Giant ANTHEM X1 Datasheet

74
ANTHEM X1
Specifications
SIZES XS,S,M,L,XL
COLORS Red/Black
ALUXX SL-Grade Aluminum,
FRAME
4" Maestro Suspension
RockShox SID Team w/ Poploc,
FORK
100mm travel
SHOCK Fox Float RP23
HANDLEBAR Giant Contact, low rise 31.8
STEM Giant Contact
SEATPOST Giant Contact, 30.9
SADDLE Fi'zi:k Tundra w/ K:ium rails
PEDALS Not Included
SHIFTERS Shimano Deore XT Rapidfire
FRONT DERAILLEUR Shimano Deore XT
REAR DERAILLEUR Shimano XTR, top normal
BRAKES Shimano Deore XT 160mm
BRAKE LEVERS Shimano Deore XT
CASSETTE Shimano Deore XT 11x34, 9-speed
CHAIN Shimano HG-73
CRANKSET Shimano Deore XT, 22/32/44
BOTTOM BRACKET
Shimano Deore XT, External
RIMS Shimano Deore XT
HUBS Shimano Deore XT
SPOKES Shimano Deore XT
TIRES Maxxis Crossmark, 26x2.1 Folding
EXTRAS
Specifications and availability subject to change without notice.
GIANT'S WORLD CUP PROS LOVE RIPPING FAST
TRAIL RIDES NEARLY AS MUCH AS THEY DO
WINNING XC RACES. WITH THIS BIKE, THEY DO BOTH.
Frame Technology
Start with an ALUXX SL aluminum frameset, a hydro-formed work of art with all the right angles,
then add 4 inches of active Maestro travel, and you get an XC race bike that's light enough to waltz
up nasty climbs and stable enough to rail rutted descents. Test editors everywhere agree with
Giant pros: Anthem X nails it.
Key Upgrades (over Anthem X2)
— RockShox SID Team, 100mm suspension fork
and Fox Float RP23 rear shock
— Shimano Deore XT/XTR components
— Giant Contact seatpost, stem and handlebar
— Shimano Deore XT wheelset
frame geometry
Actual Part Head Seat
Frame Size Number Angle Angle*
inches degrees degrees
XS 14.5 342652 71.0 74.0
S 16 342653 71.0 73.5
M 18 342654 71.0 73.0
L 20 342655 71.0 73.0
XL 22 342656 71.0 72.5
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Toptube** Headtube Chainstay Wheelbase
inches inches inches inches
21.9 4.6 16.7 41.3
22.6 4.6 16.7 41.9
23.4 5.1 16.7 42.5
24.2 5.7 16.7 43.3
25.0 6.3 16.7 44.1
Standover
Height***
inches
30.2
30.4
31.0
32.1
32.6
