Giant DEFY ADVANCED 0 - DATASHEET 2 Datasheet

32 Defy Advanced
Specifications
siZes XS,S,M,M/L,L,XL
CoLour Composite / White / Blue
FrAme Advanced-Grade composite
Advanced-Grade composite w/
Fork
composite OverDrive steerer
shoCk N/A
hAnDLeBAr Giant Contact SL/R carbon 31.8mm
stem Giant Contact SL/R carbon
seAtpost Giant Vector Advanced composite
sADDLe Fi'zi:k Antares w/ K:ium rails
peDALs Not included
shiFters Shimano Dura-Ace
Front DerAiLLeur Shimano Dura-Ace
reAr DerAiLLeur Shimano Dura-Ace
BrAkes Shimano Dura-Ace
BrAke Levers Shimano Dura-Ace
CAssette Shimano Dura-Ace 11-28T 10SPD
ChAin Shimano Dura-Ace
CrAnkset Shimano Dura-Ace 34/50T compact
Bottom BrACket Shimano internal press fit
Shimano Dura-Ace carbon clincher,
rims
tubeless-compatible 24mm
huBs Shimano Dura-Ace
spokes Shimano Dura-Ace
tires Michelin Pro Optimum 700x25c
extrAs
Specifications and availability subject to change without notice.
$
Spec Features
— Complete Shimano Dura-Ace 7900-series component group w/ compact crankset
— Giant Contact SL/R composite handlebar & stem, Vector Advanced composite seatpost
— Wheelset: Shimano Dura-Ace carbon clincher tubeless-compatible 24mm
frame geometry
A B C
Actual part head seat
Frame size number Angle Angle*
centimeters degrees degrees
XS 43.0 2115100 71.0 74.0
S 46.5 2115101 72.0 74.0
M 50.0 2115102 72.5 73.0
M/L 53.5 2115103 72.5 73.0
L 55.5 2115104 72.5 72.0
XL 58.5 2115105 72.5 72.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
D E F G
toptube** headtube Chainstay wheelbase
centimeters centimeters centimeters centimeters
51.5 12.5 42.0 98.3
53.0 14.5 42.0 99.0
54.5 16.5 42.0 99.0
56.0 18.5 42.0 100.5
57.5 20.5 42.0 100.8
59.5 22.5 42.0 102.8
H
standover
height***
inches
29.0
29.7
30.6
31.1
32.0
32.8
