RK700T
Installation Manual
For sliding gate installation
Installation Video
The opener can be powered by AC electricity ONLY.
C030418
VER250623

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RK700T and is the answer not in the manual?

Questions and answers

Summary of Contents for Topens RK700T

  • Page 1 RK700T Installation Manual For sliding gate installation Installation Video The opener can be powered by AC electricity ONLY. C030418 VER250623...
  • Page 2: Order Information

     Issue Description (Include Any Relevant Photo or Video) For Warranty Registration To register your warranty, please visit www.topens.com If you have any questions regarding what is covered by the TOPENS warranty, refer to the detailed policy at www.topens.com/pages/topens-limited-warranty. Email Us: support@topens.com...
  • Page 3: Table Of Contents

    Table of Contents Important Safety Information ......................1 Packing List ............................4 Installation Overview ......................... 5 Specifications ............................6 Before You Begin ..........................7 Installation ............................8 Terminal Function of the Control Board ..................13 Connection of Power Supply ......................14 Setting of Left / Right Open ......................15 Program the Remote Control ......................16 Adjust the Open / Close Limit Position ....................17 Setting of the Control Board ......................
  • Page 4: Before Installation

    Thank you for choosing the TOPENS RK700T sliding gate opener. When installed correctly and used properly, your opener will offer years of reliable service. This manual is designed to guide you through the proper installation of your RK700T sliding gate opener. Please carefully review all instructions before commencing the installation and operation of this automatic gate opener.
  • Page 5: During Installation

     WARNING SIGNS: Attach the provided warning signs to both sides of the gate in highly visible locations to alert the public about the automatic gate opener system. If your signs are damaged or missing, please reach out to TOPENS Customer Support for replacements.
  • Page 6 DETAILED WARRANTY POLICY: If you have  gate opener without prior consultation any questions regarding what is covered by with TOPENS will also invalidate warranty the TOPENS warranty, refer to the policy at coverage. www.topens.com/pages/topens-limited-wa NON-COMPLIANCE WITH INSTRUCTIONS: rranty. ...
  • Page 7: Packing List

    Safety Accessories Supplementary Racks (Included in specific models, please check the (If the rack is insufficient, additional racks can actual package.) be purchased separately at www.topens.com.)
  • Page 8: Installation Overview

    TEW3 Vehicle Sensor Exit Wand ❺ ⓬ TC188 Universal Keypad TRF3 Reflection Photocell Sensor ❻ ⓭ TC175P Wired Keypad TC102 Infrared Photocell Sensor ❼ ⓮ TKP3 Wireless Keypad JD110VY / JD230VY Warning Light * Available on the TOPENS website (www.topens.com) and Amazon.
  • Page 9: Overall Dimensions

    Product Model RK700T Power Input 110-120VAC/60Hz or 220-240VAC/50Hz Motor Voltage 120VAC or 230VAC Motor Power 300W (2/5 HP) Gate Moving Speed 15 cm/s (6 in/s) Max Gate Weight 700kg (1600lbs) Max Gate Length 12m (40ft.) Working Temperature -20℃ ~ +50℃ (0°F to 120°F)
  • Page 10: Before You Begin

    Check the Gate  Ensure that the gate is plumb, level, and slides smoothly in both directions without binding or dragging on the ground.  Confirm that the gate track is straight, horizontal, and firmly affixed, with positive stops installed at each end. Make sure the gate wheels and guide rollers rotate freely and are clean of dirt or grime.
  • Page 11: Installation

    CAUTION  Ensure that the opener is installed in a level and parallel position and is securely fastened.  Improper installation may result in property damage, severe injury, and / or death. STEP 1 Identify the Location of the Power Cord Hole Unscrew the four cover ...
  • Page 12 STEP 3 Lay out the Concrete Pad Dig a hole for the concrete  designated location for the opener. The dimensions should be approximately 460 x 420 x 350mm (18" x 16.5" x 14"). Install electrical  conduit (right under the power cord hole of the opener).
  • Page 13 STEP 4 Install the Opener Attach the opener to the  concrete pad, ensuring that it is perfectly parallel to the gate. Secure it to the anchor bolts with M10 Hex Nuts, ¢ 10 Lock Washers, and ¢10 Plain Washers. DO NOT over tighten the ...
  • Page 14 STEP 6 Fit the Rack Place the rack on the gear,  ensuring that it is level and fully engaged with the gear teeth across their entire thickness. Maintain a 1mm ( 0.04")  gap between the rack and the gear to prevent the weight of the gate from affecting the opener.
  • Page 15 STEP 7 Install the Magnets Attach the S and N magnets to  the magnet brackets. From the inside view of the  property, install the S magnet bracket on the left side and the N magnet bracket on the right side.
  • Page 16: Terminal Function Of The Control Board

    Terminal Function ○ 1 “L” Input terminals for AC power, connected to the live and neutral wires of ○ 2 “N” the power cord respectively. Output terminals for motor control, connected to the black, yellow, ○ and red wires of the motor, respectively. The two wires of the start 3 “U”...
  • Page 17: Connection Of Power Supply

    WARNING  A professional electrician is required for wire connection to avoid the risk of injury, electric shock, or death. NEVER connect the gate opener to an electrical outlet before all the installations have been done.  It is recommended to use a surge protector with a rated current of 10A with the power cord for the 120VAC gate opener and rated current of 5A for 230VAC gate opener.
  • Page 18: Setting Of Left / Right Open

    WARNING  Before operating your gate opener, ensure that the Left / Right Open setting on the control board matches the opening direction of the gate.  If the opener is installed on the left side of the driveway and the gate opens to left, set the opener to Left Open.
  • Page 19: How To Program The Remote Control

    B functions the same as button A. Buttons C and D can be programmed separately to operate additional sliding gate openers by adding extra ERM12 External Receivers (available on the TOPENS website www.topens.com) to each control board, allowing for standard operation without midway mode.
  • Page 20: Adjust The Open / Close Limit Position

    WARNING  Before making any adjustments, disengage the clutch of the gate opener to prevent the gate from moving unexpectedly.  Ensure that the S magnet bracket is always positioned on the left side and the N magnet bracket on the right side when viewed from inside the property. Leave some space at both ends of the gate for proper buffering.
  • Page 21 For Right Open Gate Adjusting the Open Limit Position Use the remote control to open the gate. If the gate stops halfway and fails to get to the desired  open position, disengage the clutch. Use a screwdriver to loosen the screws on the S (left) magnet bracket.
  • Page 22: Dip Switch Settings

    WARNING  Ensure that the gate opener is powered off when making any adjustments.  Keep away from the gate while setting up the gate opener system to avoid unexpected gate movement.  Carefully adjust the DIP switches to prevent the risk of damaging the gate opener and causing injury or death.
  • Page 23 DIP Switch #3: Enable / Disable Auto Close Function ON – Auto close function enabled OFF – Auto close function disabled The factory default setting is OFF. The auto close function allows the gate to automatically close after a set period. IMPORTANT NOTES: ...
  • Page 24: Potentiometer Settings

    Potentiometer Settings Potentiometer A: Adjust the Open and Close Stall Force of the Gate Opener  Turn the potentiometer clockwise to increase the stall force, and counterclockwise to decrease  Stall force regulates the gate's sensitivity to obstacles during operation. A higher stall force setting decreases sensitivity, making the gate less likely to detect objects.
  • Page 25: Stall Force Adjustment & Obstruction Test

    Fine Tune the Stall Force This force should be high enough to ensure the gate reaches both open and close limits without reversing unnecessarily or causing frequent interruptions, but low enough to prevent injury if an obstruction is encountered. The appropriate stall force settings depend on the gate's length and weight, so fine-tuning may be required.
  • Page 26: Connection Of Accessories

    NOTES  This section covers only the programming and wire connections with the control board. For additional operations, please refer to the corresponding accessory user manual.  It is highly recommended to install a photocell sensor in the following situations for safety: if you have children or pets at your property, the gate opener auto close function is set to ON, the gate opener stall force is set to the maximum, a vehicle exit sensor is installed, or other gate control devices are used.
  • Page 27 Wired Mode Connection and Operation Step 1 Remove the Battery Step 2 Wire Connection ○ Connect the “COM” and “NO” terminals to control board terminal 14 “O/S/C” and terminal ○ ○ 13 “COM”. Then connect the “9-24V AC/DC” terminals to control board terminal 13 “COM”...
  • Page 28: Tkp3 Wireless Keypad

    TKP3 Wireless Keypad Operate the gate with a user defined password Programming and Operation Press and release the Learn button  on the control board. The Learn LED will turn on, indicating that the gate opener is now in programming mode.
  • Page 29: Tc173 Wireless Push Button

    TC173 Wireless Push Button Open / close the gate by pressing the wireless button Programming and Operation Press and release the Learn button  on the control board. The Learn LED will turn on, indicating that the gate opener is now in programming mode.
  • Page 30: Tew3 Vehicle Sensor Exit Wand

    TEW3 Vehicle Sensor Exit Wand Opens the gate automatically when it senses an approaching car Wire Connection Connect the RED wire to control ○  board terminal 11 “VCC”. Connect the GREEN wire to control ○  board terminal 13 “COM”. Connect the BLACK wire to control ○...
  • Page 31: Tc175P Wired Keypad

    TC175P Wired Keypad Operate the gate with a user defined password / ID card Wire Connection Connect the wires on the JP2  terminal of the wired keypad to the control board. Connect the RED wire to control ○  11 “VCC”.
  • Page 32: Jd110Vy / Jd230Vy Warning Light

    JD110VY JD230VY Warning Light Flashing when the gate is moving, improving your gate safety Wire Connection Connect the warning light to control ○ ○  board terminals “LAMP”, regardless of the polarity. NOTE: A 2C x 0.3 mm (22AWG) cable is required for the wire connection, but it is NOT included. TRF3 Reflection Photocell Sensor Prevents the gate from closing when...
  • Page 33: Tc102 Infrared Photocell Sensor

    TC102 Infrared Photocell Sensor Prevents the gate from closing when obstructed, adds security Wire Connection Disconnect the jumper wire from ○  terminal 12 “ PHO ” and terminal ○ 13 “COM” on the control board to enable photocell sensor function.
  • Page 34: Erm12 External Receiver

    ERM12 External Receiver Allows up to 250 remotes to be programmed with the gate opener Wire Connection Connect the RED wire to control ○  board terminal 11 “VCC”. Connect the BLACK wire to control ○  board terminal 13 “COM”. Connect the BROWN wire to control ○...
  • Page 35: Maintenance And Replacement Parts

    Failure to properly adjust and retest the gate opener can increase the risk of injury or death. Replacement Parts * Available on the TOPENS website (www.topens.com) and Amazon.
  • Page 36: Troubleshooting

    If your gate opener does not function properly after installation, please follow the steps below before contacting us for assistance. This guide provides common troubleshooting steps to help resolve issues efficiently. For further assistance, please feel free to contact us through our website at www.topens.com. Symptom Possible Solution(s) Step 1 Check Control Board Input Voltage: Verify that the input voltage of the control board matches the local AC power supply.
  • Page 37 Symptom Possible Solution(s) Step 1 Check HALL Sensor: Verify that the HALL sensor board is securely connected to the control board. Step 2 Adjust Stall Force: Ensure that the open and close stall force gate starts are appropriate and not too low. Adjust Potentiometer A to increase immediately stops the force.
  • Page 38 Symptom Possible Solution(s) The motor runs but the Step 1 Check the Clutch: Verify that the clutch for emergency release gate does not move. is properly engaged and not slipping. Step 1 Check DIP Switch Setting: Set DIP Switch #4 to ON for a left-opening gate and OFF for a right-opening gate.
  • Page 43 Your comments and suggestions are important to us as they help us provide the best possible service. Should you have any need to contact us, the info below will help you get in touch: TOPENS Website www.topens.com Contact Us: E-mail: support@topens.com Kindly include your purchase channel, order #, gate information, issue description and your contact information.
