OWNER'S MANUAL
AARDWOLF
GLASS LIFTER
A G L 2 2
+84 931 707 793
www.aardwolf.com.au
info@aardwolf.com.au
May, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGL22 and is the answer not in the manual?

Questions and answers

Related Manuals for Aardwolf AGL22

Summary of Contents for Aardwolf AGL22

  • Page 1 +84 931 707 793 www.aardwolf.com.au info@aardwolf.com.au OWNER’S MANUAL AARDWOLF GLASS LIFTER A G L 2 2 May, 2022...

  • Page 2: Table Of Contents

    PURPOSE OF THIS MANUAL: The purpose of this manual is to assist the operator in the correct use of the Aardwolf Glass Lifter (AGL22), to provide information on the safe use of the Glass Lifter and to eliminate any risks that might be caused by the incorrect use of the Glass Lifter.

  • Page 3: General Safety Operations

    The Aardwolf Glass Lifter (AGL22) is the perfect piece of equipment for lifting and moving materials in the glass industry. This equipment is integrated with automatic self-adjustment without an external electric or pneumatic engine. These durable and dependable lifters are ideal for any racking system.
  • Page 4 GENERAL SAFETY OPERATIONS • Do not lift wet glass. The grip depends on friction. Lifting wet glass may cause the rubber pads to lose their grip. • Position the clamp so that it is square with the glass to be lifted, and in the center of the glass so that the load is balanced.

  • Page 5: Drawing & Parts List

    DRAWING LIST...

  • Page 6: Parts List

    PARTS LIST POS. CODE DESCRIPTION Q’TY AGL22 - 01 Lug links AGL22 - 02 Lifting rear AGL22 - 03 Lifting front AGL22 - 04 Countersunk head socket screw M8 x 30 AGL22 - 05 Top pin guide (*) AGL22 - 06...

  • Page 7: Specifications

    • Release the locking latch so that the jaws will lock onto the glass when the lifting cable is raised. Note: The Aardwolf Glass Lifter (AGL22) is integrated an auto-lock, unlock automatic mechanism which allows the glass lifter to automatically grip the glass on pick-up and release the glass on set down easier and safer.

  • Page 8: Inspections, Maintenance And Repair

    Any claims must be presented within eight days of the date delivery of the product. We grant you 12 months warranty on the Aardwolf Glass Lifter (AGL22), counted from the date of purchase. The warranty coverage is not applicable if: The clamp is handled incorrectly during manoeuvring.
