Biolight Meditech E80 Manual

Electrocardiograph
Hide thumbs

Advertisement

Quick Links

Download this manual
Product Information
 Product Model:
 Product Name:
 Manufacturer Name: Guangdong Biolight Meditech Co., Ltd.
 Contact Information:
Address: No.2 Innovation First Road, Technical Innovation Coast,
Post code: 519085
Fax: +86-756-339919
Toll-free consultation hot line: +86-400-8818-233
Revision History
This manual has a revision number. This revision number changes
whenever the manual is updated due to software or technical specification
change. Contents of this manual are subject to change without prior notice.
 Document No.: J/E12CE-A-009
 Revision number:V2.4
 Release time: Nov.2014
CE mark
EC Representative Name:
Shanghai International Trading Corp. GmbH (Hamburg)
EC Representative Address:
Eiffestrasse 80, 20537 Hamburg Germany
Copyright © 2014 Guangdong Biolight Meditech Co., Ltd. All rights
reserved.
E80/E70
Electrocardiograph
Hi-Tech Zone Zhuhai, P.R. China
I

Advertisement

loading
Need help?

Need help?

Do you have a question about the E80 and is the answer not in the manual?

Questions and answers

Related Manuals for Biolight Meditech E80

Summary of Contents for Biolight Meditech E80

  • Page 1  Document No.: J/E12CE-A-009  Revision number:V2.4  Release time: Nov.2014 CE mark EC Representative Name: Shanghai International Trading Corp. GmbH (Hamburg) EC Representative Address: Eiffestrasse 80, 20537 Hamburg Germany Copyright © 2014 Guangdong Biolight Meditech Co., Ltd. All rights reserved.
  • Page 2 Statement  Manufacturer holds the copyright of this manual, and we are also entitled to deal with this manual as confidential files. This manual is only used for operation, maintenance and service of product, someone else can not publish the manual. ...
  • Page 3 The manual is geared for clinical professionals who are expected to have a working knowledge of medical procedures, practiced and terminology as required for monitoring patients. All illustrations in this manual serve as examples only. They may not necessarily reflect the setup or data displayed on your product. Conventions: ...
  • Page 5 Content Chapter 1 General Introduction ............... 1-1   1.1 Intended use ....................... 1-1  1.2 Manufacture Config ....................1-1  1.3 Main Unit ........................1-2  1.4 Keyboard ........................1-8  1.5 Screen Display ......................1-10  1.6 Equipment Sign ......................1-12  Chapter 2 Safety ....................2-1  ...
  • Page 6 5.1 Examples and notes of Record Report ................ 5-1  5.2 Examples of Report in each Work Mode ..............5-3  Chapter 6 Battery ....................6-1   6.1 Introduction ....................... 6-1  6.2 Install battery ......................6-2  6.3 Optimizing Battery Performance ................6-3  6.4 Checking Battery Performance ...................
  • Page 7 D.4 Atrial/Ventricular Block ....................12  D.5 Ventricular Conduction Block ..................13  D.6 ST-T Morphology Statements ..................14  D.7 Myocardial Infarction ....................14  D.8 Arrhythmias ........................ 15  D.9 Diagnosis Result ......................17  D.10 Movement Test ......................17  D.11 Datum Value ......................18  Appendix E Measurement .................
  • Page 8 VIII...
  • Page 9 E80/E70 Digital Electrocardiograph User’s Manual Chapter 1 General Introduction 1.1 Intended use Electrocardiograph is applicable to medical units for patients’ ECG collection, analysis of the ECGs collected, and providing of accurate measurement values. It can conduct data saving, review, display and recording of the ECGs analyzed.
  • Page 10 E80/E70 Digital Electrocardiograph User’s Manual 1.3 Main Unit 1.3.1 Top View  E80 top view Recorder Keyboard AC power indicator Battery status indicator Equipment operation indicator  E70 top view Recorder Keyboard AC power indicator Battery status indicator Equipment operation indicator...
  • Page 11 E80/E70 Digital Electrocardiograph User’s Manual 1.3.2 Front View  E80 front view  E70 front view...
  • Page 12 E80/E70 Digital Electrocardiograph User’s Manual 1.3.3 Side View  E80 Left side : Box cover button  E70 left side Box cover button...
  • Page 13 E80/E70 Digital Electrocardiograph User’s Manual  E80 Right side:  E70 right side NO. Name Note Network connector Standard RJ45 mode connector, Factory debug. Serial port Spare Exterior in-out connector Spare USB connector 1 Standard US connector, connect special U flash disk.
  • Page 14 E80/E70 Digital Electrocardiograph User’s Manual 1.3.4 Back View  E80 back view AC mains socket Equipotential grounding Handle terminal, Connect the equipotential grounding system of hospital  E70 back view Equipotential grounding AC mains socket terminal, Connect the Handle equipotential grounding...
  • Page 15 E80/E70 Digital Electrocardiograph User’s Manual 1.3.5 Bottom View  E80 bottom view Radiator Battery compartment  E70 bottom view Radiator Battery compartment...
  • Page 16 E80/E70 Digital Electrocardiograph User’s Manual 1.4 Keyboard The keyboard of Cardiograph is designed to be user-friendly and easy to operate, and it supports entry in Chinese. According to functions, keys are divided into single function key, dual function key and combined function key.
  • Page 17 E80/E70 Digital Electrocardiograph User’s Manual  Single function key Note F1-F7 7 screen shortcut keys, with the same functions as those of keys on touch screen Power switch Turn on/off machine Reserve Reserve Enter Confirm operation Window switchover key Delete the character entered 4 directions &...
  • Page 18 E80/E70 Digital Electrocardiograph User’s Manual 1.5 Screen Display The following is the main interface of electrocardiograph: Display Note Prompt info area Including: USB connection prompt, saving medium prompt, battery power display, AC power on/off prompt and network access prompt. It indicates whether the equipment is connected to computer;...
  • Page 19 E80/E70 Digital Electrocardiograph User’s Manual Display Note Sampling time The sampling time of ECG algorithm is displayed. If without sampling, no information will be displayed in this area; the information of no paper is also displayed in this area, and during sampling, the sampling time is displayed first.
  • Page 20 E80/E70 Digital Electrocardiograph User’s Manual 1.6 Equipment Sign Sign Note Sign Note Dangerous voltage USB printer CE mark Alternating current Equipment running indicator Battery status indicator light light Non-ionizing radiation Equipotential grounding USB socket Manufacture date In-out connector Manufacturer Serial port...
  • Page 21 E80/E70 Digital Electrocardiograph User’s Manual Chapter 2 Safety 2.1 Safety Information  Warning:  Before putting the system into operation, verify that the Cardiograph, connecting cables and accessories are in correct working order and operating condition.  Use only accessories specified by our company. Using other accessories may cause damage to the Cardiograph.
  • Page 22 E80/E70 Digital Electrocardiograph User’s Manual risk of entanglement or strangulation by patient or personnel.  Keep the packing materials out of children’s reach. Disposal of the packing materials should observe the applicable waste control regulations.  Although safe request is considered during device design, but operator must not ignore device status and observing patient.
  • Page 23 E80/E70 Digital Electrocardiograph User’s Manual  Note:  Put the cardiograph in a location where you can easily see the screen and access the operating controls.  Keep this manual in the vicinity of the cardiograph so that it can be obtained conveniently when needed.
  • Page 24 E80/E70 Digital Electrocardiograph User’s Manual The unit displaying this symbol contains an F-Type isolated (floating) applied part providing a high degree of protection against shock, The type CF applied parts provide a higher degree of protection against electric shock than that provided by type BF applied parts.
  • Page 25 E80/E70 Digital Electrocardiograph User’s Manual 2.3 Important Notes for Safety  Patient Number The electrocardiograph can only be applied to one patient at one time.  Interference Do not use mobile phone in the vicinity of the electrocardiograph. High level of electromagnetic radiation emitted from such devices may result in strong interference with the electrocardiograph performance.
  • Page 26 E80/E70 Digital Electrocardiograph User’s Manual  Battery The device is equipped with a battery. The battery discharges even when the device is not in use. Store the device with a fully charged battery and take out the battery, so that the service life of the battery will not be shortened.
  • Page 27 E80/E70 Digital Electrocardiograph User’s Manual  Prompt The machine can give prompts of abnormal status arising from excessive polarization voltage of ECG electrode. For any question, contact us or native agent. 2.4 Safe Operation Conditions Methods of sterilization or Sterilization: not applicable...
  • Page 28 E80/E70 Digital Electrocardiograph User’s Manual...
  • Page 29 E80/E70 Digital Electrocardiograph User’s Manual Chapter 3 Getting Started 3.1 Unpacking and Checking 1. Unpacking Before unpacking, examine the packing case carefully for signs of damage. If any damage is detected, contact the carrier. If the packing case is intact, open the package.
  • Page 30 E80/E70 Digital Electrocardiograph User’s Manual 3.2 Power Supply 3.2.1 AC Power Supply  AC power: AC 100V-240V, 50Hz/60Hz.  Take out the accessory power cord, and insert the plug of output end into the AC power socket at back panel of Electrocardiograph, and insert the...
  • Page 31 E80/E70 Digital Electrocardiograph User’s Manual this way, the impact of AC disturbances may be reduced. For the power supply period of battery, see the product specification.  For battery maintenance, please refer to the section of Battery. 3.3 Placing Cables Insert patient cable pin into patient cable socket on the right side, and tighten the screw.
  • Page 32 E80/E70 Digital Electrocardiograph User’s Manual Electrode Electrode Electrode Electrode colors colors labels labels Position (IEC) (AAMI) (IEC) (AAMI) Right leg (On crus, midpoint Black Green between knee and ankle.) Left leg (On crus, midpoint Green between knee and ankle) On the fourth intercostal space...
  • Page 33 E80/E70 Digital Electrocardiograph User’s Manual Please refer to the following steps at the time of connecting chest electrodes: 1. Check whether the electrodes are clean and intact; 2. Clear up lead wire to avoid twisting, and firmly connect the electrode connector to electrodes;...
  • Page 34 E80/E70 Digital Electrocardiograph User’s Manual 3.5 Install the chart paper When the chart paper is not installed or is used up, “no paper” will be shown on the display screen of Electrocardiograph to remind the users of installing or replacing the chart paper. Folded thermosensitive printing paper...
  • Page 35 E80/E70 Digital Electrocardiograph User’s Manual 3) After finish the installation of the stop block and restrictor plate, you can carry out the installation of chart paper.  Install the folded thermosensitive printing paper: 1) Press downwards with one hand the box cover button on the left of...
  • Page 36 E80/E70 Digital Electrocardiograph User’s Manual Fig. 3-2 Install folded paper Pull out about 2cm chart paper from the paper outlet of recorder, and close the cover of recorder. At this time, the installation is completed. Fig. 3-3 Install folded paper ...
  • Page 37 E80/E70 Digital Electrocardiograph User’s Manual gently place the chart paper into the paper slot, and pull out about 2cm chart paper from the paper outlet of recorder; Fig. 3-5 Install reel paper 4) Close the box cover of recorder. At this time, the installation is completed.
  • Page 38 E80/E70 Digital Electrocardiograph User’s Manual 3.6 Inspecting Before Starting Please read the manual carefully before using the electrocardiograph, be familiar with the function, operations and notes. Check the following contents before starting up. 1. Environment Make sure electrocardiograph will interfered electromagnetic radiation.
  • Page 39 E80/E70 Digital Electrocardiograph User’s Manual Chapter 4 Operation Instruction This manual is based on the maximum configuration, you can choose the configurations you need. Therefore some contents may not apply to your product which will display gray on your product and are useless for users.
  • Page 40 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-1: Patient info setting In the interface, you may conduct the following operations: ——【Name】: Input patient name. (Input 16 characters at most) —— 【Patient ID】 : Input patient ID (Input 12 characters at most). You can use...
  • Page 41 E80/E70 Digital Electrocardiograph User’s Manual manufacturer.  Please check whether the switch of scanner is open before start the barcode scanner. Only the Barcode Scanner is effective can you enter the patient ID automatically.  No matter where the current cursor is in the Patient info setting dialog box, when you use the barcode scanner, the Patient ID will be filled in automatically.
  • Page 42 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-3: Freeze--More Fig. 4-4: Freeze—More—Report format setting In the interface Fig. 4-2, you may conduct the following operations: ——Select【Last page】: Display waveform last page. ——Select【Next page】: Display waveform next page. ——Select【Last sec】: Display waveform last second.
  • Page 43 E80/E70 Digital Electrocardiograph User’s Manual ——Select【Replay】: Replay freeze waveform. ——Select【Pause】: A pause in waveform replay. ——Select【More】: Store, record, print the waveform and set record format. Shown as Fig. 4-3 In the interface Fig. 4-3, you may conduct the following operations: ——Select【Return】: Return to interface shown as Fig.
  • Page 44 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-5 File main interface The above interface can divide into two parts: left part is files named date, and right part is file data contained in select files. In the interface, you may conduct the following operations: ——Select【Last page】:Turn up one page of contents displayed by interface.
  • Page 45 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-6: File Review--Waveform Fig. 4-7 File Review--Info In the file review interface, you may conduct the following operations: ——Select 【Waveform】 : Display waveform of data stored. Shown as Fig. 4-6. ——Select【Info】: Can display patient info, ECG measure result, ECG analyze result ,.
  • Page 46 E80/E70 Digital Electrocardiograph User’s Manual ——Select【Record】: Can record file selected. If it need stopping during recording, press “Record/Stop”. ——Select 【 Pdf】(Optional): Can transfer the file of current waveforms into a pdf file. ——Select 【 Print 】 (Optional): Can print and output the file of current waveforms immediately.
  • Page 47 E80/E70 Digital Electrocardiograph User’s Manual This is mainly readjusting report format stored in “Auto” mode. The selected box is failed to use while report stored is not “Auto” mode. 4.5 Work Mode Setup Pressing “ Mode ” on keyboard in main interface can switch electrocardiograph’s work mode.
  • Page 48 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-10: Work mode setting--Fast 4.5.2 Auto Mode During ECG recording in Auto mode, the lead group will switch over automatically in order, i.e. after the recording of ECG signals of leads in a group is completed within the specified period, the machine will switch over automatically to the next lead group and begin to record the ECG signals of the next lead group.
  • Page 49 E80/E70 Digital Electrocardiograph User’s Manual To stop recording in the course of recording, press “Record/Stop” key on keyboard. Fig. 4-11: Work mode setting--Auto 4.5.3 Manual Mode In manual mode, users may select lead group according to actual needs, and conduct different setups of recording parameters or other parameters for different lead groups.
  • Page 50 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-12: Work mode setting--Manual 4.5.4 Rhythm Mode In Rhythm mode, users may select lead according to actual needs, and record the rhythm waveform of single lead within 60s or rhythm waveforms of 3 leads within 20s each.
  • Page 51 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-13: Work mode setting--Rhythm 4.6 Recorder Setup The users may set the relevant information of recorder, e.g. recorder type, paper information, paper moving speed, gain. Press【Recorder/F2】in main interface can enter recorder setup interface. Shown as the following.
  • Page 52 E80/E70 Digital Electrocardiograph User’s Manual ——Select 【Speed】: Set the paper moving speed of recorder. Optional speed: 12.5mm/s，25mm/s，50mm/s. ——Select 【 Gain】: Set the length of ECG 1mV on thermo sensitive chart paper. Optional gain: 5mm/mV, 10 mm/mV, 20mm/mV, 10/5mm/mV, 20/10mm/mV, Auto. Gain 40mm/mV can optional.
  • Page 53 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-15: Report info setting In the interface, you may conduct the following operations: ——Select 【Analysis】: Select display or no display. When “Display” is selected, record of ECG automatic analysis result will be exported at the time of ECG recording;...
  • Page 54 E80/E70 Digital Electrocardiograph User’s Manual “Record/Stop” key, record of the ECG data collected within 10s after pressing this key will be exported; 3) When “Trigger sampling” selected, user presses “Record/Stop”key, Electrocardiograph will automatically trigger record once in case of arrhythmia.
  • Page 55 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-16: Filter setting In the interface, you may conduct the following operations: ——Select 【AC filter】: Select On/Off to turn on/off the status of power frequency filter. According to the frequency of network, the Factory Default can be set to “50Hz”or“60Hz ”.
  • Page 56 E80/E70 Digital Electrocardiograph User’s Manual interface. Shown as following chart: Fig. 4-17: System setting—Data-time System setup of electrocardiograph includes: Data-Time, Info, Attribute, Other and More. 4.9.1 Date-Time Setup In the system setup interface, select【Date-time】to enter the date/time setup interface, as shown in Figure 4-13 below. In the interface, you may conduct the following operations: ——Select respectively【Year】...
  • Page 57 E80/E70 Digital Electrocardiograph User’s Manual 4.9.2 Info Setup Select【Info】in system setup interface to enter info setup interface. As shown following chart. Fig. 4-18: System setting--info In the interface, you may conduct the following operations: ——Select 【Lead name】 : May select lead name displayed: “AAMI” or “IEC”.
  • Page 58 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-19: System setting--Attribute In the interface, you may conduct the following operations: ——Select【Key volume】: Set the volume of key sound. Options: small, medium, large or close. When “Close” is selected, Electrocardiograph will not give off any sound at the time of key pressing.
  • Page 59 E80/E70 Digital Electrocardiograph User’s Manual Fig. 4-20: System--Other You may conduct the following operations in this interface: ——Select 【External input】/【External output】: Electrocardiograph has external import/export port, which can be used to receive external signals or export the signals detected. You may select “Yes” or “No” to open or close this function.
  • Page 60 E80/E70 Digital Electrocardiograph User’s Manual ——Select【Save to user set】Select yes or no to save current settings of the device as user setting. ——Select【Use the default set】Select yes or no to resume the default set of the device. ——Select【IP address】Check the IP address of the current machine.
  • Page 61 Chapter 5 Read the Printed ECG Report 5.1 Examples and notes of Record Report The formats of printed reports usable for E80 electrocardiograph are described in this section. Taking 12x1 ECG record in Fast mode as an example, its contents are shown in the figure below: Fig.
  • Page 62 E80/E70 Digital Electrocardiograph User’s Manual L: Waveform info M: 1 mV calibration signal A. Patient info contains: NO. (ID), Name, Age, Gender, height, weight, Race, Room NO. and medicine. B. Measurement information includes: (heart rate：Calculated on the basis of the entire 10second ——HR...
  • Page 63 E80/E70 Digital Electrocardiograph User’s Manual resulting in measurement errors sometimes.  If missing of check of R wave is caused by some lead fall-off and QRS low voltage, the measurement of HR will possibly have big error.  In case of QRS low voltage, the calculation of ECG axis and the dividing point identification of QRS wave are unreliable sometimes.
  • Page 64 E80/E70 Digital Electrocardiograph User’s Manual Fig. 5-2: Fast mode 12×1 report 5.2.2 Auto Mode This chapter contains following examples in auto mode ( Fig. 5-3, Fig. 5-4 , Fig. 5-5 and Fig. 5-6). The notes refer to page 5-1.
  • Page 65 E80/E70 Digital Electrocardiograph User’s Manual Fig. 5-3: Auto mode 3x4+1 report Fig. 5-4: Auto mode 6x2+1report...
  • Page 66 E80/E70 Digital Electrocardiograph User’s Manual Fig. 5-5: Auto mode 12x1 report Fig. 5-6: Auto mode 12x1_rhy(V6) report...
  • Page 67 E80/E70 Digital Electrocardiograph User’s Manual 5.2.3 Manual Mode In manual mode, real-time recording of ECG waveform is conducted manually according to the requirements of users, and start and stop of recording are controlled via keys. The figure below shows 12-channel ECG record report in manual mode.
  • Page 68 E80/E70 Digital Electrocardiograph User’s Manual I: 1mV calibration signal J: AC filter status 5.2.4 Rhythm Mode In Rhythm mode, specific lead rhythm is analyzed. The machine supports single-rhythm lead mode and 3-rhythm lead mode. In single-rhythm lead mode, the waveform data of 60s are collected; in 3-rhythm lead mode, the waveform data of 20s are collected.
  • Page 69 E80/E70 Digital Electrocardiograph User’s Manual 3-rhythm lead mode: Fig. 5-9: 3-rhythm lead mode A: Patient info (include: name, ID, age and gender) B: HR C: The time recording report D: Waveform info E: Work mode F: Baseline drift filter (Off) and lowpass filter frequency...
  • Page 70 E80/E70 Digital Electrocardiograph User’s Manual 5-10...
  • Page 71 E80/E70 Digital Electrocardiograph User’s Manual Chapter 6 Battery 6.1 Introduction The electrocardiograph can be fitted with rechargeable battery to ensure its continuous work after the failure of alternating current power supply, and it needs no special maintenance under the normal condition. While the...
  • Page 72 E80/E70 Digital Electrocardiograph User’s Manual 6.2 Install battery The battery box is at the bottom of Electrocardiograph. Please refer to the following steps at the time of installing or replacing battery: 1. Power off the Electrocardiograph, and disconnect the power cord and other connecting wires;...
  • Page 73 E80/E70 Digital Electrocardiograph User’s Manual with wire; otherwise, there will be risks of fire.  Only the person be trained or having a good understand of the device can take apart the battery compartment and replace the battery.  Lithium battery shall be plugged or pulled in turn-off status;...
  • Page 74 E80/E70 Digital Electrocardiograph User’s Manual 3. Disconnect AC mains and allow the electrocardiograph to run on the battery until it shuts off. 4. The operating time of a battery reflects its performance directly. 6.5 Disposing Batteries Batteries that are damaged or depleted should be replaced and discarded properly.
  • Page 75 E80/E70 Digital Electrocardiograph User’s Manual Chapter 7 Clean and Maintenance Summarize Keep your equipment and accessories free of dust and dirt. To avoid damage to the equipment, follow these rules: 1. Always dilute according the manufacturer’s instructions or use lowest possible concentration.
  • Page 76 E80/E70 Digital Electrocardiograph User’s Manual panel.  Do not use abrasive material including wire brush or metal brightener during cleaning because this material will damage the panel and electrocardiograph screen.  Do not submerge the electrocardiograph in liquid.  While cable or plug of attachment accidentally gets wet, please rinse it with distilled water or deionized water and dry it in the environment of temperature 40℃...
  • Page 77 E80/E70 Digital Electrocardiograph User’s Manual 2． Chest electrode and limb electrode Please clean chest electrode and limb electrode before disinfection. Wipe off the conductive paste on surface of electrode with soft cloth; Take apart the electrode plate and clamp of limb electrode as well as rubber ball and metal cup of chest electrode;...
  • Page 78 E80/E70 Digital Electrocardiograph User’s Manual 7.4 Cleaning and Maintenance of Recorder To prevent stain on surface of thermosensitive printing head due to excessive long period of use of printer and clarity of recording is adversely affected, the users shall regularly...
  • Page 79 E80/E70 Digital Electrocardiograph User’s Manual Chapter 8 Accessories  Warning:  Use only accessories specified in this manual. Using other accessories may cause damage to the electrocardiograph.  Check the accessories and their packages for any sign of damage. Do not use them if any damage is detected.
  • Page 80 E80/E70 Digital Electrocardiograph User’s Manual Name Specification Thermosensitive chart 216mm*280mm 1.21.00-000024-005 paper 15PIN Type AAMI With 10K defibrillation standard integrated 1.15.52-0035-01-00 resistance 12-lead ECG cable 15PIN Type IEC With 10K defibrillation standard integrated 1.15.52-0035-02-00 resistance 12-lead ECG cable 15PIN Type AAMI...
  • Page 81 E80/E70 Digital Electrocardiograph User’s Manual Appendix A Product Specifications A.1 Safety Specifications According to the MDD 93/42/EEC, the electrocardiograph is Type Ⅱa equipment. Classified according to the IEC60601-1 is as follows: Class I, internally and externally powered equipment. Classification of...
  • Page 82 E80/E70 Digital Electrocardiograph User’s Manual A.3 Physical Specifications E80: 400mm×330mm×100mm Size (W×H×D) E70: 400mm×330mm×146mm E80: ≤7kg Weight E70: ≤6kg E80: 12.1″, 800×600 TFT LCD Display E70: 8.0″, 800×600 TFT LCD A.4 Power Specifications A.4.1 AC Power 100V-240V AC Rated Voltage...
  • Page 83 E80/E70 Digital Electrocardiograph User’s Manual ≥300 times ≥80% leave Circle times Indication of With battery capability A.5 Hardware Specifications A.5.1 Recorder Thermal dot array Recording way Horizontal resolution 40 dots/mm 8 dots/mm Vertical resolution 25 mm/s,50 mm/s, error: 5 mm/s,6.25 mm/s,10 mm/s,12.5 mm/s, Recording speed ±3%.
  • Page 84 E80/E70 Digital Electrocardiograph User’s Manual A.6 Measure and Diagnosis of ECG Waveform 30bpm -350bpm HR range ±1bpm (10s average) HR precision ≤5%, 0.333 Coefficient error P time limit, PR interphase, QRS time limit, QT interphase, QTC interphase, RR interphase, RV5swing, SV1swing,...
  • Page 85 E80/E70 Digital Electrocardiograph User’s Manual Patients leakage ≤10 μ A current ≥109 dB (with AC filter) CMRR Time for response to ≤5s wave displaying Time for baseline ≤1s recovered after switching leads 5000V 360J Recovering time for defibrillator-proof ≤5 s...
  • Page 86 E80/E70 Digital Electrocardiograph User’s Manual A.9 Storage Specification 100 groups of ECG data Fixed Memory Flash, SD card or U disk Optional Memory Background storage automatically Storage mode Storage format A.10 Function According to setup, the machine can complete reports of ECG, real-time waveform, rhythm waveform, saving review and freezing analysis;...
  • Page 87 E80/E70 Digital Electrocardiograph User’s Manual Appendix B Factory Default Setting This chapter lists some important factory default settings of electrocardiograph. Users can not change them, but electrocardiograph can be recovered to factory default setting according to actual need. Item Factory Default Setting...
  • Page 88 E80/E70 Digital Electrocardiograph User’s Manual Item Factory Default Setting Default setting Factory Continue record Default medium Flash Grid Auto Cover...
  • Page 89 E80/E70 Digital Electrocardiograph User’s Manual Appendix C Prompt Information Prompt information Cause Sampling Data collection No paper Chart paper is not installed or chart paper is used up File review The selected data are being reviewed. Operations for the recorded export data may be Continue to record continued.
  • Page 90 E80/E70 Digital Electrocardiograph User’s Manual...
  • Page 91 E80/E70 Digital Electrocardiograph User’s Manual Appendix D Diagnosis Info Mark Caution: Analysis diagnoses functions in this manual is not applied to areas where need CE Certificate. D.1 Otherwise Diagnosis Terms Info Mark Unsatisfactory Record Arm leads Reversed Counter Clock Wise Rotation...
  • Page 92 E80/E70 Digital Electrocardiograph User’s Manual D.3 Ventricular Hypertrophy and Atrial Enlargement Diagnosis Terms Info Mark High Voltage (Left Ventricle) Positive T in V1 Right Ventricular Hypertrophy? (RVH) Left Ventricular Hypertrophy? (LVH) LVH (Probably Normal for This Age) Right Ventricular Hypertrophy...
  • Page 93 E80/E70 Digital Electrocardiograph User’s Manual Diagnosis Terms Info Mark WPW Syndrome? WPW Syndrome (A) ? WPW Syndrome (B) ? PR Prolongation AV Block 2 (Wenckebach) AV Block 2 (Mobitz) 2:1 AV Block Complete AV Block Artificial Pacemaker Rhythm (A) Artificial Pacemaker Rhythm (V)
  • Page 94 E80/E70 Digital Electrocardiograph User’s Manual Diagnosis Terms Info Mark ICLBBB (Incomplete Left Bundle Branch Block) Suspect Left Anterior Hemi Block LAH (Left Anterior Hemi Block) LPH (Left Posterior Hemi Block) BBBB (Bifascicular Bundle Block) TBBB (Trifascicular Bundle Block) Peri-Infarction Block D.6 ST-T Morphology Statements...
  • Page 95 E80/E70 Digital Electrocardiograph User’s Manual Diagnosis Terms Info Mark Anterior Infarction Anterior Infarction (possibly recent) Anterior Infarction (possibly acute) Suspect Anteroseptal Infarction? Possible Anteroseptal Infarction Anteroseptal Infarction Anteroseptal Infarction (possibly recent) Suspect Lateral Infarction? Possible Lateral Infarction Lateral Infarction Lateral Infarction (possibly recent)
  • Page 96 E80/E70 Digital Electrocardiograph User’s Manual Diagnosis Terms Info Mark Suspect Left Atrial Rhythm? AV junctional Rhythm AV Dissociation Marked Sinus Bradycardia Sinus Bradycardia Sinus Tachycardia Tachycardia Bradycardia Extreme Tachycardia Extreme Bradycardia Sinus Arrhythmia Escape Beat PAC (Premature Atrial Construction) Frequent PAC...
  • Page 97 E80/E70 Digital Electrocardiograph User’s Manual Diagnosis Terms Info Mark PVC (RonT) SA Block or Marked Sinus Arrhythmia Blocked PAC Supraventricular Tachycardia Ventricular Tachycardia Ventricular Escape Rhythm Ventricular Rhythm Atrial Fibrillation Atrial Flutter Ventricular Fibrillation Undefined Arrhythmia D.9 Diagnosis Result Diagnosis...
  • Page 98 E80/E70 Digital Electrocardiograph User’s Manual D.11 Datum Value Datum value used for classification of Minnesota Code and diagnosis information is based on age and gender according two methods as following: (1)a（b1，b2）c d Age of the male or the female not less than 19 years old...
  • Page 99 E80/E70 Digital Electrocardiograph User’s Manual Appendix E Measurement One predominant beat is selected from each 12 leads waveform. The 12 predominant beats are used by EMDI to locate the waveform boundaries (the onsets and ends of P, QRS, T wave) in multilead ECG signal (the 12 standard leads) and measure features of clinical importance (such as the amplitude and duration of the Q, R, S, R’...
  • Page 100 E80/E70 Digital Electrocardiograph User’s Manual E.2 Measurements of One Beat Parameter Description Measurement unit Amplitude of the P wave Amplitude of the P’ P’a wave(in case of biphasic P wave) Amplitude of the Q wave Amplitude of the R wave Amplitude of the S wave R’a...
  • Page 101 Product name: Digital Electrocardiograph Product type: E80/E70 Manufacturer: Guangdong Biolight Meditech Co., Ltd. Address: No.2 Innovation First Road, Technical Innovation Coast, Hi-Tech Zone Zhuhai, P.R. China Fax: +86-756-3399919 Post code: 519085 Toll-free consultation hot line: +86-400-8818-233 PN: 22-041-0004...

This manual is also suitable for:

E70
