- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. GE HDA2100N00BB Owner's Manual Shop genuine replacement parts for GE HDA2100N00BB Find Your GE Dishwasher Parts - Select From 6722 Models -------- Manual continues below --------...
-
Page 2: Installation Instructions
GE Consumer & Industrial Appliances Installation Instructions Built-In Dishwasher If you have questions, call 800.GE.CARES (800.432.2737) or visit our website at: www.ge.com BEFORE YOU BEGIN IMPORTANT – The dishwasher MUST be STOP installed to allow for future removal from the Read these instructions completely and enclosure if service is required. -
Page 3: Electrical Cable
PARTS SUPPLIED IN INSTALLATION Screw Kit PACKAGE: Hex Head Phillips Head Two 8-18 x 5/8" Phillips head wood screws ■ Junction Box Screw Wood Screws Junction box cover and #10 hex head 1/2" long ■ 5/8" long ������������� Junction Box Cover screw ������������... -
Page 4: Prepare Dishwasher Enclosure
Installation Preparation–Enclosure PREPARE DISHWASHER ENCLOSURE • The dishwasher must be installed no more than 10 feet from sink for proper drainage. WARNING • The dishwasher must be fully enclosed on the top, To reduce the risk of shock, fire, or injury sides, and back. -
Page 5: Prepare Drain Plumbing
Installation Preparation–Drain METHOD 1–Air Gap with Waste Tee or Disposer PREPARE DRAIN PLUMBING Drain Requirements • Follow local codes and ordinances. • Drain hose must not exceed 10 feet in length. • A high drain loop or air gap is required. See below. Drain Method Figure C The type of drain installation depends on the... -
Page 6: Prepare Electrical Wiring
Installation Preparation–Electrical Supply PREPARE ELECTRICAL WIRING Alternate WARNING Receptacle FOR PERSONAL SAFETY: Remove house Location fuse or open circuit breaker before 18" beginning installation. Do not use an 1-1/2" Dia. Hole (Max.) extension cord or adapter plug with this Receptacle Location 18"... - Page 7 Installation Preparation–Hot Water Supply PREPARE HOT WATER SUPPLY CAUTION Hot Water Line • The line may enter from either side, rear, or floor The hot water supply line pressure must be at least 20 PSI. Lower pressures could cause the water valve to leak and within the shaded area shown in Figure F.
-
Page 8: Step 2: Check Door Balance
Dishwasher Installation STEP 3: REMOVE WOOD BASE CAUTION IMPORTANT – Do not kick off wood base! Do not remove the wood base until you are ready to Damage will occur. install the dishwasher. The dishwasher will tip over when the door is opened if the base is removed. •... -
Page 9: Step 5: Install Power Cord
The power cord and connections must comply with the National Electrical Code, Section 422 and/ or local codes and ordinances. Maximum power cord length is 6 feet. Power Cord Kit WX09X70910, available for purchase from an authorized GE Water Valve Appliance Dealer, meets these requirements. Bracket 90°... - Page 10 78" long. If a longer hose is needed, a 10 foot long hose may be purchased from an CORD, IF USED, THROUGH CABINET authorized GE appliance dealer. The 10 foot long • Upright the dishwasher and position it in front of hose is part number GPF10S.
-
Page 11: Step 11: Slide Dishwasher Into Cabinet
Dishwasher Installation STEP 11: SLIDE DISHWASHER INTO CABINET STEP 12: POSITION AND LEVEL DISHWASHER IMPORTANT – Do not push against the front IMPORTANT – Dishwasher must be level for panel with knees. Damage will occur. proper dish rack operation, wash performance, and door operation. -
Page 12: Step 14: Connect Water Supply
Dishwasher Installation STEP 13: FASTEN DISHWASHER TO STEP 14: CONNECT WATER SUPPLY UNDERSIDE OF COUNTERTOP OR SIDES Connect the water supply line to the 90° elbow OF CABINET installed in Step 6. • Slide the compression nut and then the ferrule over In this step you will need the two 5/8"... -
Page 13: Step 15: Connect Drain Line
Dishwasher Installation STEP 15: CONNECT DRAIN LINE Method 1 – Air gap with waste tee or disposer The molded end of the drain hose will fit 5/8" through 1" diameter inlet ports on the air gap, waste tee or disposer. •... -
Page 14: Step 16: Connect Power Supply
Dishwasher Installation STEP 16: CONNECT POWER SUPPLY STEP 17: INSTALL JUNCTION BOX COVER If a power cord with plug is already installed, If junction box cover is already installed, skip to proceed to Step 17. Step 18. If the dishwasher came with a factory-installed In this step you will need the junction box cover and power cord and you want to convert it to a the #10 hex head screw from the screw kit set aside... - Page 15 Dishwasher Installation STEP 19: DISHWASHER WET TEST – Check the electrical connection to the water valve. The red electrical connector should be CHECK LIST plugged into the dishwasher water valve. If it is Turn on power supply or if power cord is used, ■...
- Page 16 Dishwasher Installation STEP 20: REPLACE ACCESS PANEL AND STEP 21: LITERATURE TOEKICK Leave the Owners’ Manual, Installation ■ In this step you will need the panels and the two Instructions, samples, and/or coupons with screws set aside in Step 4. consumer.
- Page 17 • Return to Step 16 in these instructions to complete the conversion. Figure BB Figure CC Conversion Harness 06H-1949_Conversion Harness SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE GE Consumer & Industrial General Electric Company ������������������� Louisville, Kentucky 40225 Pub. No. 31-30218 Dwg. No. 206C1559P158 ND 06H-1949 (10/06)
