  • Page 1 Glass LIFTER AEVGLP4-500 OWNER’S MANUAL content table Get The AArdwolf AAdvantage SPECIFICATIONS & features drawing list part list Operating instructions Cross bar & stringer beam adjustment Information for alarm system Inspections & maintenance Warranty Dec. 2019 +84 274 371 2840 www.aardwolf.com.au...

  • Page 2: Specifications And Features

    Vertical-horizontal tilting from 0 to 90° Adjustable vacuum pads based on glass sizes Automatic vacuum pumping once the vacuum loss occurred Attach and release glass sheets by ON/OFF slide valve electric vacuum Glass LIFTER - aevglp4-500 Get The AArdwolf AAdvantage...

  • Page 3: Drawing List

    DRAWING LIST Get The AArdwolf AAdvantage...

  • Page 4: Part List

    Suction Pad AEVGLP4 Spring bushing -030 AEVGLP4 Bolt M8 -031 AEVGLP4 Hanlde -032 AEVGLP4 -033 Remote Box AEVGLP4 Screw Bolt M5 -034 AEVGLP4 Washer M5 -035 AEVGLP4 Nut M5 -036 AEVGLP4 electric vacuum Glass LIFTER - aevglp4-500 Get The AArdwolf AAdvantage...
  • Page 5 Make sure that the vacuum pad surface is clean and frı from dirt and oil. • Make sure that there is no obstructions during working process. • Perform the test of load, vacuum and pumping, pad warning light to ensure safety. Get The AArdwolf AAdvantage...
  • Page 6 • Never use the lifter in dangerous environments . • All inspections and tests must be carried out before lifting. NOTE: Aardwolf Industries LLC denies any claims due to failure of unexpected load release or human and/or material losses in event of employing non-original pads.
  • Page 7 Carefully put the electrical plug into the power source. Make sure that this plug properly with the lifter STEP 2 to avoid the risk of electric shock Turn on the POWER button on the electric cabinet STEP 3 Get The AArdwolf AAdvantage...
  • Page 8 STEP 5 for balancing to ensure the safety during lifting process Manually adjust the cross bar and stringer beam based on STEP 6 the shıt size electric vacuum Glass LIFTER - aevglp4-500 Get The AArdwolf AAdvantage...
  • Page 9 STEP 7 into the vacuum pads. Press the red button of the alarm system and observe STEP 8 If the alarm battery is fully charged: - Alarm light and red vacuum light are Get The AArdwolf AAdvantage...
  • Page 10 - For tilting the shıt in the vertical direction, press the button on the to perform STEP 9 action. - For lifting the shıt in the horizontal direction, press the button on the to perform action electric vacuum Glass LIFTER - aevglp4-500 Get The AArdwolf AAdvantage...
  • Page 11 OPERATING INSTRUCTIONS After that, place the shıt down at the desired location. STEP10 STEP 11 to stop inhaling vacuum and release material. Carefully turn off the power source by press STEP12 button to finish the lifting process Get The AArdwolf AAdvantage...
  • Page 12 The knob will be locked automatically into the hole • Step 3: Check again to ensure all knobs are inserted dıply into the holes before lifting for safety reason electric vacuum Glass LIFTER - aevglp4-500 Get The AArdwolf AAdvantage...
  • Page 13 INFORMATION FOR ALARM SYSTEM INFORMATION FOR ALARM SYSTEM INSPECTIONS AND MAINTENANCE Get The AArdwolf A • Power source: It is used to show the power level of the battery. If the battery is full, the power source will indicates the green color. If the level has not reached, the power will indicates the red color.

  • Page 14: Inspections & Maintenance

    • The lifter and hoisting accessories must be stored in a place where they are protected against weather conditions and aggressive substances. electric vacuum Glass LIFTER - aevglp4-500 Get The AArdwolf AAdvantage...

  • Page 15: Warranty

    Any damages or losses must be officially reported to The Aardwolf Industries LLC within eight days from the date of purchase.
  • Page 16 Ganesha Block, Dinnur Main Road, R. mumbai@aardwolf.co.in India / Pin no. 305801 T. Nagar P.O Bengaluru-560032 www.aardwolf.co.in Tel: +91 93584 48474 +91 98451 62959/ 91 99017 24600 sales@aardwolf.co.in bengaluru@aardwolf.co.in Web: www.aardwolf.co.in www.aardwolf.co.in © Aardwolf Industries LLC, 2019 - Designed in Vietnam Get The AArdwolf AAdvantage...
