EXTERIOR
"2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved"
ZINK

ASSEMBLY INSTRUCTIONS




FM_Exterior-Zink_R1_01/11

Advertisement

loading
Need help?

Need help?

Do you have a question about the EXTERIOR ZINK and is the answer not in the manual?

Questions and answers

Related Manuals for Misterstep EXTERIOR ZINK

Summary of Contents for Misterstep EXTERIOR ZINK

  • Page 1       EXTERIOR ZINK   ASSEMBLY INSTRUCTIONS        “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 2 Spacer tube material:    S235‐JR (EN 10027)  Surface treatment:    Nylon 6.6 ‐ Black  Railing and other components  Columns ∅22    Material:      S235‐JR (EN 10027)  Surface treatment:    hot dip galvanised (UNI EN 14.07.000.0)  Top material and accessories:  Nylon 6.6 ‐ Black  Handrail:      Moplen ‐ Black  Bolts:        304 stainless steel  “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...

  • Page 3: Overall Dimensions

    Extra Step Kit Ø1400  Extra Step Kit Ø1600  Remarks   A feature of hot dip galvanised products is small areas where the adhesion of zinc is not perfect.  It is also possible that the galvanised surface is damaged during assembly. To guarantee a long product life,  a bottle of liquid zinc is included, and can be applied by brush to make small touch‐ups after assembly. We  recommend that you periodically check the integrity of the staircase, touching up any damaged spots with  similar products available on the market. A feature of hot dip galvanised products is that they become dull  over time, due to a normal process of oxidation of the zinc exposed to the weather. It is possible to paint  the  staircase  immediately  after  assembly,  using  a  suitable  primer  or,  without  special  precautions,  after  exposure to the weather of at least 12 to 18 months.      “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...

  • Page 4: Notes For Installation

    5) Adjust the  plastic spacers  by tightening the threaded ring nut, leaving a distance of A‐170 between  the two beats. (Remember that A = HT/n° steps).  6) Insert  the  elements  in  the  pole,  starting  from  the  plate  cover  and  continuing  with  the  spacers  and  steps.  7) Position the landing at the correct exit point and secure it to the wall with wall anchors.  8) Insert the terminal flange, the threaded bar and the terminal in the pole, then tighten using the nut,  in order to compress the staircase, but leaving the steps free to rotate.  “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 5 Riser  230:  slide  the  central  columns  through  the  slot,  bringing  them  to  the  minimum  distance  between them.  Adjust the through‐columns accordingly, sliding them upwards.  13) Arrange  the  columns  on  the  landing  step  and  insert  the  tops.  Secure  the  handrails  to  the  columns,  fixing the tops with the relative screws. (The section of handrail supplied in the staircase package is  enough for 2 additional steps).    “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 6 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 7 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 8 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 9 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 10 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 11 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 12 Ø 1200  Q.  COD. IMAGE EXTERIOR  ZINK 602042010 602121010 600230510 600231510 600231710 600232510 600233010 600340010 600343010 600356010 600490010 600496017 600497017 600498017 630103542 630132042 M8 X 40 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 13 Q.  COD. IMAGE EXTERIOR  ZINK 630152000 8 X 100 630133542 M10 X 80 630142042 5 X 20 630192010 M22 X 1050 630331442 8 X 24 630333042 M10  630330242 10 X 30 640052014 640067114 640067214 640067414 640067514 640071014 640076014 640060514 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 14 Ø 1200  Q.  COD. IMAGE EXTERIOR  ZINK 640079014 650800000 640043014 640045014 640067814 640067914 640081514 640065214 630109242 M6 X 6 630109142 640400114 640400214 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 15 Ø 1400  Q.  COD. IMAGE EXTERIOR  ZINK 602043010 602122010 600230510 600231510 600231710 600232510 600233010 600340010 600343010 600356010 600490010 600496017 600497017 600498017 630103542 630132042 M8 X 40 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 16 Q.  COD. IMAGE EXTERIOR  ZINK 630152000 8 X 100 630133542 M10 X 80 630142042 5 X 20 630192010 M22 X 1050 630331442 8 X 24 630333042 630330242 10 X 30 640060514 640052014 640067114 640067214 640067414 640067514 640071014 640076014 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 17 Ø 1400  Q.  COD. IMAGE EXTERIOR  ZINK 640079014 650800000 640043014 640045014 640067814 640067914 640081514 640065214 630109242 M6 X 6 630109142 640400114 640400214 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 18 Ø 1600   COD. IMAGE EXTERIOR  ZINK 602044010 602123010 600230510 600231510 600232110 600232710 600233010 600340010 600343010 600356010 600490010 600496017 600497017 600498017 630103542 M8 X40 630132042 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 19 Ø 1600   COD. IMAGE EXTERIOR  ZINK M8 X 40 630133542 5 X 20 630142042 630192010 M22 X 1050 8 X 24 630331442 630333042 10 X 30 630330242 8 X 100 630152000 640052014 640067114 640067214 640067414 640067514 640071014 640076014 640060514 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 20 Ø 1600   COD. IMAGE EXTERIOR  ZINK 640079014 650800000 640043014 640045014 640067814 640067914 640081514 640065214 M6 X 6 630109242 630109142 640400114 640400214 “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
  • Page 21                 MISTERSTEP S.R.L. VIA TRAIANO IMPERATORE, 6 47122 FORLI’ (FC) ITALY TEL. + 39.0543.791211 FAX + 39.0543.777346 WWW.MISTERSTEP.IT INFO@MISTERSTEP.IT “2011 © Misterstep S.r.l. – Tutti i diritti riservati - All rights reserved” FM_Exterior-Zink_R1_01/11...
