Note PC
NP750XFG
NP750XFH
NP750XFT
NP754XFG
For Customer
1. Precautions
CONTENTS
2. Exploded View and Parts List
3. SW Update
4. Disassembly and Assembly
5. User Test
Notice: All functionality, features, specifications,
and other product information provided in this
document, including but not limited to, benefits,
design, pricing, components, performance,
availability, and capabilities of the product are
subject to change without notice. Samsung
reserves the right to alter this document or the
product described herein at anytime, without
obligation to provide notification of such
changes.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NP750XFG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung NP750XFG

Summary of Contents for Samsung NP750XFG

  • Page 1 Samsung reserves the right to alter this document or the product described herein at anytime, without obligation to provide notification of such...

  • Page 2: Repair Precaution

    Any damage to the product caused by an attempt to repair the product by any person other than a Samsung certified service provider will not be covered by the warranty.

  • Page 3: Exploded View And Parts List

    2. Exploded View and Parts List 2-1. Exploded View Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorisation is strictly prohibited.
  • Page 4 W4016 BA83-04829A SCREW W4039 BA83-02118A DDR_SHIELDING X0007 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorisation is strictly prohibited.

  • Page 5: Samsung Update

    3-1. Samsung Update Install and update Samsung apps and drivers on the computer easily and conveniently. This app enables the user to search for or download the BIOS, drivers, and apps over the internet. Keep the computer performing better and more stably with Samsung Update.

  • Page 6: Samsung Recovery

    [Notice]  The Samsung Recovery app may not be provided in models with less than 64 GB of storage. If you cannot access the Samsung Recovery app, refer to 3-3. Windows recovery function. ...
  • Page 7 Follow the on-screen instructions to complete the backup. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorisation is strictly prohibited.
  • Page 8 Select Create a factory state disk or Create a disk copy. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorisation is strictly prohibited.

  • Page 9: Windows Recovery Function

    The data on the disk is copied to the new disk. 3-3. Windows recovery function If the Samsung Recovery app is not supported by the computer, reinstall Windows using the recovery function of Windows. [Caution] Reinstalling Windows will erase all data saved on the computer. Back up apps and personal data to an external storage device before reinstalling Windows.
  • Page 10 For models with the Samsung Recovery app, the HDD capacity representation in Windows may be smaller than the actual capacity because the Samsung Recovery app uses a hidden area of 5–20 GB of the HDD to save the recovery image, and that hidden area is not counted towards the total size available to Windows.
  • Page 11 Tool for disassembling the Connector and other parts Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 12 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 13 - As the rear can be damaged by excessive force, be careful to prevent damage. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 14 And then remove SSD the bracket. Step 2 Remove the SSD. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 15 Step 2 Remove the left and right speaker. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 16 Pull out the FAN cable from connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 17 Step 1 Thermal module (by (+) screw driver). Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 18 Be careful not to damage any of the components near the connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 19 Remove the DDR-shielding and USB-shielding Step 3 by tweezers. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 20 Remove the screw 2ea and then remove the Step 2 Sub PBA. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 21 2. Remove screw 4ea and then remove the touchpad Assy (by (+) screw driver). Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 22 Only the LCD Assy can be replaced. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 23 Align the Power button with the keyboard. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 24 Step 1 2. Paste the conductive tape. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 25 Assemble the screw 5ea (by (+) screw driver). Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 26 Step 2 Connect the FRP FPCB connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 27 Step 4 2. Connect the LCD cable connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 28 Step 1 screw 4ea (by (+) screw driver). Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 29 Step 2 Connect the FAN cable connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 30 2. Assemble the cable to the connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 31 Step 3 screw 4ea (by (+) screw driver). Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 32 Step 2 Assemble the battery cable to connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 33: Rear Assembly

    Step 3 Assemble rubber foots (4ea) on Rear. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 34 5. User Test Samsung PC Diagnostics This application provides the diagnostic features to help you to quickly test the hardware components of Samsung PCs and easily check hardware issues. [Notice]  Your PC must run the default OS which is provided by Samsung PC.
  • Page 35 Check the test results of the item which has completed the diagnostic test on the main screen. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorisation is strictly prohibited.
  • Page 36 ⓒ Samsung Electronics Co.,Ltd This Service Manual is a property of Samsung Electronics Co.,Ltd. Any unauthorised use of Manual can be punished under applicable 2025. 06. Rev 1.1 International and/or domestic law.
  • Page 37 LPDDR4x USB3.2 Type-A Port 15.6 IPS LCD Micro SD MB To DB PA8407 Connector HDMI 1.4 Finger Printer Re-Retimer Head Phone Touch PaD Raptor Laker P 15W SPK_L Hall Sensor Codec ALC 256N SPK_R ITE 5571 WiFi 6 & BT5.2 KeyBoard W25R128JVSINT USB3.2 Type-A Port 1...
