- Page 1 UHD-PRO102 4K 1x2 HDMI™ Splitter Follow us on Youtube and Facebook with Downscale USER MANUAL www.orei.com...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Application Example FAQs & Troubleshooting Thank you for purchasing this product For optimum performance and safety, please read these instruc- tions carefully before connecting, operating or adjusting this product. -
Page 3: Registration Page
Call, email or chat with us now. OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 5 p.m. Central Time Support Email - info@orei.com |... -
Page 4: Introduction
Introduction The UHD-PRO102 1x2 HDMI Splitter lets you connect a media source and duplicate it to 2 displays. It is HDCP 2.3 and DVI 1.0 compliant and supports 4K@60Hz video resolution with an 18Gbps bandwidth. It also supports HDR10+ and Dolby Vision. The device features... -
Page 5: Features
5. Auto downscale feature 6. PCM, Dolby TrueHD, DTS-HD Master Audio 7.1CH audio support 7. CEC support between INPUT and OUT1 8. EDID management 9. Compact space saving design Package Contents UHD-PRO102 1pcs Power Adapter 1pcs User Manual 1pcs Page 05... -
Page 6: Specifications
Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.3 / 1.4 DVI Compliance DVI 1.0 Video Bandwidth 18Gbps Video Resolution Up to 4K@60Hz Color Depth 8/10/12-bit Color Space RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0 HDR, HDR10, HDR10+, Dolby Vision, HLG LPCM 2.0/5.1/7.1CH, DD, DD+, DTS, Dolby Audio Formats True HD, and DTS-HD Master... - Page 7 Specifications Connection Input 1 × HDMI [Type A, 19-pin female] Output 2 × HDMI [Type A, 19-pin female] Mechanical Housing Metal Enclosure Color Black L: 70mm / 2.75in Dimensions W: 60mm / 2.36in H: 20.5mm / 0.8in Weight 118g / 4.16oz Input: AC 100~240V 50/60Hz Output: DC Power Supply 5V/1A (US/EU standards, CE/FCC/UL certified)
-
Page 8: Operation Controls And Functions
Operation Controls and Functions Recommended HDMI Cable Video Resolution 4K60 4K30 1080P HDMI Cable Length 5m/16ft 10m/33ft 15m/49ft (HDMI IN / OUT) The use of “Premium High Speed HDMI” cable is highly recommended. Page 08... - Page 9 Operation Controls and Functions Name Function Description Used to switch the EDID mode. STD: Fixed EDID of 1080p 2CH. STD/TV TV: Copy EDID from OUT1. If OUT1 is not switch connected, copy from OUT2. POWER Connect the power adapter Connect a media device such as a DVD Player, INPUT set-top box, etc.
-
Page 10: Application Example
Application Example Power Supply DVD or Blu-ray Player UHDTV UHDTV The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Page 10... -
Page 11: Faqs & Troubleshooting
4K to 720p Still have some questions? Please feel free to contact us at: info@orei.com. OR Fill out the form on the ‘Contact Us’ page on the website. Our team will be more than happy to help you. - Page 12 4K 1x2 HDMI™ Splitter with Downscale UHD-PRO102 www.orei.com © 2024 Page 12...
