Eagle Equipment EAG-12K Installation & Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EAG-12K
Installation & Operation Manual
Symmetric
12
2023
205 S Westgate Dr
27407

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EAG-12K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eagle Equipment EAG-12K

Summary of Contents for Eagle Equipment EAG-12K

  • Page 1 EAG-12K Installation & Operation Manual Symmetric 2023 205 S Westgate Dr 27407...
  • Page 2 CONTENTS 38-39 40-42 ......46-48...
  • Page 3 PLEASE READ THE ENTIRE MANUAL BEFORE ANY INSTALLATION AND OPERATION OF LIFT. PRODUCT DESCRIPTION The EAG-12K 12,000 lbs. capacity handle Please read the safety procedures and operation instructions in this manual before operating the lift. Proper installation is very important. Keep this operation manual near the machine at all times. Make sure ALL USERS read and fully understand this manual.
  • Page 4 TERMS AND CONDITIONS Eagle Equipment Please read these terms of service carefully. policy. Eagle Equipment EAGLE Risk of Loss / Freight / Shipping EAGLE ownerships of these goods transfers to the customer when they leave our dock EAGLE Delivery, Unloading and Freight Damage...
  • Page 5 EAGLE them within three days of delivery EAGLE EAGLE Shortages: within 3 days of delivery. Installation EAGLE EAGLE EAGLE Warranties Exclusions: Other limitations:...
  • Page 6 Returns and Replacements webmaster@eagleequip.com EAGLE EAGLE EAGLE EAGLE EAGLE INSPECT YOUR LIFT UPON DELIVERY. NOTE ANY DAMAGE ON DELIVERY RECEIPT. SHIPPING AND DAMAGE CLAIMS All shipments must be inspected immediately upon receipt. Concealed damage must be reported to the freight company within three (3) days of delivery.
  • Page 7 INTRODUCTION PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE INSTALLING OR OPERATING THIS LIFT. RECORD THE MODEL NUMBER AND THE SERIAL NUMBER THIS INFORMATION WILL BE REQUIRED 1-800-336-2776...
  • Page 8 Shipments must be inspected immediately upon receipt. External damage must be noted on the bill of lading. Concealed damages must be reported to the freight company within three days of delivery. Shortages must be reported to Eagle Equipment within three days of delivery: 1-800-336-2776.
  • Page 9 BEFORE INSTALLATION Teflon Tape 3mm,5mm,8mm SHIPMENT CHECKLIST Swing Arms and 2 -Column Extensions 2- Cylinders...
  • Page 10 OWNER/EMPLOYER RESPONSIBILITIES Safety Requirements for Operation, Inspection and Maintenance...

  • Page 11: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ THESE SAFETY INSTRUCTIONS THOROUGHLY DANGER: WARNING:...
  • Page 12 PREPARATION If it is installed outdoors, your Eagle Equipment warranty is null and void. Model # EAG-12 and asymmetrical symmetrical 12,000 STRUCTURAL PERFORMANCE POWER UNIT NOTE:...

  • Page 13: Control System

    CONTROL SYSTEM lowering INSTALLATION INSTRUCTIONS PLEASE READ INSTRUCTIONS BEFORE OPERATING THE LIFT. STEP ONE – UNPACKING CAUTION: When cutting bands. Use gloves and eye protection. STEP TWO – SITE SELECTION indoor use only 13-feet is the minimum height requirement to install and service this lift. not install lift columns within 6"...
  • Page 14 Install the hydraulic hose and lock release cab brackets on the extension columns . Use M6 x 20 Hex Bolts with M6 Nylock Nut & M6 Washer...
  • Page 15 Install hydraulic cylinders Connect the extended straight fi tting and 90° fi tting. Install the cylinders through the carriages (See Below). Off side column Power side column Use Tefl on tape to seal NPT pipe threads. Do not use Tefl on tape on JIC hydraulic hose ends.
  • Page 16 Install columns (Use M12 x 30 Hex Bolt, Nylock Nut & Washer to install extensions) Lay down the two columns on the installation site parallel of each other. Position the power side column according to the actual installation site. This lift is designed with 2 sectional columns.
  • Page 17 2. When the ceiling height is over 4200mm (165 3/8”) but less than 4500mm (177 1/8”), connect the outer columns to the middle holes .
  • Page 18 GROUNDWORK FOUNDATION DRAWING Chalk Line 6 in. min. 150.5 in. Figure 1 Column Layout This lift must be installed on concrete, where the concrete is at least 5" thick, has a compressive strength of 3000 PSI and has been cured for a minimum of 30 days. Do not install this lift on any surface other than concrete.
  • Page 19 STEP FOUR – MOUNTING THE COLUMNS overhead top beam Hook on to the extension columns Use M12 x 30 Hex Bolts with M12 Nylock Nuts and Washers Tighten the bolts...
  • Page 20 Assemble the over head top beam; tighten the anchor bolts . Use M12 x 30 Hex Bolts with M12 Nylock Nuts and Washers...
  • Page 21 Install the limit control bar and limit switch Loosen Screw on Drive Use M12 x 30 Hex Bolts with Rod for adjustment, M12 Nylock Nuts and Washers Tighten the screw to install control bar brackets after adjustment Loosen Screw on Drive Rod for adjustment, Tighten the screw after adjustment...
  • Page 22 Install safety device . 145° Spring Power side safety device Use M10 x 10 Allen Head Set Screw 145° Spring 120° Spring Use M10 x 20 Hex Offside safety device Head Bolts to secure the pulley bracket...
  • Page 23 Lift the carriages up by hand and lock them at the same level .

  • Page 24: Install Cables

    Install cables 1. High setting cable connection, suitable for ceiling height over 4500mm (177 -1/8”). 1.1 Take out the carriages’ plastic covers, cable passes through from the bottom of the carriages and pulled out from the openings of the carriages, then screw the two cable nuts .
  • Page 25 1.2 Connecting the cable for high setting . High Setting Cable 2 Cable 1 Cable 2...
  • Page 26 Low setting cable connection, suitable for ceiling heights between 4200mm (165 3/8”) to 4500mm (177 1/8”) ). Low Setting Cable 2 Cable 1 Cable 2...

  • Page 27: Install Power Unit

    Install power unit Use M8 x 25 Hex Bolts with M8 Nuts & Washers...
  • Page 28 Install hydraulic hoses...
  • Page 30 Safety Cable Install...
  • Page 31 Install hose retainers . Install hose retainers using M6 x 8 screws...
  • Page 34 PRE-OPERATION RAISING THE LIFT FOR THE FIRST TIME OPERATION Always lower the lift onto the safety stops before working on, under or near the vehicle. LOWERING THE LIFT...

  • Page 35: Lowering The Lift

    Always lower the lift onto the safety stops before working on, under or near the vehicle. LOWERING THE LIFT SAFETY PROCEDURES 12000 3000 l ALWAYS LOCK THE LIFT BEFORE GOING UNDER THE VEHICLE. NEVER ALLOW ANYONE TO GO UNDER THE LIFT WHEN RAISING OR LOWERING.

  • Page 36: Daily Maintenance

    MAINTENANCE SCHEDULE MAINT WARNING: securely locked out Practice good housekeeping. DAILY MAINTENANCE MONTHLY MAINTENANCE...

  • Page 37: Annual Maintenance

    ANNUAL MAINTENANCE For all other maintenance, if any deficiencies are noted, or any parts need to be replaced, please contact a qualified repair contractor or Eagle Equipment at 800.336.2776.

  • Page 38: Troubleshooting

    TROUBLE SHOOTING Problem Possible Cause Possible Solution Instructions load...
  • Page 39 TROUBLE SHOOTING Problem Possible Cause Possible Solution Instructions valve load loaded...
  • Page 40 TROUBLE SHOOTING Problem Possible Cause Possible Solution Instructions...

  • Page 41: Specifications

    SPECIFICATIONS 12 K 72-1/2'' - 81-1/2'' 150-3/4'' 108-5/8'' 38'' - 58'' Three stage arm -1/2'' 122-5/8'' 3000 175''...
  • Page 42 Installation Height Options...
  • Page 44 Parts List...
  • Page 45 Parts List Lock washer 10mm...
  • Page 46 Parts List 37'6.750''...
  • Page 47 EagleEquipment ®...
  • Page 48 2022.03...
