Biolight Meditech S10 Service Manual

Patient monitor
Hide thumbs Also See for S10:
Table of Contents

Advertisement

Quick Links

Download this manual
S10/S12/S10A/S12A
Patient Monitor Service Manual
GuangDong Biolight Meditch Co,.ltd
No.2 Innovation First Road, Technical Innovation Coast, Hi-tech Zone, Zhuhai , P.R.China
Tel: +86-756-3630760
Fax: +86-756-3399911 Email:service@blt.com.cn
http://www.blt.com.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S10 and is the answer not in the manual?

Questions and answers

Related Manuals for Biolight Meditech S10

Summary of Contents for Biolight Meditech S10

  • Page 1 S10/S12/S10A/S12A Patient Monitor Service Manual GuangDong Biolight Meditch Co,.ltd No.2 Innovation First Road, Technical Innovation Coast, Hi-tech Zone, Zhuhai , P.R.China Tel: +86-756-3630760 Fax: +86-756-3399911 Email:service@blt.com.cn http://www.blt.com.cn...

  • Page 2: Table Of Contents

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 CONTENTS 1. Summary ........................1 1.1 About the Manual ........................1 1.2 Safety Information ........................2 1.3 Equipment Symbols ........................ 3 2. Monitor Introduction ....................5 2.1 Main Frame ..........................5 2.2 Accessories ..........................8 3.

  • Page 3: Summary

    Respiration Rate(RR), Temperature(TEMP), Pulse Oxygen Saturation(SpO2), Pulse Rate(PR), Non-invasive Blood Pressure(NIBP), Carbon dioxide(CO2), Invasive Blood Pressure(IBP) and Cardiac output(C.O.). S10A and S10 patient monitor do not support CO2, IBP and C.O. measurement. C.O. monitoring is only intended for adult patients.

  • Page 4: Safety Information

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 Warning: The monitor is intended for use only by clinical Professionals or under their guidance. It must only be used by persons who have received adequate training in its use. Anyone unauthorized or untrained must not perform any operations on it.

  • Page 5: Equipment Symbols

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 ◼ Keep the packing materials out of children’s reach. Disposal of the packing materials should observe the applicable waste control regulations. 1.2.4 Caution ◼ When the monitor is conducting some performance tests, make sure the monitor will not be interfered by electromagnetic radiation.
  • Page 6 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 Abbreviation of “Non-invasive Blood Dangerous voltage NIBP Pressure”. Abbreviation of “Invasive Equipotential grounding Blood Pressure”. Abbreviation of “Drip Auxiliary output Monitor”. Network Alternating current（AC） Defibrillator VGA display connector synchronization output connector Manufacturer Degree of protection...

  • Page 7: Monitor Introduction

    Heart Rate (HR), Respiration Rate (RR), Temperature(Temp), Pulse Oxygen Saturation(SpO2), Pulse Rate(PR), Non-invasive Blood Pressure(NIBP). Besides, it can upgrade to Invasive Blood Pressure(IBP), Carbon dioxide(CO2), Cardio Output ) and Drip Monitor (DM). S10A and S10 patient monitor do not support CO2, C.O. IBP and C.O. measurement.

  • Page 8: Alarm Light

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 2.1.2 Interfaces 2.1.3 Hardware Structure The monitor is composed of the following parts: ◆ Input system: touch-screen, power switch ◆ Output system: display screen, alarm indicator board, recorder, loudspeaker ◆ Processing and communication system: main-board ◆...

  • Page 9: Power Module

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 The monitor comprises two kinds of alarm lights: physiological alarm lights and technical alarm lights. The physiological alarm lights and technical alarm lights can emit light in three colors of yellow, cyan and red.

  • Page 10: Main Board

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 internet; 3) USB interface: It can connect with mouse and keyboard to facilitate the operation and entry of relevant information; Software update and so on; 4) SCSI Interface: * Defibrillation synchronous output/Analog output interface: it is connected with the defibrillation device and sends defibrillation synchronous signals.
  • Page 11 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 (Mainstream and Sidestream), C.O. interface cable. More than this, the monitor also could install trolley, wall mount, and rechargeable lithium. 1. ECG cable 12PIN 3-lead ECG cable (IEC) 12PIN 5-lead ECG cable (IEC)
  • Page 12 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 Analog SpO2 extension cable Analog SpO2 adult reusable sensor (9pin ) （15-100-0357） （15-100-0320） Analog SpO2 adult soft reusable sensor (9pin) Analog SpO2 pediatric reusable sensor (9pin) （15-100-0321） （15-100-0322） Analog SpO2 pediatric soft reusable sensor (9pin) Analog SpO2 neonatal reusable sensor (9pin) （15-100-0323）...
  • Page 13 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 3. PVC tube & NIBP Cuff NIBP PVC tube (15-031-0008) Neonatal Cuff M5121（6cm-11cm） Pediatric Cuff M5123（18-26cm） （15-100-0122） （15-100-0121） Adult Cuff M5124(25cm-35cm) Large Adult Cuff M5125（33cm-47cm） （15-100-0118 ） （15-100-0120） Adult Thigh Cuff M5126（44cm-53cm） Neonatal disposable Cuff pack M5541(1#,2#,3#,4#) （15-100-0142 ）...
  • Page 14 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 4. TEMP sensor TEMP surface probe TEMP coelom probe （15-031-0005） （15-031-0012） 5. IBP interface cable IBP transducer interface cable 4 pin to 6pin IBP extension connector （15-100-0029 ） (15-031-0023) 6. CO2 measuring module (Masimo) ISA CO2 sensor（Masimo）...
  • Page 15 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 NomoLine Airway Adapter Set (3829) IRMA CO2 sensor（16-100-0017） NomoLine Nasal CO2 Cannula (3832) 7. CO2 measuring module (BLT) Capno-M CO2 sensor CO2extension cable Airway adapter 15-100-0199 15-031-0010 15-100-0212 Capno-S CO2 sensor CO2 filter T4F...
  • Page 16 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 3 way airway adapter (15-100-0074) 8. C.O. C.O. cable 9. DM module (Drip Monitor Module) DM module 10. Others Wall mount Trolley Rechargeable lithium battery (2.5A/5A) 20-100-0029 20-100-0028 12-100-0031/32 Document No.: J/S-I-008 Page...
  • Page 17 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 2.2.2 Management and Maintenance of Accessories Refer to the User’s manual. Document No.: J/S-I-008 Page 15 of 42...

  • Page 18: Testing

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 3. Testing 3.1 Brief Introduction To ensure the long-term and stable working of the monitor, maintenance personnel need to conduct regular checks, maintenance and testing on it. This chapter provides the basic testing methods of the monitor and recommends the applicable...

  • Page 19: Performance Testing

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 connector pins have any loosening or distortion. 3. Whether the peripheral interface of the monitor has any loosening or pin distortion. 4. Whether the safety labels or name plates are legible. 3.2.2 Startup Testing...
  • Page 20 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 4. Adjust the ECG gains and HR values and verify whether the monitor’s ECG waveforms and HR values have relevant changes. 3.3.2 NIBP Testing Testing tool: BP simulator 1. Insert the NIBP PVC tube plug into the NIBP socket of monitor and make sure in good contact.
  • Page 21 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 1. Connect the simulator with the IBP socket of the monitor. 2. Set the simulator to zero pressure. 3. Press the “zero” in IBP menu to zero until the screen display “zero success”.
  • Page 22 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 show that “Ready for new”, select 【Start】to measure the C.O., when the screen shows that “Injection now …”, enter the start key of the simulator, observe the wave, waiting for the measured values.

  • Page 23: Maintenance

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 4. Maintenance 4.1 Maintenance Menu Enter 【Main menu】，select【System】→【Maintenance】, input password: 785623, and then enter maintenance menu: Demo password ：888 888 4.1.1. Device location Device ID setup: set Monitor name, Unfixed or Fixed, Facility, Room No., Bed NO.
  • Page 24 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 4.1.2 Patient Management Set the field: Select the items for the patient field (Room No., Visit No., Patient ID, Middle name, Doctor ID, Age) to display on the patient info menu. Custom fields: Users can define their own field, up to 4 types.
  • Page 25 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 4.1.5 Print 1) Active Grid print 2) Set the network printer service IP (network printer function is not available). 4.1.6 Unit Set the unit for Height, Pressure and Weight. 4.1.7 Other 1) Select different language menu (22 types)
  • Page 26 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 4.1.9 Module version Check the hardware and software of every parameter. 4.1.10 Machine Information 1) Check the battery voltage 2) Check the touch screen information 3) Statistics : only for R&D testing 4.1.11 Network setup...

  • Page 27: Nibp Maintenance

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 4.1.12 Upgrade Enter this menu to upgrade the opening logo of the monitor. (refer to 4.3 software upgrade) 4.2 NIBP maintenance 4.2.1 NIBP leakage test 1. Plug the air pipe plug of cuff into the connector (NIBP) of monitor until the plug and socket contact well 2.
  • Page 28 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 5. After 20 seconds or so, the system will automatically open the deflating valve, which marks the completion of an air leakage test. 6. If no error information displays on NIBP parameter area, it indicates that the airway is in good situation and no air leaks exist.
  • Page 29 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 2) Setting the simulator: enter menu 【NIBP】→【Test】→【Pressure Source】， then set the value to 200mmHg; 3) Enter menu : 【Module】→【NIBP】, then press menu【Static Pressure Test】 4) Start the simulator and the monitor to test, check the pressure values showed by monitor and simulator;...

  • Page 30: Software Upgrade

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 6) Repeater step 3 and step 4, check if the pressure showed by monitor and simulator in a same value or less than 3mmHg, then calibration complete. 4.3 Software Upgrade Software of this monitor can be upgraded by USB stick.
  • Page 31 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 4) When the monitor’s screen displays “Upgrade successful”, then press the reboot button and unplug the USB stick, and then restart the monitor. 5) Software upgrade complete. 2. Change the opening Logo of the Monitor 1.

  • Page 32: Troubleshooting

    Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 5. Troubleshooting 5.1 Overview This chapter conducts categorization based on the failure type of the monitor, and for troubleshooting, please refer to the failure table and conduct checks according to the sequence. The recommended solutions given in this chapter can solve most of the equipment failures, but may not necessarily cover all possible failures.
  • Page 33 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 LCD display screen Replace the LCD display screen. is damaged Check whether the cable of the touch screen is properly connected. Cable failure Check if the cable damaged. Re-connect the cable. Touch screen has no response Check if the screen is damaged.

  • Page 34: Maintenance And Disassembling

    Service Manual of S10&S12&S10A&S12A Patient Monitor 6. Maintenance and Disassembling 6.1 Tool During the process of disassembling and replacing the parts, you may need to use the following tools: 1. Cross screwdriver 2. Slotted screwdriver 3. Sharp-nose plier 6.2 Disassemble Procedure Note: Before disassembling the monitor, please unplug the power code and remove the battery from the monitor.
  • Page 35 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 1. Remove the screws that fix the front panel, then unplug the cables and separate the front panel from the monitors. 2. Unplug the cable that connect to the power supply board, then remove the screws, and then take out the power supply board;...
  • Page 36 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 ① ② Item Material code Item Material code SMPS wire 1.11.59-0000009-01 SMPS 1.15.01-0064-01-00 3. Remove the cables and screws, and then take out the connector panel set; ④ ① ② ③ ④ ⑤...
  • Page 37 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 panel A fixing plate TEMP & SpO2 1.19.02-000013-0-1, 1.11.59-0000005-01 NIBP connector connector wire 1.19.02-000014-0-1 DM module ECG connector 1.11.59-0000025-01 1.11.59-0000004-01 connecting wire wire Connector PCB S10 Connector 2.02.0001-03-00 1.19.02-000042-0-1 fixing plate 4. Remove the cable and cut the cable tie, then take out the valves;...
  • Page 38 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 ① ② Item Material code Item Material code speaker 1.16.21-000018-010 Speaker wire 1.11.29-0000008-01 7. Remove the cable and screws, and then take out the alarm-light board; ① ② Item Material code Item Material code Alarm-light wire 1.11.59-0000001-01...
  • Page 39 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 Item Material code Item Material code Main board Main board 2.02.0001-01-05 2.02.0001-01-08 (basic) (wifi) Main board (VGA/Analog Output/Dysn/Nurse Call) 2.02.0001-01-10 Main board (VGA/Analog Output/Dysn/Nurse Call+wifi) 2.02.0001-01-13 Main board (VGA/Analog Output/Dysn/Nurse Call+wifi+ 12 leads) 2.02.0001-01-00...
  • Page 40 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 ① ② ③ 10.4’ front panel: Item Material code Item Material code LCD mounting 10.4’ LCD 1.20.02-000004-0-1 1.14.104-1704-01-1 plate 10.4’ touch LCD cable 1.11.59-0000015-01 1.14.104-0012-00-1 screen S10 Front case 1.19.02-000040-0-1 Touch screen 1.11.59-0000000-01 Grounding role 1.21.14-000005-005...
  • Page 41 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 Item Material code Item Material code AC connector 1.10.00-0033-00-02 grounding wire 1.11.59-0000008-01 Power code 3PVH AC wire 1.11.59-0000012-01 1.20.02-000002-0-1 fixing bracket 13. Disassembling the rear case. ① ⑥ ③ ④ ⑤ ② Item...
  • Page 42 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 Main board interfaces 12.1 LCD 10.4’ LCD Alarm Touch screen backlight backlight lamp pump Speaker J20 J15 Connector SCSI panel A/B SpO2&TEMP RJ45 Connector Power switch Printer SMPS valves Battery panel C Document No.: J/S-I-008...
  • Page 43 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 Appendix A S10 Exploded view Part list Material code Material Name Material code Material Name 1.19.02-000044-0-1 battery cover plate 2 1.12.06-11-5000-00 Lithium battery (11.1V/2.5Ah) 1.20.02-000002-0-1 power code fixing bracket 4 1.10.00-0033-00-02 power socket 1.20.02-000001-0-1...
  • Page 44 Service Manual of S10&S12&S10A&S12A Patient Monitor V1.0 S12 Exploded view Part List Material code Material Name Material code Material Name 1.19.02-000061-0-1 rear cover plate 2 1.20.02-000062-0-1 recorder mounting plate 1.19.02-000054-0-1 battery cover plate 4 1.12.06-11-5000-00 Lithium battery 1.19.02-000057-0-1 interface cover plate 6 1.19.02-000060-0-1...
  • Page 45 Product Model: S10/S12/S10A/S12A Product Name: Patient monitor Manufacturer Name: Guangdong Biolight Meditech Co,.Ltd. Address: No.2 Innovation First Road, Technical Innovation Coast, Hi-tech Zone, Zhuhai, P.R.China Post code: 519085 PN: 22-075-0010...
