- Page 1 Air Hoists & Air Balancers ENDO Series...
-
Page 2: Table Of Contents
EHB-85D Series Air Balancer w/ inertia braking ....................................24 Series ABC - Fully Automatic Air Balancer ......................................25 Accessories & Options ............................................26 Hoist Modules ..............................................26 Trolley .................................................26 Hook Set ................................................26 Other Conductix-Wampfler Products .........................................27 Conductix-Wampfler Contact Information ......................................28 Visit www.conductix.us for the most current information. -
Page 3: Endo At A Glance
6.2 (1.9) Conductix-Wampfler proudly offers the ENDO Series of high-efficiency air hoists and air balancers. Prior to the merger between Conductix and Wampfler, and since 1979, Wampfler USA was the exclusive USA distributor of quality ENDO products in the USA. This partnership now continues with the combined strength of ENDO and Conductix- Wampfler sales organization. -
Page 4: Air Hoist Specification Data Sheets, Warnings And Guidelines
ENDO High-Efficiency Air Hoists More efficient solution than electric hoists Air hoists are ideal for applications where: • Accurate work placement is needed: Air hoists allow for continuously variable speed control for precise positioning. • Continuous operation is needed: Air hoists are self-cooling during operation; the “run-time” and “number of starts” are unlimited. •... -
Page 5: Wire Rope Hoists - General Features
Specification Data Sheet To choose the air hoist that will perform properly, please fill in the following information to obtain a quote. Request Date: Sales Person: Company: Contact: Title: Telephone: Fax: E-Mail: General Operating Conditions Environment: Indoor Outdoor Temperature range (°F) ________ Min ________ Max Humidity (%) ____________ Corrosives? (List) _______________________________________________________________________________________________... -
Page 6: Ehw-60
Wire Rope Series ENDO Wire Rope Air Hoist Features • Reduction Gears: Small, light, heat-treated planetary gears can accommodate large speed reductions. • Control Valve: Engineered with spring-return spool valves, two positions and three ports. The valve works by controlling the lever switch connected to the spool. -
Page 7: Ehw-60R
Series EHW Wire Rope Air Hoist The Series EHW air powered wire rope hoist is offered with pendant-style control. Air power provides the benefits of more precise placement of objects, and no down time need to cool the hoist, as would be the case with an electric hoist. These hoists are ready for operations upon receipt. Simply connect the air lines supplying lubricated air. •... -
Page 8: Ah250R
Series EHW-R Wire Rope Hoist The Series EHW air powered wire rope hoist is offered with pendant-style control. Air power provides the benefits of more precise placement of objects, and no down time need to cool the hoist, as would be the case with an electric hoist. These hoists are ready for operation upon receipt. Simply connect the air lines supplying lubricated air. •... -
Page 9: Chain Hoists - General Features
Chain Series ENDO Chain Air Hoist Features • Ideal for frequent hoist operation: No heat build-up, making it possible to operate the hoist continuously without cool-down period. • High Load capacities: Available from 132 lb (60 kg) to 6 tons with a variety of options. -
Page 10: At125K
Series AT Chain Air Hoist The compact, light-weight AT-60K and AT-125K hoists combine the high speeds of wire rope hoists (up to 77 ft./minute) with the high durability of chain hoists. These hoists are ready for operation right out of the box; just connect lubricated air. Can be mounted on air trolley or manual trolley - by request. •... -
Page 11: Atc-60K
Series ATC Chain Air Hoist The Series ATC Air Hoist features direct-controlled operation and is ready to use. Just connect lubricated air supply. Provides precise variable lifting and lowering speed. Can be mounted on air trolley or manual trolley- by request. •... -
Page 12: Ehl-025Ts
Series EHL (Type TS) Chain Air Hoist The compact, light weight Model EHL Type TS air powered chain hoist can handle weight ranges from 1/4 to 4 metric tons. These hoists come standard with a pull chain control and 3 meters of lift. Also available with pendant control, see below. Lifts can be changed from 3 meters to as little as 1 meter or as large as 20 meters with optional longer chain. -
Page 13: Ehl-1Tw
Series EHL (Type TW) Chain Air Hoist The compact light weight model EHL, Type TW, air powered chain hoist can handle weight ranges from 1 to 6 metric tons. These hoists come standard with a pull chain control and 3 meters of lift. Also available with pendant control, see pg 13. Lifts can be changed from 3 meters to as little as 1 meter or as large as 20 meters with optional longer chain. - Page 14 Series MTH Air Motor Trolley The ENDO air motor trolley is used to propel the EHL air hoist along an I-beam. These trolleys are ideal for hazardous locations, such as a chemical factory, since the power source is not electricity, but compressed air. The unit uses stepless speed controls for precise operation. For Hoist Model Use Air Motor Trolley Model EHL-025TS...
- Page 15 Series MTH Air Motor Trolley Dimensions Part No. Capacity Fits Beam Width Min. Curve Radius (kg) In. (mm) In. (mm) 2.95 (75) 137.8 (3500) MTH-1T-5 2,204 (1,000) 3.94, 4.92 (100, 125) 31.5 (800) MT-2T-5 4,409 (2,000) 4.93, 5.91 (125, 150) 39.4 (1000) MTH-6.3 13,889...
- Page 16 Series MTH Air Motor Trolley Dimensions MTH-2T5 13.39 (340) 10.67 (271) Ø 4.92 13.39 (340) B+34 13.39 (340) B-60 (125) 5.20 (132) 2.68 5.16 (68) (131) MTH-2T-5 4.37 6.02 (111) (153) Air Connection ø 0.71 ø 1.69 Rc 1/2 (18) (43) 110.2 (2800)
-
Page 17: Accessories And Spare Parts
Accessories & Spare Parts Series PFT Manual Trolleys for I-Beams The Series PTF manual trolleys are used to suspend small air hoists from I-beams, railways or jib booms. Model PTF-125 and PTF-250 are easily adjustable for different size beams. In addition, the frame is designed to protect the wheels from collisions with other trolleys and can be fitted with rubber bumpers for further protection. Dimensions are available in CAT1007 balancer catalog - Pg.27 Part No Capacity... -
Page 18: Air Balancer - General Information
Their stringent quality systems assure that you will get the right balancer or hoist every time! Conductix-Wampfler is the world leader in the design and manufacture of high- performance spring-driven and air powered devices for industrial applications and proud representative of ENDO balancers and air hoists. -
Page 19: Ehb Series Air Balancer
EHB Series Air Balancer High quality, but economically priced. The “EHB” series operates with compresssed air to provide both hoist and balancing functions. • The load on the hook can be balanced at “zero gravity” • The unit operates with very low noise •... - Page 20 EHB Series Air Balancer Dimensional Drawings EHB-85 with Hoisting Module 18.3 (466) 9.9 (252) 0.23 2.56 0.79 6.9 (176) (6) 0.59 (65) (20) 1.34 11.8 (15) (34) 3 @ Ø 0.51 (13) (300) 2 @ Ø 0.67 (17) 0.83 (21) 5.35 (136) Air Connection Rc 3/8...
-
Page 21: Ehb-Cr Double Load Chain
EHB - Type CR Double Load Chain High quality, but economically priced. The “EHB” series operates with compresssed air to provide both hoist and balancing functions. • The load on the hook can be balanced at “zero gravity” • The unit operates with very low noise •... - Page 22 EHB - Type CR Double Load Chain EHB-270CR 12.80 (325) 18.46 (469) 0.87 ø 1.26 0.35 (9) (22) 2.56 (65) (32) 0.59 (15) 1.34 (34) 0.87 3 @ ø 0.51 (13) (22) 2 @ ø 0.67 (17) 10.63 (270) Air Connection Rc 3/8 16.57 (421) 31.26 - 66.70...
-
Page 23: Ehb-85D Series Air Balancer W/ Inertia Braking
EHB-85D Series Air Balancer with Inertia Braking Inertia Braking limits the inertia action of the load and provides comfortable operation. Patent and design registration pending. • No down-drift of the load, even if air shuts off or the hose is cut •... -
Page 24: Series Abc - Fully Automatic Air Balancer
Fully Automatic Air Balancer - Type ABC “Full Auto” Air Balancers can lift various loads in different weights without any adjustment. They provide fine balancing and positioning by hand operation or with automatic adjustment for weight. • Fully automatic balancing feature without electricity •... -
Page 25: Accessories & Options
Accessories Hoist Modules ENDO’s complete line of hoisting modules allows you to use your ENDO air hoist with the ease and precision you need. From simple push button pendants, to grip style control. See the chart below to find the right one for your model. ABC-5P-B ABC-5G-B MS-AG... -
Page 26: Other Conductix-Wampfler Products
Notes Visit www.conductix.us for the most current information. -
Page 27: Conductix-Wampfler Contact Information
Visit www.conductix.us for the most current information. - Page 28 Conductix-Wampfler has just one critical mission: To provide you with energy and data transmission systems that will keep your operations up and running 24/7/365. To contact your nearest sales office, please refer to: www.conductix.contact...
