which will be allowed to access the WLAN, or define MAC addresses of devices which will not be allowed to access the WLAN.
Page 183: Frequency Band
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 135. The window for adding a rule for the MAC filter. You can specify the following parameters: Parameter Description Frequency band From the drop-down list, select a band of the wireless network.
Page 184 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual After creating the rules you need to configure the filtering modes. To open the basic or additional wireless network for the devices which MAC addresses are specified on this page and to close the wireless network for all other devices, in the section corresponding to the band (2.4 GHz or 5 GHz), left-click the line of the wireless network.
Page 185: Easymesh
To activate the EasyMesh function, in the Settings section, move the Enable switch to the right. 7 At present, you can connect up to 6 D-Link devices with EasyMesh support: 1 in the Controller role and 5 in the Agent role.
Page 186: Connecting Subordinate Devices With Ethernet Cable
(2.4GHz or 5GHz) for all devices of the configured network. When you have configured the parameters, click the APPLY button. To configure DIR-X1860 as the main or subordinate device of the mesh network, go to the Initial Configuration section (see the Initial Configuration Wizard section, page 46), from the Connection method list, select the EasyMesh value.
Page 187: Connecting Subordinate Devices Via Web-Based Interface
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Do not press the button on more than two devices simultaneously. When Agent devices with factory defaults connect to the mesh network via the hardware button, the 5 GHz backhaul band should be selected on the main device.
Page 188 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To view detailed data on a mesh network device, click the line corresponding to this device in the Network topology section. Figure 137. The device information page.
Page 189: Roaming
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Roaming On the Wi-Fi / Roaming page, you can enable the function of smart adjustment of Wi-Fi clients. This function is designed for wireless networks based on several access points or routers. If the function is enabled for all access points (routers) which establish a wireless network, then wireless clients will always connect to the device with the highest signal level.
Page 190 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To enable the function, click the ENABLE button. Upon that the following settings are available on the page. Parameter Description The number of the port used for data exchange between access Port points (routers).
Page 191: Advanced
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Advanced In this menu you can configure advanced settings of the router: create or edit VLANs • use LAN ports of the router as additional WAN ports and also use the WAN port as a LAN •...
Page 192: Vlan
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual VLAN On the Advanced / VLAN page, you can edit existing and create new virtual networks (VLAN), e.g., for distinguishing traffic or specifying additional WAN interfaces. By default, 2 VLANs are created in the router's system.
Page 193 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To create a new VLAN, click the ADD button ( Figure 140. The page for adding a VLAN. You can specify the following parameters: Parameter Description Name A name for the VLAN for easier identification.
Page 194: Wireless Interfaces
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Select a type for each port included in the VLAN. Untagged: Untagged traffic will be transmitted through the • specified port. Tagged: Tagged traffic will be transmitted through the •...
Page 195: Wan Assignment
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual WAN Assignment On the Advanced / WAN Assignment page, you can use LAN ports of the router as additional WAN ports and also use the WAN port as a LAN port.
Page 196: Using Wan Port As Lan Port
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Using WAN Port as LAN Port To configure the WAN port of the router to be used as a LAN port, follow the next steps: 1. On the Connections Setup / WAN page, remove the WAN connection assigned to the network interface of the VLAN which includes the WAN port (see the WAN section, page 84).
Page 197: Snmp
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual SNMP On the Advanced / SNMP page, you can enable and configure the SNMP agent of the router. The SNMP agent is a service which sends data on the state and settings of the device where is it enabled to the SNMP manager (the network management system of your ISP or system administrator).
Page 198: Authentication Password
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual If needed, specify an IP address of the remote subnet for which access to the SNMP agent of the router will be allowed. To do this, in the Remote subnets section, click the ADD button and enter the address of the subnet in the line displayed.
Page 199 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Specify an encryption key for data exchange between the SNMP agent and SNMP manager. The field is displayed if the DES or Encryption key AES value is selected from the Encryption protocol drop-down list.
Page 200: Dns
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual On the Advanced / DNS page, you can add DNS servers to the system. Figure 144. The Advanced / DNS page. DNS servers are used to determine the IP address from the name of a server in Intranets or the Internet (as a rule, they are specified by an ISP or assigned by a network administrator).
Page 201 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual You can specify the addresses of DNS servers manually on this page or configure the router to obtain DNS servers addresses automatically from your ISP upon installing a connection. Also here you can specify addresses of reserve DNS servers which the router can use if the addresses specified manually or obtained automatically are unavailable.
Page 202: Ddns
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual DDNS On the Advanced / DDNS page, you can define parameters of the DDNS service, which allows associating a domain name with dynamic IP addresses. Figure 145. The Advanced / DDNS page.
Page 203 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual On the opened page, you can specify the following parameters: Parameter Description Move the switch to the right to enable DDNS. Enable Move the switch to the left to disable DDNS.
Page 204: Ports Settings
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Ports Settings On the Advanced / Ports Settings page, you can configure or disable autonegotiation of speed and duplex mode or manually configure speed and duplex mode for each Ethernet port of the router.
Page 205 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 148. The window for changing the settings of the router's port. In the opened window, specify the needed parameters: Parameter Description Select the Auto value to enable autonegotiation.
Page 206 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Autonegotiation Modes To enable the needed data transfer modes, move relevant switches to the right. Flow control Move the switch to the right to enable the flow control function for the port.
Page 207: Redirect
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Redirect On the Advanced / Redirect page, you can enable notifications on the reason of the Internet connection failure. Notifications will be displayed in the browser window when a user is attempting to open a web site on the Internet.
Page 208: Routing
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Routing On the Advanced / Routing page, you can specify static (fixed) routes. Figure 150. The Advanced / Routing page. To specify a new route, click the ADD button ( Figure 151.
Page 209 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the opened window, you can specify the following parameters: Parameter Description Move the switch to the right to enable the route. Enable Move the switch to the left to disable the route.
Page 210: Tr-069 Client
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual TR-069 Client On the Advanced / TR-069 Client page, you can configure the router for communication with a remote Auto Configuration Server (ACS). The TR-069 client is used for remote monitoring and management of the device.
Page 211 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Inform Settings Move the switch to the right so the router may send reports (data on the device and network statistics) to the ACS. Interval Specify the time period (in seconds) between sending reports.
Page 212: Port Mirroring
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Port Mirroring On the Advanced / Port Mirroring page, you can enable the function of mirroring the router’s ports. This function allows to copy traffic from one or several ports to the destination port to monitor network issues with the help of traffic analysis software.
Page 213: Source Port
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Select the mode for each port traffic from which should be copied to the destination port: Both: Copy incoming and outgoing traffic from the source •...
Page 214: Upnp
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual UPnP On the Advanced / UPnP page, you can enable the UPnP function. The UPnP function allows to automatically create port forwarding rules for applications in the router’s LAN requiring a connection from an external network.
Page 215 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual When the function is enabled, the following parameters of the router are displayed on the page: Parameter Description IPv4 / IPv6 Protocol A protocol for network packet transmission.
Page 216: Udpxy
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual UDPXY On the Advanced / UDPXY page, you can allow the router to use the built-in UDPXY application. The UDPXY application transforms UDP traffic into HTTP traffic. This application allows devices which cannot receive UDP streams to access stream video.
Page 217 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To access the status page of the application, click the Status link. Figure 156. The UDPXY application status page. Page 217 of 289...
Page 218: Igmp/Mld
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual IGMP/MLD On the Advanced / IGMP/MLD page, you can allow the router to use IGMP and MLD and specify needed settings. IGMP and MLD are used for managing multicast traffic (transferring data to a group of destinations) in IPv4 and IPv6 networks correspondingly.
Page 219 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Enable Move the switch to the right to enable MLD. MLD version Select a version of MLD from the drop-down list. From the drop-down list, select a connection of the Dynamic IPv6...
Page 220: Alg/Passthrough
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual ALG/Passthrough On the Advanced / ALG/Passthrough page, you can enable the RTSP, SIP ALG mechanisms, and PPPoE/PPTP/L2TP/IPsec pass through functions. SIP is used for creating, modifying, and terminating communication sessions. This protocol allows telephone calls via the Internet.
Page 221 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual The following elements are available on the page: Parameter Description Move the switch to the right to enable SIP. Such a setting allows using the SIP ALG function. This function allows VoIP traffic to pass through the NAT-enabled router.
Page 222: Coovachilli
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual CoovaChilli The CoovaChilli service provides authorized Internet access for clients in your corporate or public network. On the Advanced / CoovaChilli page, you can add an authorization server.
Page 223 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the Main Settings section, you can specify the following parameters: Parameter Description From the drop-down list, select an interface to be used for the authorization server.
Page 224 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The password which the router uses for communication with the RADIUS server (the value of this parameter is specified in the RADIUS encryption key RADIUS server settings). Click the Show icon ( ) to display entered password.
Page 225 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 163. The page for adding an authorization server. The UAM section. In the UAM section, you can specify the following parameters: Parameter Description Move the switch to the right to enable CHAP authentication.
Page 226 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To remove a server, select the checkbox located to the left of the relevant line in the table and click the DELETE button ( Page 226 of 289...
Page 227: Vrrp
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual VRRP On the Advanced / VRRP page, you can enable VRRP (Virtual Router Redundancy Protocol), which is designed to improve availability of routers acting as default gateways. The protocol enables you to configure several devices as the default virtual router with a common IP address, which is used as the default gateway by LAN clients.
Page 228 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual If you want to enable VRRP, move the Enable VRRP switch to the right. When the protocol is enabled, the following elements are displayed on the page:...
Page 229 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The preempt mode enables a backup router to switch to the Master mode if its priority level is higher than the priority of the current Master.
Page 230: Wake-On-Lan
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Wake-on-LAN On the Advanced / Wake-on-LAN page, you can enable the Wake-on-LAN function. This function allows you to remotely power on or wake up devices connected to the router's LAN via a specific packet.
Page 231: Firewall
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Firewall In this menu you can configure the firewall of the router: add rules for IP filtering • create virtual servers • define a DMZ • configure the MAC filter •...
Page 232 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 167. The page for adding a rule for IP filtering. You can specify the following parameters: Parameter Description General Settings Move the switch to the right to enable the rule.
Page 233 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description The priority level of the rule. In the field, enter the needed value. Priority The lower the value, the higher is the priority of the rule. You can specify a value from 0 to 5000.
Page 234 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Select the destination of the packet direction from the Destination drop-down list. Router: The rule will be applied to the packets transmitted • to DIR-X1860.
Page 235: Destination Ip Address
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description End IPv4 address / The source host end IPv4 or IPv6 address. End IPv6 address Subnet IPv4 address / The source subnet IPv4 or IPv6 address. The field is displayed when Subnet IPv6 address the Subnet value is selected from the Set as drop-down list.
Page 236 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To edit a rule, select the relevant line in the table. On the opened page, change the needed parameters and click the APPLY button. To create a copy of an IP filter rule, select the checkbox located to the left of the relevant line in the table and click the Clone ( ) icon.
Page 237: Virtual Servers
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Virtual Servers On the Firewall / Virtual Servers page, you can create virtual servers for redirecting incoming Internet traffic to a specified IP address in the local area network.
Page 238 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Figure 169. The page for adding a virtual server. You can specify the following parameters: Parameter Description General Settings Move the switch to the right to enable the server.
Page 239 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Interface A WAN connection to which this virtual server will be assigned. A protocol that will be used by the new virtual server. Select a value Protocol from the drop-down list.
Page 240 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To edit the parameters of an existing server, select the relevant line in the table. On the opened page, change the needed parameters and click the APPLY button.
Page 241: Dmz
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual A DMZ is a host or network segment located “between” internal (local) and external (global) networks. In the router, the DMZ implements the capability to transfer a request coming to a port of the router from the external network to a specified host of the internal network.
Page 242 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To set a schedule for the DMZ, click the Set schedule icon ( ). In the opened window, from the Rule drop-down list, select the Create rule value to create a new schedule...
Page 243: Mac Filter
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual MAC Filter On the Firewall / MAC Filter page, you can configure MAC-address-based filtering for computers of the router's LAN. Figure 171. The Firewall / MAC Filter page.
Page 244 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the opened window, you can specify the following parameters: Parameter Description Move the switch to the right to enable the rule. Enable rule Move the switch to the left to disable the rule.
Page 245: Url Filter
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual URL Filter On the Firewall / URL Filter page, you can specify restrictions on access to certain web sites and define devices to which the specified restrictions will be applied.
Page 246 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To specify URL addresses to which the selected filtering mode will be applied, in the Addresses section, click the ADD button ( ). In the opened window, you can specify the following...
Page 247 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To set a schedule for the URL filter rule, click the Set schedule icon ( ) in the line corresponding to this rule. In the opened window, from the Rule drop-down list, select the Create rule value to create a new schedule (see the Schedule section, page 261) or select the Select an existing one value to use the existing one.
Page 248: Adblock
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual AdBlock On the Firewall / AdBlock page, you can enable the function of blocking advertisements which appear during web surfing. Figure 175. The Firewall / AdBlock page.
Page 249: Remote Access
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Remote Access On the Firewall / Remote Access page, you can configure access to the web-based interface of the router. By default, the access from external networks to the router is closed. If you need to allow access to the router from the external network, create relevant rules.
Page 250 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the opened window, you can specify the following parameters: Parameter Description Move the switch to the right to enable the rule. Enable Move the switch to the left to disable the rule.
Page 251 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To edit a rule for remote access, left-click the relevant rule. In the opened window, change the needed parameters and click the SAVE button. To change or delete the schedule for a rule, click the Edit schedule icon ( ) in the line corresponding to this rule.
Page 252: System
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual System In this menu you can do the following: change the password used to access the router's settings • restore the factory default settings • create a backup of the router's configuration •...
Page 253: Configuration
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Configuration On the System / Configuration page, you can change the password for the administrator account used to access the web-based interface of the router and to access the device settings via TELNET...
Page 254 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Remember or write down the new password for the administrator account. In case of losing the new password, you can access the settings of the router only after restoring the factory default settings via the hardware RESET button.
Page 255: Buttons Configuration
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Buttons Configuration On the System / Buttons Configuration page, you can edit or add commands for the RESET and WPS hardware buttons. Figure 179. The System / Buttons Configuration page.
Page 256 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the opened window, specify the following parameters: Control Description Reset / WPS Command From the drop-down list, select a command. From the drop-down list, select an action for the command.
Page 257: Firmware Update
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Firmware Update On the System / Firmware Update page, you can update the firmware of the router and configure the automatic check for updates of the router's firmware.
Page 258 Configuring via Web-based Interface User Manual By default, in the Remote server URL field, the D-Link update server address (fwupdate.dlink.ru) is specified. To add one more address, click the ADD button and enter the address in the displayed line. To remove the address, click the DELETE button ( ) in the line of the address.
Page 259: Local Update
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Local Update Attention! Do not turn off the router before the firmware update is completed. This may cause the device breakdown. To update the firmware of the router locally, follow the next steps: 1.
Page 260: Remote Update
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Remote Update Attention! Do not turn off the router before the firmware update is completed. This may cause the device breakdown. To update the firmware of the router remotely, follow the next steps: 1.
Page 261: Schedule
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Schedule On the System / Schedule page, you can enable/disable Wi-Fi connection and the Wi-Fi filter, configure automatic reboot of the device on a schedule, and set a schedule for different rules and settings of the firewall.
Page 262 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the opened window, in the System Time field, the system time of the device is displayed. You can select the Simplified mode value from the Mode drop-down list and specify the following...
Page 263 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To set a schedule for a task which will be applied to a rule or setting of the firewall or will enable/disable Wi-Fi connection or Wi-Fi filter, click the ADD button ( ) in the All Tasks section.
Page 264 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Specify the time period for performing a task. Every minute. • Every hour: When this value is selected, the Time field is • displayed in the section.
Page 265: Logging
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Logging In this menu you can enable event logging and create rules for sending the log to a remote server. Local On the System / Logging / Local page, you can enable event logging and set its basic options.
Page 266 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description Logging to buffer From the drop-down list, select the severity level of messages which Level will be logged. Upon that messages which severity level is equal to the selected level or higher than the selected one will be logged.
Page 267: Remote
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Remote On the System / Logging / Remote page, you can create rules for sending the event log to a remote server. Figure 186. The System / Logging / Remote page.
Page 268 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description A port of the host specified in the Server field. By default, the Port value 514 is specified. After specifying the needed parameters, click the APPLY button.
Page 269: Ping
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Ping On the System / Ping page, you can check availability of a host from the local or global network via the ping utility. The ping utility sends echo requests to a specified host and receives echo replies.
Page 270 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To specify additional settings, click the MORE SETTINGS button. Figure 189. The System / Ping page. The additional settings window. In the opened window, in the Packet size field, specify the volume of data sent in a request. In the Waiting for response field, specify the response waiting period in seconds.
Page 271: Traceroute
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Traceroute On the System / Traceroute page, you can trace the route of data transfer to a host via the traceroute utility. Figure 190. The System / Traceroute page.
Page 272 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual To specify additional settings, click the MORE SETTINGS button. Figure 191. The System / Traceroute page. The additional settings window. In the opened window, you can specify the following parameters:...
Page 273: Telnet/Ssh
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Telnet/SSH On the System / Telnet/SSH page, you can enable or disable access to the device settings via TELNET and/or SSH from your LAN. By default, access is disabled.
Page 274: System Time
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual System Time On the System / System Time page, you can manually set the time and date of the router or configure automatic synchronization of the system time with a time server on the Internet.
Page 275 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual 4. Click the APPLY button. The System date and System time fields will be filled in automatically. In case of successful synchronization with the NTP server, the Completed value will be displayed in the Synchronization field.
Page 276 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual When the router is powered off or rebooted, the system time is reset to the default value. If you have set automatic synchronization for the system time, the internal clock of the device will be configured after connecting to the Inter net.
Page 277: Auto Provision
On the System / Auto Provision page, you can enable the Auto Provision function. The Auto Provision function allows your ISP to manage the device’s settings remotely: DIR-X1860 connects to the ISP’s server, compares the current configuration file with the configuration file stored on this server, and updates its settings if the files are different.
Page 278 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Parameter Description File name The location of the configuration file on the ISP's server. A time period (in seconds) between attempts to compare the current File check period configuration file with the configuration file on the ISP's server.
Page 279: Skydns
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual SkyDNS This menu is designed to configure the SkyDNS service. SkyDNS is a web content filtering service which provides protection against malicious web sites for devices connected to the router's network, and also allows to configure filtering, block access to adult web sites, and use search engines safely.
Page 280: Settings
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Settings On the SkyDNS / Settings page, you can enable the SkyDNS service and specify settings for its operation. Figure 195. The SkyDNS / Settings page. To enable the SkyDNS service, click the ENABLE button. Then in the Mail and Password fields, enter the account data (the e-mail address and the password correspondingly) specified upon registration on the SkyDNS service web site.
Page 281 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual By default, the account parameters are automatically synchronized with the SkyDNS service web site once an hour (3600 seconds). To change the automatic synchronization period, specify another value in the Sync period field and click the APPLY button.
Page 282: Devices And Rules
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual Devices and Rules On the SkyDNS / Devices and Rules page, you can assign a specific filtering profile to a device connected to the router's network. Figure 196. The SkyDNS / Devices and Rules page.
Page 283 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Configuring via Web-based Interface User Manual In the opened window, specify the following parameters: Parameter Description The MAC address of a device from the router's LAN to which the specified filtering profile will be applied. You can enter the MAC MAC address address of a device connected to the router's LAN at the moment.
Page 284: Chapter 5. Operation Guidelines
5 – 2025. Month: 1 – January, 2 – February, ..., 9 – September, A – October, B – November, C – December. If a fault is detected, please contact D-Link service center or technical support group. Page 284 of 289...
Page 285: Wireless Installation Considerations
RF noise in your home or office. To maximize your wireless range, follow the guidelines below. 1. Keep the number of walls and ceilings between the DIR-X1860 device and other network devices to a minimum – each wall or ceiling can reduce your wireless network range by 3- 90 feet (1-30 meters).
Page 286: Abbreviations And Acronyms
DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Abbreviations and Acronyms User Manual CHAPTER 6. ABBREVIATIONS AND ACRONYMS Third Generation Access Category Advanced Encryption Standard Access Point Address Resolution Protocol BPSK Binary Phase-shift Keying BSSID Basic Service Set Identifier Complementary Code Keying...
Page 287 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Abbreviations and Acronyms User Manual HTTPS Hypertext Transfer Protocol Secure ICMP Internet Control Message Protocol Identifier Internet Gateway Device IGMP Internet Group Management Protocol Internet Key Exchange IMEI International Mobile Equipment Identity IMSI...
Page 288 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Abbreviations and Acronyms User Manual OFDM Orthogonal Frequency Division Multiplexing Password Authentication Protocol Push Button Configuration Port Control Protocol Perfect Forward Secrecy Personal Identification Number Port Mapping Protocol Power over Ethernet Point-to-Point Protocol...
Page 289 DIR-X1860 AX1800 Wi-Fi 6 EasyMesh Gigabit Router Abbreviations and Acronyms User Manual Secure Shell SSID Service Set Identifier STBC Space-time block coding Transmission Control Protocol TKIP Temporal Key Integrity Protocol Transport Layer Security Type of Service Universal Access Method User Datagram Protocol...

D-Link DIR-X1860 User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for D-Link DIR-X1860

Summary of Contents for D-Link DIR-X1860

Table of Contents
