QUIK CORP QUIK SPRAY 5SCE Instruction Manual

Dual cab system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
INSTRUCTION MANUAL
QUIK SPRAY
QUIK SPRAY
DUAL CAB
DUAL CAB
SYSTEM
SYSTEM
5SCE • 5TCE
5SCE • 5TCE
T
T
info@quikcorp.com.au
info@quikcorp.com.au
07 5493 8944
07 5493 8944
www.quikspray.com.au
www.quikspray.com.au
F
F
07 5493 8957
07 5493 8957
15 Research Street
15 Research Street
Coolum Beach QLD 4573
Coolum Beach QLD 4573

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QUIK SPRAY 5SCE and is the answer not in the manual?

Questions and answers

Related Manuals for QUIK CORP QUIK SPRAY 5SCE

Summary of Contents for QUIK CORP QUIK SPRAY 5SCE

  • Page 1 INSTRUCTION MANUAL INSTRUCTION MANUAL QUIK SPRAY QUIK SPRAY DUAL CAB DUAL CAB SYSTEM SYSTEM 5SCE • 5TCE 5SCE • 5TCE info@quikcorp.com.au info@quikcorp.com.au 07 5493 8944 07 5493 8944 15 Research Street 15 Research Street www.quikspray.com.au www.quikspray.com.au 07 5493 8957 07 5493 8957 Coolum Beach QLD 4573 Coolum Beach QLD 4573...
  • Page 2 Proudly Australian Owned and Operated info@quikcorp.com.au 07 5493 8944 37 Production Avenue www.quikspray.com.au 07 5493 8957 Warana, QLD 4575...
  • Page 3 Dual Cab Manual Dual Cab Manual KEY FEATURES BERTOLINI PUMPS e r i o i t y t i l o t i n i We have sourced only the best high quality parts to incorporate into our Quik Spray range. POWERED BY HONDA Every engine that sports the ‘Green and Gold Approved’Honda symbol has been “matched”...
  • Page 4 As an Australian owned business your investment has enabled our every success. As a division of Quik Corp, our team have provided over three decades of high-quality agricultural products into the Australian market. From our humble beginnings in 1988, our product range has continually expanded and our innovation sparks from the passion and commitment we have for the agricultural industry.
  • Page 5 Dual Cab Manual Pre-operation checklist Unpacking your unit Product range overview General overview Radio receiver & transmitter Operation instructions Optional quik spray accessories Maintenance Chain and sprocket maintenance Trouble shooting Machine specifications Parts diagrams Warranty...

  • Page 6: Pre-Operation Checklist

    Dual Cab Manual Dual Cab Manual WARNING PLEASE FOLLOW ALL WARNINGS AS FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY, PERMANENT INJURY OR DEATH DO NOT start the unit until you have read this manual carefully. DO NOT let any person near the unit while it is operating. DO NOT start motor with pressure lever in the “press position”...

  • Page 7: Unpacking Your Unit

    Dual Cab Manual Dual Cab Manual UNPACKING YOUR UNIT When unpacking your new Quik Spray unit, please check it thoroughly for any transport damage that may Aerial/s have occured during transit. Check that all parts and Transmitter/s accessories that were ordered, have been included. Instruction Manual/s (Honda, Bertolini, Quik Spray) All accessories as ordered...

  • Page 8: Product Range Overview

    Dual Cab Manual Dual Cab Manual PRODUCT RANGE OVERVIEW TWIN REEL SYSTEM - MODEL 5TCE 5SCE | 5TCE Description Tank lid fill inlet Forklift tyne pockets UV stabilised tank Pump filter Bearing housing and reel bearing 10. Karin pressure controller T-400 nozzle gun holders 11.
  • Page 9 Dual Cab Manual Dual Cab Manual Operation Panel Description Aerials for remote retraction 11. Ball valve tank shut off Bypass return line 12. Low pressure boom kit controller and gauge (Optional Karin pressure controller accessory) Pressure controller gauge 13. Tank drain Safety valve return line 14.

  • Page 10: General Overview

    Dual Cab Manual Dual Cab Manual GENERAL OVERVIEW FIGURE 1 Filter housing and removal nut. To clean filter with water in the tank, turn valve OFF before loosening filter nut. Ensure O-ring is seated properly before tightening nut. FIGURE 2 PA430 Karin pressure gauge.
  • Page 11 Dual Cab Manual Dual Cab Manual GENERAL OVERVIEW FIGURE 4 Radio reciever box. This box contains the electrical components for the remote controlled retraction operation. For optimal radio control range and correct machine operation, ensure the 12 volt battery’s voltage output is 12.5 volts.
  • Page 12 RADIO RECEIVER & TRANSMITTER Quik Spray 5SDE 9SDE Manual Quik Spray 5SDE 9SDE Manual Dual Cab Manual 915 MHz RADIO RECEIVER & TRANSMITTER RADIO RECEIVER & TRANSMITTER This transmitter (remote) is the control module that is used on the following Quik Spray models 915 MHz 5SDM 5SDE...
  • Page 13 Quik Spray 9TBE Manual Quik Spray 9TBE Manual Dual Cab Manual RADIO RECEIVER & TRANSMITTER 915 MHz RADIO RECEIVER & TRANSMITTER RADIO RECEIVER & TRANSMITTER This transmitter (remote) is the control module that is used on the following Quik Spray models 915 MHz 915 MHz 9TBE...
  • Page 14 Dual Cab Manual Dual Cab Manual OPERATION INSTRUCTIONS TURNING ON UNIT Ensure pre-operation checklist has been completed. Fill tank to desired level. If optional “Venturi Fast Filler” is fitted to your unit, please refer to page 20 of this manual. Never fill tank with the lid closed.
  • Page 15 Dual Cab Manual Dual Cab Manual OPERATION INSTRUCTIONS SET PRESSURE & SPRAY When your unit arrives from the factory, the pressure controller is set at BYPASS. The pressure handle will be OUT. To increase the pressure, you will need to wind the handle IN. With the motor running, switch the controller lever to PRESS (PRESSURE).
  • Page 16 Dual Cab Manual Dual Cab Manual OPERATION INSTRUCTIONS TURNING ON TRANSMITTER Turn radio ON/OFF power switch to the ON position. Be aware of strong retraction! Be prepared to release the Assign each operator with a transmitter. If you are using transmitter button when approaching the reel/s as personal a twin reel system, be sure that each operator is carrying injury or damage to the unit may occur.
  • Page 17 Dual Cab Manual Dual Cab Manual OPERATION INSTRUCTIONS FILLING TANK WITH OPTIONAL “FAST FILLER” Connect suction hose to floating filter and tank mounted When the tank has been filled, remove the suction hose “Fast-Filler”. from the water supply while the pump is still running to Place floating filter into water supply.
  • Page 18 Dual Cab Manual Dual Cab Manual OPTIONAL QUIK SPRAY ACCESSORIES There are a variety of accessories you can add to your Quik Spray unit. Aerial springs Lifting bars and forklift mounts T400 spray gun Boomless Jet with mounting bracket Quik Flush pump and tank wash concentrate Quik Spray Belt - For pulling out hose by using your waist Tiny Tacho hour reader for motor Galvanized framework...

  • Page 19: Maintenance

    Dual Cab Manual MAINTENANCE DAILY Clean inline filter (Fig. 2). Check oil level in pump. Check all drive belts for tension and wear Check oil level in engine. Check all chain drives (Refer pg. 23) Check all hoses and fittings for leaks. 20 HOURS Check water in the 12 volt battery (if fitted).
  • Page 20 Dual Cab Manual CHAIN AND SPROCKET MAINTENANCE Chain maintenance for all chain sizes should be lubricated every 3 - 6 months as required. Check all chains for tension and wear. This will be dependent on the amount of usage. Be sure to replace when indicated. 40-1 CHAIN (Standard clutch drive chain on all fully integrated Quik Spray systems) Lubricate with TAC2 or similar chain lubrication and remove run off.

  • Page 21: Troubleshooting

    Dual Cab Manual Dual Cab Manual TROUBLE SHOOTING PUMPS AND PRESSURE CONTROLLER PROBLEM PROBABLE CAUSE REMEDY Pump does not deliver If good flow is being achieved from bypass pressure back to the tank Sting pressure regulator not set for pressure Set the lever to PRESS and adjust the handle Damaged or worn seat or spring in pressure...
  • Page 22 Dual Cab Manual Dual Cab Manual TROUBLE SHOOTING PUMPS AND PRESSURE CONTROLLER contd. PROBLEM PROBABLE CAUSE REMEDY If hoses are not jumping pressure Damaged or worn seat or spring in the Replace pressure regulator Sticking pressure regulator slide Remove slide and lubricate with marine grease Spray nozzle/s worn, missing or exceeding Replace nozzle/s with correct size...
  • Page 23 Dual Cab Manual Dual Cab Manual TROUBLE SHOOTING RADIO ELECTRICS AND REEL REWIND PROBLEM PROBABLE CAUSE REMEDY Reel brake and adjustment too tight Adjust brake (Located behind clutch) Reel rewind speed too slow Engine revs too low Increase engine revs to 3/4 revs or 2400RPM Drive belts slipping Adjust belts with belt tensioner.

  • Page 24: Machine Specifications

    Dual Cab Manual Dual Cab Manual MACHINE SPECIFICATIONS 5SDM 5SDE 9SDE 9TBE 9TDE Reels Horsepower Honda Motor GX160 GX160 GX270 GX270 GX270 U1 HXU U1 HXE8 U HKS8 UT QSE8 U HKS8 Bertolini Pump PA330 PA330 PA530 PA530 PA530 Litres p/min (max) PSI (max) (max working)

  • Page 25: Parts Diagrams

    Dual Cab Manual Dual Cab Manual PARTS DIAGRAMS T-400 NOZZLE PARTS EXPLOSION...
  • Page 26 Dual Cab Manual Dual Cab Manual PARTS DIAGRAMS STING PRESSURE CONTROLLER PARTS EXPLOSION...
  • Page 27 Dual Cab Manual Dual Cab Manual PARTS DIAGRAMS PUMP PA330 PARTS EXPLOSION...
  • Page 28 Dual Cab Manual Dual Cab Manual PARTS DIAGRAMS PUMP PA530 PARTS EXPLOSION...
  • Page 29 Dual Cab Manual Dual Cab Manual PARTS DIAGRAMS PUMP PA730 PARTS EXPLOSION...

  • Page 30: Warranty Policy

    Dual Cab Manual Dual Cab Manual WARRANTY POLICY This document sets out the warranties that are given by Quik Corp Pty Ltd (ABN 18 081 235 556) in relation to the Product purchased from or manufactured by Quik Corp. 1. Definitions 1.1.
  • Page 31 6.1. If the Product has been acquired for the purposes of a business, then pursuant to section 43(2) of the Consumer Guarantees Act 1993 (“CGA”) it is agreed that provisions of the CGA do not apply. To the fullest extent permitted by law in New Zealand, Quik Corp excludes any liability for any direct or indirect loss or damage of the provisions of the CGA do not apply.

  • Page 32: Your Notes

    YOUR NOTES ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________...

  • Page 33: Warranty Process

    WARRANTY PROCESS Please fill out form on our website at https://quikspray.com.au/warranty-claim-submission/ Before submitting a claim, please ensure the issue encountered is covered under our Warranty Policy, you can access this policy by clicking the link below. To complete the following form, you will need the following details at hand: •...

This manual is also suitable for:

Quik spray 5tceQuik spray 5sdeQuik spray 9sdeQuik spray 9tde
