Reign X0
Specifications
SIZES XS,S,M,L
COLORS Ti Gray/Light Smoke
ALUXX SL-Grade Aluminum,
FRAME
6.7" Maestro Suspension
Fox 36 TALAS FIT RC2 w/ 20mm Thru
FORK Axle and tapered steerer,
120/140/160mm travel
SHOCK Fox DHX 5.0, air
HANDLEBAR
Race Face Atlas, low rise 31.8
STEM Race Face Atlas AM
Crank Brothers Joplin-R Adjustable,
SEATPOST
30.9
Fi'zi:k Zeak w/ 7mm K:ium rails,
SADDLE
Custom for Giant
PEDALS Not Included
SRAM X9 trigger w/
SHIFTERS
Matchmaker Clamp
Shimano SLX w/ Race Face Atlas
FRONT DERAILLEUR
Shiftguide
REAR DERAILLEUR SRAM X0
Avid Elixir CR 185F/160R, Custom
BRAKES
Colored for Giant w 2pc rotor
BRAKE LEVERS Avid Elixir CR
CASSETTE Shimano XTR 11x34, 9-speed
CHAIN Shimano HG-73
CRANKSET Race Face Atlas, 24/36/RG
BOTTOM BRACKET Race Face X Type, External
DT Swiss EX1750 w/Custom decals
RIMS
for Giant
DT Swiss EX 1750, [F] w/ 20mm Axle,
HUBS
[R] w/ 12mm Axle, 32h
SPOKES DT Competiton, 14/15g
TIRES Kenda Nevegal, 26x2.35 Folding
EXTRAS Large has 180R rotor
Specifications and availability subject to change without notice.
IN THE fiERCE WORLD OF AGGRESSIVE ALL-
MOUNTAIN RIDING, STUFF HAPPENS, AND
IT HAPPENS FAST. BE READY FOR ANYTHING.
Frame Technology
If you're going to bomb wicked steeps and stick big drops, you better trust your ride. No suspension
has proven more trustworthy than Maestro. With 6.7 inches of cush travel and an all-new,
incredibly lightweight and stable frame, think of Reign X as your all-mountain security blanket.
Key Upgrades (over Reign X1)
— Fox 36 Talas FIT RC2, 120/140/160mm suspension fork, Fox DHX 5.0 air rear shock
— SRAM X.9 shifters/X.0 rear derailleur with Avid Elixir CR disc brakes
— Crank Brothers Joplin-R seatpost
— DT Swiss EX1750 rim/DT Swiss EX1750 20mm hub, wheelset
frame geometry
Actual Part Head Seat
Frame Size Number Angle Angle*
inches degrees degrees
XS 346852 67.0 72.5
S 346853 67.0 72.5
M 346854 67.0 72.5
L 346855 67.0 72.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Toptube** Headtube Chainstay Wheelbase
inches inches inches inches
22.0 4.6 17.1 43.7
22.4 4.6 17.1 44.1
23.2 5.0 17.1 44.9
24.1 5.9 17.1 45.7
Standover
Height***
inches
27.1
28.4
29.5
30.6
