- Page 1 D - L i n k Version 1.0 | 03/28/2023 User Manual AX3000 Wi-Fi Gigabit Router DIR-X3000Z...
-
Page 2: Table Of Contents
Section 1 - Product Overview Catalogue Preface ................................................4 Package Contents .............................................4 System Requirements ..........................................5 Introduction ..............................................6 Features ..............................................7 Hardware Overview ...........................................9 Installation ..............................................11 Wireless Installation Considerations ...................................... 12 Manual Setup ............................................13 Configuration ............................................15 Setup Wizard ............................................16 Configuration ..............................................20 Connected Clients ........................................... - Page 3 Section 1 - Product Overview 1. Why can’t I access the web-based configuration utility? ..............................54 2. What can I do if I forgot my password? ....................................55 Appendix ................................................. 56 Wireless Basics ............................................56 What is Wireless? ..........................................56 How does wireless work? ........................................
-
Page 4: Section 1 - Product Overview
Wi-Fi Configuration Note If any of the above items are missing, please contact your reseller. Note: Using a power supply with a different voltage rating than the one included with the DIR-X3000z will cause damage and void the warranty for this product. -
Page 5: System Requirements
Section 1 - Product Overview System Requirements • An Ethernet-based cable, DSL or fiber modem • IEEE 802.11ax/ac/n/g/b/a wireless clients Network Requirements • 10/100/1000 Ethernet Computer with the following: • Windows®, Macintosh, or Linux-based operating system • An installed Ethernet adapter Browser Requirements: Web-based Configuration •... -
Page 6: Introduction
The DIR-X3000z supports the latest wireless security features to help prevent unauthorized access, be it from over a wireless network or the Internet. Support for WPA2™ and WPA3™ standards ensure that you will be able to use the best possible encryption regardless of your client devices. -
Page 7: Features
Always Up-to-Date with the Latest Features The DIR-X3000z will automatically check daily for updates to make sure that the device always has the latest security upgrades and new features, which will install silently in the background. For extra peace of mind, in the event of failure during the firmware update, the router will store a backup system image in the memory before proceeding with the update. - Page 8 * Maximum wireless signal rate derived from IEEE Standard 802.11a, 802.11g, 802.11n and 802.11ac and 802.11ax specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely affect wireless signal range. D-Link DIR-X3000z User Manual...
-
Page 9: Hardware Overview
Receptor for the supplied power adapter. 4 Power Button Press the power button to power the DIR-X3000Z on and off. 5 Reset Button Long press for 8 seconds to reset the router to default settings. Located at bottom of device. - Page 10 A solid light indicates that the wireless is operating. 5 LAN LEDs 1-4 A solid light indicates a connection to an Ethernet-enabled computer on ports 1-4 respectively. 6 WAN LED A solid light indicates a connection to an Internet-enabled on ports. D-Link DIR-X3000z User Manual...
-
Page 11: Installation
• If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet. D-Link DIR-X3000z User Manual... -
Page 12: Wireless Installation Considerations
1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized. -
Page 13: Manual Setup
3. Unplug the Ethernet cable from your modem (or existing router if upgrading) that is connected to your computer. Plug it into the LAN port labeled 1 on the back of your router. The router is now connected to your computer. Computer DIR-X3000z（as the sample） D-Link DIR-X3000z User Manual... - Page 14 Press the power button and verify that the power LED is lit. Allow 1 minute for the router to boot up. Power Outlet INTERNET 7. If you are connecting toa broadband service, you may be online already and further configuration will be optional. D-Link DIR-X3000z User Manual...
-
Page 15: Configuration
There are several different ways you can configure your router to connect to the Internet and connect to your clients: • D-Link Setup Wizard - This wizard will launch when you log into the router for the first time. Refer to page 12. -
Page 16: Section 3 - Getting Started
Configuration on page 19. The wizard is designed to guide you through a step-by-step process to configure your new D-Link router and connect to the Internet. Click Start to continue. Please wait while your router detects your Internet connection type. After the router detects your Internet connection, you may need to enter your ISP information such as your username and password. - Page 17 The software is no longer needed andwill not work through a router. If the router detected or you selected Static, enter the IP and DNS settings supplied by your ISP. Click Next to continue. D-Link DIR-X3000z User Manual...
- Page 18 Click Next to continue. In order to secure the router, please enter a new password. You will be prompted for this password everytime you want to use the router’s web configuration utility. Click Next to continue. D-Link DIR-X3000z User Manual...
- Page 19 Section 3 - Getting Started The Summary window will display your settings.And wait a while will display the complete information. D-Link DIR-X3000z User Manual...
-
Page 20: Configuration
The bar at the top of the page has quick access to Settings and Management functions. You may quickly jump back Home at any time. Note: The system will automatically log out after a period ofinactivity. D-Link DIR-X3000z User Manual... - Page 21 Internet icon. Click IPv4 or IPv6 to see details of the IPv4 connection and IPv6 connection respectively. Click Release to disconnect from the Internet. If you do this and wish to reconnect, click Renew. To reconfigure the Internet settings, refer to Internet on page 19. D-Link DIR-X3000z User Manual...
- Page 22 Section 4 - Configuration DIR-X3000z Click on the DIR-X3000z icon to view details about the router and its wireless settings. Here you can see the router’s current wireless settings, as well as its MAC address and IPv4/IPv6 addresses. To reconfigure the network settings, either click Go to settings on the lower left, or click Settings (at the top of the page) and then Network on the menu that appears.
-
Page 23: Connected Clients
The schedule may be set to Always OFF to indefinitely deny network access to the client, or you can create your own schedules in the Schedules section (refer to Time & Schedule on page 63) Click Save when you are done. D-Link DIR-X3000z User Manual... -
Page 24: Settings
For Dynamic IP (DHCP) refer to Dynamic IP (DCHP) on page 24 For Static IP refer to Static IP on page 25 For PPPoE refer to PPPoE on page 26 To configure an IPv6 connection, click the IPv6 link. Refer to IPv6 on page 60. D-Link DIR-X3000z User Manual... -
Page 25: Dynamic Ip (Dchp)
The default MAC address is set to the physical MAC address of the Clone: router. You can use the drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client. Click Save when you are done. D-Link DIR-X3000z User Manual... -
Page 26: Static Ip
The default MAC address is set to the physical MAC address of the router. You can use drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client. Click Save when you are done. D-Link DIR-X3000z User Manual... -
Page 27: Pppoe
Enter the secondary DNS server IP address assigned by your ISP. Server: MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP. Click Save when you are done. D-Link DIR-X3000z User Manual... - Page 28 Click Advanced Settings... to expand the list and see all of the options. For Auto Detection refer to Auto Detection on page 33. For Static IPv6 refer to Static IPv6 on page 35. For Auto Configuration (SLAAC/DHCPv6) refer to Auto Configuration (SLAAC/ DHCPv6) on page 37. D-Link DIR-X3000z User Manual...
-
Page 29: Auto Detection
Enable or disable DHCP-PD for other IPv6 routers connected to the Enable Automatic LAN interface. DHCP-PD in LAN: Note: This feature requires a smaller subnet prefix than /64 (i.e. allowing for a larger address allocation), such as /63. Contact your ISP for more information. D-Link DIR-X3000z User Manual... -
Page 30: Static Ipv6
Enter the LAN (local) IPv6 address for the router. LAN IPv6 Address: Displays the router’s LAN link-local address. LAN IPv6 Link- Local Address: Check to enable the Automatic IPv6 Address Assignment feature. Enable Automatic IPv6 Address Assignment: D-Link DIR-X3000z User Manual... -
Page 31: Wireless
Select the optimum channel width foryour wireless network from the drop-down menu. Visibility Status: The default setting is Visible. Select Invisible if you do not want to broadcast the SSID of your wireless network. D-Link DIR-X3000z User Manual... - Page 32 The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section (refer to Schedule on page 64). Click Save when you are done. D-Link DIR-X3000z User Manual...
-
Page 33: Guest Zone
Internet Access Enabling this option will confine connectivity to the Internet, Only: disallowing guests from accessing other local network devices and any other service provided by the router itself. Click Save when you are done. D-Link DIR-X3000z User Manual... -
Page 34: Network
Enter the starting and ending IP addresses for the DHCP server’s IP Address Range: assignment. Note: Ifyou statically (manually) assign IP addresses toyour computers or devices, make sure the IP addresses are outside of this range or you may have an IP conflict. D-Link DIR-X3000z User Manual... - Page 35 Enable to allow IPv4 multicast traffic to pass through the router from IPv4 Multicast the Internet. Stream: Enable to allow IPv6 multicast traffic to pass through the router from IPv6 Multicast the Internet. Stream: Click Save when you are done. D-Link DIR-X3000z User Manual...
-
Page 36: Firewall
To configure the IPv4 firewall rules, click the IPv4 Rules tab. Refer to Firewall Settings To configure the IPv6 firewall rules, click the IPv6 Rules tab. Refer to Firewall Settings Click Save at anytime to save the changes you have made on this page. D-Link DIR-X3000z User Manual... -
Page 37: Parental Control
You can add multiple days and multiple periods per day to the schedule. If no time periods are selected, all devices in this profile will be denied Internet access. D-Link DIR-X3000z User Manual... - Page 38 URLs containing ABC. Enter the same website name asthe above in this field to block only the specific URL. You can also modify or delete an existing rule by clicking Edit or Delete respectively. D-Link DIR-X3000z User Manual...
-
Page 39: Port Mapping
Use the drop-down menu to select the time schedule that the rule will be enabled on. The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section (refer to Schedule on page 64). Click Apply when you are done. D-Link DIR-X3000z User Manual... -
Page 40: Virtual Server
Use the drop-down menu to select the time schedule that the rule will be enabled on. The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section (refer to Schedule on page 64). Click Apply when you are done. D-Link DIR-X3000z User Manual... -
Page 41: Website Filter
Create New Rule. Next, under Website URL/Domain enter the URL or domain. If you wish to remove a rule, click on its trash can icon in the Delete column. If you wish to edit a rule, simply replace the URL or domain. Click Save when you are done. D-Link DIR-X3000z User Manual... -
Page 42: Management
Click Save when you are done. To configure and manage your schedules, click Schedule and refer to Schedule on page 64. D-Link DIR-X3000z User Manual... - Page 43 You can add multiple days to the schedule, but only one period per day. To remove a time period from the schedule, click on the cross icon. Click Apply when you are done. D-Link DIR-X3000z User Manual...
-
Page 44: System Log
The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section (refer to Schedule on page 64). Click Save when you are done. D-Link DIR-X6000Z User Manual... -
Page 45: Admin
The port number used to access the DIR-X3000z isusedin the URL. Remote Admin Example: http://x.x.x.x:8080 where x.x.x.xisthe Internet IP address of Port: the DIR-X3000z and 8080 is the port used for the web management interface. Note: Ifyou enabledHTTPSServerand wish to access the routerremotely and securely,you must enterhttps://atthe beginning oftheaddress. -
Page 46: System
Settings: you have created. If you want to save the current router configuration settings, use the Save Settings To Local Hard Drive button above. Reboot The Click to reboot the router. Device: D-Link DIR-X6000Z User Manual... -
Page 47: Upgrade
If you wish to upgrade manually, first download the firmware file you Firmware: wish to upgrade to. Next, click the Select File button and browse to the file to install the new firmware.You can also browse toa language pack file to install a new language pack. D-Link DIR-X3000z User Manual... -
Page 48: Connecting To A Wireless Network
Step 1 - Press the WPS button on the DIR-X3000z for about 1 second. The Internet LED on the front will start to blink. Step 2 - Within 2 minutes, press the WPS button on your wireless client (or launch the software utility and start the WPS process). -
Page 49: Section 6 - Connect A Wireless Client To Your Router
You will then be prompted to enter the Wi-Fi password (network security key) for the wireless network. Enter the password into the box and click Next to connect to the network. Your computer will now automatically connect to this wireless network when it is detected. D-Link DIR-X3000z User Manual... -
Page 50: Windows® 8 - Wpa/Wpa2
Enter the password into the box and click Next. dlink If you wish to use Wi-Fi Protected Setup (WPS) to connect to the router, you can also press the WPS button on your router at this point to enable the WPS function. D-Link DIR-X3000z User Manual... - Page 51 Section 6 - Connect a Wireless Client to your Router When you have established a successful connection with a wireless network, the word Connected will appear next to the name of the network to which you are connected. dlink D-Link DIR-X3000z User Manual...
-
Page 52: Windows® 7- Wpa/Wpa2
Connect button. If you get a good signal but cannot access the Internet, check your TCP/IP settings for your wireless adapter. Refer to Networking Basics on page 146 for more information. D-Link DIR-X3000z User Manual... - Page 53 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as the one on the wireless router. D-Link DIR-X3000z User Manual...
-
Page 54: Troubleshooting
1. Why can’t I access the web-based configuration utility? When entering the IP address ofthe D-Link router (192.168.0.1 for example), you are not connecting to a website, nor do you have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility. -
Page 55: What Can I Do If I Forgot My Password
Section 7 - Troubleshooting • Access the web configuration. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your web configuration. • If you still cannot access the configuration, unplug the power to the router for 10 seconds and plug back in. Wait about 30 seconds and try accessing the configuration. -
Page 56: Appendix
D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business, or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products allows you to access the data you want, when, and where you want it. You will be able to enjoy the freedom that wireless networking delivers. -
Page 57: How Does Wireless Work
Who uses wireless? Wireless technology has become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. D-Link DIR-X3000z User Manual... -
Page 58: Home Uses/Benefits
Using a D-Link USB adapter with your laptop, you can access the hotspot to connect to the Internet from remote locations like: airports, hotels, coffee shops, libraries, restaurants, and convention centers. -
Page 59: Tips
Extend and Strengthen Your Wireless Network with Wi-Fi Mesh D-Link’sWi-Fi Mesh is a scalable solution that allows you to easily increase the coverage and eliminate weak spots ofyour wireless AX network. Setup is effortless; configuration of multiple routers and extenders can be done in minutes as settings can be passed on to other devices once the first is configured. -
Page 60: Networking Basics
Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below. - Page 61 Set Preferred DNS the same as the LAN IP address of your router. The Alternate DNS is only optional or you may enter a DNS server from your ISP. 5. When you’re done, click Save. D-Link DIR-X3000z User Manual...
-
Page 62: Wireless Security
WPA3 has the strongest encryption among these with the increased cryptographic capability and the requirements of the Protected Management Frames (PMFs) to help prevent snooping attacks. D-Link DIR-X3000z User Manual... -
Page 63: Technical Specifications
- lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. Frequency Range varies depending on country’s regulation. The router does not include 5.25-5.35 GHz & 5.47-5.725 GHz in some regions. D-Link DIR-X3000z User Manual... -
Page 64: Appendix H - Wall Mounting Information
To mount the unit directly onto a wall, use 2 screws (not included) with the dimensions shown below. Install the screws 85 mm (3.35 in) apart and slide the mounting holes into the base of the router over them. The screw head should project out from the wall at 7 mm (0.28 in) as shown below. D-Link DIR-X3000z User Manual... -
Page 65: Appendix G - Regulatory Information
Note The country code selection is for non-USA models only and is not available to all USA models. Per FCC regulations, all WiFi product marketed in the USA must be fixed to USA operational channels only. D-Link DIR-X3000z User Manual... -
Page 66: Important Notice
Le présent appareil est conforme aux CNR d'ISED applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. D-Link DIR-X3000z User Manual... -
Page 67: Radiation Exposure Statement
Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. D-Link DIR-X3000z User Manual... - Page 68 Potencia máxima de Salida Bandas de Frecuencia Potenza max. Output Frequenza/e Frequentie(s) Max. Output Power 5.15 – 5.25 GHz 200 mW 5.25 – 5.35 GHz 200 mW 5.47 – 5.725 GHz 2.4 – 2.4835 GHz 100 mW 2.4 G D-Link DIR-X3000z User Manual...
-
Page 69: European Community Declaration Of Conformity
υλικολογισμικό του προϊόντος είναι διαθέσιμα για λήψη από τη σελίδα του προϊόντος στην τοποθεσία www.dlink. com. Par les présentes, D-Link Corporation déclare que ce produit, ces accessoires et ce logiciel sont conformes aux Français [French] directives 2014/53/UE.Le texte complet de la déclaration de conformité de l'UE et le icroprogramme du produit sont disponibles au téléchargement sur la page des produits à... - Page 70 2014/53/EU. Pełen tekst deklaracji zgodności UE oraz oprogramowanie sprzętowe do produktu można pobrać na stronie produktu w witrynie www.dlink.com. Desta forma, a D-Link Corporation declara que este produto, os acessórios e o software estão em conformidade Português [Portuguese] com a diretiva 2014/53/UE. O texto completo da declaração de conformidade da UE e do firmware...
-
Page 71: Warning Statement
Appendix G - Regulatory Information Hér með lýsir D-Link Corporation því yfir að þessi vara, fylgihlutir og hugbúnaður eru í samræmi við tilskipun 2014/53/EB. Sækja má ESB-samræmisyfirlýsinguna í heild sinni og fastbúnað vörunnar af vefsíðu vörunnar á www. Íslenska [Icelandic] dlink.com. -
Page 72: Usage Notes
Access Points unterstützen die Funktionen DFS (Dynamic Frequency Selection) und TPC (Transmit Power Control) wie erforderlich bei Betrieb auf 5 GHz innerhalb der EU. • Bitte schlagen Sie im Handbuch oder Datenblatt nach nach, ob Ihr Gerät eine 2,4 GHz und / oder 5 GHz Verbindung nutzt. D-Link DIR-X3000z User Manual... -
Page 73: Notes D'utilisation
5 Ghz dentro de la UE. • Por favor compruebe el manual o la ficha de producto para comprobar si el producto utiliza las bandas inalámbricas de 2.4 GHz y/o la de 5 GHz. D-Link DIR-X3000z User Manual... - Page 74 Toegangspunten ondersteunen DFS (Dynamic Frequency Selection) enTPC (Transmit Power Control) functionaliteit zoals vereist bij gebruik in 5 GHz binnen de EU. • Raadpleeg de handleiding of de datasheet om te controleren of uw product gebruik maakt van 2.4 GHz en/of 5 GHz. D-Link DIR-X3000z User Manual...
-
Page 75: Safety Instructions
• Halten Sie das Produkt von Heizkörpern und anderen Quellen fern, die Wärme erzeugen. • Trennen Sie das Produkt immer von der Stromzufuhr, bevor Sie es reinigen und verwenden Sie dazu ausschließlich ein trockenes fusselfreies Tuch. D-Link DIR-X3000z User Manual... -
Page 76: Consignes De Sécurité
• Mantenga el producto alejado de los radiadores y de otras fuentes de calor. • Desenchufe siempre el producto de la alimentación de red antes de limpiarlo y utilice solo un paño seco sin pelusa. D-Link DIR-X3000z User Manual... -
Page 77: Istruzioni Per La Sicurezza
• Houd het product uit de buurt van radiators en andere warmtebronnen. • U dient het product steeds los te koppelen van de stroom voordat u het reinigt en gebruik uitsluitend een droge pluisvrije doek. D-Link DIR-X3000z User Manual... - Page 78 D-Link designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging. D-Link recommends that you always switch offor unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions.
- Page 79 D-Link et l’environnement Chez D-Link, nous sommes conscients de l'impact de nos opérations et produits sur l'environnement et nous engageons à le réduire. Pour limiter cet impact, D-Link conçoit et fabrique ses produits de manière aussi écologique que possible, en utilisant des matériaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.
- Page 80 D-Link zijn producten zo milieuvriendelijk mogelijk, door het gebruik van recycleerbare producten met lage toxiciteit in product en verpakking. D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekkerte halen wanneer u ze niet gebruikt. Door ditte doen bespaart u energie en beperkt u de CO2-emissies.
- Page 81 D- Link a životní prostředí Ve spole£nosti D-Link jsme si v domi vlivu na ich provoz¦ a výrobk¦ na ivotní prost edí a sna íme se o minimalizaci t chto vliv¦. Proto své výrobky navrhujeme a vyrábíme tak, aby byly co nejekologi£t j í, a ve výrobcích i obalech pou íváme recyklovatelné a nízkotoxické materiály.
- Page 82 D-Link produkter som er så miljøvennlig som mulig, ved å bruke resirkulerbare, lav-toksiske materialer både i produktene og forpakningen. D-Link anbefaler at du alltid slår av eller frakobler D-Link-produkter når de ikke er i bruk. Ved å gjøre dette hjelper du å spare energi og å redusere CO2-utslipp.
- Page 83 D-Link sine produkter, så de er så miljøvenlige som muligt, ved at bruge genanvendelige materialer med lavt giftighedsniveau i både produkter og emballage. D-Link anbefaler, at du altid slukker eller frakobler dine D-Link-produkter, når de ikke er i brug. Ved at gøre det bidrager du til at spare energi og reducere CO2-udledningerne.
- Page 84 D-Link rekommenderar att du alltid stänger av eller kopplar ur dina D-Link produkter när du inte använder dem. Genom att göra detta hjälper du till att spara energi och minska utsläpp av koldioxid.
