Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Wear protective
instructions
gloves
1.
SAFETY
WARNING! This product is only suitable for well insulated spaces or occasional use.
1.1.
ELECTRICAL SAFETY
WARNING! It is the user's responsibility to check the following:
Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all
9
electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products.
Electrical safety information. It is important that the following information is read and understood:
Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9
Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
9
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the correct
fuse.
DO NOT pull or carry the appliance by the power cable.
8
DO NOT pull the plug from the socket by the cable.
8
DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately by a
8
qualified electrician.
If the cable or plug is damaged during use, switch off the electricity supply and remove from use. If the supply cord is damaged, it must
be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Ensure that repairs are carried out by a qualified electrician.
1.2.
GENERAL SAFETY
WARNING! A qualified installer is required to install, adjust and, where necessary, convert the appliance for use with other fuel types.
▲
DANGER! Risk of carbon monoxide poisoning. Failure to provide proper ventilation could result in serious illness or death.
Consult the appliance manufacturer before replacing parts other than those specified or recommended in the servicing instructions.
9
When not in use for an extended period, store in a safe, dry area, out of reach of children.
9
IMPORTANT: This appliance is not intended for persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they DO NOT play with the appliance.
Cleaning and user maintenance on the appliance shall not be made by children without supervision.
9
WARNING! The appliance shall be disconnected from its power source during service and when replacing parts and, if that the removal
of the plug is foreseen, it shall be clearly indicated that the removal of the plug has to be such that an operator can check from any of
the points to which he has access that the plug remains removed.
Check that the heater is in sound condition and good working order. Take immediate action to repair or replace damaged parts.
9
Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Only use diesel or kerosene to fuel this heater, in accordance with instructions in this manual and heaters nameplate.
9
Locate heater on a level and stable surface.
9
Only use heater in well ventilated areas. Ensure continuous ventilation is provided to the heater operating area via windows and doors
9
etc. If people are not required to be present in the heated area, the volume of air to be heated (m³)/heat output kW) ratio must be at
least 10:1 and people must be advised not to remain in the heated area for prolonged periods. If people are required to be present in
the heated area, the volume of air to be heated (m³)/heat output (kW) ratio must be at least 30:1. Ventilation must be to the outside of
the premises in which the heater is to be operated. The total open area (m²) must be at least 0.003 times the total heat output (kW).
The volume concentration of oxygen (O
Before refuelling, shut down the heater and wait for it to cool down.
9
All fuel containers are to be located within safe distance from the heater, as per the applicable regulations.
9
Fuel is to be stored in rooms with insulated floor, so that the fuel cannot penetrate the floor into the open flame below causing fuel
9
combustion.
Fuel storage need to follow all the applicable regulations.
9
WARNING! DO NOT use the heater near flammable material, liquids, solids, gases or compressed gas cylinders etc.
DO NOT stand or place any object less than 2m from the heater output and keep the heater a minimum of 2m from any walls or
8
objects.
DO NOT use the heater in closed rooms, living areas, basements or below ground level.
8
© Jack Sealey Limited
INFRARED SPACE HEATER KEROSENE/
DIESEL HEATER 68,000BTU/HR SPACE
WARMER®
MODEL NO:
Warning
Warning:
Electricity
Hot surfaces
) in the heated room, must always remain above 17%.
²
Original Language Version
IR20.V6
Do not cover
Keep in dry area
protect from rain
Use in well
ventilated areas
IR20.V6
Issue 2
09/08/24
