- Page 1 V-SOLDER BON-8116／8216 V-CUT SOLDER MACHINE Applicable solder wire diameter 1.0 ~ 1.6 mm USER’S MANUAL Preparation in July 2024 The 1 edition...
-
Page 2: Table Of Contents
CONTENTS page 1. Preface ·········································································· 1 2. Notes for safety ······························································ 1 3. Notes for installation and use ··········································· 2 4. How to use ( A ) Contents and name ··················································· 3 ( B ) How to set and replace a solder wire ······················ 4~5 ( C ) How to check and adjust the V-grooved depth ···············... -
Page 3: Preface
1. PREFACE Thank you very much for purchasing V-cut solder machine. The V-cut solder machine is effective to prevent solder balls and flux scattering by making V-groove onto a solder wire. If your solder wire originally has solder ball prevention effect, this machine may not provide you with a sufficient effect. -
Page 4: Notes For Installation And Use
3. NOTES FOR INSTALLATION AND USE For your safety, make sure to observe the following matters. ◼ This machine is designed with ground specification. For safety, be sure to use a grounded electrical outlet. If you do not have such outlet, install it separately. ◼... -
Page 5: How To Use
4. HOW TO USE (A) CONTENTS AND NAME Footswitch ③ Hex wrench ② Reel shaft ① Body (3 mm) (220V) (100 V) 3P power cable Contents： ① BON-8116 / 8216 Body Including 3P Power cable and Footswitch ② Reel shaft ③... -
Page 6: B ) How To Set And Replace A Solder Wire
HOW TO SET AND REPLACE A SOLDER WIRE (1) Loosen the screw on the guide pulley with a 3 mm Hex wrench, Adjustment lever align the adjustment lever with the same scale as the diameter of the solder to be used, and then tighten the screw firmly to fix it in place. - Page 7 (4) Check if the solder wire is V- grooved correctly. ※ Refer to page 6 "(C) How to Adjustment lever check and adjust V-grooved depth". ※ Check the effect of V-groove shallow processing and adjust the V- groove depth accordingly. deep (5) V-Solder main body should be used on a level surface.
-
Page 8: C ) How To Check And Adjust The V-Grooved Depth
(C) HOW TO CHECK AND ADJUST V-GROOVED DEPTH (1) Cut the V-grooved solder wires vertically three places of about 20 cm each with a cutter. Place the V-grooved section upper, and push the cutter blade straight down to check the cross section easier. -
Page 9: D ) Cleaning
(D) CLEANING V-grooving to solder wire can prevent flux or solder residues from scattering during soldering. However, the residues will adhere to the machine, so clean up the machine frequently. (1）Remove the V-blade protection cover. V-blade protection cover ※2 Unscrew 2 x Philips head screws on the cover (refer to phot ※2) to remove it. -
Page 10: Specifications
5. SPECIFICATIONS Model No. BON-8116 BON-8216 Input voltage 100VAC 220VAC Solder feeding 50Hz: approx. 34 mm/sec. amount 60Hz: approx. 40 mm/sec. Feeding method Footswitch Applicable 1.0 φ ～ 1.6 φ mm solder diameter Dimension 180W x 100D x 115H mm Weight Approx. -
Page 11: Trouble Shooting
6. TROUBLE SHOOTING Troubles Measures How to set a solder wire. Refer to page 4 How to adjust solder wire DIA. Refer to page 4 How to adjust V-grooved depth Refer to page 4 & 6 V-blade or Guide pulley is Refer to page 7 getting dirty. -
Page 12: Warranty And After Sales Service
If the machine has trouble, please read this guide manual once again. If the trouble is still not resolved, please contact your dealer or our service department. JAPAN BONKOTE CO., LTD. 600-14 Kasahara-cho, Mito-shi, Ibaraki 310-0852 JAPAN TEL: +81 29-241-2725 FAX: +81 29-241-2726 URL: http://bonkote.co.jp...
