Faith *
Specifications
siZes S,M,L
CoLour Metallic Green / White
ALUXX SL-grade aluminum,
FrAme
7.0" Maestro suspension
RockShox Totem RC2 DH Solo Air,
Fork
tapered, 20QR, 180mm travel
shoCk RockShox Vivid Coil RC2
hAnDLeBAr Giant Contact AM 31.8x750mm
stem Giant Contact FR
seAtpost Giant Contact 30.9x375mm
sADDLe Giant DJ
peDALs Alloy platform sealed
shiFters SRAM X.9
Front DerAiLLeur N/A
reAr DerAiLLeur SRAM X.9 med cage
Avid Elixir CR F:203mm / R:180mm
BrAkes
hydraulic disc
BrAke Levers Avid Elixir CR
CAssette SRAM PG-970 11-32T 9SPD
ChAin Shimano HG73
CrAnkset Race Face Atlas FR 36T
Bottom BrACket Race Face X Type external
rims Sun Ringle MTX31 32H
F:Giant Tracker 20QR
huBs
R:DT Swiss 350 12mm
spokes DT Competiton 14/15g
tires Kenda Nevegal 26x2.5" Stick-E
MRP Mini G2 Guide,
extrAs
RC442/445 swappable dropouts
Specifications and availability subject to change without notice.
$
Spec Features
— RockShox Totem RC2 DH Solo Air, 180mm suspension fork, RockShox Vivid coil shock
— SRAM X.9 drivetrain w/ Race Face Atlas FR crankset, Avid Elixir CR disc brakes
— Giant Contact AM handlebar, Contact FR stem & Contact seatpost
— Wheelset: Sun Ringle MTX31 rims/ F:Giant Tracker 20QR, R:DT Swiss 350 hubs
frame geometry
A B
Actual part
head Angle seat Angle*
Frame size number
inches degrees degrees
S 16 2112800 66.8 / 66.3 62.9 / 62.4
+
M 16.5 2112801 66.8 / 66.3 62.2 / 61.7
+
L 17 2112802 66.8 / 66.3 63.3 / 62.8
+
Variable data for head angle, seat angle, chainstay and wheelbase based on replaceable dropout option (Included)
+
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
*available in limited quantities
C D E F
toptube** headtube Chainstay
inches inches inches
22.1 4.5 17.4 / 17.5
+ +
+ 23.2 4.5 17.4 / 17.5 +
24.4 4.5 17.4 / 17.5
+ +
97
G H
standover
wheelbase
height***
inches inches
43.9 / 44.0 29.9
+
44.8 / 44.9 + 30.0
46.2 / 46.4 31.1
+
