Shizuoka Seiki VAL6 FIR-X5 Owner's Manual

Far infrared oil heater

Advertisement

Quick Links

Owner's Manual
• This Owner's Manual provides important information on proper handling, operation, and maintenance. FAILURE TO FOLLOW THE INSTRUC-
TIONS, PRECAUTIONS, OR SAFETY TIPS IN THIS MANUAL AUTOMATICALLY VOIDS ALL WARRANTIES, EXPRESS OR IMPLIED.
• FAILURE TO COMPLY WITH THE INSTRUCTIONS, PRECAUTIONS, AND SAFETY TIPS IN THIS MANUAL CAN RESULT IN DEATH,
SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION,
CARBON MONOXIDE POISONING, AND / OR ELECTRICAL SHOCK.
• Read and thoroughly understand this Owner's Manual before using the heater in any way, including unpacking, assembling, fueling, inspecting,
lighting, operating, adjusting, turning off, cooling down, moving, or storing the heater.
• Please keep this Manual for the user's need and reference.
• Do not allow anyone who has not read and understood this Owner's Manual to assemble, inspect, light, operate, adjust, turn off, cool down, re-
fuel, move, or store the heater.
• The requirements of local authorities having jurisdiction shall be followed.
• The installation of the unit shall be in accordance with the regulations of the authorities having jurisdiction.
FAR INFRARED OIL HEATER
IMPORTANT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAL6 FIR-X5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Shizuoka Seiki VAL6 FIR-X5

  • Page 1 FAR INFRARED OIL HEATER Owner’s Manual IMPORTANT • This Owner’s Manual provides important information on proper handling, operation, and maintenance. FAILURE TO FOLLOW THE INSTRUC- TIONS, PRECAUTIONS, OR SAFETY TIPS IN THIS MANUAL AUTOMATICALLY VOIDS ALL WARRANTIES, EXPRESS OR IMPLIED. •...
  • Page 2: Table Of Contents

    Contents 1. Special precautions ..................3 2. Names of components ................7 3. How to use ....................8 3-1. Preparation for operation ..............8 3-2. Operating procedures ................. 9 3-3. Explanation of operation mode ............10 3-4. Operation with Portable Generator ..........11 4.
  • Page 3: Special Precautions

    Thank you for having bought our Far Infrared Oil Heater “VAL6”. Special precautions This Manual explains necessary precautions that must be strictly followed for proper and safe op- ◆ eration. Danger, Warning, and Caution. Please read Precautions are divided into 3 categories and understand well the details and meanings of each category.
  • Page 4 To Help Ensure Safe Operation, Comply with the Following Precautions * It is important that the safety precautions listed below are understood and followed prior to first operation of the heater. These precautions must also be followed thereafter. DANGER Never use gasoline, for any purpose, for example, for cleaning or as fuel, in Use of gasoline connection with, or around, operation or storage of the heater, as a fire and/or prohibited...
  • Page 5 To Help Ensure Safe Operation, Comply with the Following Precautions CAUTION Keep flammable ma- To avoid a fire, please keep all flammables away from the heater. terials away from the (Refer to the numbers below) heater Top, Front : 1.5m (5ft.) or higher / Rear : 0.1m (0.32ft.) or higher / Side: 0.3m (0.98ft.) or higher To avoid a fire, never place any object within 1m (3.28ft.) from the front of Do not block the the heater.
  • Page 6 To Help Ensure Safe Operation, Comply with the Following Precautions CAUTION Do not place excessive force on the cord by bending, pulling, twisting, pinch- Do not damage the ing or remodeling. Also, do not place any heavy objects on the heater, etc. that power cord may damage it, to avoid a fire and electric shock.
  • Page 7: Names Of Components

    Names of components ⑤ ④ ② ⑩ ⑬ ① ⑨ ⑪ ③ ⑧ ⑫ (inch) ⑥ ⑦ < Burner section > < Operation panel > ㉒ ⑳ ㉓ ㉔ ㉕ ㉖ ㉗ ⑲ ㉑ Display PHT RUN FL ㉙ ⑮ ⑭...
  • Page 8: How To Use

    How to use 3-1. Preparation for operation • Never use highly flammable fuel like gasoline, to avoid fire. • Never contaminate or mix fuels. For example, never contaminate kerosene with gasoline by DANGER using a gasoline container to carry kerosene. Even a small amount of gasoline, or other vol- atile fuels, in kerosene is hazardous.
  • Page 9: Operating Procedures

    ■ Refueling Observations • Please use “kerosene” or “Fuel-Oil no heavier than No.2 (Diesel)” and do not use poor quality or foul fuel, to help avoid ignition, operating, and other problems. Remove the fuel cap and insert a handy suction pump into the fuel tank. Watch the fuel gauge while refueling. When the gauge reaches the maximum level, stop refueling. Tighten well the fuel cap, and wipe off any spilt fuel. • Please wipe off any spilt if spilled. CAUTION Please wear the protective gloves and wipe off the spilt fuel to avoid injury.
  • Page 10: Explanation Of Operation Mode

    ■ Ignition Procedures Observations • To make sure the heater is ignited, please do not leave the heater until you confirm that it is burning and otherwise func- tioning properly. 1 Use the fuel gauge to check if the fuel is sufficiently filled up in the tank.
  • Page 11: Operation With Portable Generator

    ■ Auto Control Mode The combustion level is automatically adjusted according to the set temperature. How to operate Press the Mode button to light the Auto Control Mode lamp. In order to set desired temperature, press the Up/Down button.(default value 55°F) After 5 seconds, the temperature setting is fixed and the display changes from blinking to lighting.
  • Page 12: Inspection

    Inspection • Never inspect or service the heater while it is burning, in operation, hot or plugged-in WARNING to avoid any injury and/or trouble. • Before starting any inspection or service, to avoid electric shock, please make sure the CAUTION heater is shut down and that the power cord is disconnected.
  • Page 13 7 Wipe off fuel or water spilled over the tank and the surrounding area. 8 Be sure to dispose of in a safe manner as approved in your local area the kerosene, etc, placed in the empty container and the materials used to clean up any spilled kerosene, etc.
  • Page 14: Periodic Inspection

    4-2. Periodic inspection The heater must be checked periodically, and especially after periods of sustained or heavy use, for safe and proper operation, and for service maintenance. Have your dealer inspection of the heater no less than twice a year. How to store the heater • If the heater is stored or not used for an extended period of time, empty the fuel tank to CAUTION help prevent fuel leakage and other possible fire dangers. When you store the heater, please disconnect the power plug from the extension cord and/or the AC outlet and store the heater indoors where it is less humid.
  • Page 15 If the following phenomenon takes place, it is usually not a sign of trouble. Please check again before consulting with your dealer. Phenomenon Explanation When used for the first time, smoke or Because fuel is burning together with dusts, etc. This phenomenon will smell comes out of the heater. disappear after a short while. At the time of ignition or shut-down of the Noise is caused by expansion or shrinkage of the burner section due to heater, noise comes from the burner section.
  • Page 16: How To Replace The Fuse & Nozzle

    How to replace the Fuse & Nozzle • Never service the heater while it is burning, in operation, hot or plugged-in to avoid WARNING any injury and/ or trouble. • Before starting any service to avoid electric shock, please make sure the heater is shut CAUTION down and that the power cord is disconnected.
  • Page 17: Specifications

    Specifications Model Type VAL6 FIR-X5 Electric Fuse 56 dBA(Lvl.5), 55dBA(Lvl.4), 54dBA(Lvl.3), Type Radiated / Direct-fired Operating Noise Level 53dBA(Lvl.2), 52dBA(Lvl.1) Ignition System High intensity discharge Tip-over Switch Kerosene or Fuel-Oil no heavier than Flame Monitor Fuel No.2(Diesel) Electrical System Protection Safety Systems (High Voltage, Low Voltage, Level 5 : 0.53 GAL/h, 1.72 kg/h (75,100 BTU, 22.0 kW) Prevention of automatic ignition after black-out) Level 4 : 0.50 GAL/h, 1.63 kg/h (71,300 BTU, 20.9 kW) Fuel Consumption Overheat Protection Level 3 : 0.48 GAL/h, 1.55 kg/h (67,600 BTU, 19.8 kW) (Heat Output) Anomaly detection system for fan motor Level 2 : 0.45 GAL/h, 1.46 kg/h (63,800 BTU, 18.7 kW)
  • Page 18: Safety Labels

    Safety labels ● Safety labels provide important information for safe use of the heater. So, please do not remove or soil them. ● If any of the labels is unreadable or removed, please ask your dealer for a new one and replace with the new one. ①...
  • Page 19: Warranty Policy

    VAL6 Series Heaters by SHIZUOKA SEIKI WARRANTY POLICY VAL6 Far Infrared Heater series SHIZUOKA SEIKI warrants that its heaters and component parts will be free from defects in material and work- manship for a period of 24 months from date of purchase, when properly installed, operated, and maintained in accordance with the installation and Maintenance Instructions, safety guides and labels contained with each unit.
  • Page 20: User Registration

    USER REGISTRATION Please enter the following temporary ID & Password and complete the user registration form on our website. By completing your registration, you will obtain your own ID & Password. This allows you to download the owner's manual and/or parts list from our website. ● ID: VAL6 ● Password: shizuoka ● https://www.shizuoka-seiki.co.jp/english/ Manufacturer 4-1 Yamana-cho, Fukuroi 437-8601 Japan Te l + 8 1 - 5 3 8 - 2 3 - 3 9 9 0 F a x + 8 1 - 5 3 8 - 2 3 - 3 1 9 2 Printed in Japan 50361 −...
