- Page 1 79556 DIE GRINDER INSTRUCTION MANUAL 550W 220-230V~50Hz SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION WARNING: read all safety warnings and instructions.Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.Save all warnings and instructions for future reference.The term ”power tool” in the warnings refers to your mains-operated (corded) power tool. Work area safety a) Keep work area clean and well lit. - Page 3 SAFETY Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.
- Page 4 SAFETY Note: Symbology Class II Double insulated for additional protection CE conformity Read the instruction manual before using Wear hearing protection while operating the tool Wear hand protection Always use breathing apparatus when machining materials which generate dust. Wear ear protection. Waste electrical products should not be disposed of with household waste.
-
Page 5: Specifications
SPECIFICATIONS SPECIFICATIONS Rated Voltage 220~230V Frequency 50Hz Rated input power 550W Collet diameter 6mm / 1/4" No load speed : 7000-34000/min Max. Grinding Diameter 38mm Protection class FUNCTIONS FUNCTIONS Variable speed knob Anti-heat cover Switch Collet nut... -
Page 6: Operation Regulations
SET UP OPERATION REGULATIONS 1. ASSEMBLE AND DISASSEMBLE THE SANDING HEAD Please put on of spanner on spindle, and use another spanner screw out the collet nut. The direction of clockwise is to fixing the sanding head. The direction of unclockwise is take the sanding head off. (figure 1.) Spanner figure 1. -
Page 7: Service And Maintenance
SERVICE AND MAINTENANCE SERVICE AND MAINTENANCE 1. Always disconnect the tool before carrying out inspection or cleaning. Never use water or other liquids to clean the tool. Clean the tool by brushing it with a brush. 2. The air-vent of the tool should be cleaned regularly to avoid the motor too hot due to air-vent blocked. 3. -
Page 8: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Problem Possible causes Likely Solutions Tool will 1 . Cord not connected. 1 . Check that cord is plugged in. not start. 2. Check power at outlet. If outlet is unpowered, 2. No power at outlet. turn off tool and check circuit breaker. If 3. -
Page 9: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79556 DIE GRINDER Complies with the essential health and safety requirements of the following Directices: the EMC directive (2014/30/EU) Standards and technical specifications referred to:... - Page 10 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
