LCD MONITOR

quick start guide

400MX-2 400MXn-2 460MX-2 460MXn-2


Advertisement

   Related Manuals for Samsung 400FP-2 - SyncMaster - 40" LCD Flat Panel Display

   Summary of Contents for Samsung 400FP-2 - SyncMaster - 40" LCD Flat Panel Display

  • Page 1: Lcd Monitor

    LCD MONITOR quick start guide 400MX-2 400MXn-2 460MX-2 460MXn-2...

  • Page 2

    Introduction Package Contents Note Please make sure the following items are included with your LCD Display. If any items are missing, contact your dealer. Contact a local dealer to buy optional items. Note This stand is not for the Floor Standing Type. Checking the Contents of the Package Remove the lock from the package box, as shown in the figure above.

  • Page 3: Lcd Display

    Introduction Unpacking LCD Display Manuals Warranty Card Quick Setup Guide User's Guide (Not available in all locations) MagicInfo Software CD MagicInfo Manual CD (Applicable to the FPn-2 model only) Cables Power Cord Others HDD Cover Batteries (AAA X 2) Remote Control (Applicable to the FPn-2 model (Not available in all locations) only)

  • Page 4

    Introduction Ferrite Core for Lan Cable BNC to RCA Adaptor Jack (Applicable to the 46-inch network model only.) Sold separately D-Sub Cable DVI Cable Wall Mount KIT LAN Cable NetWork Box TV tuner box (Applicable to the FPn-2 model (Applicable to the FP-2 model only) only) Semi Stand KIT...

  • Page 5

    Introduction Your LCD Display Front MENU button [MENU] Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu or return to the previous menu. Navigate buttons (Up-Down buttons) Moves from one menu item to another vertically or adjusts selected menu values.

  • Page 6

    Introduction Note • This is available when a TV tuner box is installed. Power button [ Use this button for turning the LCD Display on and off. Power indicator Shows PowerSaver mode by blinking green Note See PowerSaver described in the manual for further information regarding power saving functions.

  • Page 7

    Introduction RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port DVI / PC / HDMI IN [DVI/PC/HDMI AU- DIO IN] (PC/DVI/HDMI Audio Connection Terminal (Input)) DVI / PC / HDMI IN [HDMI] Connect the HDMI terminal at the back of your LCD Display to the HDMI terminal of your digital output device using a HDMI ca- ble.

  • Page 8

    Introduction AV AUDIO OUT [L-AUDIO-R] (LCD Dis- play Audio Connection Terminal (Output)) BNC/COMPONENT OUT[R/PR, G/Y, B/ PB, H, V] (BNC/Component Connection Terminal (Output)) BNC (Analog PC) Connection: connecting the R, G, B, H, V ports. Component Connection: connecting the PR, Y, PB ports.

  • Page 9

    Introduction Kensington Lock The Kensington Lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may differ from the illustra- tion depending on the manufacturer.

  • Page 10

    Introduction POWER Number Buttons button + VOL - MUTE TV/DTV MENU INFO COLOR BUTTONS TTX/MIX STILL AUTO S.MODE LOCK SOURCE ENTER/PRE-CH CH/P D.MENU GUIDE RETURN Up-Down Left-Right buttons EXIT MagicInfo P.MODE DUAL/MTS SWAP Turns the product On. POWER Turns the product Off. 3.

  • Page 11

    Introduction The "-" button operates only for DTV. It is used to select MMS (multi-channel) for a DTV. 4. DEL button 5. + VOL - Adjusts the audio volume. Pauses (mutes) the audio output temporarily. This is dis- MUTE played on the lower left corner of the screen. The audio resumes if MUTE or - VOL + is pressed in the Mute mode.

  • Page 12

    Introduction 22.GUIDE Electronic Program Guide (EPG) display. Returns to the previous menu. RETURN 24. Up-Down Left-Right but- Moves from one menu item to another horizontally, vertically tons or adjusts selected menu values. Exits from the menu screen. EXIT Selects SRS TruSurround XT mode. 27.MagicInfo MagicInfo Quick Launch Button.

  • Page 13

    Introduction Mechanical Layout(400FP-2.400FPn-2) Mechanical Layout...

  • Page 14: Installation Vesa Bracket

    • At least 2 persons are needed in order to move the LCD Display. • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion.

  • Page 15

    • Contact a technician for installing the wall bracket. • SAMSUNG Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. • This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.

  • Page 16

    Introduction Insert and tighten the Captive Screw in the direction of the arrow. When done, mount the wall bracket on the wall. There are two hinges(left and right). Use the correct one. Captive Screw Wall Bracket Hinge (Left) Hinge (Right) Before drilling into the wall, check if the length between the two locking holes at the back of the product is correct.

  • Page 17

    Introduction To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) Remove the 4 screws on the back of the product. Insert the screw B into the plastic hanger.

  • Page 18

    Introduction Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket. LCD Display Wall Bracket Wall...

  • Page 19

    Introduction Make sure to use the top center, and not the leftor the right side of the product to adjust the angle. Mechanical Layout(460FP-2, 460FPn-2) Mechanical Layout...

  • Page 20

    • At least 2 persons are needed in order to move the LCD Display. • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion.

  • Page 21

    • Contact a technician for installing the wall bracket. • SAMSUNG Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. • This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.

  • Page 22

    Introduction Wall Bracket Assembly Note There are two hinges(left and right). Use the correct one. Insert and tighten the Captive Screw in the direction of the arrow. When done, mount the wall bracket on the wall. There are two hinges(left and right). Use the correct one. Captive Screw Wall Bracket Hinge (Left)

  • Page 23

    Introduction Check the installation diagram and mark the drill points on the wall. Use the 5.0 mm bit to drill holes deeper than 35 mm. Fix each anchor in the corresponding hole. Match each of the brackets and hinge holes to the corresponding anchor holes and insert and tighten the 11 screws A.

  • Page 24

    Introduction Tighten the 4 screws in step 2 (plastic hanger + screw B)to the rear holes of the product. Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket.

  • Page 25

    Introduction Make sure to use the top center, and not the leftor the right side of the product to adjust the angle.

  • Page 26: Connecting A Computer

    Connections Connecting a Computer Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When un-wiring the earth lead, make sure to disconnect the AC power in advance.

  • Page 27: Connecting To Other Devices

    Note • Turn on both your computer and the LCD Display. • Contact a local SAMSUNG Electronics Service Center to buy optional items. Connecting to Other devices Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power.

  • Page 28: Connecting A Dvd Player

    Connections Select AV using the SOURCE . Note The LCD Display has AV connection terminals to connect AV input devices like DVDs, VCRs or Camcorders. You may enjoy AV signals as long as the LCD Display is turned on. Connecting to a Camcorder Locate the AV output jacks on the camcorder.

  • Page 29

    Connections Connect a set of audio cables between the AV AUDIO IN [L-AUDIO-R] on the LCD Dis- play and the AUDIO OUT jacks on the DVD player. Connect a Component cable between the BNC/COMPONENT IN - P , Y, P port on the LCD Display and the P , Y, P...

  • Page 30: Connecting Using A Dvi To Hdmi Cable

    Connections Note • For an explanation of Component video, see your Set Top Box owner's manual. Connecting Using a HDMI Cable Note • Input devices such as digital DVD are connected to the HDMI terminal of the LCD Display using the HDMI cable. •...

  • Page 31: Connecting A Usb Device

    Connections Note • Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and AUDIO OUT [L-AUDIO-R] on LCD Display. Connecting a LAN Cable Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power.

  • Page 32

    Connections Note You can connect USB devices such as a mouse or keyboard. (Applicable to the FPn-2 model only)

  • Page 33: Troubleshooting

    Troubleshooting Self-Test Feature Check Note Check the following items yourself before calling for assistance. Contact a Service Center for problems that you cannot solve by yourself. Self-Test Feature Check Turn off both your computer and the LCD Display. Unplug the video cable from the back of the computer. Turn on the LCD Display.

  • Page 34: Check List

    Do not use benzene, thinner or other flammable sub- stances, or a wet cloth. • We recommend that a SAMSUNG cleansing agent is used to prevent damage to the screen. 2) Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel) smoothly.

  • Page 35

    Troubleshooting Check if the signal cable between the computer and the LCD Display is securely con- nected. (Refer to Connecting a Computer) Problems related to the Screen Note Problems related to the LCD Display screen and their solutions are listed. The screen is blank and the power indicator is off.

  • Page 36

    Troubleshooting The screen color is inconsistent. Adjust color using Custom under OSD Color Adjustment menu. The color image is distorted by dark shadows. Adjust color using Custom under OSD Color Adjustment menu. The color white is poor. Adjust color using Custom under OSD Color Adjustment menu. The Power Indicator blinks.

  • Page 37

    Troubleshooting Check the polarities (+/-) of the batteries. Check if the batteries are empty. Check if the power is on. Check if the power cord is securely connected. Check if a special fluorescent or neon lamp is on in the vicinity. Problems related to MagicInfo Note Making a Bootable USB Flash Disk.

  • Page 38

    Troubleshooting Set the resolution in the Control Panel !’ Appearance and Themes !’ Display !’ Screen Saver. Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer Manual). Windows ME/2000: Set the resolution at the Control Panel !’ Display !’ Screen Saver. Set the function in the BIOS-SETUP of the computer.
