JVC GR-SXM26EA Service Manual

COMPACT VHS CAMCORDER
GR-SXM26EA/46EA
/260A-S/460A-S/760A-S
Regarding service information other than these sections, refer to the GR-SXM26EG, SXM46EG service manual (No. 86543).
Also, be sure to note important safety precautions provided in the service manual.
SPECIFICATIONS
(The specifications shown pertain specifically to the model GR-SXM26EA/46EA)
General
Format : S-VHS/VHS PAL standard
Power source : DC 6.0 V
Power consumption
LCD monitor* off, viewfinder on : 4.2 W
LCD monitor* on, viewfinder off : 4.6 W
LCD monitor* on, viewfinder on : 5.2 W
Video light* : 3.0 W
Signal system : PAL-type
Video recording system
Luminance : FM recording
Colour : Converted sub-carrier direct recording
Conforms to VHS standard
Cassette :
Tape speed
SP : 23.39 mm/sec.
LP : 11.70 mm/sec.
Recording time (max.)
SP : 60 minutes
LP : 120 minutes (with EC-60 cassette)
Operating temperature : 0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Weight : Approx. 980 g (GR-SXM46EA)
Approx. 970 g (GR-SXM26EA)
Dimensions (W x H x D) : 198 mm x 119 mm x 99 mm
(with the LCD monitor* closed and with the viewfinder fully tilted
downward)
Pickup : 1/4" format CCD
Lens : F1.6, f = 3.9 mm to 62.4 mm, 16:1 power zoom lens with auto iris
and macro control, filter diameter 40.5 mm
Viewfinder : Electronic viewfinder with 0.5" black/white CRT
White balance adjustment : Auto/Manual adjustment
LCD monitor : 3" diagonally measured, LCD panel/TFT active matrix system
(GR-SXM46EA)
2.5" diagonally measured, LCD panel/TFT active matrix system
(GR-SXM26EA)
Speaker : Monaural
SPECIFICATIONS
Camcorder
/ cassette
This service manual is made from all recycled paper.
©
COPYRIGHT 2000 VICTOR COMPANY OF JAPAN, LTD.
625
Connectors
JLIP : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
: 1 V (p-p), 75 Ω unbalanced, analogue output (via Video output
Video
connector)
Audio : 300 mV (rms), 1 kΩ analogue output (via Audio output connector)
: Y : 1 V (p-p), 75 Ω, analogue output
S-Video
C : 0.29 V (p-p), 75 Ω, analogue output
AC Power Adapter/Charger AA-V16EA
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Power consumption : 23 W
Output
Charge : DC 8.5 V , 1.3 A
VTR : DC 6.3 V , 1.8 A
Charging system : Constant current, peak detection, timer controlled
Dimensions (W x H x D) : 125 mm x 42 mm x 68 mm
Weight : Approx. 270 g
Cassette Adapter C-P7U
Dimensions (W x H x D) : 188 mm x 25 mm x 104 mm
Weight : Approx. 240 g
Accessory : "R6 (AA)"-size battery x 1
Optional Accessories
•Battery Packs BN-V12U, BN-V20U, BN-V856U
•Car Battery Charger BH-V3E
•Compact S-VHS ( ) Cassettes SE-C45/30
•Compact VHS ( ) Cassettes EC-60/45/30
•Remote Control Unit RM-V700U
•Active Carrying Bag CB-V7U
Some accessories are not available in some areas. Please consult your nearest JVC dealer for details on
accessories and their availability.
Specifications shown are for SP mode unless otherwise indicated.
E & O.E. Design and specifications subject to change without notice.
VHS
PAL
No. 86554
March 2000
