ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1
Hardware Maintenance Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ThinkPad E14 Gen 5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lenovo ThinkPad E14 Gen 5

Summary of Contents for Lenovo ThinkPad E14 Gen 5

  • Page 1 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 2 Third Edition (June 2024) © Copyright Lenovo 2024. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...

  • Page 3: Table Of Contents

    Power management ... . . 1080 I/O board and I/O board cable ..Sleep mode ....© Copyright Lenovo 2024...
  • Page 4 1140 LCD bezel assembly ... Appendix B. Abbreviation table ..99 1150 LCD panel and elastic adhesive tapes ..ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 5: About This Manual

    21JN, 21JQ, 21JT, and 21JU ThinkPad R14 Gen 5 21JM ThinkPad E14 Gen 5, ThinkPad R14 Gen 5 and ThinkPad E16 Gen 1 might be shipped with different ® microprocessors, namely Intel and Advanced Micro Devices (AMD). Hereby Intel models and AMD models are used to distinguish computer models with different microprocessors.
  • Page 6 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 7: Chapter 1. Safety Information

    • Fan louvers on the machine help to prevent overheating of internal components. Do not obstruct fan louvers or cover them with labels or stickers. Electrical safety Observe the following rules when working on electrical equipment. © Copyright Lenovo 2024...
  • Page 8 This practice ensures correct grounding of the units. • If an electrical accident occurs: – Use caution; do not become a victim yourself. – Switch off power. – Send another person to get medical aid. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 9: Safety Inspection Guide

    4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-ThinkPad / non-Lenovo alterations. Use good judgment as to the safety of any non-ThinkPad / non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 10: Grounding Requirements

    The safety notices in this section are provided in the following languages: • English • Arabic • Brazilian Portuguese • French • German • Hebrew • Japanese • Korean • Spanish • Traditional Chinese DANGER DANGER ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 11 DANGER DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 12 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 13 PERIGO PERIGO PERIGO Chapter 1 Safety information...
  • Page 14 PERIGO PERIGO PERIGO PERIGO PERIGO DANGER DANGER ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 15 DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 16 DANGER VORSICHT VORSICHT VORSICHT VORSICHT ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 17 VORSICHT VORSICHT VORSICHT VORSICHT Chapter 1 Safety information...
  • Page 18 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 19 Chapter 1 Safety information...
  • Page 20 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 21 Chapter 1 Safety information...
  • Page 22 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 23 Chapter 1 Safety information...
  • Page 24 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 25: Chapter 2. Important Service Information

    – “FRU identification” on page 20 Important: • Advise customers to contact the Lenovo Customer Support Center if they need any assistance in obtaining or installing any software fixes, drivers, and UEFI BIOS downloads. Telephone numbers for Lenovo Support are available at: https://pcsupport.lenovo.com/supportphonelist...

  • Page 26: How To Use Error Message

    Dynamic Configure To Order (CTO) model This model provides the ability for a customer to configure a Lenovo solution from a Web Site, and have this configuration sent to fulfillment, where it is built and shipped directly to the customer. The machine label and eSupport will load these products as the 4-character MT, 4-character model, and 2-character country code.

  • Page 27: Chapter 3. General Checkout

    Before checking problems with the computer, determine whether the damage is covered under the warranty by referring to the following list: © Copyright Lenovo 2024...

  • Page 28: Checkout Guide

    Note: If you are unable to isolate and repair the problem yourself after running the program, save and print the log files created by the program. You need the log files when you speak to a Lenovo technical support representative.

  • Page 29: Quick Test Programs

    Run quick test programs to troubleshoot and resolve computer problems, especially when the computer does not have the Vantage app installed. To download and install a quick test program, go to https://www.lenovo.com/diags , and follow the instructions on the Web site.

  • Page 30: Bootable Diagnostic Programs

    If the computer you are servicing is not installed with the UEFI diagnostic program, you can download a bootable diagnostic program from the Lenovo Support Web site. The bootable diagnostic program enables you to view system information and test some hardware devices in your computer, such as memory, storage devices, the LCD, and system board buses.

  • Page 31: Checking The Built-In Battery And Operational Charging

    Checking the built-in battery and operational charging This system supports only batteries specially designed for this specific system and manufactured by Lenovo or an authorized manufacturer. The system does not support unauthorized batteries or batteries designed for other systems.
  • Page 32 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 33: Chapter 4. Related Service Information

    When the latest maintenance diskette and the system program service diskette become available, they will be posted on: https://support.lenovo.com Reset or restore Windows To reset or restore Windows, refer to the information below： • Use Lenovo recovery options. 1. Go to https://support.lenovo.com/HowToCreateLenovoRecovery 2. Follow the on-screen instructions. • Use Window recovery options.

  • Page 34: Supervisor Password

    The system management password can also protect the system information stored in UEFI BIOS like a supervisor password, but it has lower authority by default. The system management password can be set through the UEFI BIOS menu or through Windows Management Instrumentation (WMI) with the Lenovo client-management interface.

  • Page 35: How To Remove The Power-On Password

    Lenovo cannot reset your passwords or recover data from the storage drive. You can contact a Lenovo authorized service provider to have the storage drive replaced. A fee will be charged for parts and service. If the storage drive is a CRU (Customer Replaceable Unit), you can also contact Lenovo to purchase a new storage drive to replace the old one by yourself.

  • Page 36: Power Management

    Hibernation mode In hibernation mode, the following occurs: • The system status, RAM, VRAM, and setup data are stored on the solid-state drive. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 37: Symptom-To-Fru Index

    • The system is powered off. Note: If the computer enters the hibernation mode while it is connected to the dock, do not disconnect it before resuming normal operation. If you do disconnect it and then try to resume normal operation, you will get an error message, and you will have to restart the system.

  • Page 38: Numeric Error Codes

    HDD (HDD0) 3. Replace the system board. 2200 Have the computer serviced. Machine Type and Serial Number are invalid. 2201 Replace the system board. Machine UUID is invalid ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 39: Error Messages

    Beep errors Lenovo SmartBeep technology enables you to decode beep errors with your smartphone when a black screen occurs with beeps from your computer. To decode the beep error with Lenovo SmartBeep technology, do the following: 1.
  • Page 40 Note: We recommend that you speak to our Customer Support Center before attempting to service the computer yourself so that you can be directed to the correct documentation and repair information. It might be recommended to have a Lenovo-authorized service provider repair your computer depending on the complexity of the error or fault.

  • Page 41: Beep Symptoms

    If the LCD you are servicing has two or less visible defective pixels, it should not be considered faulty. However, if the LCD has three or more visible defective pixels, it will be deemed as defective by Lenovo and it should be replaced.

  • Page 42: Intermittent Problems

    • This policy applies to all ThinkPad Notebooks purchased on 1 January, 2008 or later. • Lenovo will not provide warranty replacement if the LCD is within specifications because we cannot guarantee that any replacement LCD will have zero pixel defects.
  • Page 43 Verify that all attached devices are supported by the computer. Verify that the power supply being used at the time of the failure is operating correctly. See “Power system checkout” on page 24. 1. Turn off the computer. 2. Visually check each FRU for damage. Replace any damaged FRU. 3.
  • Page 44 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 45: Chapter 5. Special Keys

    Decline incoming calls on Microsoft Teams Customize the function of this key on the Vantage app Open Magnifier Open calculator (for ThinkPad E16 Gen 1 only) Enter sleep mode (for ThinkPad E16 Gen 1 only) Open Snipping Tool © Copyright Lenovo 2024...
  • Page 46 Scroll contents Send system request Open system information Window Enter sleep mode To wake up the computer, press any of the keys. Go to beginning Go to end ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 47: Chapter 6. Locations

    Chapter 6. Locations Locating computer controls and connectors Front view ThinkPad E14 Gen 5 Description Description Item Item Webcam privacy shutter Infrared camera / Camera Microphones Touch screen © Copyright Lenovo 2024...
  • Page 48 Description Description Item Item ® Power button with fingerprint reader TrackPoint pointing stick Trackpad TrackPoint buttons * for selected models ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 49: Side View

    ThinkPad E16 Gen 1 Description Description Item Item Webcam privacy shutter Infrared camera / Camera Microphones Touch screen Power button with fingerprint reader TrackPoint pointing stick Trackpad TrackPoint buttons * for selected models Side view Intel models Chapter 6 Locations...
  • Page 50 USB-C (Thunderbolt™ 4) connector Always On USB-A 3.2 Gen 1 connector HDMI™ connector Speakers Audio connector Security-lock slot Ethernet connector USB-A 2.0 connector * for selected models ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 51 AMD models Description Description Item Item USB-C power connector USB-C (3.2 Gen 2) connector Always On USB-A 3.2 Gen 1 connector HDMI connector Speakers Audio connector Security-lock slot Ethernet connector USB-A 3.2 Gen 1 connector * for selected models Chapter 6 Locations...

  • Page 52: Locating Frus And Crus

    Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You can find a list of CRUs for your product in this Hardware Maintenance Manual. An electronic version of this manual can be found at .

  • Page 53: Major Frus And Crus

    Major FRUs and CRUs ThinkPad E14 Gen 5 Chapter 6 Locations...
  • Page 54 Microsoft Windows operating system. It might not come with the computer, and a user might order it from https://pcsupport.lenovo.com/ , though additional shipping and handling fees might apply. lenovorecovery ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 55 ThinkPad E16 Gen 1 Chapter 6 Locations...
  • Page 56 Thermal fan assembly (for DIS models) Trackpad cable Trackpad Lenovo factory recovery USB key* Power cord* ac power adapter* Miscellaneous parts kits (see “Miscellaneous parts” on page 53) * for selected models ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 57: Lcd Frus And Crus

    Notes: • Depending on the computer model, your computer might look different from the illustration above. • The Lenovo factory recovery USB key is used to restore the Microsoft Windows operating system. It might not come with the computer, and a user might order it from https://pcsupport.lenovo.com/...
  • Page 58 Camera Module LCD cover assembly eDP cable Hinge kit * for selected models Note: Depending on the computer model, your computer might look different from the illustration above. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 59: Miscellaneous Parts

    • Spec Connector and cable guide This topic provides information to help Lenovo authorized service technicians identify connectors and cables for replacement purpose. To view each FRU and the exploded illustration of the computer, see “Major FRUs and CRUs” on page 47 and “LCD FRUs and CRUs” on page 51.
  • Page 60 Thunderbolt 4 compatible device AMD models: USB-C (3.2 Gen 2) to this connector. connector (external) Always On USB 3.2 Gen 1 Connect USB-compatible devices connector (external) to this connector. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 61 Insert the wireless LAN card into this slot. Keyboard connectors (internal) Keyboard assembly cable The keyboard assembly comes with the keyboard assembly cable. Connect one end of the cable to this connector. I/O board connectors ThinkPad E14 Gen 5 Chapter 6 Locations...

  • Page 62: Looking Up Fru Information

    Connect the I/O card cable to this connector. connector (internal) Looking up FRU information For detailed FRU information, including part numbers, descriptions, and substitution part numbers, go to: https://support.lenovo.com/partslookup ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 63: Chapter 7. Fru Replacement Notices

    • Keep the screw kit in your tool bag. For the part number of the screw kit, go to: https://support.lenovo.com/partslookup Tighten screws as follows: • Plastic to plastic Turn an additional angle of 90 degrees after the screw head touches the surface of the plastic part. © Copyright Lenovo 2024...

  • Page 64: Retaining Serial Numbers

    Maintenance Key. Note: Only an authorized Lenovo service technician can access the above Web site. 3. Restart the computer. 4. When the logo is displayed, press Esc. The ThinkPad Config Information Update Utility interface is displayed.

  • Page 65: Retaining The Uuid

    To check what ECAs have been previously applied to the machine, use the ECA Information Read/Write function on the LENOVO ThinkPad Hardware Maintenance Diskette or Maintenance Key. 1. Insert the latest version of LENOVO ThinkPad Hardware Maintenance Diskette or Maintenance Key, and then restart the computer.
  • Page 66 Note: Only the ECA number is stored in the EEPROM. The machine type of the ECA is assumed to be the same as the machine type of the machine that had the ECA applied to it. 1. Insert the latest version of LENOVO ThinkPad Hardware Maintenance Diskette or Maintenance Key, and then restart the computer.

  • Page 67: Chapter 8. Removing Or Replacing A Fru

    2. Click Power Options, and then click Choose what the power buttons do on the left pane. 3. Click Change settings that are currently unavailable at the top. 4. If prompted by User Account Control (UAC), click Yes. © Copyright Lenovo 2024...

  • Page 68: 1010 Base Cover Assembly

    Wait three to five minutes to let the computer cool. 1010 Base cover assembly Removal step of the base cover assembly ThinkPad E14 Gen 5 ThinkPad E16 Gen 1 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 69 Chapter 8 Removing or replacing a FRU...
  • Page 70 Genuine Microsoft label SN label Country label GEO label ThinkPad E16 Gen 1 Item Item Asset tag label Genuine Microsoft label SN label COA label Country label GEO label ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 71: 1020 Built-In Battery

    1020 Built-in battery DANGER Use only the Lenovo authorized battery specified for the computer. Any other battery could ignite or explode. Important notice for replacing a battery Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and provides no warranties for failures or damage arising out of their use.

  • Page 72: 1040 M.2 Solid-State Drive

    • Do not apply pressure to the M.2 solid-state drive. • Do not touch the contact edge or circuit board of the M.2 solid-state drive. Otherwise the M.2 solid-state drive might get damaged. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 73: 1050 Speaker Assembly

    • Do not make the M.2 solid-state drive subject to physical shocks or vibration. Put the M.2 solid-state drive on a soft material, such as cloth, to absorb physical shocks. Removal steps of the M.2 2242 solid-state drive Note: Before installing a new M.2 2242 solid-state drive, ensure that the thermal pad is installed properly. Step Screw (quantity) Color...

  • Page 74: 1060 Wireless Lan Card

    • Ensure that the connector is attached firmly. • Ensure that the cable is routed properly. 1060 Wireless LAN card For access, remove this FRU: • “1010 Base cover assembly” on page 62 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 75: 1070 Thermal Fan Assembly

    Removal steps of the wireless LAN card Step Screw (quantity) Color Torque M2 × L0.5 mm, flat-head, nylon-coated (1) Black 0.181 Nm (1.85 kgf-cm) When installing: Plug the gray cable into the main connector, and the black cable into the auxiliary connector on the card.
  • Page 76 Either too much or too less application of grease can cause a thermal problem due to imperfect contact with a component. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 77: 1080 I/O Board And I/O Board Cable

    1080 I/O board and I/O board cable For access, remove this FRU: • “1010 Base cover assembly” on page 62 Chapter 8 Removing or replacing a FRU...
  • Page 78 Removal steps of the I/O board and I/O board cable ThinkPad E14 Gen 5 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 79 Step Screw (quantity) Color Torque M2.5 × L6 mm, flat-head, nylon-coated (2) Black 0.294 Nm (3.0 kgf-cm) M2 × L2 mm, flat-head, nylon-coated (1) Black 0.181 Nm (1.85 kgf-cm) ThinkPad E16 Gen 1 Chapter 8 Removing or replacing a FRU...

  • Page 80: 1090 Power Button With Or Without Fingerprint Reader And Fingerprint Reader Cable

    (1.85 kgf-cm) When installing: Ensure that the screws are installed firmly. 1090 Power button with or without fingerprint reader and fingerprint reader cable For access, remove this FRU: ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 81: 1100 Coin-Cell Battery

    ThinkPad E16 Gen 1 When installing: Ensure that the screws are installed firmly. 1100 Coin-cell battery DANGER Use only the Lenovo authorized battery specified for the computer. Any other battery could ignite or explode. Chapter 8 Removing or replacing a FRU...

  • Page 82: 1110 Trackpad And Trackpad Cable

    • “1020 Built-in battery” on page 65 Removal steps of the trackpad and trackpad cable Note: There might exist a waterproof mylar covering the trackpad, remove the mylar before replacement. ThinkPad E14 Gen 5 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 83 Torque Step Screw (quantity) Color M2 × L1.7 mm, flat-head, nylon-coated (7) White 0.147 Nm (1.5 kgf-cm) ThinkPad E16 Gen 1 Chapter 8 Removing or replacing a FRU...

  • Page 84: 1120 System Board

    • Be careful not to drop the system board on a bench top that has a hard surface, such as metal, wood, or composite. • Avoid rough handling of any kind. • At every point in the process, be sure not to drop or stack the system board. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 85 Note: Input the exact brand name as shown in this table. Product name Machine type (MT) ThinkPad E14 Gen 5 21JR, 21JS, 21JK, and 21JL ThinkPad E16 Gen 1 21JT, 21JU, 21JN, and 21JQ...
  • Page 86 Screw (quantity) Color M2.5 × L6 mm, flat head, nylon-coated (2) Black 0.294 Nm (3 kgf-cm) M2 × L2 mm, flat head, nylon-coated (3) Black 0.181 Nm (1.85 kgf-cm) ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 87 ThinkPad E16 Gen 1 Note: The new system board does not come with a new M.2 solid-state drive thermal pad, it is suggested that you order an extra thermal pad in case the old thermal pad is damaged during replacement. Chapter 8 Removing or replacing a FRU...

  • Page 88: How To Input The Product Information With Thinkpad System Board Self Repair Tool (For End Users)

    Do not turn off the computer and disconnect the computer from ac power during the whole process. 1130 LCD unit For access, remove this FRU: ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 89 • “1010 Base cover assembly” on page 62 Removal steps of the LCD unit ThinkPad E14 Gen 5 Step Screw (quantity) Color Torque Black 0.294 Nm M 2.5 × L6 mm, flat-head, nylon-coated (4) (3.0 kgf-cm) Chapter 8 Removing or replacing a FRU...
  • Page 90 ThinkPad E16 Gen 1 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 91 Step Screw (quantity) Color Torque M 2.5 × L6 mm, flat-head, nylon-coated (5) Black 0.294 Nm (3.0 kgf-cm) Chapter 8 Removing or replacing a FRU...
  • Page 92 Attention: When you route the cables, ensure that they are not subject to any tension. Tension could cause the cables to be damaged by the cable guides, or a wire to be broken. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 93: 1140 Lcd Bezel Assembly

    1140 LCD bezel assembly For access, remove these FRUs in order: • “1010 Base cover assembly” on page 62 • “1130 LCD unit” on page 82 Removal steps of the LCD bezel assembly When installing: Ensure that all the latches are attached firmly. Note: After the LCD bezel assembly is removed, if it cannot be used anymore, a new LCD bezel assembly is required for replacement.
  • Page 94 Note: Do not pull the tapes too fast, otherwise, the tapes might snap. 2. Turn over the LCD panel and detach the LCD cable from the LCD panel as shown. ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 95 Installation steps of LCD panel and elastic adhesive tapes 1. Peel off the release liners from one side of the new elastic adhesive tapes. Apply the tapes to the correct locations. Peel off the release liners from the other side of the tapes. Ensure that the tapes are applied correctly as shown.

  • Page 96: 1160 Lcd Hinges

    ThinkPad E14 Gen 5 Table 12. Screw specification Torque Step Screw (quantity) Color M2.5 × L6 mm, flat-head, nylon-coated (6) Black 0.294 Nm (3.0 kgf-cm) ThinkPad E16 Gen 1 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 97: 1170 Camera And Microphone Rubber(For Selected Models)

    • “1130 LCD unit” on page 82 • “1140 LCD bezel assembly” on page 87 • “1150 LCD panel and elastic adhesive tapes” on page 87 Removal steps of the camera ThinkPad E14 Gen 5 ThinkPad E16 Gen 1 Chapter 8 Removing or replacing a FRU...
  • Page 98 When installing: Ensure that the connector is attached firmly. Removal steps of the microphone rubber ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 99: 1180 Edp Cable Assembly

    • “1140 LCD bezel assembly” on page 87 • “1150 LCD panel and elastic adhesive tapes” on page 87 • “1160 LCD hinges” on page 90 Removal steps of the wireless LAN antenna assembly ThinkPad E14 Gen 5 Chapter 8 Removing or replacing a FRU...

  • Page 100: 1200 Lcd Cover Assembly

    • “1130 LCD unit” on page 82 • “1140 LCD bezel assembly” on page 87 • “1160 LCD hinges” on page 90 • “1150 LCD panel and elastic adhesive tapes” on page 87 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 101 • “1170 Camera and microphone rubber(for selected models)” on page 91 • “1190 Wireless LAN antenna assembly (for selected models)” on page 93 Chapter 8 Removing or replacing a FRU...
  • Page 102 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...

  • Page 103: Appendix A. Notices

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
  • Page 104 Trademarks Lenovo, Lenovo logo, ThinkPad, ThinkPad logo, and TrackPoint are trademarks of Lenovo. Intel and Thunderbolt are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Microsoft, Microsoft Teams, and Windows are trademarks of the Microsoft group of companies. The terms HDMI and HDMI High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 105: Appendix B. Abbreviation Table

    Electrically Erasable Programmable Read-Only Memory Extensible Firmware Interface Electrostatic discharge Field Replaceable Unit General Announce Variant Integrated circuits Liquid Crystal Display Machine type and model POST Power-on self-test RFID Radio-frequency identification Supervisor password UUID Universally unique identifier © Copyright Lenovo 2024...
  • Page 106 ThinkPad E14 Gen 5 / ThinkPad E16 Gen 1 Hardware Maintenance Manual...
  • Page 108 Part Number: SP41G78221 Printed in China (1P) P/N: SP41G78221 *1PSP41G78221*...
