Discover your Lenovo notebook ® Thank you for choosing a Lenovo notebook! We are dedicated to delivering the best solution to you. Before starting your tour, please read the following information: • Illustrations in this documentation might look different from your product.
Chapter 1. Meet your computer This chapter introduces the appearance, features and specifications of your computer. Front view Have a quick glance at the front view of your computer. ThinkPad E14 Gen 7 Description Description Item Item Microphone Infrared camera / Camera...
Page 10
Description Description Item Item ® Power button with fingerprint reader* TrackPoint pointing stick Speaker TrackPoint Three Buttons Trackpad * for selected models ThinkPad E16 Gen 3 User Guide...
Page 11
Description Description Item Item Microphone Infrared camera / Camera Webcam privacy shutter Touch screen* ® Power button with fingerprint reader* TrackPoint pointing stick Trackpad TrackPoint Three Buttons Webcam privacy shutter Slide the webcam privacy shutter to cover or uncover the camera lens. It is designed to protect your privacy. Important information Your computer contains magnets.
Side view Have a quick glance at ports on both sides of your computer. Intel models Description Description Item Item Security slot HDMI™ connector ® USB-C power connector (USB 20Gbps) Ethernet connector USB-C power connector (Thunderbolt™ USB-A connector (USB 5Gbps) USB-A connector (USB 10Gbps, Always On USB) Audio connector...
Page 13
AMD models Description Description Item Item Security slot HDMI™ connector USB-C power connector (USB 5Gbps) Ethernet connector USB-A connector (USB 5Gbps) USB-C power connector (USB4 40Gbps) USB-A connector (USB 10Gbps, Always On USB) Audio connector Note: For more information about the USB connector name update, see Appendix C “Notice for USB connector name update”...
• “Charge the computer with ac power” on page 33 • “USB specifications” on page 8 • “Lock the computer” on page 37 Bottom view Have a quick glance at the bottom part of your computer. ThinkPad E14 Gen 7 ThinkPad E16 Gen 3 Description Description Item...
Page 15
Step 3. Connect your computer to ac power and then turn on your computer. If your computer is still no response, you can call Lenovo Customer Support Center to get further help. CAUTION: When the computer is operating, it should be placed on a hard and flat surface with its bottom area not in contact with user’s bare skin.
• Select the country or region. • Connect to an available network. • Accept the license agreement. • Create a Microsoft account or log in with your Microsoft account. • Set up your password, fingerprint, or facial recognition as preferred. •...
Print screen. Open Snipping Tool. ® Open Microsoft Phone Link. Launch Lenovo AI Now. Notes: • This app is available in some countries and regions. • The function varies by countries or regions. Chapter 2 Get started with your computer...
You can customize keyboard settings in Vantage app. To customize detailed settings, open the Vantage app, and then click Device ➙ Input & Accessories. For more keyboard shortcuts, go to https://support.lenovo.com/solutions/windows-support Use the TrackPoint pointing device The TrackPoint pointing device enables you to perform all the functions of a traditional mouse, such as pointing, clicking, and scrolling.
Page 23
TrackPoint pointing stick Use your finger to apply pressure to the pointing-stick nonslip cap (hereafter referred to as the red cap) in any direction parallel to the keyboard. The pointer on the screen moves accordingly. The higher the pressure applied, the faster the pointer moves. TrackPoint Three Buttons TrackPoint left button and TrackPoint right button correspond to the left and right buttons on a traditional mouse.
Use the Trackpad You can use the Trackpad to perform all the pointing, clicking, and scrolling functions of a traditional mouse. It is ideal for you to use for occasions with high portability requirements, for example, business trips. Description Description Item Item Right-click zone...
Page 25
• Some gestures are not available if the last action was done from the TrackPoint pointing device. • Some gestures are only available when you are using certain apps. • If the Trackpad surface is stained with oil, turn off the computer first. Then, gently wipe the Trackpad surface with a soft and lint-free cloth moistened with lukewarm water or computer cleaner.
Page 26
To do this Gesture Two fingers pinch in. Zoom out. Two fingers slide horizontally or vertically. Scroll through items. Three-and-four-finger touch gestures To do this Gesture Three fingers tap once. Open search window. Four fingers tap once. Open notification center. Three- or four-finger swipes up.
To do this Gesture Three- or four-finger swipes down. Show the desktop. Three- or four-finger swipes left or right. Switch between open apps or windows. Disable the Trackpad The Trackpad is enabled by default. To disable the device: Step 1. Open the Start menu, and then click Settings ➙...
Page 28
One-finger touch gesture To do this Gesture Tap and hold. Open a shortcut menu. Swipe from the left. Open the widget panel. Swipe from the right. Open notification center. Two-finger touch gesture To do this Gesture Move two fingers towards. Zoom out.
Page 29
Three-and-four-finger touch gesture To do this Gesture Swipe with three fingers up. Show all open windows. Swipe with three fingers down. Show the desktop. Swipe with three fingers to the left or right. Switch apps. Swipe with four fingers to the left or right. Switch desktops.
Step 7. If the touch screen still cannot work normally, the touch screen might get damaged. You can call Lenovo Customer Support Center to get further help. Connect to an external display Connect your computer to a projector or a monitor to give presentations or expand your workspace.
Depending on your computer models, your computer supports either of the following: • For Intel models, the HDMI connector supports the HDMI 2.1 (up to 4K/60Hz) standard. Connect to a compatible digital audio device or video monitor, such as an HDTV. •...
• PC Assistant: Set up and optimize your computer. It provides smart setup features and can connect you to timely Lenovo services. For example, you can ask AI Now to help turn on Eye Care mode or find the nearest service center.
Notes: • To quickly chat with Lenovo AI Now, you can launch the AI Now mini window by pressing Ctrl+Q. • Lenovo AI Now makes periodic updates to keep bringing the latest AI technologies to you and improving your experience. The description of features might be different from that on your actual user interface. For the latest information about Lenovo AI Now, go to https://support.lenovo.com/solutions/lenovo-ai-...
Page 35
• App streaming: Stream apps from your phone or tablet to the computer. • Webcam: Make video calls using the camera of your phone or tablet. Note: Select the correct camera option in the meeting app to use the webcam. •...
Lenovo Smart Meeting Lenovo Smart Meeting is a video conferencing app for working scenarios. It integrates multiple features to help enhance your professional image, protect your privacy, and reduce power consumption.
• The available features vary depending on the computer model. • Lenovo Smart Meeting makes periodic feature updates to keep improving your experience with your computer. The description described here might be different from that on your actual user interface.
Page 38
Step 1. Click the flyout and click ADVANCED SETTINGS. Step 2. Select Single-tapping under TrackPoint Quick Menu Launch. The TrackPoint Quick Menu is enabled by default. Press Fn+G to disable or enable the tapping gesture. When disabled, it cannot be launched by tapping the TrackPoint pointing stick. Use the TrackPoint Quick Menu You can click the edit button to rearrange the features in the preview panel, or drag and drop the features...
You can suppress your own background noise and the noise from other meeting participants. – Off: Disable noise suppression. – Low: Suppress low-level background noise. – High: Suppress all non-speech background noise. Note: The feature does not work when Dolby Voice is off. Click the link in NOISE SUPPRESSION to help you enable it.
Mode Recommended scenario • You want the computer to be quieter and cooler. Best power efficiency • You want to maximize the battery life. • You plan to frequently switch between different computer tasks over a period time. Balanced • You prefer to balance device performance with temperature and fan noise.
Note: Some models might not ship with ac adapters or power cords. Use only the certified adapters and power cords provided by Lenovo that comply with the requirements of relevant national standards to charge the product. It is recommended to use the Lenovo qualified adapters. You can refer to https:// www.lenovo.com/us/en/compliance/eu-doc...
Charge your computer with P-to-P 2.0 charging function Both USB-C connectors (Thunderbolt 4) on the computer feature the Lenovo-unique P-to-P 2.0 (Peer to Peer 2.0) charging function. Note: The actual charging speed of your computer depends on many factors, such as the remaining battery power of the computers, the wattage of the ac power adapter, and whether you are using the computers.
Page 43
Conventional pair This topic helps you connect to a Bluetooth device by conventional pair. Step 1. Type Bluetooth in the Windows search box and then press Enter. Step 2. Turn on both the Bluetooth on your computer and the Bluetooth device. Make sure the device is discoverable.
Note: The slot supports cable locks that conform to the Kensington ManoSaver lock standards using Cleat™ locking technology. You are responsible for evaluating, selecting, and implementing the locking device and security feature. Lenovo is not responsible for the locking device and security feature. You can purchase the cable locks at https://smartfind.lenovo.com Log in with fingerprint recognition The fingerprint reader is integrated with the power button.
However, there is no guarantee that all data is saved in any situation. To check the type of your M.2 solid-state drive: Step 1. Restart the computer. When the logo screen is displayed, press F10 to enter the Lenovo diagnostics window. Step 2.
Step 3. Locate the Device Type section to check the information. UEFI BIOS passwords You can set passwords in UEFI (Unified Extensible Firmware Interface) BIOS (Basic Input/Output System) to strengthen the security of your computer. Password types You can set a power-on password, supervisor password, system management password, or NVMe password in UEFI BIOS to prevent unauthorized access to your computer.
In the Changes have been saved window, press Enter. Step 6. Press F10 to save changes and exit the UEFI BIOS menu. If you have not set a supervisor password or a system management password, contact a Lenovo-authorized service provider to have the power-on password removed. User Guide...
Lenovo-authorized service provider to have the storage drive replaced. A fee will be charged for parts and service. If the storage drive is a CRU (Customer Replaceable Unit), you can also contact Lenovo to purchase a new storage drive to replace the old one by yourself. To check whether the storage drive is a CRU and the relevant replacement procedure, see “CRU list”...
FIDO (Fast Identity Online) authentication Your computer supports FIDO (Fast Identity Online) authentication feature. This feature works as an alternative to password-based authentication to achieve passwordless authentication. This feature only works when a power-on password is set in UEFI BIOS and the FIDO2 USB device is registered in ThinkShield™...
Note: The Lenovo BIOS Simulator Center makes periodic updates of the settings. The UEFI BIOS simulator interface and description of settings might be different from that on your actual user interface. Customize BIOS Defaults The feature provides a solution to backup your preferred BIOS Setup settings.
Step 2. Select Restart ➙ Save Custom Defaults. Step 3. Click Yes to save the settings configuration you customized. Load the customized settings configuration Follow the instructions to load the customized settings configuration. Step 1. Restart the computer. When the logo screen is displayed, press F1 to enter the UEFI BIOS menu. Step 2.
Scroll down to the bottom. Click Get help and follow the on-screen instructions. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
For more solutions to audio problems, go to https://support.lenovo.com/solutions/ht501860 If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Keyboard problems My keyboard does not work Problem: What should I do if my keyboard does not work? Solution: If your keyboard does not work or types wrong characters, try the following solutions one by one to troubleshoot and fix the issue: 1.
If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist My keyboard backlight does not work Problem: What should I do if my keyboard backlight does not work?
5. Update UEFI BIOS to the latest version. For details, refer to “UEFI BIOS problems” in this User Guide. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Select Diagnostics or Lenovo Diagnostics and run a battery test to check for hardware issues. c. Follow on-screen instructions to fix the issue. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
2. In the search box of the Get Help app, type troubleshoot BSOD error. 3. Follow the guided walkthrough. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
4) In the popup window, select Uninstall. 5) If you're asked to confirm your choice, select Yes. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Right-click the display driver and select Properties. d. Under Driver, select Roll Back Driver and follow the on-screen instructions. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Follow the on-screen instructions to install the device drivers and necessary programs. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
5) Restart your computer. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Note: During the enrollment, it is recommended that you follow the on-screen instructions to enroll the full image of your fingerprint. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Right-click the touchpad, and select Properties. d. Under Driver, select Roll Back Driver and follow the on-screen instructions. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Restart the computer. When the logo screen is displayed, press F1 to enter the UEFI BIOS menu. b. Select Config ➙ Keyboard/Mouse, then turn on the TrackPoint switch. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Follow the on-screen instructions to install the device drivers and necessary programs. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Type task manager in the Windows search box and press Enter. b. Terminate power-consuming applications or processes that are not in use. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Follow the on-screen instructions to install the device drivers and necessary programs. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
3. If the issue is still not fixed, update the UEFI BIOS to the latest version. For details, refer to “UEFI BIOS problems” in this User Guide. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
3. Update Lenovo Pen Settings, an app preinstalled on your computer, and ensure that your pen has paired to your computer through Bluetooth. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
4. Click Restore to and choose a new location to save the files. • Recover data by using a reliable USB data recovery tool. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
2. Update your Windows operating system to 23H2 or later version. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
If Windows does not reinstall the driver automatically, open device manager and click Action ➙ Scan for hardware changes. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
8. Contact your Internet service provider to check if there are any issues with your internet plan or connection. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist My built-in battery cannot be charged Problem: What shoud I do if my built-in battery cannot be charged?
2. If you are using a power strip or surge protector, ensure it is turned on and working. 3. Press the power button to turn on your computer again. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
2. Check the power button on your computer and if it is a customer replaceable unit, replace it when necessary. For details, refer to the part replacement information in this User Guide. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
For details, refer to the part replacement information in this User Guide. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Get the latest updates from the Windows Update. For details, go to https://support.microsoft.com/ windows_update c. Restart your computer. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist “no bootable device” error Problem: What should I do if my computer displays a “no bootable device”...
• If your computer uses UEFI boot mode, the USB drive should be formatted with FAT32. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
Depending on your specific situation, you can choose from different recovery options. For details, go to https://support.microsoft.com/windows_recovery 12. Use memory module(s) with higher speed. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
3. Ensure that all internal hardware components such as memory and graphics card are properly connected. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
1. Type Sign-in options in the Windows search box and press Enter. 2. Select Password ➙ Change and follow on-screen instructions to change the password. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
For more details, go to https://support.microsoft.com/windows/finding-your-bitlocker-recovery-key-in-windows If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
6. Follow the on-screen instructions to install the device drivers and necessary programs. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
4. Follow the on-screen instructions to install the device drivers and necessary programs. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
You suspect your device has been infected. Use installation media to reinstall Windows operating system. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist Driver problems Update or install the latest device driver Problem: How to update or install the latest device driver? Solution: Download the latest driver for a component when you notice poor performance from that component or when you install a new component.
1. Restart your computer. 2. Reinstall the driver. Find general solutions, go to https://support.lenovo.com/solutions/HT105331 If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist User Guide...
2. If the latest UEFI BIOS update package is available, follow the on-screen instructions to download and install the package. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
33% to 65% LED indicators on Esc, F1 and F4 blink simultaneously 66% to 100% If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
If the solid-state drive firmware update package is available, follow the on-screen instructions to download and install the package. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
If the solid-state drive firmware update package is available, follow the on-screen instructions to download and install the package. If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist...
If the problem persists, do not hesitate to call Lenovo Customer Center. For the latest Lenovo Support phone numbers for your country or region, go to https://pcsupport.lenovo.com/supportphonelist Recover my computer Problem: How to recover my computer? Solution: To recover your computer, try the following solutions one by one:: 1.
Page 96
IMEI number. • Parts lookup and purchase: . You can find service parts by serial https://support.lenovo.com/parts-lookup number or machine type. • Lenovo BIOS Simulation Center: https://download.lenovo.com/bsco/index.html . You can explore the BIOS settings of your device. • Additional services purchase: .
Page 97
– Type get help in the Windows search box – Use Windows Search – Microsoft Support Web site: https://support.microsoft.com • Reset or restore Windows – Use Lenovo recovery options: https://support.lenovo.com/HowToCreateLenovoRecovery – Use Windows recovery options: Go to https://pcsupport.lenovo.com and search by the product name or serial number.
If you see a message that is not included in the following table, record the error message first, then shut down the computer and call Lenovo for help. See “Lenovo Customer Support Center” on page 97. Message Solution The computer turned off because the battery power is low.
Page 100
• We recommend that you speak to our Customer Support Center before attempting to service the computer yourself so that you can be directed to the correct documentation and repair information. It might be recommended to have a Lenovo-authorized service provider repair your computer depending on the complexity of the error or fault.
(service provider only). Diagnostics tool This section provides introduction to a set of diagnostics and troubleshooting tools at Lenovo Support Web site, the Vantage app, and in your computer. They can help you diagnose common software and hardware issues.
Lenovo Service Bridge. Lenovo Service Bridge helps to connect your computer with Lenovo diagnosing tools. • Lenovo Support Web site makes periodic updates of the sections to keep improving your experience with your computer. The Web site interface and descriptions of sections might be different from that on your actual interface.
Lenovo Memory Self Repair (for Intel models only) Lenovo Memory Self Repair (hereafter referred to as repair tool) enables you to repair memory single-bit or single-row failure with internal redundant resources. It is recommended that you use the repair tool in the following situations: •...
In some cases, an earlier Windows version might be preinstalled under the terms of the Windows Pro edition license downgrade rights. Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Prepare the needed information before you contact Lenovo.
• Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service.
Page 106
• https://www.lenovo.com/warranty/llw_02 • https://pcsupport.lenovo.com/warrantylookup User Guide...
If you intend on installing a CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You might be required to return the defective part that is replaced by the CRU.
For the removal procedure, refer to the built-in battery replacement instructions in this documentation. • For the non-CRUable built-in battery connected to the system board with comb connectors: Call Lenovo Customer Support Center for help. To check whether the built-in battery on your computer is a CRU, see the CRU list in Chapter 8 “CRU replacement”...
Page 109
• Pry tool Step 1. Loosen the seven captive screws and remove the base cover assembly as shown below. Note: Prepare a pry tool to release the hooks. • ThinkPad E14 Gen 7 • ThinkPad E16 Gen 3 Chapter 8 CRU replacement...
Step 2. Install the base cover assembly in reverse order. If the computer does not start up after you reinstall the base cover assembly, disconnect the ac power adapter and then reconnect it to the computer. Memory module Follow the instructions to replace the memory module. Before you start, read Generic Safety and Compliance Notices Attention: Do not touch the contact edge of the memory module.
Step 2. Install the memory module as shown below. M.2 solid-state drive and M.2 solid-state drive bracket Follow the instructions to replace the 2242 M.2 solid-state drive. Before you start, read Generic Safety and Compliance Notices Attention: If you replace a M.2 solid-state drive, you might need to install a new operating system. For details on how to install a new operating system, see “Install a Windows operating system and drivers”...
Page 112
• Before replacing the M.2 solid-state drive, make a backup copy of all the data that you want to keep. • Do not apply pressure to the M.2 solid-state drive. • Do not touch the contact edge or circuit board of the M.2 solid-state drive. Otherwise, the M.2 solid-state drive might get damaged.
Batteries supplied by Lenovo for use with your product have been tested for compatibility and should only be replaced with approved parts. A battery other than the one specified by Lenovo, or a disassembled or modified battery may not be covered by warranty.
Page 114
• If the battery is incorrectly replaced, there is danger of an explosion. The battery contains a small amount of harmful substances. Lenovo recommends you use a qualified repair technician or ensure that you carefully follow all instructions provided by Lenovo. The Lenovo-authorized repair facilities or technicians recycle Lenovo batteries according to local laws and regulations.
Step 2. Before installing the built-in battery, thoroughly check the battery compartment and ensure that there are no foreign or sharp objects that could cause damage to the battery. Step 3. Install the built-in battery in reverse order. When installing: •...
Page 116
Step 2. Install the speaker assembly in reverse order. User Guide...
– TP00166B0 for India only Further compliance information related to your product is available at https://www.lenovo.com/compliance Table 1. Korean Minimum Energy Performance Standard (MEPS) value (For ThinkPad E14 Gen 7) Energy efficiency labeling Energy efficiency information Computer type • For Intel Arrow Lake models: 20 Annual power consumption (kWh) •...
Page 118
Table 1. Korean Minimum Energy Performance Standard (MEPS) value (For ThinkPad E14 Gen 7) (continued) Energy efficiency labeling Energy efficiency information • For Intel Arrow Lake models: 0.92 Power consumption in sleep mode (W) • For Intel Raptor Lake Refresh models: 0.91 •...
The following illustration shows the antenna locations on your computer: Wireless LAN antenna Operating environment This section provides information about the operating environment of your computer. Maximum altitude (without pressurization) 3048 m (10 000 ft) Temperature • Operating: 5°C to 35°C (41°F to 95°F) •...
Appendix C. Notice for USB connector name update The USB Implementers Forum published a revision of the guideline for USB connector names in September, 2022. Lenovo follows the revised guideline and updates USB connector names accordingly. You can refer to the table below for naming update details.
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Page 126
Furthermore, some measurements may have been estimated through extrapolation. Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any ® Linux agreement(s) which may accompany software included with this product.
