Biolight Meditech AnyView A8 Service Manual

Patient monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AnyView A8/A6/A5/A3
Patient Monitor Service Manual
GuangDong Biolight Meditch Co,.ltd
No.2 Innovation First Road, Technical Innovation Coast, Hi-tech Zone, Zhuhai , P.R.China
Tel: +86-756-3399900
Fax: +86-756-3399989
http://www.blt.com.cn
J/A8-112-2011A4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AnyView A8 and is the answer not in the manual?

Questions and answers

Related Manuals for Biolight Meditech AnyView A8

Summary of Contents for Biolight Meditech AnyView A8

  • Page 1 AnyView A8/A6/A5/A3 Patient Monitor Service Manual GuangDong Biolight Meditch Co,.ltd No.2 Innovation First Road, Technical Innovation Coast, Hi-tech Zone, Zhuhai , P.R.China Tel: +86-756-3399900 Fax: +86-756-3399989 http://www.blt.com.cn J/A8-112-2011A4...

  • Page 2: Table Of Contents

    Service Manual of Patient Monitor CONTENTS Chapter 1 Summary....................2 1.1 About the Manual........................2 1.2 Safety Information ........................3 1.3 Equipment Symbols ......................4 Chapter 2 Monitor Introduction................6 2.1 Main Frame ...........................6 2.2 EMS Module ........................15 2.3 MPS module........................17 2.4 Other Parameter Modules ....................18 2.4 Accessories..........................20 Chapter 3 Testing....................23 3.1 Brief Introduction........................23...

  • Page 3: Chapter 1 Summary

    Service Manual of Patient Monitor Chapter 1 Summary 1.1 About the Manual 1.1.1 Notes This service manual introduces in detail the hardware composition, assembling, disassembling, testing and trouble-shooting of this product and its relevant spare parts so as to facilitate the maintenance personnel to handle common failures more effectively.

  • Page 4: Safety Information

    Service Manual of Patient Monitor Warning: The monitor is intended for use only by clinical Professionals or under their guidance. It must only be used by persons who have received adequate training in its use. Anyone unauthorized or untrained must not perform any operations on it.

  • Page 5: Equipment Symbols

    Service Manual of Patient Monitor Please connect the monitor to a socket with protective earth. If the socket does not have protective earth conductor, please do not use the socket and use battery to provide power to the monitor Keep the packing materials out of children’s reach. DiSpOsal of the packing materials should observe the applicable waste control regulations.
  • Page 6 Service Manual of Patient Monitor Symbol Symbol Note Symbol Symbol Note Auxiliary output Short for “Carbon dioxide” connector DVI display connector Short for “Anesthetic gas” Short for “Impedance VGA display connector cardiography” Defibrillator USB socket synchronization output connector Auxiliary plug-in box Network connector connector Manufacture date...

  • Page 7: Chapter 2 Monitor Introduction

    Heart Rate (HR), Respiration Rate (RR), Temperature(Temp), Pulse Oxygen Saturation(SpO2), Pulse Rate(PR), Non-invasive Blood Pressure(NIBP), Invasive Blood Pressure(IBP), Impedance Cardiograph(ICG), Carbon dioxide(CO2), Anesthetic gas(AG), Oxygen(O ) and so on. AnyView A8 AnyView A6 Document NO: J/A8-112-2011A3 Page 6 of 72...
  • Page 8 Conduct real-time display, review, storage, and output of the monitored parameters or waveforms. Multiple operation input mode, including keys, trim knob, touch-screen, keyboard and mouse. Wire connection with CMS system provided. Program upgrade. 2.1.2 Appearance, Connector, Slot AnyView A8/A6/A5: Document NO: J/A8-112-2011A3 Page 7 of 72...
  • Page 9 Service Manual of Patient Monitor AnyView A3: Document NO: J/A8-112-2011A3 Page 8 of 72...
  • Page 10 Service Manual of Patient Monitor 2.1.3 Hardware Structure The host monitor is composed of the following parts: Input system: key board, trim knob, touch-screen (optional), power switch and indicator board Output system: display screen, alarm indicator board, recorder, loudspeaker and SD card (optional) Processing and communication system: main-board, CIS board (or based board for main board), host plug-in box and SORT board (...
  • Page 11 Service Manual of Patient Monitor Touch key board Key board On the right side of the screen, 5 key inputs are provided, and the touch key board is located on the bottom of the front interface component and is connected to the main-board.
  • Page 12 Service Manual of Patient Monitor Display The host monitor has a built-in high-brightness LCD display. The display is connected with the backlight board and the main-board, and the DC power it uses for operation is provided by the main-board and is supplied to the backlight board by the key board and then supplied to the display by the backlight board.
  • Page 13 Battery interface board: connect with batteries and power module SORT board: connect with Power module（Anyview A3） 2.1.3.5 Equipment Interface System: SOPA Interface Board, SOPB Interface Board AnyView A8/A6： AnyView A5： SOPA interface board: with DVI, VGA interfaces, it can be connected with DVI or VGA video output.
  • Page 14 It also can be connected to nurse call system in hospital. When an alarm occurs, outputting the nurse call signal to remind nurse. 2.1.4 Design Principle Schematic diagram: AnyView A8/A6: Document NO: J/A8-112-2011A3 Page 13 of 72...
  • Page 15 Service Manual of Patient Monitor Switch Alarm lamp Battery Power module Touch-key board Battery interface board Board CIS board Back light Speaker I/O interface board A interface Main board Recorder board B SD card Parameter module EMS Interface board SOPA interface board SOPB interface board EMS module NETWORK...

  • Page 16: Ems Module

    Service Manual of Patient Monitor AnyView A3: 2.2 EMS Module 2.2.1 Overview EMS is a multi-functional measurement module with a color display screen. It can monitor 3-lead, 5-lead and 12-lead ECG (including Arrhythmia and ST segment), Resp, SpO2, PR, Temp, NIBP and IBP. Under the module mode, EMS can serve as a multi-functional measurement module, which is used in combination with the host monitor.
  • Page 17 Service Manual of Patient Monitor 2.2.2 Appearance, Connector 1. ECG（3-lead,5-lead or 12-lead）, 2. 2temp, 3. NIBP, 4. 2IBP, 5. SpO2, 6. Key, 7. power switch 2.2.3 Hardware Structure EMS module comprises the following constituents: Input system: key board, power switch and indicator board, signal input board and ECG board Output system: display, alarm indicator board, and loudspeaker Processing and communications system: main-board...

  • Page 18: Mps Module

    Service Manual of Patient Monitor MPS module 2.3.1 Overview MPS is a multi-functional measurement module. It can monitor 3-lead, 5-lead and 12-lead ECG (including Arrhythmia and ST segment), Resp, SpO2, PR, Temp, NIBP and IBP. EMS can serve as a multi-functional measurement module, which is used in combination with the host monitor.

  • Page 19: Other Parameter Modules

    Service Manual of Patient Monitor Processing and communications system: main-board 2.3.4 Design Principle Schematic diagram: key board signal main-board input board ECG board 2.4 Other Parameter Modules EMS module: contains（ECG, RESP, SpO2, PR, TEMP, NIBP）and 2 IBP Other modules: IBP module, TEMP module, Nellor SpO2 module, Masimo SpO2 module,CO2 module（contains Mainstream CO2, Side stream CO2 and Micro stream CO2）, AG module, ICG module Document NO: J/A8-112-2011A3...
  • Page 20 Service Manual of Patient Monitor 2-IBP module NELLCOR SpO2 module 2-TEMP module Sidestream CO2 module Microstream CO2 module AG module Document NO: J/A8-112-2011A3 Page 19 of 72...

  • Page 21: Accessories

    Service Manual of Patient Monitor ICG module 2.4 Accessories 2.4.1 General Accessories General accessories mostly contains ECG cable,SpO2 sensor,NIBP cuff, Temperature probe, in addition, it contains mainstream CO2 measurement groupware, micro stream CO2 measurement groupware, AG measurement groupware, ICG measurement groupware. More than this, the monitor also could install ledge, cart, stand of EMS/MPS module for hanging on bed and Rechargeable lithium ion battery of host monitor ECG cable...
  • Page 22 Service Manual of Patient Monitor IBP Extension cable Main stream CO2 sensor and adapter Microstream CO sensor Mainstream AG sensor ICG cable EMS/MPS Extension cable Document NO: J/A8-112-2011A3 Page 21 of 72...
  • Page 23 Service Manual of Patient Monitor Wall Mount Cart Rechargeable lithium ion Stand of EMS/MPS module battery （host monitor） for hanging on bed 2.4.2 Management and Maintenance of Accessories Refer to the User’s manual. Document NO: J/A8-112-2011A3 Page 22 of 72...

  • Page 24: Chapter 3 Testing

    Service Manual of Patient Monitor Chapter 3 Testing 3.1 Brief Introduction To ensure the long-term and stable working of the monitor, maintenance personnel need to conduct regular checks, maintenance and testing on it. This chapter provides the basic testing methods of the monitor and recommends the applicable testing frequency and testing tools, and the maintenance personnel are requested to conduct maintenance and testing on the monitor according to actual demands and choose applicable testing tools.

  • Page 25: Performance Testing

    Service Manual of Patient Monitor 3. Whether external cable has any wear or tear, whether the connector pins have any loosening or distortion. 4. Whether the peripheral interface of the monitor has any loosening or pin distortion. 5. Whether the safety labels or name plates are legible. 3.2.2 Startup Testing Startup test is used to verify whether the monitor can be normally started to work, and if the monitor can accomplish startup according to the following procedures, the...
  • Page 26 Service Manual of Patient Monitor displays “Turning off”. Observe whether the module is able to turn off the monitor normally. 3. Mount the EMS module onto the host monitor, and check if the host monitor indicates “EMS module has been inserted”, “EMS trend upload”, and the host monitor displays the relevant parameters and their scanning lines;...
  • Page 27 Service Manual of Patient Monitor 2. Connect one side of SpO2 probe to the SpO2 extension cable, and connect the other side with the SpO2 simulator. 3. The parameter setup in the simulator is as follows: SpO2 is 96%; pulse rate is 80 bpm.
  • Page 28 Service Manual of Patient Monitor and consistent. 2. In case of such failures as paper lack or paper jam, the screen shall have relevant indication and after restoration, it shall work normally. 3. Conduct the alarm printing of various parameters, turn on the alarm record switches of the various parameters, set up different alarm limits, and in case of a parameter alarm, there shall be the relevant printout of the parameter alarm.
  • Page 29 Service Manual of Patient Monitor 1. Use standard ICG cable and sensor, and configure the ICG simulator and the monitor into a testing system. 2. Select 【ICG Set】 → 【Input info>>】 , and set up the relevant parameters as follows: Gender Male 120 mmHg...

  • Page 30: Chapter 4 Maintenance

    Service Manual of Patient Monitor Chapter 4 Maintenance Enter operation mode, select【Maintenance】→input password:785623,and then ,return main screen, select【Maintenance】,and enter maintenance screen: System Machine Factory Language Software Nurse Defibrillator Setup Alarm Maintenance Maintenance Select Upgrade Call Synchronization Setup 4.1 Maintenance of Monitor Network NIBP PHASEIN...
  • Page 31 Service Manual of Patient Monitor 4.1.3.3 Soft overpress Test It is used for factory maintenance. 4.1.3.4 Air leakage Testing 1. Plug the air pipe plug of cuff into the connector (NIBP) of monitor until the plug and socket contact well 2.
  • Page 32 Service Manual of Patient Monitor 2. Reading of manometer should be 0 before deflate, if not, cut the connection until it return to zero. 3. Select【Maintenance】→input password→【Main Menu】→【Maintenance】 →【Machine Maintenance】→【NIBP Maintenance】→【Adult】→【NIBP Calibration】. 4. Turn up pump output pressure to 150 mmHg,the pressure showed by monitor and consult manometer can’t be over 3 mmHg,if not, setting 【Press Calibration】...
  • Page 33 Service Manual of Patient Monitor Caution: User may only perform zero reference calibration under the instruction of the technical personnel authorized by manufacturer. Warning: Incorrect zero reference calibration will result in false gas readings. 4.1.5 IBP Pressure Calibration The menu is mainly for pressure (IBP) calibration and factory maintenance. 4.1.6 CO2 Module Maintenance The menu is mainly for maintenance of the sidestream CO2 module.
  • Page 34 Service Manual of Patient Monitor 2. Make connections in accordance with the following figure: A. Connect the air outlet tubes of standard gas bottle to one terminal of the 3-way connector, and the middle terminal of the 3-way connector opens to the atmosphere; connect the gas sampling tube provided by our Company to the remaining terminal of the 3-way connector (see the circle part of the above figure), connect the other terminal of the sampling tube to the dehydration bottle and the dehydration bottle is...
  • Page 35 Service Manual of Patient Monitor B. Turn the trim knob, and after moving the cursor to the main menu, press the key to enter【Main Menu】→【Maintenance】→【Machine Maintenance】→【CO2 Module Calibration】, select 【Offset Calibration】as “manual”; C. Enter CO2 menu, select 【Zero】, and enter relevant value according to the concentration of the CO2 standard gas and then press 【Ok】;...

  • Page 36: Factory Maintenance

    Service Manual of Patient Monitor Do not attempt zeroing if the temperature is not stable. Zeroing with CO in the adapter or cannula can lead to inaccurate measurements or other error conditions. If you attempt zeroing while CO remains in the adapter or cannula, the time required to zero the sensor may be increased.

  • Page 37: Entire Setup

    Service Manual of Patient Monitor 3. After inserting the USB disk, the monitor will automatically read the info of the USB disk and the monitor will automatically upgrade the software. 4. When the monitor’s screen displays “Upgrade completed, please unplug USB disk”, unplug the USB disk and then restart the monitor.

  • Page 38: Defibrillator Synchronization

    Service Manual of Patient Monitor technical alarms. 2. Enter 【Main Menu】 【Maintenance】 【Nurse Call】,setting signal output of nurse call ,including continuous signal and 1s pulse signal. （ ） 4.7.2 Analog Signal Output correlate set 1 ． In maintenance mode, 【 Main Menu 】 【...

  • Page 39: Chapter 5 Troubleshooting

    Service Manual of Patient Monitor Chapter 5 Troubleshooting 5.1 Overview This chapter conducts categorization based on the failure type of the monitor, and for troubleshooting, please refer to the failure table and conduct checks according to the sequence. The recommended solutions given in this chapter can solve most of the equipment failures, but may not necessarily cover all possible failures.
  • Page 40 Service Manual of Patient Monitor 1. Check whether the cable from the LCD display screen to the main-board is Cable failure properly connected. 2. Check whether cables and connectors Black screen, are damaged. monitor runs normally Backlight board is Replace the backlight board. damaged LCD display screen Replace the LCD display screen.
  • Page 41 Service Manual of Patient Monitor Recorder is 1. Check whether the cable from the unable to print recorder to the main-board is properly Cable failure connected. 2. Check whether cables and plugs are damaged. Recorder failure Replace the recorder. 1. Under the maintenance mode, 【Main Relevant output menu】...

  • Page 42: Chapter 6 Maintenance And Disassembling

    Attention: When disassembling the EMS/MPS module, press the EMS/MPS clip with one hand, and hold the EMS/MPS module with the other and remove it. AnyView A8/A6: AnyView A5: Document NO: J/A8-112-2011A3 Page 41 of 72...

  • Page 43: Disassemble The Host Monitor

    Service Manual of Patient Monitor AnyView A3: 6.3 Disassemble the Host Monitor 6.3.1 AnyView A8/A6/A5 Open the monitor 1）As shown in the following figure, place the monitor with its back downward, then unscrew the 2 M4×12 screws. AnyView A8/A6: Document NO: J/A8-112-2011A3...
  • Page 44 Service Manual of Patient Monitor AnyView A5: 2）Unscrew the 5 screws of the rear enclosure with a cross screwdriver and then open the monitor. AnyView A8/A6: Document NO: J/A8-112-2011A3 Page 43 of 72...
  • Page 45 Service Manual of Patient Monitor AnyView A5: 3）Unplug the cable connecting the LCD and the key board.(Available on AnyView A8/A6 ) 3) Unplug the cable connecting the LCD, touch-screen transfer board and key board, and unscrew the screw fasting the LCD ground wire.( Available on AnyView A5) Key board wire Touch-screen...
  • Page 46 Service Manual of Patient Monitor 4) Remove the front cover. AnyView A8/A6: AnyView A5: Touch-screen transfer board 2. Disassemble the LCD screen 1) Unscrew the M3 screws, and when it is open, the backlight inverter can be seen. Document NO: J/A8-112-2011A3...
  • Page 47 Service Manual of Patient Monitor AnyView A8/A6: Backlight board AnyView A5: 2) Unscrew the M3×6 screws, unplug the relevant cables, and the LCD can be removed. AnyView A8/A6: Document NO: J/A8-112-2011A3 Page 46 of 72...
  • Page 48 Service Manual of Patient Monitor Key board Touch key board AnyView A5: LCD screen Touch screen Key board Touch key board Document NO: J/A8-112-2011A3 Page 47 of 72...
  • Page 49 Service Manual of Patient Monitor 3. Disassemble the internal block 1) Disassemble the recorder: unplug the recorder cable, then unscrew the 2 M3×8 screws with washers securing the recorder with a cross screwdriver. AnyView A8/A6: AnyView A5: Recorder wire slot 2) Disassemble SD card interface board: unplug the cable of the SD card interface board, then unscrew the M3×6 screws with washers securing the interface board with...
  • Page 50 Service Manual of Patient Monitor AnyView A8/A6: AnyView A5: 3) Disassemble the main-board and the CIS board. AnyView A8/A6: Unplug the relevant cables on the board, unscrew the 4 M3×4 round cap screws each securing the main-board and the CIS board.
  • Page 51 Service Manual of Patient Monitor CIS board Main board AnyView A5: Unplug the relevant cables on the main board, unscrew the 3 M3×4 round cap screws each securing the main-board. Main board VGA wire Document NO: J/A8-112-2011A3 Page 50 of 72...
  • Page 52 3 copper columns. Based board for main board 4) Disassemble the bracket AnyView A8/A6: Unscrew the 4 M3×6 round cap screws securing the bracket. AnyView A5: Unscrew the 4 flat screws, 2 inner screws with gasket and 3 long screws on the power module.
  • Page 53 Service Manual of Patient Monitor 5) Disassemble the slot Unscrew the 3 M3×6 round cap screws securing the various slots. Document NO: J/A8-112-2011A3 Page 52 of 72...
  • Page 54 Unscrew the 2 and 5 M3×6 round cap screws securing the I/O board A and I/O board B 7) Disassemble the power module Unscrew the 4 screws securing the power module and remove the power module. AnyView A8/A6: Power module Document NO: J/A8-112-2011A3...
  • Page 55 Service Manual of Patient Monitor AnyView A5: Power module 6.3.2 AnyView A3 1）Unscrew the 5 screws of the rear enclosure with a cross screwdriver and then open the monitor. Unplug the power cable and data communications cable to remove the front 2）...
  • Page 56 Service Manual of Patient Monitor Data communications Power cable cable 3）Unscrew the 4 screws, Unplug the VGA and SPI cable to remove the main board. Recorder Factory debug slot wire slot Main board wire wire Data Power communications wire slot cable slot Document NO: J/A8-112-2011A3 Page 55 of 72...
  • Page 57 Service Manual of Patient Monitor 4）Unscrew the 12 screws, Unplug the backlight, LCD, touch screen wire and the cover of the knob to remove the main board. Recorder LCD wire slot wire slot Touch screen wire slot Back light Note: Plug the touch screen wire to the main board earth with the king finger side.
  • Page 58 Service Manual of Patient Monitor Unscrew the 5 screws remove the LCD. Then the touch screen will appear. 5） Touch screen Document NO: J/A8-112-2011A3 Page 57 of 72...
  • Page 59 Service Manual of Patient Monitor ）Unscrew the 6 screws at the bottom of the device, then unplug the correlative wires to remove the power part. Speaker slot 12V slot Alarm lamp slot Interface board wire slot IO board wire slot Recorder power wire slot Power wire slot...
  • Page 60 Service Manual of Patient Monitor Note: Under the plastic flake on the power board is the area of 220V. Please install to prevent electric shock. The power board type is PS139-A3 8）Unscrew the 5 screws to remove the interface board. Interface 12V wire board data bus...
  • Page 61 Service Manual of Patient Monitor 11）Unscrew the 5 screws to remove the handle (the alarm lamp is inside). Unscrew the 4 screws and open the handle, then the alarm lamp and fix block appear. Document NO: J/A8-112-2011A3 Page 60 of 72...

  • Page 62: Disassemble Ems Module

    Service Manual of Patient Monitor Alarm lamp board 12）Unscrew the correlative screws to remove the SD card and speaker. Speaker SD card slot 6.4 Disassemble EMS Module Attention: Before disassembling EMS, the built-in battery of the module needs to be removed.
  • Page 63 Service Manual of Patient Monitor Open the module, unplug the LCD cable and key cable. EMS inside structure: Front board BM200 ARM9 board 2. Disassemble the LCD, key board and alarm indicator Respectively unscrew the 4 M3×6 round cap screws securing the LCD, 3 for the key board and 2 for the alarm indicator.
  • Page 64 Service Manual of Patient Monitor Alarm indicator board Key board interface board 3. Disassemble the BM200 module Unplug the air tube and cable assembly, unscrew the 4 M3×6 round cap screws and remove the insulation board, and finally unscrew the 2 copper columns. Document NO: J/A8-112-2011A3 Page 63 of 72...
  • Page 65 Service Manual of Patient Monitor BM200 ARM9 board BM200 ECG board 4. Disassemble the ECG board Remove the insulation board, unplug the cable assembly, and then unscrew the 4 copper columns; remove the plugs of the air pump and air valve and the ECG board can be removed.

  • Page 66: Disassemble Mps Module

    Service Manual of Patient Monitor Pump, valve 6.5 Disassemble MPS Module Please disassemble the MPS module as follows 1. Open MPS Unscrew the 4 M3×6 round cap screws securing the surface enclosure. Document NO: J/A8-112-2011A3 Page 65 of 72...
  • Page 67 Service Manual of Patient Monitor Open the module, unplug the button cable then the inside structure appear. 2. Disassemble the BM200 module Unscrew the 2 M3×6 round cap screws to remove the insulative board. Unscrew the 2 M3×6 round cap screws to remove BLT SpO2 board. Then unplug the air tube and cable assembly, at last unscrew the 2 copper columns.
  • Page 68 Service Manual of Patient Monitor SpO2 board 排线 BM200 NITS board 3. Disassemble the ECG board Remove the insulation board, unplug the cable assembly, and then unscrew the 4 copper columns; remove the plugs of the air pump and air valve and the ECG board can be removed.
  • Page 69 Service Manual of Patient Monitor 4. Disassemble the ECG board, the air pump and solenoid valve under the module appear. 气泵，气阀 Document NO: J/A8-112-2011A3 Page 68 of 72...

  • Page 70: Appendix A Exploded View Of Monitor

    Service Manual of Patient Monitor Appendix A Exploded View of Monitor Description Description Underlay Back enclosure Front enclosure Power supply 1- plug-in module LCD stand EMS module Main board 1- plug-in module Main bracket 2- plug-in module Back connect plug-in slot 3-module slot Speaker stand 1-module slot...

  • Page 71: Appendix B Products Components List

    Service Manual of Patient Monitor Appendix B Products Components List AnyView A8 main unit: Materiel Code Description 2.31.0001-01-00 A8 battery interface board 13-031-0001 2.31.0002-01-00 A8 SOP interface board A（standard） 13-031-0002 2.31.0002-02-00 A8 SOP interface board B 13-031-0003 2.31.0004-01-00 A8 IO interface board A 13-031-0004 2.31.0004-02-00...
  • Page 72 Service Manual of Patient Monitor AnyView A5 main unit: Materiel Code Description 2.31.0001-01-00 A8 battery interface board 13-031-0001 2.38.0001-01-00 A5 SOP interface board A（standard） 13-040-0006 2.38.0002-01-00 A5 SOP interface board B 13-040-0007 2.31.0004-01-00 A8 IO interface board A 13-031-0004 2.31.0004-02-00 A8 IO interface board B 13-031-0005 2.31.1001-01-00...
  • Page 73 Service Manual of Patient Monitor 1.11.40-0000009-00 A3 2PVH external power wire 11-042-0009 1.11.40-0000002-00 A3 web/USB wire 11-042-0002 Other parts: Materiel Code Description 2.31.0101-03-00 BM200 ARM9 board（NIBP+2TEMP+2IBP） 13-031-0013 BM200 ARM9 board 2.31.0101-01-00 13-031-0013 （NIBP+SPO2+2TEMP+2IBP+RS232） 2.31.0102-02-00 BM200 5-lead ECG board 13-031-0014 2.31.0102-01-00 BM200 12-lead ECG board 13-031-0014 2.31.1002-01-00...
  • Page 74 Service Manual of Patient Monitor 2.32.0001-01-00 A6 alarm lamp board 13-032-0001 2.32.0002-01-00 A6 key board 13-032-0002 2.32.0003-01-00 A6 power switch key board 13-032-0003 1.12.06-37-0180-00 LB-02 lithium ion battery（3.7V/1800mAh) 12-100-0001 1.12.06-11-4000-00 LB-08 lithium ion battery 11.1V/4000mAh 12-100-0003 3.18.01-01 A8 plug-in monitor 23-031-0001 3.24.01-01 A8 2-temp plug-in box...
  • Page 75 Product Model: Any View A8/A6/A5/A3 Product Name: Patient monitor Manufacturer Name: Guangdong Biolight Meditech Co,.Ltd. Address: No.2 Innovation First Road, Technical Innovation Coast, Hi-tech Zone, Zhuhai, P.R.China Post code: 519085 PN: 22-031-0006...
