USER MANUAL
CLASS 120 KISTOCK
KT 120 – KH 120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLASS 120 KISTOCK and is the answer not in the manual?

Questions and answers

Related Manuals for sauermann CLASS 120 KISTOCK

Summary of Contents for sauermann CLASS 120 KISTOCK

  • Page 1 USER MANUAL CLASS 120 KISTOCK KT 120 – KH 120...

  • Page 3: Table Of Contents

    Table of contents 1 SAFETY INSTRUCTIONS..............................4 1.1 Precautions for use............................... 4 1.2 Symbols used............................... 4 2 PRESENTATION OF THE DEVICE............................ 5 2.1 Use..................................5 2.2 Applications................................. 5 2.3 Description of the device............................5 2.4 Description of the keys............................5 2.5 PC connection..............................5 2.6 Fixation................................

  • Page 4: Safety Instructions

    1 SAFETY INSTRUCTIONS 1.1 Precautions for use Please always use the device in accordance with its intended use and within parameters described in the technical features in order not to compromise the protection ensured by the device. 1.2 Symbols used For your safety and in order to avoid any damage of the device, please follow the procedure described in this user manual and read carefully the notes preceded by the following symbol: The following symbol will also be used in this user manual:...

  • Page 5: Presentation Of The Device

    2 PRESENTATION OF THE DEVICE 2.1 Use The KT 120 and KH 120 data loggers of the HVAC range allow the internal measurement of temperature only (KT 120) or of temperature and humidity (KH 120). This class of devices is dedicated to the food transport. The devices have a male USB plug and an integrated software in PDF format which enables to download and configure the data logger without specific software.

  • Page 6: Fixation

    Fixation The KT 120 and KH 120 KISTOCK data loggers have a magnetic mounting, so you can fix it easily. Magnetic mounting 3 TECHNICAL FEATURES 3.1 Devices KT 120 KH 120 Units displayed °C, °F °C, °F, %RH Resolution 0.1°C, 0.1°F 0.1°C, 0.1°F, 0.1%RH External input USB connector...

  • Page 7: Housing

    3.2 Housing Dimensions 100 x 42.5 x 15.9 mm Weight 53 g 1-line LCD screen Display Dimensions of screen: 32 x 25.5 mm 1 OK key Control 1 Selection key Compatible with food industry environment Material ABS housing IP65: KT 120 Protection IP20: KH 120 PC communication...

  • Page 8: Use Of The Device

    4 USE OF THE DEVICE 4.1 Display DATASET is finished Indicates that one value is being recorded. It flashes: the DATASET did not start already. Flashing slowly: DATASET is between 80 and 90 % of the storage capacity. FULL Flashing quickly: DATASET is between 90 and 100 % of the storage capacity. Constant: storage capacity full.
  • Page 9 Device Action Type of start/stop Illustration state selected used generated Start: indifferent During 3 Dataset stop seconds During 3 seconds Stop: by key Start: indifferent Dataset in progress Group change (groups 2 and Stop: indifferent Start: indifferent Groups scrolling (groups 1, 2 and 3)* Stop: indifferent Indifferent...

  • Page 10: Groups Organisation

    4.3 Data logger configuration with the integrated PDF file The class 120 KISTOCK data loggers have an integrated PDF file which allows to configure quickly and easily the data logger. Therefore, you can directly configure your data logger without opening the KILOG software.
  • Page 11 The integrated configuration file opens: The file header indicates the device name and serial number. Button which allows to load a previous configuration, saved before on the computer. “General information”  Displays the name of the dataset and the possible comments. “Configuration”...
  • Page 12 • Configuration Recorder Active screen: tick “Yes” to activate the screen display or “No” to deactivate it. Management DST: for an automatic management of DST, tick “Yes” or tick “No” to deactivate it. If you choose “Yes”, the “Next time change” fields become accessible. Dates and times of the next time change are proposed by default.

  • Page 13: Data Logger Download With Pdf Report Edition

    4.4 Data logger download with PDF report edition ➢ Plug the class 120 KISTOCK data logger on an USB plug of the computer*. Wait a few seconds, then the following window opens: ➢...

  • Page 14: Configuration, Data Logger Download And Data Processing With The Kilog Software

    Example of report: The header State indicators: indicates the date  : Alarm activated and time of the report  : Alarm deactivated edition  : Alarm OK Device references   : Alarm triggered Serial number and The background firmware version information indicates The channel the dataset name and statistics indicate...

  • Page 15: Device Maintenance

    5 DEVICE MAINTENANCE 5.1 Replace the battery With 500 days to 3 years* battery life, KISTOCK guarantees long-term measurement. To replace the battery: Button battery CR 2450 1. Unlock the battery hatch with a screwdriver or a coin. 2. Turn towards the left until the marker aligns in front of the opened padlock symbol. 3.

  • Page 16: Calibration

    Accessories Part numbers Illustrations 1 button battery CR2450 KBL-2450 KILOG Lite Free software to download on the Sauermann website sauermanngroup.com KILOG-LITE Allows the data download (graphics and points statement) and the data logger configuration. KILOG software KILOG software enables to configure, save and process your data in a very simple KILOG-3-N way.
  • Page 17 TROUBLESHOOTING...
  • Page 20 NT_Kistock KT120 - KH120_EN – 12/07/23 – Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
