Forge Hector MEN0905 Quick Start Manual

PARTS INCLUDED
A B
SS-20.1350 SS-20.1351
x1
H
G
SS-20.1356 x1 SS-20.1357
STEP 1
Place the seat frame A on a clean surface, with the
holes facing upwards.
Attach the legs B and C to the seat frame A by
threading the long bolts J half-way into the holes in
the legs as shown, using wrench K.
DO NOT fully tighten the bolts.
E
B
Attach the footrests E to the legs B and C by
threading the short bolts I half-way into the holes in
the legs as shown, using the wrench K.
DO NOT fully tighten the bolts.
Hector
Dual Height Stool
C
x1 SS-20.1352
I
Short Bolt
x1 SS-10.1358
I
K
J
Holes facing
A
upward
4803117
Model MEN0905
D
x1 SS-20.1353
J
Long Bolt
x20 SS-10.1359
STEP 2
Attach the wood seat D to the seat frame A
by threading the long bolts J half-way into
the holes in the wood seat as shown, using
the wrench K.
NOTE: The wood seat D should not cover the
back of the legs B and C.
Once bolts have been threaded into all
holes, fully tighten the bolts attaching the
wood seat.
Fully tighten the bolts inserted in Step 1.
C
B
Front
D
QUESTIONS?
Contact Customer Care
1-800-721-4191
Monday - Friday 8 - 5 Central Time
E
x1 SS-20.1354 x2
K
Wrench
x12 SS-10.1360 x1
C
K
F
x4
SS-20.1355
L
SS-20.1361 x4
J
A
Back
