Aardwolf AL50A Owner's Manual

Slab lifter automatic
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

OWNER'S MANUAL
AARDWOLF
SLAB LIFTER AUTOMATIC
A L 5 0 A
+84 931 707 793
www.aardwolf.com.au
info@aardwolf.com.au
November, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AL50A and is the answer not in the manual?

Questions and answers

Related Manuals for Aardwolf AL50A

Summary of Contents for Aardwolf AL50A

  • Page 1 +84 931 707 793 www.aardwolf.com.au info@aardwolf.com.au OWNER’S MANUAL AARDWOLF SLAB LIFTER AUTOMATIC A L 5 0 A November, 2022...

  • Page 2: Purpose Of This Manual

    Aardwolf Slab Lifter AL30AWJ is the best solution for you. This lifter is not only providing a bigger surface of contact but also clamping force is tighter and safer.
  • Page 3 • Do not lift wet slabs. The grip depends on friction. Lifting wet slabs may cause the rubber pads to lose their grip. • The Aardwolf Slab Lifter AL50A combines friction and force on the load being lifted and therefore, will safely hoist up to 2 x 20mm thick stone slabs together.
  • Page 4  The combined weight of the slabs being lifted must not exceed the (2,646 lb). AL50A working load limit of 1200 kg • Position the clamp so that it is square with the slab to be lifted, and in the center of the slab so that the load is balanced.

  • Page 5: Drawing List

    DRAWING LIST...

  • Page 6: Parts List

    Camplate (AL50A-015) C002029 Rubber pieces (AL50A-016) L004012 Compression spring (AL50A-021) L004009 Top extension spring (AL50A-022) D020018 Shackle (AL50A-023) AL30A-SC Spring cap (AL50A-024) AL50A-LP Lifting pin (AL50A-026) AL-LP Locking pin (AL50A-027) B015021 Hexagon socket set screw M8x16 (AL50A-028) AL30A-PC Plastic cap (AL50A-029)

  • Page 7: Specifications

    • Release the locking latch so that the jaws will lock onto the slab when the lifting cable is raised. • For the Aardwolf Slab Lifter Automatic: Is integrated an auto-lock, unlock Automatic mechanism which allows the clamp to automatically grip the slabs on pick-up and release the slabs on set down easier and safer.

  • Page 8: Warranty

    Any claims must be presented within eight days of the date delivery of the product. We grant you 24 months warranty on the Aardwolf Slab Lifter, counted from the date of purchase. The warranty coverage is not applicable if: The clamp is handled incorrectly during manoeuvring.
