Solid state drive

NOTE: You computer supports two SSD configurations.
● Single SSD configuration: One SSD is installed in either of the two slots.
● Dual SSD configuration: SSDs are installed in both slots.
To upgrade from a single SSD configuration to a dual configuration by adding an SSD, users must install SSD heatsinks on
both SSDs to ensure optimal performance. These heatsinks must be purchased separately.
Removing the M.2 2230 solid-state drive in a single SSD
configuration
Prerequisites
1. Follow the procedure in
2. Remove the side cover.
About this task
The following images indicate the location of the M.2 2230 solid-state drive and provide a visual representation of the removal
procedure.
Figure 16. Removing the 2230 solid-state drive
42 Removing and installing Customer Replaceable Units (CRUs)
Before working inside your computer.
