Summary of Contents for ONKRON TS2551
- Page 1 TS2551 Max weight 30.5 kg 67.4 lbs Height adjustment 900 - 1500 mm 32.5" - 59 " VESA 100 х 100 ~ 600 х 400 mm ASSEMBLY MANUAL 32" - 60" Mobile TV stand Мобильная стойка для ТВ...
- Page 2 Read the entire instruction manual before you start installation and assembly. If you have any questions regarding any of the instructions or warnings, please contact your local distributor for assistance. CAUTION: Use with products heavier than the rated weights indicated may result in instability causing possible personal injuries and product failure. •T V stands must be assembled as specified in assembly instructions.
- Page 3 A1 M5x25 (x4) A2 M6x20 (x2) B1 M6x25 (x4) B2 (x1+1) C1 M8x25 (x4) С2 M5x12 (x2) F1 M8x50 (x4) D2 M6x15 (x4) D1 16x6.2x1.5mm (x4) E2 S5(x1) E1 17x8.2x12mm (x4) F2 16x6.2x1.5(x4)
- Page 4 Installation of the wheels to the base Установка колёс на базу Lock castors before assembling Зафиксируйте колёса перед началом сборки...
-
Page 5: Installation
Support column installation Установка колонны основания на базу 1-1. 1-1. 1-2. The direction of the column should match with the direction shown on the diagram. (direction holes are measured inside) Направление колонн должно соответствовать направлению, показанному на чертеже 1-3. IMPORTANT NOTE! Ensure that the screws are tightened securely and vertical column don't wave or tilt Убедитесь, что... - Page 6 Installation of interface Установка VESA панели 1-1. 1-1. 1-2.
- Page 7 Rail installation to the TV Установка направляющих к ТВ CAUTION: Use the supplied spacers in case screws are longer than mounting holes E1 D1 ВАЖНО: A1/B1+D1+E1; Во избежание повреждения ТВ A1/B1+D1; используйте пластиковую шайбу C1/F1+E1 M8x25mm(C1) M8x50mm(F1) M5x25mm(A1) M6x25mm(B1)
- Page 8 Attaching the Display to the VESA panel Установка телевизора на стойку Make sure that the hight adjusting knob is Warning: securely locked, before mounting your Two people are required to liſt the flat panel TV on the stand in to the stand Перед...
- Page 9 AV shelf assembly and installation Сборка и установка полки для техники Position of the AV shelves may be optional Вы можете выбрать 2 варианта установки полок 1. Shelf is mounted with side margins UP - for smaller accessories Установка полки для устройств с ограничителем...
- Page 10 Cables and wires installation Прокладывание проводов в кабель-канале...
- Page 12 Мы надеемся, что Вы довольны приобретённым продуктом, и он не вызвал проблем при сборке. Если Вам понравился продукт, то просим оставить нам свой отзыв. If you have issues with your products, please email us at sale@onkron.de for EU / sale@onkron.us for US or call +494029996807 for EU / +13159682278 for US and we help you as soon as we can Если...
