1. BEFORE YOU BEGIN
A. INTRODUCTION
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
B. INSTALLER HAZARD NOTIFICATION
CAUTION: Risk of personal injury. Cast iron
baths are extremely heavy. Wear appropriate safety
equipment when installing these products.
NOTICE: Observe all local plumbing codes.
D. PRODUCT REQUIREMENTS
S Apron baths are not reversible. If the drain and
faucet are on the left end of the recess area, the
installation requires a left-outlet bath.
S Install the unit to a level subfloor.
S Provide properly-dimensioned framing.
S Consult the Kohler Design Manual or the individual
Specification Sheets for the recommended drain.
Above-the-floor (rear outlet) or through-the-floor
drain installations will require a variation code
when ordering Kohler drains.
S Carefully uncrate and inspect the new bath for
damage. Make sure there is no damage to the
bath. If there is a problem, do not install the bath.
Report the specific problem to your dealer immedi-
ately.
S After inspection, return the bath to the crate until
you are ready to install it.
S Most apron baths are 5' to 5-1/2' long, and 14" or
16" high. Measure the bath and the area where the
bath is to be installed to ensure a correct fit.
S Allow for clearance of the water inlets into the
bathing well.
S Ensure that the drain location corresponds to the
bath outlet.
CB
100206-2-
R
ENAMELED CAST IRON
All information in these instructions is based on the latest
product information available at the time of publication.
Kohler Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time
without notice.
These instructions contain important care, cleaning, and
warranty information – please leave instructions for the
consumer.
C. NOTES
For the overall dimensions, weight, and capacity to
overflow, consult the Kohler Design Manual or the
individual Specification Sheets.
E. PRODUCT INFORMATION
Mendota (left outlet) . . . . . . . . . . . . . . . . . . . . . . . . .
Mendota (right outlet) . . . . . . . . . . . . . . . . . . . . . . . .
Dynametric 5.5' (left outlet)
Dynametric 5.5' (right outlet)
Dynametric 5' (left outlet)
Dynametric 5' (right outlet)
Villager (left outlet – extra 4" ledge)
Villager (right outlet – extra 4" ledge)
Villager (left outlet) . . . . . . . . . . . . . . . . . . . . . . . . . .
Villager (right outlet) . . . . . . . . . . . . . . . . . . . . . . . . .
Memoirs (left outlet) . . . . . . . . . . . . . . . . . . . . . . . . .
Memoirs (right outlet) . . . . . . . . . . . . . . . . . . . . . . . .
Seaforth (left outlet) . . . . . . . . . . . . . . . . . . . . . . . . .
Seaforth (right outlet) . . . . . . . . . . . . . . . . . . . . . . . .
Guardian (left outlet) . . . . . . . . . . . . . . . . . . . . . . . .
Guardian (right outlet) . . . . . . . . . . . . . . . . . . . . . . .
Mayflower (left outlet) . . . . . . . . . . . . . . . . . . . . . . . .
Mayflower (right outlet)
APRON BATHS
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
E 2000 Kohler Co.
K-505
K-506
K-515
K-516
K-519
K-520
K-713
K-714
K-715
K-716
K-721
K-722
K-745
K-746
K-785
K-786
K-821
K-824
