Model No. FDSS90030 Serial No. USER’S MANUAL Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the garage organizer. 1. Read all instructions in this manual before 8. The work bench is designed to support a using the garage organizer. maximum weight of 1,000 pounds.
The model number is enhance your workspace. FDSS90030. The serial number can be found on a decal attached to the work bench (see the front cover of For your benefit, read this manual carefully before this manual for the location of the decal).
ASSEMBLY Before beginning assembly, carefully read the • Tighten all parts as you assemble them, unless following information and instructions: instructed to do otherwise. • Assembly requires two persons. • As you assemble the garage organizer, make sure all parts are oriented exactly as shown in •...
Page 6
2. Identify a Short Front Right Post (5) and a Short Front Left Post (4); each of these Posts has a lip on one side and is labeled with a sticker. Attach the Short Front Right Post (5) to the Cabinet Base (1) with a 5/16”...
4. Set a Shelf (17) on the four Shelf Brackets (31). Slide a Short Side Panel (13) into the indicated slots in the Short Front Left Post (4) and the left Short Rear Post (3). Make sure the Short Side Panel is in the indicated slot in the Cabinet Base (1).
Page 8
6. Attach a Cabinet Top (2) to the four Posts (3, 4, and 5) with four 5/16” x 2 1/4” Button Head Bolts (57) and four Spacer Inserts (26). Tall Two-Door Locker Do not put a bolt in this hole 7.
Page 9
8. Identify the two Tall Front Posts (7); each of these Posts has a lip on one side. Attach one of the Tall Front Posts (7) to the Cabinet Base (1) with a 5/16” x 2 1/4” Button Head Bolt (57). Attach the other Tall Front Post and the two Tall Rear Posts (6) to the Cabinet Base in the same manner.
Page 10
10. Insert three Shelf Brackets (31) into the indicated slot in one of the Tall Rear Posts (6). Secure the Shelf Brackets at the desired heights with three 1/4” x 1 1/2” Cap Screws (56). Insert three Shelf Brackets into each of the other three Tall Posts. Secure the Shelf Brackets with 1/4”...
Page 11
12. Set a Cabinet Top (2) on the four Posts (7 and 6). Thread four 5/16” x 2 1/4” Button Head Bolts (57) with four Spacer Inserts (26) two complete turns into the Cabinet Top and the Posts; do not tighten the Button Head Bolts yet.
Page 12
Drawer Cabinet Do not put a bolt in this hole 14. Have a second person hold a Cabinet Base (1) in the position shown. Insert a Right-Tab Insert (22) into the indicated corner of the Cabinet Base. Attach a Locking Caster (19) and the Right-Tab Insert to the Cabinet Base with three 5/16”...
Page 13
17. See drawing 17a. Orient a Small Drawer Front Panel (37) at an angle as shown. Hold the Small Drawer Front Panel under the indicated tabs on the Side Panels (35, 36) of one of the drawers. See drawing 17b. (Note: This drawing shows the drawer from the back.) Press the indicated tabs on the Small Drawer Front Panel (37) onto the indicated lip on the Drawer Bottom (33).
19. Slide a Short Side Panel (13) into the indicated slots in the Left Post Assembly (B). Insert another Short Side Panel and a Short Rear Panel (14) in the same manner. Slots 20. Attach the remaining Cabinet Top (2) to the Post Assemblies (A, B) with four 5/16”...
21. Insert the drawer with the Locking Drawer Face (8) into the top two Drawer Slides (41). Insert the remaining three drawers in the same manner. Make sure the large drawer is at the bottom. Large Drawer Work Bench 22. Note: Do not remove the Table Top (46) from the box yet.
Page 16
23. With the help of a second person, remove the Table Top (46) from the box and stand it on the Table Legs (45). Have a second person hold the Table Brace (47) against the Table Legs (45) and the Table Top (46).
USING THE GARAGE ORGANIZER PLUGGING IN THE POWER CORD The temporary adapter should be used only until a properly grounded outlet (see drawing 1) can be installed by a qualified electrician. DANGER: Improper connection The green-colored rigid ear, lug, or the like extending of the equipment-grounding conductor can from the adapter (see drawing 2) must be connected result in an increased risk of electric shock.
Page 18
LOCKING THE CASTERS REMOVING THE DRAWERS The locking casters can be locked to prevent the short To remove a drawer, first pull the drawer out as far as and tall two-door lockers and the drawer cabinet from it will go. Locate the small lever on the inner drawer moving.
Page 20
REMOVE THIS PART IDENTIFICATION CHART, PART LIST, AND EXPLODED DRAWING BEFORE BEGINNING ASSEMBLY. SAVE THIS PART IDENTIFICATION CHART, PART LIST, AND EXPLODED DRAWING FOR FUTURE REFERENCE.
Page 21
PART IDENTIFICATION CHART— Model No. FDSS90030 R1103A #8 Nylon #10 Nylon Locknut 5/16” Nylon 1/4” Star 1/4” Washer (62) Locknut (64) (65) Locknut (50) Washer (51) 5/16” Star #8 x 3/8” #10 x 3/8” 1/4” x 1/2” Cap 1/4” x 5/8”...
Page 22
PART LIST—Model No. FDSS90030 R01103A Key No. Qty. Description Key No. Qty. Description Cabinet Base Small Drawer Front Panel Cabinet Top Large Drawer Front Panel Short Rear Post Small Drawer Face Short Front Left Post Large Drawer Face Short Front Right Post...
To order replacement parts, call our Customer Service Department toll-free at 1-877-660-1666, Monday through Friday, 6 a.m. until 6 p.m. MST (excluding holidays). Please be prepared to give the following information: • The MODEL NUMBER of the product (FDSS90030) • The NAME of the product (FORGE garage organizer) •...
