- Page 1 EAG-11K Installation & Operation Manual Asymmetric 2023 205 S Westgate Dr 27407...
- Page 2 CONTENTS 13-38 39-40 43-44 45-46 Power Unit View ..................51-53 Electrical wiring Instructions ..............................
-
Page 3: Product Description
PLEASE READ THE ENTIRE MANUAL BEFORE ANY INSTALLATION AND OPERATION OF LIFT. PRODUCT DESCRIPTION The EAG11K 11,000 lbs. capacity handle Please read the safety procedures and operation instructions in this manual before operating the lift. Proper installation is very important. Keep this operation manual near the machine at all times. Make sure ALL USERS read and fully understand this manual. - Page 4 TERMS AND CONDITIONS Eagle's Equipment Please read these terms of service carefully. policy. Eagle Equipment EAGLE Risk of Loss / Freight / Shipping EAGLE ownerships of these goods transfers to the customer when they leave our dock EAGLE Delivery, Unloading and Freight Damage...
- Page 5 EAGLE within three days of delivery EAGLE EAGLE Shortages: within 3 days of delivery. Installation EAGLE EAGLE EAGLE Warranties Exclusions: Other limitations:...
- Page 6 Returns and Replacements eagleequip EAGLE EAGLE EAGLE EAGLE EAGLE INSPECT YOUR LIFT UPON DELIVERY. NOTE ANY DAMAGE ON DELIVERY RECEIPT. SHIPPING AND DAMAGE CLAIMS All shipments must be inspected immediately upon receipt. Concealed damage must be reported to the freight company within three (3) days of delivery.
- Page 7 INTRODUCTION PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE INSTALLING OR OPERATING THIS LIFT. RECORD THE MODEL NUMBER AND THE SERIAL NUMBER THIS INFORMATION WILL BE REQUIRED 1-800-336-2776...
- Page 8 Shipments must be inspected immediately upon receipt. External damage must be noted on the bill of lading. Concealed damages must be reported to the freight company within three days of delivery. Shortages must be reported to Eagle Equipment within three days of delivery: 1-800-336-2776.
-
Page 9: Before Installation
BEFORE INSTALLATION Teflon tape - 12' Ladder SHIPMENT CHECKLIST long symmetrical and 2 asymmetrical... -
Page 10: Owner/Employer Responsibilities
OWNER/EMPLOYER RESPONSIBILITIES Safety Requirements for Operation, Inspection and Maintenance... -
Page 11: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ THESE SAFETY INSTRUCTIONS THOROUGHLY DANGER: WARNING:... -
Page 12: Power Unit
PREPARATION If it is installed outdoors, your Eagle Equipment warranty is null and void. Model # EAG-11 and asymmetrical symmetrical 11,000 STRUCTURAL PERFORMANCE POWER UNIT NOTE:... -
Page 13: Control System
CONTROL SYSTEM INSTALLATION INSTRUCTIONS PLEASE READ INSTRUCTIONS BEFORE OPERATING THE LIFT. STEP ONE – UNPACKING CAUTION: When cutting bands. Use gloves and eye protection. STEP TWO – SITE SELECTION indoor use only 13-feet is the minimum height requirement to install and service this lift. - Page 14 Assembly Process...
- Page 15 Install hydraulic cylind Connect the straight fi tting to the cylinders inside the carriages. Offside Power Side Column Column Use Tefl on tape to seal pipe threads. Fitting towards the hole of the column...
-
Page 38: Site Layout
GROUNDWORK FOUNDATION DRAWING 17-3/16 in. 17-3/16 in. 6 in. min. 137-1/2'' in. Figure 1 Column Layout This lift must be installed on concrete, where the concrete is at least 5" thick, has a compressive strength of 3000 PSI and has been cured for a minimum of 30 days. Do not install this lift on any surface other than concrete. - Page 39 on page 20 Figure 3 Column Spacing...
-
Page 40: Pre-Operation
PRE-OPERATION RAISING THE LIFT FOR THE FIRST TIME OPERATION Always lower the lift onto the safety stops before working on, under or near the vehicle. LOWERING THE LIFT... -
Page 42: Daily Maintenance
MAINTENANCE SCHEDULE MAINT WARNING: securely locked out Practice good housekeeping. DAILY MAINTENANCE MONTHLY MAINTENANCE... -
Page 43: Annual Maintenance
ANNUAL MAINTENANCE For all other maintenance, if any deficiencies are noted, or any parts need to be replaced, please contact a qualified repair contractor or Eagle Equipment at 800.336.2776. -
Page 44: Troubleshooting
TROUBLE SHOOTING Problem Possible Cause Possible Solution Instructions load... - Page 45 TROUBLE SHOOTING Problem Possible Cause Possible Solution Instructions valve load loaded...
- Page 46 TROUBLE SHOOTING Problem Possible Cause Possible Solution Instructions...
-
Page 47: Specifications
SPECIFICATIONS Assymetric 81'' 137.5'' 96'' 31'' -43-1/2'' 41''-60'' 110'' 2750 146''... - Page 48 POWER UNIT Push Button To Raise Fill Cap Release Handle Oil Outlet Figure 7 Figure 7 - SAE 10 (ISO Grade AW32) is the only hydraulic fluid recommended for the lift. Use of other fluids may damage the hydraulic equipment or cause the lift to fail. WARNING:...
- Page 49 Exploded View...
- Page 52 NOT USED NOT USED 32'-9.50''...
- Page 53 WIRING THE POWER UNIT OPTION 2: WIRE DIRECT TO RELAY TERMINAL OPTION 1 : TIE INTO THE EXISTING PIG TAIL SEE FIG : 2 & 3 SEE FIG:1 FIG. 2 FIG.1 FIG. 3...
- Page 54 EagleEquipment ® Tire changers...
- Page 55 205 S Westgate Dr 27407 2023...
